Fritz! FRITZ!FON C5 User manual

FRITZ!Fon C5
Configuration
and Operation
I
T
Z
!
F
o
n
C5
o
n
fi
g
uration
d
O
p
eratio
n

FRITZ!Fon C5 2
Table of Contents
Important Instructions . . . . . . . . . . . . . . . . . . . . . 7
Safety Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Note for Hearing Aid Users . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Prerequisites for Operating FRITZ!Fon . . . . . . . . . . . . . . . . . 8
1 FRITZ!Fon C5 at a Glance. . . . . . . . . . . . . . . . . . . . 9
1.1 Package Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
1.2 Getting to Know the FRITZ!Fon. . . . . . . . . . . . . . . . . . . . . . . 10
1.3 Icons on the Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
2 Starting Operation of the FRITZ!Fon C5 . . . . . . . 12
2.1 Starting and Registering . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
2.2 Charging the Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
2.3 Changing the Battery. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
3 Operating FRITZ!Fon . . . . . . . . . . . . . . . . . . . . . . 16
3.1 Switching FRITZ!Fon On and Off . . . . . . . . . . . . . . . . . . . . . 16
3.2 Selecting Functions—Navigating. . . . . . . . . . . . . . . . . . . . . 16
3.3 Opening New Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
3.4 Entering Numbers and Text. . . . . . . . . . . . . . . . . . . . . . . . . 19
3.5 Locking Keys. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
3.6 Switching Off the Ring Tone. . . . . . . . . . . . . . . . . . . . . . . . . 21
3.7 Switching Off Ringer for a Call. . . . . . . . . . . . . . . . . . . . . . . 22
3.8 Paging a Mislaid FRITZ!Fon . . . . . . . . . . . . . . . . . . . . . . . . . 22

FRITZ!Fon C5 3
4 Registering with Multiple Base Stations . . . . . . 23
4.1 Registering with the 2nd, 3rd or 4th Base Station. . . . . . . 23
4.2 Switching Base Stations . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
4.3 Deregistering from a Base Station . . . . . . . . . . . . . . . . . . . 24
5 Making Telephone Calls . . . . . . . . . . . . . . . . . . . 25
5.1 Function Keys for Making Telephone Calls . . . . . . . . . . . . . 25
5.2 Dialing Numbers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
5.3 Accepting a Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
5.4 Enabling Direct Pickup . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
5.5 Adjusting the Volume . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
5.6 Switching on Hands-Free Calling . . . . . . . . . . . . . . . . . . . . 27
5.7 Muting the Microphone. . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
5.8 Making Internal Calls. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
5.9 Alternating Between Calls. . . . . . . . . . . . . . . . . . . . . . . . . . 29
5.10 Three-Party Conference Call . . . . . . . . . . . . . . . . . . . . . . . . 30
5.11 CLIR: Calling Line Identification Restriction . . . . . . . . . . . . 31
6 Entering Telephone Numbers . . . . . . . . . . . . . . . 33
6.1 Assigning Telephone Numbers in the FRITZ!Box . . . . . . . . 33
6.2 Selecting a Telephone Number before a Call . . . . . . . . . . . 34

FRITZ!Fon C5 4
7 Telephone Book and Call Lists . . . . . . . . . . . . . . 35
7.1 Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
7.2 Setting Up a Telephone Book in FRITZ!Box. . . . . . . . . . . . . 35
7.3 Calling a Telephone Number from the Telephone Book. . . 36
7.4 Calling a Telephone Number from the Call List . . . . . . . . . 37
7.5 Changing or Adding a Telephone Number . . . . . . . . . . . . . 37
7.6 Searching in the Telephone Book . . . . . . . . . . . . . . . . . . . . 38
7.7 Saving a New Telephone Book Entry. . . . . . . . . . . . . . . . . . 39
7.8 Saving Numbers from the Call List . . . . . . . . . . . . . . . . . . . 40
8 Answering Machine. . . . . . . . . . . . . . . . . . . . . . . 41
8.1 Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
8.2 Configuring an Answering Machine in FRITZ!Box . . . . . . . . 41
8.3 Switching the Answering Machine On and Off. . . . . . . . . . 42
8.4 Recording a Greeting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
8.5 Playing Back Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
8.6 Deleting Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
8.7 Picking Up a Call from the Answering Machine . . . . . . . . . 44
8.8 Recording a Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
8.9 Listening In as New Messages Are Recorded . . . . . . . . . . . 45
8.10 Answering Machine Voice Menu. . . . . . . . . . . . . . . . . . . . . 45
9 Configuring Call Diversion. . . . . . . . . . . . . . . . . . 46
9.1 Configuring Call Diversion in the FRITZ!Box . . . . . . . . . . . . 46
9.2 Switching Call Diversion On and Off . . . . . . . . . . . . . . . . . . 47

FRITZ!Fon C5 5
10 Switching the Alarm On and Off . . . . . . . . . . . . . 48
10.1 Configuring the Alarm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
10.2 Switching the Alarm On and Off . . . . . . . . . . . . . . . . . . . . . 49
11 Configuring the Baby Monitor. . . . . . . . . . . . . . . 50
12 Web Services . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
12.1 Receiving and Sending E-mail. . . . . . . . . . . . . . . . . . . . . . . 51
12.2 Receiving RSS Feeds . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
12.3 Listening to Podcasts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
12.4 Listening to Web Radio . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
13 Connecting a Headset . . . . . . . . . . . . . . . . . . . . . 59
13.1 Suitable Headsets . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
13.2 Connecting a Headset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
14 Configuring FRITZ!Fon . . . . . . . . . . . . . . . . . . . . . 60
14.1 Configuring the Start Screen. . . . . . . . . . . . . . . . . . . . . . . . 60
14.2 Configuring Favorites. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
14.3 Settings in the FRITZ!Fon Menu. . . . . . . . . . . . . . . . . . . . . . 63
14.4 Settings in the FRITZ!Box User Interface. . . . . . . . . . . . . . . 65
14.5 DECT Eco: Switching Off Radio When Idle. . . . . . . . . . . . . . 67
15 Updating the Firmware . . . . . . . . . . . . . . . . . . . . 68
15.1 Preparation: Checking the FRITZ!Box Firmware . . . . . . . . . 68
15.2 Performing a Firmware Update . . . . . . . . . . . . . . . . . . . . . . 68

FRITZ!Fon C5 6
16 Operating Devices in the Home Network . . . . . . 69
16.1 Switching the FRITZ!Box Wireless Network On and Off . . . 69
16.2 Switching Smart Home Devices On and Off . . . . . . . . . . . . 69
16.3 Using FRITZ!Fon as a Media Player . . . . . . . . . . . . . . . . . . . 70
17 Technical Specifications . . . . . . . . . . . . . . . . . . . 71
18 Customer Service. . . . . . . . . . . . . . . . . . . . . . . . . 72
18.1 Support from the Support Team . . . . . . . . . . . . . . . . . . . . . 72
Manufacturer’s Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . 73
Legal Notice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
Declaration of CE Conformity . . . . . . . . . . . . . . . 75
Disposal Information. . . . . . . . . . . . . . . . . . . . . . 76
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77

FRITZ!Fon C5 7
Important Instructions
Safety Instructions
Be sure to observe the following security instructions for handling the
FRITZ!Fon to protect yourself and the FRITZ!Fon from harm:
•Moisture and liquids that find their way into the FRITZ!Fon can
cause electric shocks or short circuits.
–Only use the FRITZ!Fon indoors.
–Never let liquids get inside the FRITZ!Fon.
•Heat accumulation can lead to overheating of the FRITZ!Fon
and subsequently damage the FRITZ!Fon.
–Protect the FRITZ!Fon from direct sunlight.
–Do not cover the FRITZ!Fon.
•The FRITZ!Fon contains hazardous components and should on-
ly be opened by authorized repair technicians.
–Do not open the FRITZ!Fon housing.
–If the FRITZ!Fon needs to be repaired, please take it to a
specialized vendor.
•Dust, moisture and vapors as well as caustic cleaners or sol-
vents can damage the FRITZ!Fon.
–Protect the FRITZ!Fon from dust, moisture and steam.
–Switch the FRITZ!Fon before cleaning.
–Clean the FRITZ!Fon with a slightly moist, lint-free cloth.

FRITZ!Fon C5 8
Note for Hearing Aid Users
If you wear a hearing aid, FRITZ!Fon can cause unpleasant noises.
These are caused by radio signals coupled into the hearing aid.
Prerequisites for Operating FRITZ!Fon
•You need a DECT base station that is connected with a tele-
phone landline or the Internet.
•If you would like to use all of the functions offered by the
FRITZ!Fon, you need a FRITZ!Box that supports DECT as your
base station. The latest firmware must be installed on both
devices.

FRITZ!Fon C5 9
FRITZ!Fon C5 at a Glance
FRITZ!Fon MT-D 9
1 FRITZ!Fon C5 at a Glance
FRITZ!Fon C5 is a cordless telephone with which you can make tele-
phone calls on the Internet and the landline network. FRITZ!Fon was
developed especially for the FRITZ!Box, but can be used with other
DECT base stations.
Telephone calls over the Internet can be conducted with FRITZ!Fon in
HD to enjoy natural sound quality.
FRITZ!Fon supports DECT Eco “No Emission”. If all of the cordless tele-
phones registered with one FRITZ!Box support DECT Eco, the
FRITZ!Box can switch off the DECT network whenever the telephones
are on standby.
1.1 Package Contents
•FRITZ!Fon C5
•Charging station with power supply unit
•Rechargeable battery

FRITZ!Fon MT-D 10
Getting to Know the FRITZ!Fon
FRITZ!Fon C5 10
1.2 Getting to Know the FRITZ!Fon
Headset
and headphones
Display
Microphone
Loudspeaker
Loudspeaker
(on the back) Side key:
Volume +/-
Right select key
Menu key
Message key
Hands-free calling key
“End call” key
Calling key
Control ring
Numeric keys
Pound sign key /
key lock
Numeric keys /
Play back messages
Asterisk key /
“Do Not Disturb” key
Left select key

FRITZ!Fon C5 11
Icons on the Display
FRITZ!Fon MT-D 11
1.3 Icons on the Display
Icon Meaning Icon Meaning
Establishing connection Call in HD
Connection established “DECT Eco” function en-
abled in the FRITZ!Box
Connection cleared Deletes the last entry
Incoming call Missed calls, new messag-
es or firmware update avail-
able
Answering machine
enabled
Microphone off
Call diversion enabled Loudspeaker/handset
muted
Alarm enabled Headset connected
Three-party conference call Quality of connection with
base station
Keypad locked Battery state of charge
Do Not Disturb enabled Charging battery

FRITZ!Fon MT-D 12
Starting Operation of the FRITZ!Fon C5
FRITZ!Fon C5 12
2 Starting Operation of the FRITZ!Fon C5
2.1 Starting and Registering
1. Pull the protective film downward out of the FRITZ!Fon C5.
FRITZ!Fon C5 starts automatically.
2. Press the registration button on your DECT base station. De-
pending on the device, it is usually called the DECT or Paging
button.
FRITZ!Fon C5 is connected with the DECT base station and can
be used immediately.

FRITZ!Fon C5 13
Charging the Battery
FRITZ!Fon MT-D 13
2.2 Charging the Battery
1. Connect the power supply unit to the charging station.
2. Plug the other end into a power outlet.
3. Place the FRITZ!Fon in the charging station.
The battery will be charged.

FRITZ!Fon MT-D 14
Changing the Battery
FRITZ!Fon C5 14
2.3 Changing the Battery
FRITZ!Fon C5 is supplied with electrical power by a lithium-ion bat-
tery. Once the battery has died, you can replace it yourself.
Here is how to replace the FRITZ!Fon C5 battery:
1. Place a coin in the slot at the bottom of FRITZ!Fon. Rotate the
coin until the battery cover pops open and take off the battery
cap.
2. Insert the battery. The conductors of the battery must be in
contact with the conductors in the housing.

FRITZ!Fon C5 15
Changing the Battery
FRITZ!Fon MT-D 15
3. Close the battery compartment.

FRITZ!Fon MT-D 16
Operating FRITZ!Fon
FRITZ!Fon C5 16
3OperatingFRITZ!Fon
3.1 Switching FRITZ!Fon On and Off
To switch the FRITZ!Fon on or off, press and hold the clear call
key .
3.2 Selecting Functions—Navigating
The functions of FRITZ!Fon are operated using a menu on the display.
Keys
Use these keys to navigate through the menu:
Back
Back
Down
Select key / OK
Up
Select key / OK
To start screen

FRITZ!Fon C5 17
Opening New Messages
FRITZ!Fon MT-D 17
Opening the Menu
Press the Menu key .
The main menu appears on the display.
Selecting a Menu Item
A menu item performs an action or opens a sub-menu.
1. Press the up and down navigation keys to navigate up and
down in the menu.
2. Press the OK key to select a menu item.
You can return to the previous menu by pressing the left Select
key .
3.3 Opening New Messages
If new messages are available, an audio signal sounds, the notifica-
tion key flashes, and the “New Messages” icon appears
in the display. Messages are:
•Missed calls
•Notifications about firmware updates
•Messages on the answering machine
•e-mail, podcasts and RSS feeds
Here is how to open new messages:
1. Press the message key .
2. If different messages are available, select the kind of message
(for instance calls, e-mail). Press the OK key .

FRITZ!Fon MT-D 18
Opening New Messages
FRITZ!Fon C5 18
3. Select a message. Press the OK key .
New messages are black; messages that have already been
read are gray.

FRITZ!Fon C5 19
Entering Numbers and Text
FRITZ!Fon MT-D 19
3.4 Entering Numbers and Text
You can enter numbers and text using the FRITZ!Fon keys.
Entering Numbers and Letters
Press the corresponding keys to enter numbers and letters.
For information about which numbers, letters and special
characters are assigned to the individual keys, refer to the ta-
ble.
“1 x” means “press once”, “2 x” “press twice”, and so on.
Key 1x 2x3x4x5x6x7x8x9x10x11x12x13x
1Space1£$¥
2 A a B b C c 2 Ä ä Á á À à Â â Ã ã Ç ç Ææ å
3 D d E e F f 3 Ë ë É é È è Ê ê
4 G g H h I i 4 Ï ï Í í Ì ì Î î
5 J j K k L l 5
6 M m N n O o 6 Ö ö Ñ ñ Ó ó Ò ò Õ õ Ô ô Ø ø
7 P p Q q R r S s 7 ß
8 T t U u V v 8 Ü ü Ú ú Ù ù Û û Ý ý
9 W w X x Y y Z z 9
0Space.,?!0+-:"' ; _
* * /()<=>%{} [ ]
## @\&§~

FRITZ!Fon MT-D 20
Entering Numbers and Text
FRITZ!Fon C5 20
Setting Capitalization, Lower Case Letters and Numerals
Press the Menu key until the desired entry mode ap-
pears at the lower right of the display:
Moving the Cursor in the Text
How to move the cursor in the text:
Deleting Text
Press the Select key with the display to de-
lete text to the left of the cursor.
Text Entry Mode Function
Shift Capitalize next letter
ABC Capitals
abc Lower case
123 Numerals
Abc Standard mode
The cursor jumps ... Press ...
one character forward the right navigation key briefly
one character backward the right navigation key long
one word forward the left navigation key briefly
one word backward the left navigation key long
one line upward the top navigation key
one line downward the bottom navigation key
