AIR HOCKEY
FRONTGATE
Do you have a question concerning your American Heritage Billiards product? Pleasecontct the retailer you purchased
your furniture from to get more information on he product. lf you cannot contact the retaileryou purchased from,please
send us an inquiry to our website and we’’ll do best to help.Thank you for your support!

1-1-35-910 HD
©2009 Sportcraft, Ltd.
www.sportcraft.com
Español
¡Felicitaciones!
¡Nosotros esperamos que este nueva mesa de
fútbol AHB le proporcione muchas horas de
diversión!
¡ADVERTENCIA!
Esto no es un juguete de niños. La supervisión adulta es
requerida para jugar este juego por los niños. Por favor leer las
instrucciones con cuidado. El empleo apropiado de este juego
puede evitar el daño o la herida.
ANTES DE ASAMBLEAR:
¿Recibió usted 1 caja?
¿Inspeccionó usted su campo de juego/marco de mesa antes
de la asamblea? No es reemplazable y debe ser devuelto al
lugar original de compra.
HERRAMIENTAS NECESARIAS PARA MONTAR:
Destornilladores Phillips y de cabeza ranurada / o destornillador
eléctrico (no incluido)
Llave hexagonal (incluida)
¡POR FAVOR GUARDE ESTAS INSTRUCCIONES!
Su número de modelo es necesario en caso de que
deba comunicarse con nosotros.
Por favor leer este manual de instrucciones para
familiarizarse con todas las piezas y los pasos a seguir en
el montaje.
de que todas las piezas hayan sido incluidas.
English
Congratulations!
We hope you will have many hours of enjoyable
use with your new AHB AIR HOCKEY Table!
WARNING!
This is not a child’s toy. Adult supervision is required for
children playing this game. Please read instructions carefully.
Proper use of this set can avoid damage or injury.
BEFORE ASSEMBLY:
Did you receive 1 box?
assembly? It is not replaceable and must be returned to the
original place of purchase if damaged.
TOOLS REQUIRED FOR ASSEMBLY:
Phillips and Slotted Head Screwdrivers / or Power Driver (not
included)
Allen Wrench (included)
PLEASE KEEP YOUR INSTRUCTIONS!
Your Model number is necessary should you
need to contact us.
Please read through this instruction book to
familiarize yourself with all the parts and assembly
steps.
have been included.
ASSEMBLY INSTRUCTIONS:
We recommend that two adults work together to
assemble this table.
The table will be assembled upside down This is a very heavy table
and turning it right side up it will require at least two strong adults.
to protect the top of your air hockey table while assembling.
INSTRUCCIONES DE ENSAMBLE
Nosotros recomendamos que dos adultos trabajen juntos
para ensamblar esta mesa.
pesada y el voltearla va a requerir al menos dos personas adultas.
cuando es ensamblado.

Foot
Receiver
Leg connector
Side foot column
Connect board Foot column

Using #7 bolt and #8 washer put #2 foot and #3 connect board into #4 foot column and #5
side foot column.
Step1:
Step2:
Using #13 bolt to screw #12 receiver on the back of the table

Attach the ready legs on the support board of table through #9 bolt and #8 washer. Using #10
Using two strong adults, turn the table right side up and enjoy!
bolt and #11 washer to screw #14 leg connector to both legs Screw in #6 leg levelers.
Step3:
