Frontgate DAX POOL TABLE 165665 User manual

DAX POOL TABLE
Item #165665
Assembly Instruction
Step 1: Attach the leg runner to the legs by using Bolt(R), Plug(W) and CROSS DOWEL (V)
NO NAME SIZE PCS DRAW
R BOLT Ø5/16"X4 1/2" 2
VCROSS DOWEL Ø5/16"XØ5/8" 2
WWOOD PLUG ∅21 X 10mm 2
V
R
W
1/7
NO NAME SIZE PCS DRAW
2Leg runner
Legs 2
1
1
39 1/4" x 6" x 26 5/8"
57 3/16" x 2" x 8"
1
2
1

Q
P
Q
L
Q
P
Q
L
DAX POOL TABLE
Item #165665
Assembly Instruction
Step 2: Attach the legs to the long beams by using Bolt(P),Washer(Q) and Nut(L)
NO NAME SIZE PCS DRAW
PBOLT
Ø3/8" x Ø3/4"
Ø3/8" X 4"
NUT
Q32
16
L∅3/8"
WASHER
16
2/7
NO NAME SIZE PCS DRAW
Long beams 2
390 3/4" x 1 3/8" x 3"
3
1
1
2

P
Q
Q
L
P
Q
Q
L
P
Q
Q
L
P
Q
Q
L
DAX POOL TABLE
Item #165665
Assembly Instruction
Step 3: Attach the legs to the short beams by using Bolt(P),Washer(Q) and Nut(L)
3/7
NO NAME SIZE PCS DRAW
PBOLT
Ø3/8" x Ø3/4"
Ø3/8" X 4"
NUT
Q16
8
L∅3/8"
WASHER
8
NO NAME SIZE PCS DRAW
Short beams 2
437 13/32" x 3 3/8" x 1 1/2"
3
3
4
4
5
5
1
1
2
Short beams 2
549" x 4" x 1 1/2"

NO NAME SIZE PCS DRAW
K∅1/4"X2-1/2"
SCREW 12
Step 4A: Locate the center piece of framed slate and
position it on the cross beam assembly so that it is
centered to both the length and width of the
assembly (you must be very accurate with
placement). Pre-drill a hole through the slate screw
hole using a 3/16” drill bit. Vacuum out debris and
secure using slate screws (K). Continue with same
process with both outside sections of slate.
Step 4B: With a level or straight edge, be sure that
the slate seams are flat and level. If adjustments
need to be made, loosen slate screws and place a
shim(s) in area that needs adjustment. Tighten
screws and check for levleness. Use Bee’s Wax or
similar to fuse the seams of the slate together.
Step 5: Remove any wax, dust and debris from the
slate surface to prep it for the bedcloth. Layout
bedcloth centering it over the slate surface. Starting
at one end, staple cloth to slate framing working
from center out toward the pockets stretch cloth
toward pockets. Go to opposite end of table and
repeat process but pull the cloth tight while stapling.
Repeat on long sides working from center between
center pocket and end pocket stretching cloth
toward the pockets as you staple. Once cloth is
completely stapled, cut pocket openings by cutting
small vertical incisions in cloth to relax the fabric so
it can be stretched and stapled around
opening. Finally, make “X” style slits in cloth where
rail bolts will go through the slate holes (see photo).
DAX POOL TABLE
Item #165665
Assembly Instruction
K
K
K
K
K
K
K
K
K
K
K
K
4/7

NO NAME SIZE PCS DRAW
D
E
∅5/16"
NUT
F
Step 6: Assemble the blinds completely using Dowel (A), Washer (I) and Bolt (J).
Step 7A: Assemble the end rails completely using Dowels (A), Washer (C), Nut (D)
and Threaded Rod (B).
Step 8: Attach the top rail assembly to the blind assembly using Screw (E) and Metal (F).
NO NAME SIZE PCS DRAW
A
BTHREADED ROD ∅5/16"X3"
∅10mmX30mm
DOWEL
CWASHER ∅5/16"X3/4"X2mm
4
18
G
H
I
J
8-7/8"X2-5/8"X1/8"
METAL
5-7/8"X1-1/2"X1-1/2"
METAL
∅1/4"X∅5/8"
WASHER
BOLT ∅1/4"X5/8"
8
8
2
4
24
24
BA
C
D
C
D
BOTTOM VIEW Step 7A
E
F
A
X
G
X
AH
I
J
DAX POOL TABLE
Item #165665
Assembly Instruction
Step 7B
Step 6 and Step 8
108
SCREW #8X1/2"
5" x 1" x 1"
METAL 18
5/7
XSCREW #8X3/4" 12
NO NAME SIZE PCS DRAW
Long blinds 2
6
Short blinds 2
755 3/8" x 3/4" x 6 3/4"
Short rails right 2
851 1/8" x 7 1/8" x 1 1/2"
2
9
Short rails 2
10
6
7
7
6
9
9
8
8
10
10
Short rails left
100 7/8" x 3/4" x 6 3/4"
51 1/8" x 7 1/8" x 1 1/2"
58 1/4" x 7 1/8" x 1 1/2"
Step 7B: Assemble the middle rails completely using Dowels (A), Metal (G) and Screw (X)

NO NAME SIZE PCS DRAW
M
N
DOME WASHER
∅3/8"
NUT
O
Step 9: Attach rail/blind assemblies to the slate using Dome Washer (M), Star Washer (N), Threaded Rod (O), and Nut (L).
18
L
STAR WASHER
THREADED ROD
∅3/8"
∅3/8"
∅3/8"X3"
18
18
18
O
M
N
O
L
M
N
O
L
M
N
O
L
M
N
O
L
M
N
O
L
M
N
O
L
M
N
O
L
M
N
O
L
M
N
L
DAX POOL TABLE
Item #165665
Assembly Instruction 6/7

NO NAME SIZE PCS DRAW
U
Step 10: NOTE: the side pockets and corner pockets ARE different and will only work correctly one way. To install the pockets,
squeeze the top of the pocket and bring it up through the pocket opening from the bottom. Be sure not to push back the pockets
so they are flush against the rail; the first priority is to ensure they line up with the felt near the playing surface. Peel back the
paper to reveal the sticky side of the velcro on the backside of the Pocket to secure the Pocket to the Rail.
4
TCORNER POCKET
CENTER POCKET 2
U
T
DAX POOL TABLE
Item #165665
Assembly Instruction 7/7
