FROST NOVA2 Install guide

1
Fitting instruction
Montageanleitung
Monteringsvejledning
Monteringsvägledning
Montage hanleiding
Manuel de montage
NOVA2 CARE
ARM SUPPORT
782 mm
730
FLOOR
142 mm
32 mm
4 mm
145 mm
145 mm
760
Exclusion of liability
FROST accepts no liability whatsoever
for damage to persons or property that
occurs or has occurred as a result of
improper installation or maintenance,
particularly if the safety instructions
and other points to note listed are not
or have not been observed in full.
Warning and hazard notices
Improper mounting or use can lead to
accidents involving serious injuries.
Before installing, the installer must ensure that the
material and strength of the wall are sucient.
FROST CARE products must be mounted on a solid or
reinforced wall.
Recommended installation height: 73 cm (bracket
holes). 76 cm (top of bracket)
Recommended user height: 80 cm (top of armrest)
If any other user height is required, simply position
the holes of the bracket 7 cm below the
required height.
N1961

2
Operating
Bedienung
Betjening
Buk
Bediening
Emploi
Max. 150 kg
Tested by everyday life
To ensure that the arm rest is capable of withstanding heavy load and conditions every day, the product
has been tested in accordance to the requirements of the European standard for technical aids for
disabled, BS/EN 12182:2012. This includes a static proof load test with
150 kg, following by a static overload test with 225 kg.
We recommend all FROST CARE products are installed on a solid wall. Reinforcement should always be
used if the wall is not stable. All tests are carried out on products mounted on a solid wall, thus we cannot
guarantee the same performance and durability if this is not observed.
This product has a maximum weight capacity of 150 kg.
For safety reasons, we recommend to check all bolt connections to ensure that no parts are loose and that
all attachment to the wall are intact.
COVER FOR ARM SUPPORT - N1961-1 (Additional use)
1.
2.
3.
Cleaning and maintenance
Stainless steel surfaces should be
cleaned with a microbre cloth,
glass cleaner or other non abrasive
and gentle agents.
Attention:
Never use solvents or aggressive
household cleaners like bleach,
acids (e.g. descalers) or ammo-
nia-based bathroom cleaner to
clean the product. Steel wool and
hard brushes can permanently
damage the surfaceof the steel.

3
Bavne Allé 32
DK-8370 Hadsten
[phone]
[e-mail]
www.frost.dk
ARM SUPPORT
N1961
Brushed
Material: Stainless steel, AISI 304
Design: Bønnelycke mdd
Manufacturer: FROST A/S
O1961
Polished
Ø14 x 75
AB
2x
CD
M10 x 115
2x
4MM
1x
8MM
1x
N1961-C
Polished Copper
N1961-C
Polished Gold
N1961-BOC
Brushed Copper
N1961-BMG
Brushed Gold
N1961-B
Matt Black
N1961-W
Matt White
N1961-BCB
Brushed Black
