FSP Technology EnerX 3000 User manual

Version: 1.1
User Manual
EnerX 3000
Portable Energy Storage System

Table Of Contents
ABOUT THIS MANUAL ......................................................................................................................................1
Purpose............................................................................................................................................................1
Scope...............................................................................................................................................................1
SAFETY INSTRUCTIONS...................................................................................................................................1
INTRODUCTION .................................................................................................................................................2
Basic System Architecture...............................................................................................................................2
PRODUCT OVERVIEW.......................................................................................................................................3
Main Unit..........................................................................................................................................................3
External Battery Module (Purchased separately)............................................................................................5
INSTALLATION...................................................................................................................................................6
Package Contents............................................................................................................................................6
Preparation ......................................................................................................................................................6
Internal Battery Connection .............................................................................................................................7
AC Input Connection........................................................................................................................................7
PV Connection.................................................................................................................................................8
AC Output Connection.....................................................................................................................................9
USB Charger..................................................................................................................................................10
Parallel Function............................................................................................................................................11
OPERATION......................................................................................................................................................15
Power ON/OFF ..............................................................................................................................................15
Operation and Display Panel.........................................................................................................................15
Pages Information..........................................................................................................................................16
Configurations................................................................................................................................................17
Wi-Fi Connection ...........................................................................................................................................18
Prioritizing Energies Scenarios......................................................................................................................18
CLEARANCE AND MAINTENANCE FOR ANTI-DUST KIT............................................................................22
Overview........................................................................................................................................................22
Clearance and Maintenance..........................................................................................................................22
SPECIFICATIONS.............................................................................................................................................23
TROUBLE SHOOTING.....................................................................................................................................24
Appendix I: The Wi-Fi Operation Guide.........................................................................................................26

1
ABOUT THIS MANUAL
Purpose
This manual describes the assembly, installation, operation and troubleshooting of this unit. Please
read this manual carefully before installations and operations. Keep this manual for future reference.
Scope
This manual provides safety and installation guidelines as well as information on tools and wiring.
SAFETY INSTRUCTIONS
WARNING: This chapter contains important safety and operating instructions. Read and
keep this manual for future reference.
1. Before using the unit, read all instructions and cautionary markings on the unit, the batteries and all
appropriate sections of this manual.
2. Do not disassemble the unit. Take it to a qualified service center when service or repair is required.
Incorrect re-assembly may result in a risk of electric shock or fire.
3. To reduce risk of electric shock, disconnect all wirings before attempting any maintenance or cleaning.
Turning off the unit will not reduce this risk.
4. CAUTION –Only qualified personnel can install this device with battery.
5. NEVER cause AC output and DC input short circuited. Do NOT connect to the mains when DC input
short circuits.
6. Warning!! Only qualified service persons are able to service this device. If errors still persist after
following troubleshooting table, please send this inverter/charger back to local dealer or service center
for maintenance.
7. WARNING: Because this inverter is non-isolated, only three types of PV modules are acceptable:
single crystalline, poly crystalline with class A-rated and CIGS modules. To avoid any malfunction, do
not connect any PV modules with possible current leakage to the inverter. For example, grounded PV
modules will cause current leakage to the inverter. When using CIGS modules, please be sure NO
grounding.
8. CAUTION: It’s requested to use PV junction box with surge protection. Otherwise, it will cause
damage on inverter when lightning occurs on PV modules.

2
INTRODUCTION
This is a portable energy storage system for home and adventure. The power stations have a battery,
inverter and smart charging technology all built into a neat plug and play unit. Plug and Play off-grid system
provides multiple charging options, giving you the flexibility to charge from AC (wall outlet or generator) and
solar panel. All units are provided multiple power sockets and USB charger ports, allowing to power your
diverse electronic devices.
Basic System Architecture
The following illustration shows basic application for this inverter/charger. It also includes following devices
to have a complete running system:
1. Generator or Utility.
2. PV modules
Consult with your system integrator for other possible system architectures depending on your requirements.
This inverter can power all kinds of appliances in home or office environment, including motor-type
appliances such as tube light, fan, refrigerator and air conditioner.
Figure 1 Energy Storage System

3
PRODUCT OVERVIEW
Main Unit - EnerX 3000
Optional receptacles

4

5
External Battery Module - EnerXPack 2500 (Purchased separately)

6
INSTALLATION
Package Contents
Before installation, please inspect the content. Be sure that nothing inside the package is damaged. You
should have received the following items inside the package:
EnerX 3000
(Inverter with built-in battery)
Manual
AC power cord
Cable Gland x 2
Caster stopper x 2
Optional kit:
PV connector
PV connector with cable
Parallel Cable
Preparation
Before operation, it’s recommended to install the caster stoppers to enhance the stability.

7
Internal Battery Connection
For safety concern, the internal battery is disconnected from the internal DC breaker before shipment.
Before installation, please remove two screws from the top panel and turn on the internal DC breaker. Then,
fix those screws firmly.




AC Input Connection
Connect the AC power cord to the IEC Inlet and then plug it into utility.

8
PV Connection
There are two methods to connect PV panels.
1. Connect directly on the terminal block.
2. Using a pluggable connector.
Direct Terminal Connection
1. Take off the PV connector cover by removing screws as shown below.
2. Install the cable gland to connector cover.
3. Fixing the PV cables on the terminal.
4. Install cover back to the rear panel.




Pluggable Connector Connection
Please follow below steps to implement PV module connection:
1. Take off the PV connector cover by removing screws as shown below.
2. Install the cable gland.
3. Check correct polarity of wire connection from PV modules and PV input terminals.
Connect positive pole (+) of connection wire to positive pole (+) of PV input terminal. Connect negative
pole (-) of connection wire to negative pole (-) of PV input terminal.
4. Install cover back to the rear panel.





9
AC Output Connection
CAUTION: If signal unit operation, please close the cover of parallel socket to reduce risk of electric shock.
Plug AC power cord on the AC output socket.
Output powered when the main switch on the front panel pressed for 3 sec.
In case the load rating higher than the socket could support (>13Amp), please connect the power cable on
the AC output terminal block. Before doing that, please be sure the unit is “OFF” completely.
1. Remove insulation sleeve 10mm for three conductors. And shorten phase L and neutral conductor N 3
mm.
2. Insert AC output wires according to polarities indicated on terminal block and tighten the terminal
screws. Be sure to connect PE protective conductor (G) first.
3. Make sure the wires are securely connected and then knock terminal cover to install cable gland.
4. Insert the terminal cable to cable gland, and install cover box on rear panel.
CAUTION: Important
Please install the terminal cover firmly to reduce risk of electric shock

10
USB Charger
Use USB output cable (not provided) to charge your electronic devices.
USB charger port could be turned on/off through the LCD operation.

11
Parallel Function
1. Introduction
This portable energy bank can be operated in parallel with 2 units. The supported maximum capacity is
6KW. If longer backup time is required, this unit can be connected with more battery modules up to 2
units.
CAUTION: Parallel feature will be disabled when only PV power is available.
2. System Configuration
There are several configurations available as shown below.
Note: The gray unit in the picture is the external battery module.
Expand Battery Capacity
3KW, 2.5KWh
3KW, 5.0KWh
3KW, 7.5KWh
Expand Power and Battery Capacity
6KW, 5.0KWh
6KW, 7.5KWh
6KW, 10KWh
6KW, 12.5KWh
6KW, 15KWh

12
3. Preparation
Before connecting all wires, be sure to take off top panel and wire cover by removing six screws.
Refer to below chart for the details.
4. External Battery Connection
If longer backup time is required, it’s necessary to connect external battery modules.
Maximum connection number is two.
CAUTION: Before connecting to battery modules, please disconnect the DC breaker located on the top of
the unit.
Step 1: Follow the polarity near the battery terminal to connect battery terminals with two battery cables
supplied in external battery module! Simply plug battery cable to battery terminals on EnerX 3000 module
and EnerXPack 2500 external battery module as shown below charts.
Expand Battery Capacity
3KW, 5.0KWh
3KW, 7.5KWh
Expand Output Power and Battery Capacity
6KW, 7.5KWh
6KW, 10KWh

13
6KW, 12.5KWh
6KW, 15KWh
NOTICE: It’s not applied for common battery when expanding the output power with 2 units. External
battery module only connects to its integrated main unit.
Step 2: Connect extension port on the battery modules with RJ11 cables (supplied in the external battery
module). After wiring installation is complete, set up ID for each battery module. The ID code for each
battery module MUST be unique. Not the same number for 2 battery modules in parallel system. Refer below
chart for the details.
NOTE: ID Switch indicates the unique ID code for each battery module. It's required to assign a unique ID to
each battery module for normal operation. From number 0 to 1, the number can be random; no particular
order. Maximum 2 battery modules can be operated in parallel.
Expand Battery Capacity
3KW, 5.0KWh
3KW, 7.5KWh
Expand Output Power and Battery Capacity

14
6KW, 7.5KWh
6KW, 10KWh
6KW, 15KWh
5. AC Output Connection
Open the parallel port cover and use one parallel cable (purchased separately) to connect the parallel ports
on the two main unit. Once paralleled units are powered on, you can plug devices on either Master or Slave
unit.


When parallel system is operated successfully, the LCD information on Master and Slave will present.
Master unit
Slave unit

15
OPERATION
The unit is equipped with rechargeable Lithium battery. Be sure to charge the battery at least more than 12
hours before initial use. To accurate the calculation of battery capacity, it’s recommended to have fully
charged and discharged for 1~2 times. For long-term storage, it’s necessary to fully charge the battery,
disconnect the internal DC breaker and store it in a cool, dry place.
Power ON/OFF
Once the unit has been properly installed and the batteries are connected well, simply press and hold the
power button for 2-3 seconds until one beep is heard, then release the power button. The unit will be
turned on.
Operation and Display Panel
The operation and display panel, shown in below chart, is located on the top of the unit. It includes seven-
page colorful LCD display, scrollbar and graphic touch pads, indicating the operating status and input/output
power information.

16
Pages Information
When the unit is turned on, the LCD display will show home page after few seconds.
Home page: (tap icon
0.5s)
indicates the summarized
power flow and energy
information.
Battery page:
indicates the battery cell
and pack information.
Cell indication in battery page:
AC input page:
indicates the AC input
source type and information.
PV page:
indicates the PV
information.
AC output page:
indicates the AC output
information.
USB charger page:
real-time control on the
output of USB charger ports.
Logs page:
indicates all event, warning,
and fault messages.

17
Configurations
Press icon for 3s to enter the setting menu.
There are three sub-menus: Information, Basic and Advanced.
Click icon again to exit setting return Home page.
Information
Basic
Change the main page
Setup home page
Turn on/off Wi-Fi module
Turn on/off buzzer
Setup date
Setup time
Setup log record duration
Enable screen off timer
Change RGB LED color
Advanced
Configure the nominal voltage and frequency
Default: 230Vac, 50Hz (or 120Vac, 60Hz)
Note: 120VAC and 230VAC belongs to different model.
Configure the output and charger source priority
Regular: Priority arranged per day
Schedule: Priority arranged per hours
Default: Regular
Configure the stop and restart discharging capacity and
minimum SOC
Default: 10%, 80%, 10%
