FSR CDA-2EQA User manual

REGULATORY COMPLIANCE
FSR'S ELECTRONIC PRODUCTS have been tested for compliance with: FCC Class A
and CE The Power Adapter has been tested for compliance with: UL, CSA and CE.
WARRANTY POLICY
This product is warranted against failures due to defective parts or faulty workmanship for
a period of one year after delivery to the original owner. During this period, FSR will make
any necessary repairs or replace the unit without charge for parts or labor. Shipping charges
to the factory or repair station must be prepaid by the owner, return-shipping charges, via
UPS / FedEx ground, will be paid by FSR.
This warranty applies only to the original owner and is not transferable. In addition, it does
not apply to repairs done by other than the FSR factory or Authorized Repair Stations.
This warranty shall be cancelable by FSR at its sole discretion if the unit has been
subjected to physical abuse or has been modified in any way without written authorization
from FSR. FSR’s liability under this warranty is limited to repair or replacement of the
defective unit.
FSR will not be responsible for incidental or consequential damages resulting from the use
or misuse of its products. Some states do not allow the exclusion of incidental or conse-
quential damages, so the above limitations may not apply to you. This warranty gives you
specific legal rights, and you may also have other rights which vary from state to state.
Warranty claims should be accompanied by a copy of the original purchase invoice
showing the purchase date (if a Warranty Registration Card was mailed in at the time of
purchase, this is not necessary). Before returning any equipment for repair, please read the
important information on service below.
SERVICE
Before returning any equipment for repair, please be sure that it is adequately packed and
cushioned against damage in shipment, and that it is insured. We suggest that you save
the original packaging and use it to ship the product for servicing. Also, please enclose a
note giving your name, address, phone number and a description of the problem.
NOTE: all equipment being returned for repair must have a Return Authorization
(RMA) Number. To get a RMA Number, please call the
FSR Service Department (973-785-4347).
Please display your RMA Number prominently on the front of all packages.
Contact Information:
244 Bergen Boulevard,
West Paterson, NJ 07424
Tel: [phone] · Fax: [phone]
E-Mail: [email protected] · Web: http://www.fsrinc.com
CDA - 2EQA
1 x 2 DISTRIBUTION AMPLIFIER
with EQUALIZATION
OPERATIONS MANUAL
244 Bergen Boulevard, West Paterson, NJ 07424
Tel: [phone] ·Fax: [phone]
E-Mail: [email protected]
Web: http://www.fsrinc.com
FSR
LIT1024
issue date: 8-03
FRONT
REAR

PROPRIETARY INFORMATION
All information in this manual is proprietary to and the
property of FSR inc. This publication is protected by the Federal
Copyright Law, with all rights reserved. No part
of this document may be reproduced, transcribed, or transmitted,
in any form or by any means, without prior
explicit written permission from FSR inc.
Thanks for purchasing the FSR CDA - 2EQA, a 1 x 2 distribution
amplifier with equalization. In addition to scaling switchers, such as
the MAS-4100, FSR offers a full line of interfaces, line drivers,
distributionamplifiers,downconverters,powersequencersandmore.
Operators Safety Summary
The general safety information in this summary is for operating
personnel.
Do Not Remove Covers or Panels There are no user-serviceable
parts within the unit. Removal of the top cover will expose
dangerous voltages. To avoid personal injury, do not remove the
top cover. Do not operate the unit without the cover installed.
Power Source This product is intended to operate from a,
provided, wall transformer power source.
Use the Proper Power Cord Use only the power cord and
connector specified for your product. Use only a power cord that is
in good condition. Refer cord and connector changes to qualified
service personnel.
Do Not Operate in Explosive Atmospheres To avoid explosion,
do not operate this product in an explosive atmosphere.
AUDIO
Bandwidth: 20 Hz to 20 kHz (+/-0.05 dB)
THD + Noise: 0.01% @ 20 kHz at rated Max Output S/N
>98 dB
Noise Floor: < 98 dB
Stereo separation: -90 dB @ 1 kHz
AUDIO INPUT
Number/type: 2 stereo unbalanced
Connectors: Two 3.5mm stereo mini connectors
Impedance: 10K Ohms unbalanced
Maxlevel: +6 dBm
AUDIO OUTPUT
Number/type: 1 Balanced Stereo (may be used in
unbalanced configuration)
Connector: 5 Position mini Phoenix
Impedance: 50 ohms
Gain: + 6 dB balanced or unbalanced
MaximumLevel: 600 ohms: +12 dBm Balanced / +6 dBm
Unbalanced Hi – Z: +14 dBm Balanced /
+8 dBm Unbalanced
SYNC
Input level: 2.0 Vp-p to 5.0 Vp-p
Output level: 4.0 Vp-p into Hi-Z, 2.0 Vp-p into 75 ohm
Input Impedance: 511 ohms
Output impedance: 75 ohms
Polarity: Positive or negative
Horizontal frequency: 15 kHz - 200 kHz
Vertical frequency: 30 Hz - 150 Hz
POWER
Wall Transformer (provided)
with locking connector 9Vac @ 500 ma

INTRODUCTION
The CDA-2EQA, is an ultra high bandwidth 1x2 Distribution
Amplifier with Equalization for applications requiring the highest
possible video quality. Computer video signals quickly lose color
and clarity after about 25 feet. Unbalanced audio is prone to hum
and buzz. This unit will permit cable runs of 175 feet.
You spend a significant amount of time generating the best possible
image as well as the highest quality audio, don't trust those signals
to retain that fidelity in a long cable run. The CDA-2EQA will
compensate for the cable's shortcomings and deliver both the video
and audio to it's destination with the same fidelity that it was
created with. High bandwidth and flat frequency response - just
what you need.
To insure the best possible signal reproduction, the CDA-2EQA has
been designed to provide up to 525 MHz of bandwidth, ensuring
compatibility with today's and tomorrow's most demanding video
signal requirements. The audio is also handled properly resulting in
a balanced audio drive.
The CDA-2EQA solves problems and more in one easy to install
package.It combines an ultra high bandwidth video line driver and
an active audio balancer into one easy to install package. The unit
also features user selectable cable equalization, a fully buffered
local monitor output, and greater than 525 MHz of bandwidth.
APPLICATIONS
• Boardrooms • Houses of Worship
• Classrooms • Staging and Rental
• Conference Centers • Control Rooms
TECHNICALSPECIFICATIONS
VIDEO INPUT
Number/type: VGA / SVGA / XGA / SXGA / UXGA /
RGBHV / RGBS / RGsB / RsGsBs
Connectors: 15 pin HD female
Level(nominal): Analog 0.7 Vp-p
Level(maximum): 2 Vp-p
Impedance: 75 ohms
EQUALIZED VIDEO OUTPUT
Number/type: 1 VGA / SVGA / XGA / SXGA / UXGA /
RGBHV / RGBS / RGsB / RsGsBs
Connectors: One 15 pin HD female
Bandwidth:
Without cable 500MHz
50' cable 308 MHz (-3dB) 0-215 MHz +/-0.25dB
100' cable 225 MHz (-3dB) 0-180 MHz +/-0.25dB
150' cable 173 MHz (-3dB) 0-150 MHz +/-0.25dB
This performance data is based on the CDA-2EQA plus the
specified length of WP8255 (West Penn) cable with a full
amplitude (0.7v P-P) signal applied.
Level(nominal): Unity / User adjustable via HI / MED / LOW
Jumper
Gain: HI = 125’ to 175’, MED = 60’ to 125’,
LOW = 0’ to 60’
Impedance: 75 ohms
DesignCable: West Penn WP8255 or equal
LOCAL VIDEO OUTPUT
Number/type: 1 VGA / SVGA / XGA / SXGA / UXGA /
RGBHV / RGBS / RGsB / RsGsBs
Connectors: One 15 pin HD female
Bandwidth: 300MHz @ -3dB
Gain: Unity (buffered)
Impedance: 75 ohms

L+
-
+
-
R
SH
Output Connector Wiring
L+
-
+
-
R
SH
Balanced Wiring Unbalanced Wiring
Jumper
Connect the audio output cables to the captive screw terminals
labeled “Audio Out”. The appropriate wiring configuration for
balanced and unbalanced connections is shown on the next page.
Set the cable equalization jumpers for optimum performance at the
desired cable length (LOW = 0 - 60', MED = 60 - 125',
HI = 12 5- 175'). These settings are based on WP 8255 (West Penn)
cables or equivalint.
Connect the 9 VAC power supply output to the locking Power In
connector
Confirm proper video and audio operation before mounting the
CDA - 2EQA
Use the supplied brackets to mount the CDA - 2EQA to the
underside or topside of the table.
Perform the final operational check.
MOUNTING BRACKETS (2)
AND SCREWS (4) INCLUDED
FOR ABOVE OR BELOW TABLE MOUNTING
POWER EQUALIZED
VIDEO OUTPUT
9V AC
CABLE
EQ GAIN
AUDIO OUTPUT
-
+
-
+S
H
RL H
ILO MED
PROJECTOR
AMP / SPEAKERS
9V AC POWER SUPPLY
(INCLUDED)
CABLE RUN UP TO 175'
SOURCE
COMPUTER
(
POWERPOINT
)
LOCAL MONITOR
POWER
AUDIO
LOCAL MONITOR VIDEO CDA-2EQA
INPUT
OUTPUT
. 5 4 Model
TYPICALAPPLICATION
AUDIO
INSTALLATION
Do not plug in the power supply until all wiring is completed.
Connect the video and audio connectors per the diagram.
FRONT VIEW
REAR VIEW
