FTE Maximal Multivision Plus Operating instructions

All rights reserved 1 © FTEmaximal
Operating instructions and
installation guide for
Multivision Plus
Audio / video switch

All rights reserved 2 © FTEmaximal
Table of contents Multivision
Installation Page
Safety instructions
Unconditional note 2
Included parts
Is the delivery complete? 5
Multivision parts
Main function
Accessories
Technical data
6
7
8
Fast information
What is for what 8
Correct position
Multivision set up
Remote control system
11
12
Combinations
Connecting the Multivision
Remote control
13
14
Parameters
Modulator’s output channel
Remote control adjustment
15
17
Use
Usual operating
The remote control
Front buttons
18
19
20
Troubleshooting
Self-help
If something doesn’t work 21

All rights reserved 3 © FTEmaximal
Multivision
Safety instructions
Very important
Multivision system has to be installed according to the instructions of this
manual and the general technical rules. If you do not agree with it,
intentional or careless, the manufacturer is out of warranty and
responsibility.
Please take care of you and the people around as it is a plugged device.
Is it necessary to read the complete manual?
Yes, recommended!
With one Multivision system from FTEmaximal you have many possibilities.
For your safety
Caution, do not open the cabinet, you can have a shock by electricity.
Equipment must be repaired by a professional technical service.
There is no fuse inside or anything to adjust.
When you clean or work on the connection of the system, first disconnect the
plug.
To switch it off is not enough, because some connectors on the rear side can
also have power.
When you are going to be for long time out of your home (e.g. holiday)
disconnect also the plug from the 230V socket.

All rights reserved 4 © FTEmaximal
Safety instructions Multivision
Never pull on the cable for the power supply, every time pull the plug directly.
Otherwise the cable will be damaged.
Have a look that the plug always has strong and safety hold to the socket.
Shaky plugs or sockets have a risk of fire disaster.
Defects like this must be fast repaired by a professional.
Never work during a thunderstorm on the Multivision system, on TV connections
or on other equipment.
Dangerous high power voltage can be on pieces of metal from the equipments.
Use the device only in a dry and aired environment.
Moisture can lead to dangerous error voltages.
This danger is specially great, when liquids run into the device.
Move then the power plug immediately from the socket!
Cleaning
Do not employ liquids neither corrosive materials or detergents.
A dry cloth is the best solution to clean electronic devices as the
Multivision system.

All rights reserved 5 © FTEmaximal
Multivision
Included parts
Is the delivery complete?
Please check whether in your delivery following items are contained:
☺ Multivision system
☺ Two remote controls with batteries
1,5V LR 6 (Size AA)
☺ Remote infrared receiver
☺ LED cable
☺ Power supply for infrared receiver
☺ Scart – Scart cable
☺ Coaxial cable
☺ VE 1 Splitter for two TV sets

All rights reserved 6 © FTEmaximal
Multivision parts Multivision
Available parts
☺5 inputs (2x RCA + 3x Scart)
☺Remote control with direct selection of the input.
☺Remote receiver of infrared signals that let control the equipments from
another room.
☺Adjustable PLL Modulator CH21...CH69
Multivision allows to select between 5 available inputs Scart and RCA connectors.
It has 2 separate outputs, 1x mono modulator 1x stereo Scart, which can be
switched independently by each other.
Usually the Scart output will be connected to the nearest TV set ant the modulator
output is used for remote rooms.
The modulator converts for this purpose the A/V signals into TV-signals according
to used standard.
It is possible to mix this signal with the rest of the ones which are received from
the terrestrial TV or cable or to send only the one which is generated by
Multivision.
The output channel of the modulator can be chosen in the UHF range between
channel 21 and 69 freely.
The control of A/V equipments as well as the control on Multivision can be done
from the remote room using its function of infrared repeater.
Multivision includes necessary elements for one remote control position.
There are available accessories to enlarge the number of positions with infrared
repeater.
The selection of the inputs for each output is appreciated in the front panel
through coloured LEDs.

All rights reserved 7 © FTEmaximal
Multivision
Multivision parts
Accessories
Following accessories are available
Additional Remote control MMV Art. number: 6000502
The remote control MMV is
considered as second remote
control exclusively for the adjacent
rooms. It can only control modulator
output avoiding selection changes at
Scart output or disconnections of
Multivision.
Extension Kit MV Art. number: 6000504
Through this kit we can add a
second (or more) position from
where can control the equipments of
Multivision. It contains:
1x Remote control with selection
functions for modulator output
1x Receiver for remote room
1x Power supply for infrared receiver
Signals amplifier TAM MV Art. number: 6000506
With this amplifier we can have
more level of signals to compensate
looses in the distribution. It has an
additional mix input for terrestrial
signals if don’t need amplification.
Frequency range (MHz): 80 – 862
Return channel (MHz): 5-65
Gain (dB): 18
Noise (dB): 5
Output level (dBµV): 112
Power supply: 230V / 50 Hz

All rights reserved 8 © FTEmaximal
Multivision parts Multivision
Technical features
A/V frequency range 20Hz – 15kHz
A/V impedance 75Ω(Video), 47kΩ(Audio)
A/V input level 1 Vpp (Video), 0.4V (Audio)
A/V inputs 2xRCA, 3x21pin Scart
A/V outputs 1x 21pin Scart
Impedance of modulator 75Ω
Output frequency range 470 - 862 MHz
Output level of modulator 85 dBµV
Audio - video carrier - 17dB
Audio carrier frequency 5,5 MHz
Modulator connectors IEC 169-2 (m) + IEC 169-2 (m)
Output level IR receiver 72dBµV /
Power supply 220~240VAC / 50Hz
Measures 290 x 185 x 53mm
Weight 1,5 kg
Fast guide Multivision
What is for what?
The remote control
The press buttons of the remote control
can
be taken into an upper one and into a
lower keypad together.
With the upper keypad (AV) is possible to
select the active input (R2-R6) for scart
output (R7).
With the lower keypad (RF) active input (R2-R6) is
controlled for modulator output (R9).
Power key is to turn Multivision off.
U
pp
er ke
yp
ad
Lower ke
yp
ad

All rights reserved 9 © FTEmaximal
Multivision
Fast guide
What is for what?
Front panel of the Multivision
F1 POWER Button Multivision On or Stand by
F2 STAND BY LED lights up in the stand by mode
F3 IR-Sensor Reception eye for the signals of the remote control
F4-F8 Manual selection buttons for the inputs AUX1 - VCR
F9
A/V-RF Selects manually the input to be programmed
Buttons F4-F9 are equipped with bicolour light-emitting diodes (LED) for simple
programming, the colour will indicate selected function.
Rear panel of the Multivision
R1 Mains 230 VAC / 50 Hz
R2-R6 Inputs A/V signals
R7 Output scart to television set
R8 Dip-Switch let select output channel of the modulator
R9
Modulator-output to remote rooms
R10
Antenna input for the rest of TV signals from the antenna.
R11
Output for LED cable for transmitting the infrared signals.
F1
F2 F3 F4 F5 F6 F7 F8 F9
R1
R2 R3
R4
R5
R6
R7 R8
R9
R10R11

All rights reserved 10 © FTEmaximal
Fast Guide
What is for what?
IR Remote Receptor
IR 1 IEC-Connector for TV set
IR 2 LED Indicator for signal IR
IR 3 Level adjuster for return channel
IR 4 IR-Receiver for IR signal
IR 5 IEC-Connector for antenna socket
(Backside)
Power unit for IR Remote Receiver
N 1 Network plug for 230V socket
N 2 Connector for
IR Remote Reception
LED cable
M 1 Connector for the
connection to Multivision
M 2 IR sending diodes
IR 1
IR 2
IR3
IR 4
IR 5
M 1
M 2
N 1
N 2
IR – IR signals are not visible to human eye. It’s very important that between
IR sending diode and devices to be controlled there is a direct vision. Lens
type included generates a light cone that must cover the devices. Angle of
incidence of infrared light on detector of each device can generate defects in
functioning. Separate emitter as much as you can to get a lighting most
p
er
p
endicular as
p
ossible to all devices.

All rights reserved 11 © FTEmaximal
Multivision
Correct position
Setting up Multivision
The correct site ...
... logically, as nearer as possible to main TV set and other A/V signal
sources, it will be better. You have to choose a stable position at wich you
can lay necessary connecting cables in a comfortable way and plug the
Multivision.
The equipment, like any other electronic device, generates a working
temperature, take care of where you place it if there are more devices
because a temperature excess can be generated and damage all
equipments. Choose an aired place and far from any external heat source
like radiators, chimneys etc.
Therefore:
Never expose the system to direct solar radiation.
Choose one site, where liquids can not be spilt inside under any circumstance.
Assure the connection to the mains, a false contact could cause a fire. Net cable
must be specially far away from external heat sources. Make sure that children
have no access to net cable or electrical connections.
Important:
Choose a place where you can reach the power plug in any case of danger
situations and move the power plug from the socket (230V)

All rights reserved 12 © FTEmaximal
Correct position Multivision
IR Remote Reception
For the right function of remote control repeater, the choice of LED cable
position is very important. Cable length is 1,9 meters.
The LED cable transmits the signals generated in remote rooms to control the
Multivision as well as the rest of devices that have this function.
Most entertaintment devices A/V have an infrared sensor on its front panel, so
they all can be controlled from the same place.
The complement of the LED cable is the IR receiver located in the remote
rooms. It gets the signals from remote controls, modulates them in 11 MHz and
transmits them through the coax cable from this room to the Multivision.
To install the IR receiver following things must be considered.
1st Cable length between receiver and sensor IR 4 (this is the one that really
receives infrared signal) is 1,9 meters.
2nd The Sensor (IR 4) must be located in a visible place.
3rd Receiver must be plugged in a power supply (included in the equipment).
DVD
Multivision
VCR
SAT
LED
cable
IR-
sending
diode
Start with the last diode of the LED
cable and the farest unit.
Place the sending diode on the side
of the sensor window.
You can fix the LED after removing the
adhesive.
0145
Display
IR-sensor
LED
cable
IR-
Sending
diode

All rights reserved 13 © FTEmaximal
Multivision
Combinations
Connecting the Multivision
Here is an installation example of the Multivision system.
It seems to be complicated but following these instructions you will see that’s
very easy to install.

All rights reserved 14 © FTEmaximal
Connection of the inputs R2 - R6
Once all connections with equipments A/V are made, plug the Multivision.
Connections R2 (AUX1) and R3 (AUX 2) are used to connect equipments with
RCA outputs for instance Handycam or videogames. Input R4 is marked as SAT
(satellite receiver) and can be selected from the front panel or remote control
with SAT key. Same procedure must be applied to the rest: R5 (DVD), and R6
(VCR).
These inputs selection is not obligatory, you can connect any audio and video
source (that accomplish specifications in page 8), in any input. Indications are
as common installing example and to fix selection buttons.
R9 connector is an input of terrestrial or cable TV.
Signals that come in this input only appear in R10 output and are not modified
by Multivision´s modulator.
For example, if in input R9 exists the channel C10 (210,25 MHz) at output
connector (R10) there is also this channel available for TV set.
Connection Outputs R7 and R10
Main television set (Room 1) is connected directly to the Multivision system,
using R7 and included Scart-Scart cable. In this output all incoming signals in
inputs R2-R6 are available now in Stereo for the main TV (if the input source
supplies a Stereo signal). The output of the modulator R10 combines incoming
signals from antenna or cable with the channel generated by Multivision, and
send all it through coaxial cable to remote room.
Modulator output channel by factory default is channel 21.
System to select the output channel is described in page 15.
Necessary elements top distribute this signal up to remote rooms are not
included in Multivision.
It must be considered that all used elements in distribution to remote rooms
must allow to have a return channel (5-30MHz) for the function of remote control
repeater.
Ask your usual installer or distributor to know best elements for distribution and
avoid future changes.
Connect in R11 LEDs cable connector M 1.
If all connections are already made you can plug the Multivision and enjoy your
new equipment.

All rights reserved 15 © FTEmaximal
Multivision
Parameters
Necessary adjustments in Multivision system are only 2.
1. Modulator output channel
2. Adjustment of output level in remote receiver
Modulator output channel
Adjustment of output channel is made by some microswitches placed in the rear
panel of Multivision.
Make sure that the channel that is going to be selected is free and the one
immediately lower and upper are also free. Example: If you decide to use CH26
check that CH25 and CH27 are free specially lower one.
Microswitches are marked from 1 to 8.
Microswitch position follows this rule: If in the board of page 16 appears “0” then
suitable microswitch must be up, otherwise if in the board appears “1” position
must be down (ON).
Position 7 is used to generate a video test pattern (to tune TV sets). Switching ON
this position is activated the picture of two vertical white lines on black
background.
Position 8 is unused.
Use test pattern generator to tune the channel of Multivision
in TV sets of remote roomsaand also to check that the channel
is free of interferences. To modify the selection of microswitches
use a small screwdriver.
R 8

All rights reserved 16 © FTEmaximal
Parameters Multivision
CH Frequency Position 1 Position 2 Position 3 Position 4 Position 5 Position 6
CH21 471,25 0 0 0 0 0 0
CH22 479,25 1 0 0 0 0 0
CH23 487,25 0 1 0 0 0 0
CH24 495,25 1 1 0 0 0 0
CH25 503,25 0 0 1 0 0 0
CH26 511,25 1 0 1 0 0 0
CH27 519,25 0 1 1 0 0 0
CH28 527,25 1 1 1 0 0 0
CH29 535,25 0 0 0 1 0 0
CH30 543,25 1 0 0 1 0 0
CH31 551,25 0 1 0 1 0 0
CH32 559,25 1 1 0 1 0 0
CH33 567,25 0 0 1 1 0 0
CH34 575,25 1 0 1 1 0 0
CH35 583,25 0 1 1 1 0 0
CH36 591,25 1 1 1 1 0 0
CH37 599,25 0 0 0 0 1 0
CH38 607,25 1 0 0 0 1 0
CH39 615,25 0 1 0 0 1 0
CH40 623,25 1 1 0 0 1 0
CH41 631,25 0 0 1 0 1 0
CH42 639,25 1 0 1 0 1 0
CH43 647,25 0 1 1 0 1 0
CH44 655,25 1 1 1 0 1 0
CH45 663,25 0 0 0 1 1 0
CH46 671,25 1 0 0 1 1 0
CH47 679,25 0 1 0 1 1 0
CH48 687,25 1 1 0 1 1 0
CH49 695,25 0 0 1 1 1 0
CH50 703,25 1 0 1 1 1 0
CH51 711,25 0 1 1 1 1 0
CH52 719,25 1 1 1 1 1 0
CH53 727,25 0 0 0 0 0 1
CH54 735,25 1 0 0 0 0 1
CH55 743,25 0 1 0 0 0 1
CH56 751,25 1 1 0 0 0 1
CH57 759,25 0 0 1 0 0 1
CH58 767,25 1 0 1 0 0 1
CH59 775,25 0 1 1 0 0 1
CH60 783,25 1 1 1 0 0 1
CH61 791,25 0 0 0 1 0 1
CH62 799,25 1 0 0 1 0 1
CH63 807,25 0 1 0 1 0 1
CH64 815,25 1 1 0 1 0 1
CH65 823,25 0 0 1 1 0 1
CH66 831,25 1 0 1 1 0 1
CH67 839,25 0 1 1 1 0 1
CH68 847,25 1 1 1 1 0 1
CH69 855,26 0 0 0 0 1 1

All rights reserved 17 © FTEmaximal
Multivision
Parameters
Adjustment of output level in remote receiver
To be sure that signals from remote control
repeater arrive at their destination, infrared receiver
has an amplifier built in which can adjust the level.
As any other amplifier it can cause distortions
in signals if level is excessive or not arrive at
destination if it’s weak.
How to decide which is the suitable level is
complicated and should need right tools to exactly
measure what’s happening.
For a correct adjustment of this level consider the
following:
1st Function of remote control repeater must
perfectly work if line is direct from Multivision to remote room. If there are more
devices signal will be weaker (arriving to cancel the signal)
2nd It should not appear interferences in TV when this function is used.
Depending on adjusted level some horizontal lines could appear in the picture, in
this case adjust output level with a small screwdriver turning on the left the
adjusting potentiometer of infrared receiver IR 3 until they disappear but the
repeater is functioning.
Check that repeater works correctly with all remote controls that you are going to
use.
Anyway you must know that with factory default adjustment it should work without
problems if installation is conventional.
IR3

All rights reserved 18 © FTEmaximal
Usual operating Multivision
For the functioning of Multivision there are two possibilities:
The first and most convenient: to use remote control
Second is with buttons in the front panel
Your remote control...
… transmits necessary signals to make any combination of inputs and outputs in
the Multivision through infrared signals.
You must be sure that infrared sensor is free of obstacles and there is direct
vision between it and remote control.
Point the remote control to the sensor meanwhile the keys of inputs selection are
pressed.
Are the batteries empty?
Use alkaline batteries as they have longer life than normal ones. When replace
batteries change them all, don’t mix batteries with different charge.
Insert new batteries in the position showed in the drawing in remote control and
use always type AA LR6 1,5V.
Attention:
Exhausted batteries must be disposed in suitable container for its correct
recycling.

All rights reserved 19 © FTEmaximal
Multivision
The remote control
Selecting input signals...
It’s very simple.
All you have to do is to press the key of
Desired input belonging to the output
you wish to program. It’s easier than it
seems to be…
Upper keypad indicates output SCART (R7)
And lower keypad output modulator (R9).
Example 1: Pressing SAT in upper keypad
Signal coming from satellite receiver connected in SAT input (R4)
appears in output R7 that is connected to the main TV set.
LED in front panel F 7 lights in red colour.
Example 2: Pressing DVD in lower keypad
DVD signal is sent to the output R9 through the modulator (R 9) and from this
output through coax cable to remote rooms.
LED in front panel F 6 lights in green colour.
NOTE: When in both outputs is selected the same input, there is only one
LED lighting between F4 and F8 in ORANGE colour.
Selection buttons in front panel are:
Due to selection buttons in front panel are not separated for each output
programming procedure has two steps.
U
pp
er ke
yp
ad
Lower ke
yp
ad
F4 F5 F6 F7 F8 F9

All rights reserved 20 © FTEmaximal
Buttons on the front Multivision
First you have to select wich output is going to be programmed with key F9
(AV/RF):
LED lights in red if output is selected by SCART, if it is pressed color will change
into green and output will be programmed by modulator, selection is sequential
RED = SCART output
GREEN = Modulator output
Once output to be programmed is selected, press desired input between F4 and
F8.
Video Recording (VCR)
The scart marked as VCR is configurated in bidirectional mode, it means that has
input signals (generated by the video when is turned ON) and also output
connections to record in the video selected source to TV out. For example, if you
wish to record a program from satellite receiver you must select SAT input to
main TV and use right input channel in the video (LINE IN/AV etc.).
Attention:
Used scart-scart must have 21 pins connected and must not modify input source
selection meanwhile it is recording (in this case it would record another signal).
