3EN
Presentation
Thank you for purchasing FT Injectors. In this manual you will nd all the information you will need to ensure proper operation, conguration and
maintenance of your injectors.
The FT Injector is available ow rate: 170 lb/h
Each FT Injector is made with the best possible materials, including corrosion-resistant internals, allowing them to be used with any fuel from gasoline
to Nitromethane, Nitropropane and even fuels that contain MTBE and ETBE. Silver plated terminals ensure the best electrical connection possible
along with an EV1 style connector for positive locking and vibration resistance.
Warranty terms
The use of this equipment must be in complete compliance within the terms set out in this manual, failure to do so excludes the manufacturer from
all responsibility.
This product is not certied for aeronautic purposes or any ying vehicles, as it has not been designed for such applications.
Before starting any electrical installation, disconnect the battery.
This product is not certied for aeronautic purposes or any ying vehicles, as it has not been designed for such applications.
In some countries where an annual inspection of vehicles is enforced, no modication in the OEM ECU is permitted. Be informed about local laws and
regulations prior to the product installation.
Important warning for proper installation of this product:
Always remove and insulate unused wires. NEVER roll up excess wiring as this may create an antenna that
captures electromagnetic interference that may generate product malfunction.

4
EN
Limited warranty
This product warranty is limited to 90 days from the purchase date, only covering manufacturing defects and requiring purchase invoice presentation.
Any disassembly of the unit or removal or replacement of any internal component of the unit will void the product warranty and render the unit ineligible
for service.
Damage caused by disassembly or misuse of the unit will not be covered by the warranty. Warranty will be void unless repair is done exclusively by
FuelTech warranty department.
Manual Version 1.2 – June/2023
Characteristics
Compatible with any kind of fuel, including:
- Gasoline
- Ethanol
- Methanol
- Nitromethane
- Nitropropane
- MTBE/ETBE
Electrical specications
- High impedance
- Coil resistance: (8.2 - 8.1) Ohms
- Ingress protection Rating: IP67 / NEMA6

5EN
1
2
3
4
5
Dimensions mm (in)
1 - Overall height - 74 mm (2.91”)
2 - Overall width - 18 mm (0.71”)
3 - Top O-ring diameter - 14.58 mm (0.57”)
4 - Tip - 4.1 mm (0.16”)
5 - Bottom O-ring diameter - 12.83 mm (0.51”)
Installation
Electrical
- Pin 1: 12V to 24V switched power (never wire to constant power, this will damage the injector)
- Pin 2: ECU injector output (Blue outputs)
Electrical with Peak and Hold
Use the Peak and Hold is mandatory when to use injectors in gray and yellow outputs. In this case its necessary
to install a Peak and Hold 8A/2A. See Peak and Hold manual’s for more information.
Testing your injectors before rst startup
- Go to the outputs screen under the sensors and calibration menu in FTManager software
- Setup each injector output, write map to ECU
- Once the outputs are set, you can power the ECU up and click on the lightning bolt button near each injector output. The injectors will pulse when
the test button is pressed. Test each injector to ensure correct functionality, and to make sure they’re on the correct cylinder and rail according
to your selection.

6
EN
If your injectors are not working use the diagnostic
guide below
- Check all fuses related to injector power
- Check to make sure all relays related to injectors are energized
- Check for power at the injector connector with a voltmeter or
LED test light
- Check the injector output from your ECU with a noid light set or
LED test light
- Make sure either your peak and hold driver or jumper is plugged
in if using a FuelTech terminated harness
- Check for power and ground at your peak and hold module
Fuel injector installation
O-ring style injectors
a. Lube the upper and lower o ring with petroleum jelly or ATF
b. Press the bottom of the injector into your intake manifold injector
bung
c. Align all injectors and press the fuel rail onto the top of the injector
ensuring all of the o rings are intact and seated properly
IMPORTANT
Once installed, pressurize the system to inspect
for leaks before starting
NOTE
In some cases, it will be necessary to increase the diameter of the injector tting holes in the intake manifold.

7EN
10 Volts 11 Volts 12 Volts 13 Volts 14 Volts 15 Volts 16 Volts 18 Volts 20 Volts
0.510 0.270 0.160 0.000 -0.110 -0,270 -0,310 -0.325 -0.335
Conguration
Navigate to engine settings on the quick access panel.
a. Click Fuel injection
b. Enter your total ow by adding your injectors together
Example: 170lb/h x 4 cylinders = 680
c. Enter your primary injector dead time
Battery voltage compensation
Next step is on battery voltage compensation in fuel tables.

8
EN
Base fuel pressure (differential)
The recommended base fuel is 43.5PSI, this allows a better fuel atomization in the combustion chamber.
Execute the following steps to regulate it:
a. Disconnect the fuel regulator vacuum hose
b. Rev the engine up to 3000RPM steady
c. Regulate the base fuel pressure at 43.5PSI or desired pressure, making sure to have a stable number
IMPORTANT
It’s not recommended use more than 120PSI of differential fuel pressure, this will damage the injectors
Battery
voltage
(V)
Fuel pressure PSI - (BAR) - 170 lb/h
30 (2.1) 40 (2.8) 43.5 (3) 50 (3.4) 60 (4.1) 70 (4.8) 80 (5.5) 90 (6.2) 100 (6.9)
10 1.42 1.50 1.53 1.58 1.65 1.80 1.94 2.10 2.25
12 1.11 1.20 1.24 1.28 1.33 1.38 1.44 1.53 1.60
13 0.99 1.04 1.08 1.12 1.22 1.30 1.36 1.42 1.48
14 0.94 0.99 1.04 1.06 1.17 1.19 1.23 1.28 1.32
16 0.81 0.84 0.86 0.90 0.95 0.97 1.02 1.06 1.08
Injection time (ms)

9EN
Horsepower vs Injector size
170 lb/h Injectors
43.5 PSI fuelpressure differential (HP)
Power 4 injectors 6 injectors 8 injectors
Ethanol 639 957 1277
Gasoline 894 1341 1788
Methanol 426 639 851
Max ow vs Pressure
Injectors are a volume ow device, This means it ows a certain volume of uid through it at whatever differential pressure you currently have over a
certain amount of time.
Example: cc/min (Cubic Centimeters per minute) or GPM (gallons per minute)
However Injectors are often talked about and displayed in pounds per hour. In Order to accurately dene this you need to know the density of the uid
you intend on owing through them. Below is some simple math on how this is done.
First you must know the specic gravity of the uid you will be owing through your injector. And then you need to know how many grams are in 1
pound (453.592)
Example: 0.72 grams per cubic centimeter or 720 kilograms per cubic meter.
Now you multiply your cc/min ow rate by the specic gravity then divide it by how many grams are in one pound and multiply by 60 to convert from
minutes to hours. Here is how that would calculate out below: (1785cc/min × 0.72 ÷ 453.592) × 60 = 170.003 Pounds Per Hour
If you change to a uid with a different density you need to do the calculation with the specic gravity of that new uid.
Now that we know how it’s calculated, here are some of the more popular fuels used in the racing industry.

10
EN
PSI BAR cc/min GPM lb/h
30 2.1 1491 0.394 142.002
35 2.4 1617 0.427 154.003
40 2.8 1711 0.452 162.955
43.5 31785 0.472 170.003
45 3.1 1858 0.491 176.955
50 3.4 1932 0.510 184.003
55 3.8 2079 0.549 198.003
60 4.1 2142 0.566 204.003
65 4.5 2236 0.591 212.956
70 4.8 2331 0.616 222.004
75 5.1 2415 0.638 230.004
80 5.5 2499 0.660 238.004
85 5.8 2593 0.685 246.957
90 6.2 2656 0.702 252.957
FT Injector 170 lb/h using VP Q16
* Fluid Specic gravity (0.72 g/cm3)
PSI BAR cc/min GPM lb/h
30 2.1 1491 0.394 140.523
35 2.4 1617 0.427 152.398
40 2.8 1711 0.452 161.258
43.5 31785 0.472 168.232
45 3.1 1858 0.491 175.112
50 3.4 1932 0.510 182.086
55 3.8 2079 0.549 195.941
60 4.1 2142 0.566 201.878
65 4.5 2236 0.591 210.738
70 4.8 2331 0.616 219.691
75 5.1 2415 0.638 227.608
80 5.5 2499 0.660 235.525
85 5.8 2593 0.685 244.384
90 6.2 2656 0.702 250.322
FT Injector 170 lb/h using VP C23
* Fluid Specic gravity (0.7125 g/cm3)

11 EN
PSI BAR cc/min GPM lb/h
30 2.1 1491 0.394 144.961
35 2.4 1617 0.427 157.211
40 2.8 1711 0.452 166.350
43.5 31785 0.472 173.545
45 3.1 1858 0.491 180.642
50 3.4 1932 0.510 187.836
55 3.8 2079 0.549 202.128
60 4.1 2142 0.566 208.254
65 4.5 2236 0.591 217.393
70 4.8 2331 0.616 226.629
75 5.1 2415 0.638 234.796
80 5.5 2499 0.660 242.962
85 5.8 2593 0.685 252.101
90 6.2 2656 0.702 258.227
FT Injector 170 lb/h using VP C16
* Fluid Specic gravity (0.735 g/cm3)
PSI BAR cc/min GPM lb/h
30 2.1 1491 0.394 137.663
35 2.4 1617 0.427 149.297
40 2.8 1711 0.452 157.976
43.5 31785 0.472 164.808
45 3.1 1858 0.491 171.548
50 3.4 1932 0.510 178.381
55 3.8 2079 0.549 191.953
60 4.1 2142 0.566 197.770
65 4.5 2236 0.591 206.449
70 4.8 2331 0.616 215.220
75 5.1 2415 0.638 222.976
80 5.5 2499 0.660 230.732
85 5.8 2593 0.685 239.411
90 6.2 2656 0.702 245.227
FT Injector 170 lb/h using VP C25
* Fluid Specic gravity (0.698 g/cm3)

12
EN
PSI BAR cc/min GPM lb/h
30 2.1 1491 0.394 156.794
35 2.4 1617 0.427 170.045
40 2.8 1711 0.452 179.930
43.5 31785 0.472 187.711
45 3.1 1858 0.491 195.388
50 3.4 1932 0.510 203.170
55 3.8 2079 0.549 218.629
60 4.1 2142 0.566 225.254
65 4.5 2236 0.591 235.139
70 4.8 2331 0.616 245.129
75 5.1 2415 0.638 253.963
80 5.5 2499 0.660 262.796
85 5.8 2593 0.685 272.681
90 6.2 2656 0.702 279.306
FT Injector 170 lb/h using VP M1
* Fluid Specic gravity (0.795 g/cm3)
PSI BAR cc/min GPM lb/h
30 2.1 1491 0.394 156.597
35 2.4 1617 0.427 169.831
40 2.8 1711 0.452 179.703
43.5 31785 0.472 187.475
45 3.1 1858 0.491 195.142
50 3.4 1932 0.510 202.915
55 3.8 2079 0.549 218.354
60 4.1 2142 0.566 224.970
65 4.5 2236 0.591 234.843
70 4.8 2331 0.616 244.821
75 5.1 2415 0.638 253.643
80 5.5 2499 0.660 262.466
85 5.8 2593 0.685 272.338
90 6.2 2656 0.702 278.955
FT Injector 170 lb/h using VP C85
* Fluid Specic gravity (0.794 g/cm3)

13 EN
FT Injector 170 lb/h ow table
4450 RPM - Flow x Injection time (ms)
Ideal ow 0,00 10 20 30 40 50 60 70 80 90 100 140 170
Effective pulse width 0,00 1,625 3,25 4,875 6,375 8 9,625 11,25 12,75 14,375 16,000 22,374 26,875
Actual pulse width 0,00 2,475 4,164 5,789 7,289 8,914 10,539 12,164 13,664 15,289 16,914 23,289 26,969
Pulse addition 0,00 0,850 0,914 0,914 0,914 0,914 0,914 0,914 0,914 0,914 0,914 0,914 0,072
Flow without
correction 0,00 4,40 14,69 24,91 34,35 44,57 54,79 65,01 74,45 84,67 94,89 134,99 168,33
Flow with correction 0,00 10,22 20,44 30,66 40,10 50,32 60,54 70,76 80,20 90,42 100,64 140,74 170
* Minimum pulse width 1.5 ms
0,00
20,00
40,00
60,00
80,00
100,00
120,00
140,00
160,00
180,00
0
20
40
60
80
100
120
140
160
180
0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30
FT Injector 170 lb/h
Flow Ideal flow

14
EN
Fuel lter system with mechanical fuel pump
When using mechanical fuel pump, it is also necessary to install a 60-micron lter. Install the lter as close to the feed point of the injectors as possible.
7 - Fuel tank
8 - Fuel hose with minimum 11/4" thickness
9 - Mechanical fuel pump
10 - Fuel hose with minimum 12AN
11 - 60-micron fuel lter
Injector care and maintenance
Fuel lter requirements
FuelTech recommends a 60-micron lter after the fuel pump. Install the lter as close to the feed point of the injectors as possible.
1
4
3
25
7
8 9 10 11
1 - Fuel tank
2 - Fuel pump
3 - Fuel pump: 12V from relay (activated by ECU
output)
4 - Fuel pump: ground
5 - Fuel lter 60-micron

15 EN
Off season maintenance (Removing injectors)
If you will have the car sitting for more than 3 weeks without running, follow the instructions below:
a. Drain or seal your fuel system
b. Remove the injectors from the car
c. Pulse each injector continuously for 3 seconds, applying clean/dry compressed air (30 to 90 psi) into the fuel inlet portion of the injector. This
operation removes residual fuel from inside the injectors.
d. Store your injectors in a plastic sealable bag
If you do not use an oxygenated fuel simply seal your fuel system off by capping the breather and keep the fuel cell or tank lled to the top.
Do not attempt to disassemble the product or to remove or replace any of its components. Any attempt to do so could damage the product and will
void the product warranty. FuelTech will not service or replace any injector that has been opened or where attempts to open are visible. Failure to heed
any of the warnings or precautions described in this manual may cause engine damage and will void this product warranty.
Off season maintenance (without removing injectors)
If you will have the car sitting for more than 3 weeks without running, follow the instructions below:
a. Remove and drain the fuel rail
b. Turn on the ignition and go to the Outputs menu in the FTManager software, hold the “lightning bolt” test output feature button continuously for
3 seconds whilst applying clean/dry compressed air (30 to 90 psi) into the fuel inlet portion of the injector. This operation removes residual fuel
from inside the injectors.
c. Assemble the fuel rail. This procedure is necessary if the vehicle will be sitting for more than 3 weeks without running.
This procedure is necessary of the vehicle sitting for more than 3 weeks without running.
IMPORTANT
Do not disassemble the product or remove/replace any components. Doing so may damage the product and
will void the warranty.

16
PT
Apresentação
Obrigado por adquirir o FT Injector. Neste manual, você encontrará todas as informações necessárias para garantir a operação, conguração e
manutenção adequadas de seus injetores:
O FT Injector está disponível na versão de: 170 lb/h.
Cada FT Injector é feito com os melhores materiais possíveis, incluindo componentes internos resistentes à corrosão, permitindo que sejam usados
com qualquer combustível, desde gasolina, etanol a nitrometano, nitropropano e até mesmo combustíveis que contenham metanol e ETBE. Os
terminais banhados a prata garantem a melhor conexão elétrica possível, juntamente com um conector tipo EV1 e EV6 para travamento positivo e
resistência à vibração.
Termo de garantia
A utilização deste equipamento implica na total concordância com os termos descritos neste manual e exime o fabricante de qualquer responsabilidade
sobre a utilização incorreta do produto. Leia todo o Manual do produto antes de começar a instalação.
Este produto deve ser instalado e regulado apenas por ocinas especializadas ou pessoas capacitadas e que tenham experiência
com regulagem e preparação de motores.
O não cumprimento de qualquer um dos avisos e precauções descritos neste manual pode causar danos ao motor e perda da garantia deste produto.
Acerto incorreto do produto pode causar danos ao motor.
Antes de começar qualquer instalação elétrica desconecte a bateria.
Este equipamento não possui certicação para utilização em aeronaves ou assemelhados, portanto não é prevista para este m.

17 PT
AVISO IMPONTANTE PARA CORRETA INSTALAÇÃO
Sempre corte as sobras de o – NUNCA enrole o pedaço sobrando, pois isso se torna uma antena captadora de
interferências e pode gerar o mau funcionamento do equipamento.
Garantia limitada
A garantia deste produto é de 90 dias a partir da data da compra e cobre apenas defeitos de fabricação.
Qualquer desmontagem da unidade ou remoção ou substituição de componentes da unidade anulará a garantia do produto.
Defeitos e danos causados pela incorreta utilização do produto não são cobertos por garantia.
Manual versão 1.2 – Junho/2023
Características
Compatível com qualquer tipo de combustível, incluindo:
- Gasolina
- Etanol
- Metanol
- Nitrometano
- Nitropropano
- MTBE / ETBE
Especicações elétricas
- Alta Impedância
- Resistência da bobina: entre (8,2 - 8,1) Ohms
- Classicação de proteção de entrada: IP67 / NEMA6
IMPORTANTE
“Revisões e garantias dos injetores só podem ser executadas pela empresa MRB Injetores pelo contato
whatsapp : [phone].”

18
PT
Dimensões (mm)
1 - Altura (74 mm)
2 - Largura (18 mm)
3 - Diâmetro do O-ring superior (14,58 mm)
4 - Ponta (4,1 mm)
5 - Diâmetro do O-ring inferior (12,83 mm)
Instalação
Elétrica
- Pino 1: 12V a 24V (pós-chave nunca conecte alimentação direta, isso danicará o injetor.
- Pino 2: Saída de injeção da ECU
Testando seus injetores antes da primeira inicialização
- No software FTManager acesse “Sensores e calibração/Saídas”
- Congure cada saída do injetor e grave o mapa
- Após a saída denida, você pode ligar a ECU e clicar no botão com um desenho de raio próximo
a cada saída do injetor. O injetor acionará quando o botão de teste for pressionado. Teste cada
injetor para garantir a funcionalidade adequada e para certicar-se de que eles estão no cilindro
e bacada corretos de acordo com sua seleção.
1
2
3
4
5

19 PT
Para detectar problemas no injetor, use o guia de
diagnóstico abaixo
- Verifique se há energia no conector do injetor com um
multímetro ou luz de teste;
- Verique a saída de injeção da ECU com luz de teste
- Verique os relés e fusíveis relacionados aos injetores
Instalação do FT Injector
Injetores tipo O-ring
a. Lubrique o anel de vedação superior e inferior com vaselina
ou ATF
b. Pressione a parte inferior do injetor no coletor de admissão
c. Alinhe todos os injetores e pressione a auta de combustível
na parte superior do injetor garantindo que todos os anéis de
vedação estejam intactos e encaixados corretamente
IMPORTANTE
Uma vez instalado, pressurize o sistema para
inspecionar se há vazamentos antes de iniciar
NOTA
Em alguns casos será necessário aumentar o diâmetro dos furos de encaixe dos injectores no coletor de admissão.

20
PT
Conguração
Navegue até as congurações do motor no painel de acesso rápido.
a. Clique em injeção
b. Insira a vazão total da bancada, adicionando todos os injetores
juntos
Exemplo: 170 lb / h x 4 cilindros = 680
c. Insira o Dead time do injetor
Compensação de tensão da bateria
O próximo passo é a compensação da tensão da bateria no mapa
de injeção
10 Volts 11 Volts 12 Volts 13 Volts 14 Volts 15 Volts 16 Volts 18 Volts 20 Volts
0.510 0.270 0.160 0.000 -0.110 -0,270 -0,310 -0.325 -0.335
