Fujifilm Instax link wide User manual

User's Guide (Full version)

NA_EN

model number: FI022W

2

Table of Contents

Before Use��3

Notes on Disposing of the Printer�� 3

Part Names��3

Attaching the Strap��4

Placing on the Stand��4

Installing the INSTAX LINK WIDE Smartphone App ��4

Charging the Battery ��4

Charging status indication with the LED��4

Loading/Unloading the INSTAX WIDE™ Instant Film

Pack ��5

Loading the Film Pack��5

Unloading a Used Film Pack ��5

Turning on/off the Printer��6

Checking the Printer Status with the LED��6

Connecting Your Smartphone and Printer Together and

Printing��6

When Establishing Connection for the First Time ��6

When the Printer and Your Smartphone Are Already

Connected��9

Specifications ��10

Troubleshooting ��10

IMPORTANT SAFETY NOTICE��11

Common Sense Printer Care�� 11

Bluetooth® Devices: Cautions�� 12

3

Before Use

Before using the printer, check the following.

Supplied Accessories

• Micro USB cable for charging

(1)

(BOD700-101)

• User's Guide (1)

• Limited Product Warranty (1)

• Stand (1)

• Strap (1)

The battery has not been fully charged at the factory. Be sure

to charge the battery before using the printer.

Notes on Disposing of the Printer

A built-in lithium ion battery is used for this printer�

When you dispose of the printer, follow your local regulations and

dispose of it properly.

For proper disposal in the United States at product end-of-life,

please contact 1-800-800-3854 Option #1 INSTAX.

For proper disposal in Canada at product end-of-life, please

contact 1-800-461-0416.

Do not attempt to remove the built-in battery. Injury may result.

Read “IMPORTANT SAFETY NOTICE”(Page 11 ) for safety use.

Part Names

Before using the printer for the first time, be sure to fully charge

the battery.

Front

3

2

1

4 5

Rear

67

1 Film ejection slot

2 Power button/LED1

3 Strap holes

4 Reset button2

5 Micro USB port

6 Film door lock

7 Film door

1For details on LED indication status, see pages 4 and 6.

2If the printer does not work properly, press the reset button to

reset the printer.

4

Attaching the Strap

Attach the strap as illustrated below.

Be sure the strap does not obstruct the film ejection slot.

Placing on the Stand

The printer can be placed on the stand. When using the stand with

the printer, be sure the film ejection slot is facing up.

Installing the INSTAX LINK WIDE Smartphone

App

Please install the free INSTAX LINK WIDE Smartphone App on your

Smartphone before using the printer. This is required for use of all

available product features.

• If you are using an Android OS Smartphone, please search for

the INSTAX LINK WIDE Smartphone App in the Google Play Store

and install it.

*Requirements for Android OS Smartphones: Android Ver. 5.0

or higher with Google Play Store installed

• If you are using an iOS Smartphone, please search for the

INSTAX LINK WIDE Smartphone App in the App Store and install it.

*Requirements for iOS Smartphones: iOS Ver. 10.0 or higher

• Depending on your Smartphone model, you may not be able to

use the INSTAX LINK WIDE Smartphone App even if you have

installed it and your Smartphone meets the above

requirements.

Access the INSTAX LINK WIDE App download site by scanning

the below QR codes for the latest information on system

requirements�

Android OSiOS

Charging the Battery

Be sure to properly attach the Micro USB cable as indicated.

Note that USB AC adapter is not included,

but is typically provided with your

Smartphone or otherwise purchased

separately.

To an indoor

power outlet

Connect the printer with a USB AC adapter (not included with

INSTAX LINK WIDE printer) using the supplied Micro USB cable,

then connect the USB AC adapter to an indoor power outlet.

• You can print an image while charging is in progress.

• Charging time is approximately 80 to 120 minutes.

Charging status indication with the LED

Indication Charging status

LED lights up in white Not charging

LED flashes in white Charging

Check the charging status with your Smartphone when connected

with the free INSTAX LINK WIDE App.

For instructions on how to download the App, please see the

Installing the INSTAX LINK WIDE Smartphone App section on this

page.

* When the printer is turned off, the LED goes off after the

charging is completed. When the printer is turned on and not

connected with the App, the LED lights up in white after the

charging is completed.

Charging from a PC:

• Connect the printer and PC directly using the supplied Micro

USB cable. Insert the Micro USB cable into the Micro USB port

of the printer and the USB port of the PC. Do not connect via

a Micro USB hub or keyboard.

• If the PC goes into sleep mode while charging, charging is

discontinued. To continue charging, exit sleep mode and then

reconnect the Micro USB cable.

• The battery may not be able to charge depending on the

specifications and settings or conditions of the PC .

Notes

• The battery has not been fully charged at the factory. Be sure

to charge the battery before using the printer.

• The battery cannot be removed.

• For notes about the battery, see“Common Sense Printer Care”.

(p.11)

5

Loading/Unloading the INSTAX WIDE™

Instant Film Pack

Caution

Do not open the film door until you have used up the film;

otherwise, the rest of the film will become exposed and turn

white� The film can no longer be used�

• When you load the film pack, never press the two rectangular

holes on the back of the film pack.

• Never use a film pack beyond its shelf life; otherwise, it may

damage the printer.

Use FUJIFILM INSTAX WIDE instant print film only. The

INSTAX SQUARE™ or INSTAX MINI™ instant print film cannot be

used.

Notes on the INSTAX WIDE instant film pack

• Each FUJIFILM INSTAX WIDE instant film pack contains one

black film protective cover and 10 film sheets.

• Do not remove the film pack from its inner bag until you are

ready to load it into the printer.

• The film cover is ejected automatically from the printer after

you close the film door.

For details, refer to the instructions and warnings on the

package of FUJIFILM INSTAX WIDE instant print film.

Loading the Film Pack

1 Slide and hold the film door lock and open the film

door.

2 Insert film pack by aligning the yellow marks�

3 Close the film door�

4 Remove the black film cover that is automatically

ejected�

The INSTAX LINK WIDE Smartphone printer is designed for use

with INSTAX WIDE instant print film only.

Unloading a Used Film Pack

1 Slide the film door lock and open the film door�

2 Grasp the rectangular holes on the film pack, then

pull film pack out from the printer�

6

Turning on/off the Printer

Press and hold the Power button for approximately 1 second to

turn the printer on or off.

Turning the printer on lights up the LED.

If no operation occurs for a certain period of time, the printer turns

off automatically.

Checking the Printer Status with the LED

You can check the printer status with the LED.

Color LED status Status

Blue Flashing Firmware is being updated

Yellow Lights Up Cannot be charged

Film ejection error occurred

Yellow Flashing Attempted to print images

when the film door was

being opened

Low battery state

Connecting Your Smartphone and Printer

Together and Printing

With the functions of the IINSTAX WIDE Smartphone App, you can

edit your favorite smartphone images before printing by adding

text, applying filters, and much more! See Page 4 on how to install

the Instax Wide Smartphone App or check out the following site:

https://instax.com/link_wide/

When Establishing Connection for the First Time

1 Press and hold the Power button for approximately

1 second to turn the printer on�

The LED lights up.

2 Start the downloaded INSTAX LINK WIDE

Smartphone App�

3 Click through the below pop-up windows to set up

the printer�

7

4 Read the Terms of Use, check the [Agree] box and

tap the [AGREE] bar�

5 Quick instructions are displayed� Read the

instructions and tap [Let’s Play! →]�

6 Set up the Bluetooth connection between your

Smartphone and the printer�

[Bluetooth connection] can also be set in the process of

printing.

7 When a printer is detected, tap [Connect]�

If multiple printers are detected, select the printer you

would like to connect to from the list.

Locate the printer’s identifier (device name) on the bottom

of the printer.

Make sure the printer is on during this step. If not, turn the

printer on by pressing and holding the Power button for 1

second.

Note

If your Bluetooth settings are switched off, the following

screen appears.

Tapping [Please turn on Bluetooth] opens the Bluetooth

settings screen. Put the Bluetooth settings on.

8

11 Tap or swipe the image up on the screen to print

your image�

The printer starts printing.

You can also select the number of images to print during

image transfer.

12 When the film has been ejected (the printer stops

making a sound), hold the edge of the film, then

take it out�

Confirm the number of images remaining in your INSTAX

WIDE instant film pack on the Smartphone screen.

8 When the message is displayed, check the box and

tap [PAIR]�

9 When a printer is connected, tap [Close]�

10 To select an image to print, click the Simple Print

button on the INSTAX LINK WIDE Smartphone App

home screen and select an image from your photo

roll�

To edit your image, click on the below editing options on

the bottom of the screen before printing�

Enters text on images.

Zooms up/down or rotates images.

Applies a filter on images.

Adjusts the brightness of images.

9

When the Printer and Your Smartphone Are Already

Connected

1 Press and hold the Power button for approximately

1 second to turn the printer on�

The LED lights up.

2 Start the downloaded INSTAX LINK WIDE

Smartphone App�

3 To select an image to print, click the Simple Print

button on the INSTAX LINK WIDE Smartphone App

home screen and select an image from your photo

roll�

To edit your image, click on the below editing options on

the bottom of the screen before printing�

Enters text on images.

Zooms up/down or rotates images.

Applies a filter on images.

Adjusts the brightness of images.

4 Tap or swipe the image up on the screen to print

your image�

The printer starts printing.

You can also select the number of images to print during

image transfer.

5 When the film has been ejected (the printer stops

making a sound), hold the edge of the film, then

take it out�

Confirm the number of images remaining in your INSTAX

WIDE instant film pack on the Smartphone screen.

10

Troubleshooting

Please check the following items before considering a problem to

be a malfunction. If the problem persists even after taking action,

please contact the Fujifilm service center for repair in your country

or visit the website below.

Fujifilm website: http://www.fujifilm.com/

If the following problem occurs��

Problem Possible causes and solutions

I cannot turn on

the printer.

• The battery may not be charged. Please

charge the printer.

• You did not press the Power button long

enough. Press and hold the Power button

for approximately 1 second.

The battery

loses its charge

quickly.

If you use the printer in a very cold

environment, the battery will drain quickly.

Please keep the printer warm before

printing.

The power cut

off during use.

The battery level may be low. Please charge

the printer.

Charging does

not start.

Make sure that the USB power adapter plug

is properly connected to the power outlet.

It takes too long

to charge.

At low temperatures, charging may take

some time.

Charging stops

during charging.

Charge the battery in a temperature range of

5°C to 40°C (41°F to 104°F). If you cannot

charge the printer in this range, contact your

FUJIFILM dealer or support center.

The printer does

not work

properly.

• There may be a temporary malfunction.

Please press the reset button. If it still does

not work properly, please contact our

repair service center for repair.

• The battery may not be charged. Please

charge the printer.

The film pack

does not load or

does not load

smoothly.

• Please use FUJIFILM INSTAX WIDE instant

print film only (INSTAX SQUARE or INSTAX

MINI instant print film cannot be used).

• Align the yellow mark on the film pack

with the printer alignment mark (yellow)

and load it.

The film does

not unload.

• The film may be misaligned due to shock

such as vibration or dropping. Please load

a new film pack.

• If the film is jammed, turn the printer off

and turn it on again. If the problem

persists, remove the jammed film and

then load a new film pack.

Some or all of

the finished

prints are white.

Do not open the film door until the film is

used up. If the film door is opened with film

remaining, the film is exposed and the

exposed area becomes white.

The print is

uneven.

• Do not shake, bend, fold or hold the print

immediately after it is printed.

• Do not obstruct the film ejection slot.

Specifications

Recording method 3-color exposure with OLED

Film used FUJIFILM INSTAX WIDE instant film (sold

separately)

Number of images 10 images/film pack

Image size 62 mm × 99 mm/2.4 in. × 3.9 in.

Supported image

size

800 × 1260 dots

Printing resolution 12.5 dots/mm (318 dpi, 80 μm dot pitch)

Printing levels 256 levels per color (RGB)

Interface Standard compliance: Bluetooth Ver. 4.2

(BLE)

Supported image

format

JPEG, PNG, HEIF, DNG

Printing time Image recording - photo output (fed out):

Approximately 12 sec.

Approximate

printing capacity

Approximately 100 prints (from full

charge)

* The number of prints depends on the

usage conditions.

Power supply Lithium ion battery (internal type: not

removable)

Charging time Approximately 80 to 120 minutes

(Charging time depends on the

temperature and battery remaining level)

Power consumption Approximately 3 W

Operating

environment

Temperature: +5ºC to +40ºC (+41ºF to

+104ºF)

Humidity: 20% to 80% (no condensation)

Main unit

dimensions

139 mm × 127.5 mm × 33.7 mm/5.5 in. ×

5 in. × 1.3 in.(excluding projecting parts)

Main unit weight Approximately 340 g/12 oz (excluding

film pack)

Supplied

accessories

Micro USB cable (BOD700-101, Length:

30 cm/11.8 in.)

Stand (1)

Strap (1)

*The above specifications are subject to change.

11

Common Sense Printer Care

■Handling the Printer and Battery

• CAUTION - Do not expose to excessive heat such as sunshine,

fire or the like, that can result in an explosion or the leakage of

flammable liquid or gas during use, storage or transportation or

disposal.

• CAUTION - Do not dispose of a battery into fire or a hot oven, or

mechanically crush or cut a battery, that can result in an

explosion.

• CAUTION - Do not subject to extremely low air pressure at high

altitude that may result in an explosion or the leakage of

flammable liquid or gas.

■Printer Care

1. Do not open the film door until you have used up the film;

otherwise, the rest of the film is exposed and turns white�

The film can no longer be used�

2. Your printer is a precision instrument. Do not get it wet or drop

it. Also, do not expose it to sand, dust or dirt.

3. Do not use cleaning products or solvents such as those with

bleach or alcohol to remove dirt.

4. Keep the film chamber and printer interior clean to avoid

damaging the film.

5. In hot weather, do not leave your printer in hot places such as

in a car or on the beach. Do not leave it in damp places or

places where weather exposure could result.

6. Moth repellent gas such as naphthalene may affect your

printer and prints. Store your printer and photo prints in a

place where exposure to harmful cleaning or other household

elements will be avoided.

7. Note that the temperature range within which your printer can

be used is 5°C to 40°C (41°F to 104°F).

8. Take great care to ensure that your prints do not violate

copyright, image rights, privacy or other personal rights and

do not offend public decency. Actions that violate the rights of

others, are contrary to public decency or constitute a nuisance

may be punishable by law or otherwise legally actionable.

9. This printer is designed for household use. It is not suitable for

commercial printing which requires a large amount of printing.

■Charging the Battery

The battery is not charged at shipment� Charge the battery

completely before use�

Charge the battery using the supplied Micro USB cable.

Charging times will increase at ambient temperatures below

10°C (50°F) or above 35°C (95°F). Do not attempt to charge

the

battery in environments with temperatures above 40

°C (104°F);

at temperatures below 5°C (41°F), the battery will not charge.

■Battery Life

At normal temperatures, the battery can be recharged about

300 times. A noticeable decrease in the length of time the

battery will hold a charge indicates that it has reached the end

of its service life.

■Caution: Handling the Battery

The battery and printer body may become warm to the touch

after extended use. This is normal.

IMPORTANT SAFETY NOTICE

This product has been designed with safety in mind, and to

provide safe service when handled correctly and in accordance

with the instructions in this User’s Guide� It is important that

both the product and the INSTAX WIDE instant film pack are

handled properly and used only to print photos as instructed in

this User’s Guide and in the INSTAX WIDE instant film pack

instructions� For your ease and safety, strictly follow the

instructions in this User’s Guide� Keep this User’s Guide in a safe,

convenient place for easy future reference as needed�

WARNING

This symbol indicates danger, which could result in product

damage, injury or death. Follow the instructions indicated to avoid

damage to the printer or injury.

WARNING

If one of the following cases occur, immediately unplug the

Micro USB cable, turn the printer off and refrain from any

further use of the printer:

• The printer becomes hot, emits smoke, has a burnt smell, or

otherwise seems abnormal�

• The printer is dropped into water, or foreign objects like

water, sand, dirt or metal get inside the printer�

The printer has a built-in battery� Do not subject it to heat,

expose it to an open flame, drop it, or otherwise apply impact

to it� Doing so may cause the printer to explode, resulting in

injury�

WARNING

Never attempt to take this product apart� You may be injured�

All repairs should be handled solely by Fujifilm� Injury may

result from attempts to self-assess or repair this printer�

If this product is dropped or damaged so that the inside is

showing, do not touch it� Contact Fujifilm�

Do not touch any parts which are inside the film door� You may

be injured�

Never get this product wet or handle it with wet hands� Doing

so may result in electric shock and injury�

Promptly unplug the Micro USB cable once battery is fully

charged�

Keep out of the reach of small children� This product could

cause injury in the hands of a child�

Do not cover or wrap the printer or the AC power adapter in a

cloth or blanket, or otherwise place the printer in the sun or

an environment where heat may build up� This could distort

the casing or cause a fire�

The “CE” mark certifies that this product satisfies the

requirements of the EU (European Union) regarding

safety, public health, environment and consumer

protection. (“CE”is the abbreviation of Conformité

Européenne.)

12

■Certification marks acquired by the printer are located inside

the film chamber�

■Cautions During Printing

Do not shake the

printer while

printing.

Do not drop the

printer while

printing.

Do not cover the

film ejection slot

while printing.

■INSTAX WIDE Instant Film and Print Care

See FUJIFILM INSTAX WIDE instant film pack use instructions.

Follow all instructions for safe and proper use.

1. Keep the film in a cool place. Do not leave the film in a place

where the temperature is extremely high (e.g., in a closed car)

for many hours.

2. Do not puncture, tear, or cut INSTAX WIDE instant film. If film

becomes damaged, do not use.

3. When you load a film pack, use the film as soon as possible.

4. If the film has been kept in a place where the temperature is

extremely high or low, bring it to room temperature before

loading or starting to print photos.

5. Be sure to use the film before the expiration or“Use Before”date.

6. Avoid airport checked luggage inspection and other strong

X-ray illumination. The effect of fogging, etc. may appear on

unused film. Carrying your printer and film onto an aircraft in

your carry-on luggage is recommended. (Check with each

airport for more information.)

7. Avoid strong light, and keep the developed prints in a cool and

dry place.

8. Do not puncture or cut this film as it contains a small amount

of caustic paste (high alkaline). Never let children or animals

put the film into their mouth. Also pay attention so that the

paste does not come into contact with skin or clothes.

9. If the paste inside the film comes into contact with skin or

clothes, immediately wash off with plenty of water. If the paste

comes into contact with the eyes or mouth, immediately wash

the area with plenty of water and contact a doctor. Note that

the alkaline inside the film remains active for about 10 minutes

after the photo has been printed.

■Cautions on Handling the Film and Prints

See below for film activities to be avoided.

Bluetooth® Devices: Cautions

IMPORTANT: Read the following notices before using the

product’s built-in Bluetooth transmitter�

■Use only as part of a Bluetooth network�

FUJIFILM Corporation and its affiliates do not accept liability for

damages resulting from unauthorized use. Do not use in

applications requiring a high degree of reliability, for example in

medical devices or other systems that may directly or indirectly

impact human life. When using the device in computer and other

systems that demand a greater degree of reliability than Bluetooth

networks, be sure to take all necessary precautions to ensure

safety and prevent malfunction.

■Use only in the country in which the device was purchased�

This device conforms to regulations governing Bluetooth devices

in the country in which it was purchased. Observe all location

regulations when using the device. FUJIFILM Corporation and its

affiliates do not accept liability for problems arising from use in

other jurisdictions.

■Wireless data (images) may be intercepted by third parties�

The security of data transmitted over wireless networks is not

guaranteed.

Do not use the device in locations subject to magnetic fields, static

electricity, or radio interference.

■Do not use the transmitter in the vicinity of microwave ovens

or in other locations subject to magnetic fields, static

electricity, or radio interference that may prevent reception of

wireless signals� Mutual interference may occur when the

transmitter is used in the vicinity of other wireless devices

operating in the 2�4 GHz band�

■The Bluetooth transmitter operates in the 2�4 GHz band� The

standard output is approximately 3�16 mW�

■This device operates on the same frequency as commercial,

educational, and medical devices and wireless transmitters�

It also operates on the same frequency as licensed transmitters

and special unlicensed low-voltage transmitters used in radio-

frequency identification tracking systems for assembly lines and in

other similar applications.

13

■To prevent interference with the above devices, observe the

following precautions�

Confirm that the radio-frequency identification transmitter is not

in operation before using this device. If you notice that this device

causes interference in low-voltage radio-frequency identification

tracing systems, contact a Fujifilm representative.

■The following may be punishable by law:

– Disassembly or modification of this device.

– Removal of device certification labels.

■Trademark Information

The Bluetooth® word mark and logos are registered trademarks

owned by the Bluetooth SIG, Inc., and any use of such marks by

Fujifilm is under license.

For customers in the USA:

Contains IC : 7736B-03000007

Contains FCC ID : W2Z-03000008

FCC Statement

This device complies with part 15 of the FCC Rules. Operation is

subject to the following two conditions: (1) This device may not

cause harmful interference, and (2) this device must accept any

interference received, including interference that may cause

undesired operation.

For more information, access the website below.

https://www.fujifilm.com/products/instant_photo/printers/

instax_link_wide/

CAUTION

This equipment has been tested and found to comply with the

limits for a Class B digital device, pursuant to Part 15 of the FCC

Rules. These limits are designed to provide reasonable protection

against harmful interference in a residential installation. This

equipment generates, uses, and can radiate radio frequency

energy and, if not installed and used in accordance with the

instructions, may cause harmful interference to radio

communications. However, there is no guarantee that interference

will not occur in a particular installation. If this equipment does

cause harmful interference to radio or television, which can be

determined by turning the equipment off and on, the user is

encouraged to try to correct the interference by one or more of

the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from

that to which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

Changes or modifications not expressly approved by Fujifilm

responsible for compliance could void the user’s authority to

operate the equipment.

This transmitter must not be co-located or operated in conjunction

with any other antenna or transmitter.

The available scientific evidence does not show that any health

problems are associated with using low power wireless devices.

There is no proof, however, that these low power wireless devices

are absolutely safe. Low power wireless devices emit low levels of

radio frequency energy (RF) in the microwave range while being

used. Whereas high levels of RF can produce health effects (by

heating tissue), exposure of low-level RF that does not produce

heating effects causes no known adverse health effects. Many

studies of low-level RF exposures have not found any biological

effects. Some studies have suggested that some biological effects

might occur, but such findings have not been confirmed by

additional research. This device has been tested and found to

comply with FCC radiation exposure limits set forth for an

uncontrolled environment and meets the FCC radio frequency (RF)

Exposure Guidelines.

Notes on the Grant

To comply with Part 15 of the FCC Rules, this product must be used

with a Fujifilm-specified Micro USB cable.

For customers in Canada :

CAN ICES-3 (B)/NMB-3 (B)

This device contains licence-exempt transmitter(s)/receiver(s) that

comply with Innovation, Science and Economic Development

Canada’s licence-exempt RSS(s). Operation is subject to the

following two conditions:

1. This device may not cause interference.

2. This device must accept any interference, including

interference that may cause undesired operation of the device.
