Owner’s Manual
CERTIFIED PHOTOFINISHING SERVICE
●Have your film processed by a Photo Finisher which displays the above sign.
●Different Photo Finishers may provide different services.
Consult them for details of their services.
The “CE” mark certifies that this product satisfies the require-
ments of the EU (European Union) regarding safety, public
health, environment and consumer protection. (“CE” is the
abbreviation of Conformite Euroeepnne.)
This product conforms with Directive 89/336/EEC.

2
CONTENTS
FEATURES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
PART NAMES . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
ATTACHING THE STRAP . . . . . . . . . . . . . . . . . . . . 4
LOADING THE BATTERY . . . . . . . . . . . . . . . . . . . . 4
SETTING THE DATE . . . . . . . . . . . . . . . . . . . . . . . . 6
SELECTING THE DATE MODE . . . . . . . . . . . . . . . . 7
TURNING THE POWER ON/OFF . . . . . . . . . . . . . . 9
LOADING THE FILM CARTRIDGE . . . . . . . . . . . . . 10
SELECTING THE PRINT FORMAT . . . . . . . . . . . . . 12
TAKING PICTURES . . . . . . . . . . . . . . . . . . . . . . . . . 14
USING THE AUTO-FOCUS LOCK . . . . . . . . . . . . . 17
UNLOADING THE FILM CARTRIDGE . . . . . . . . . . . 18
FILM CARTRIDGE MID-ROLL CHANGE
FUNCTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
SELECTING THE EXPOSURE MODE . . . . . . . . . . 23
SELECTING SELF-TIMER MODE . . . . . . . . . . . . . . 27
ERRORS, POSSIBLE CAUSES, AND
REMEDIES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . 30
CAMERA CARE AND CAUTIONS . . . . . . . . . . . . . . 31
FEATURES
Thank you for purchasing our product. Read and under-
stand the following manual to insure correct use.
■Auto Focus 23–69mm Zoom
■Simple and error-free Drop-In Loading
■Mid-Roll Change
■3 Selectable Print Formats
■Print Quality Enhancement Through Information
Exchange System
■Auto Flash
■Automatic Film Advance and Rewind
■Auto Focus
■Auto Exposure
■Film Safety Lock
■Date or Time Printing Capability

3
PART NAMES
!9
@0
@1
@2
@3
@4
@5
@6
@7
@8
@9
#0
#1
#2
q
w
e
r
t
y
u
i
o!8
!0
!1
!2
!3
!4
!5
!6
!7
qAE Window
wFlash
eViewfinder Window
rAF (Auto focus) Light Emitter Window
tRed-eye Reduction/Self-timer Lamp
yFujinon Lens
uAF (Auto focus) Light Sensor Window
iSlide Cover
oShutter Release Button
!0 Viewfinder Eye-piece
!1 AF Lamp (green)
!2 Format Selector
!3 Zoom Lever
!4 Strap Lug
!5 Film Cartridge Compartment Cover Release Knob
!6 Battery Compartment Cover
!7 Film Cartridge Compartment Cover
!8 Tripod Socket
Liquid Crystal Display
!9 Self-timer Mode Sign
@0 Landscape Mode Sign
@1 Back Light Compensation/Flash Off Mode Sign
@2 Red-eye Reduction Flash Mode Sign
@3 Date Display (Type of Film Cartridge/Camera ISO
Display)
@4 Liquid Crystal Display (LCD)
@5 MRC Button (Mid-Roll Change Button)
@6 Film Cartridge Mark
@7 Battery Capacity Sign
@8 Exposure Counter
@9 SET (Date Set) Button
#0 SEL. (Date Select) Button
#1 MODE Button
#2 DATE Button
(Refer to the illustrations while you read this manual)

4
Fig. 1
Fig. 2
Attach the strap as illustrated.
✻When using a commercial strap, check the
strength and other properties of the strap.
Because straps for cellular telephones, PHS, etc.
are for light devices, be especially careful when
using them.
Lithium battery to be used: CR123A/DL 123A or
equivalent (one)
Open the Battery Compartment and insert (one) 3V
Lithium battery.
✻Be sure to reset the date when replacing battery.
✻Do not load the cartridge before inserting the bat-
tery.
✻One lithium battery has enough power for taking
approximately 300 shots (Based on our test condi-
tions). If multiple rolls of film are being used such
as for vacation or traveling where batteries may
be difficult to obtain, it is advisable to carry a
spare.
ATTACHING THE STRAP
LOADING THE BATTERY

5
✻When inserting battery, lens may move if camera
is in the on position. This is a normal occurrence,
not a problem.
Once the power is on, you can check the battery
capacity display on the LCD.
qon : Battery capacity is insufficient; provide a
new battery.
wblink: Shutter release will not trip because the
battery has no charge; change the battery.
Fig. 3
q
w

6
qPress the DATE Button for more than 2 seconds, until the year number blinks.
wPress the SET Button and adjust the numbers that blink.
ePress the SEL. Button to select the position of the blinking sign year →month →day →
hour →minute order, and adjust each figure using the SET Button.
Adjustable items are as follows.
Year : ’99 - ’30 (1999 - 2030)
Month : 1 - 12 Day : 1 - 31
Hour : 0 - 23 Minute : 00 - 59
rAfter adjusting the year →month →day →hour →minute, press the DATE Button.
✻The year, month, and day change together with the hour and minute.
✻To set the hour or minute by radio, press the DATE Button when the time signal announces
zero.
Fig. 4
SETTING THE DATE
(YEAR : MONTH : DAY/HOUR : MINUTE)

7
With the Advanced Photo System
The date (year:month:day / hour:minute) can be
printed on the front and back of the print. Front
printing can be seen when inserted in an album and
back printing is convenient for cataloging.
✻Changes, such as eliminating the date, are possi-
ble when reprinting (Some photo-finishers may
not support this feature).
✻With some backgrounds, the date display on the
front may be difficult to see.
Fig. 5
SELECTING THE DATE MODE

8
Each time the DATE Button is pressed, the date for-
mat changes in sequence.
A Year-Month-Day
B Month-Day-Year
C Day-Month-Year
D Hour-Minute
E No print
The indicated mode is recorded when the picture is
taken, and printed on the front and back of the print
when printed.
✻Some Print Service shops may not support Front
printing.
✻Nothing will be printed on the print when the “- - -”
mark is displayed.
Fig. 6
ABC
ED

9
When the slide cover is opened by sliding it fully in
the arrow direction, the power is turned on, the flash
lamp pops up, the lens advances, and the camera
enters the "Ready-to-Shoot" state. When the slide
cover is closed, the power is turned off.
✻When turning on the power, do not press the lens
with your finger. The camera may malfunction.
✻If the camera is not operated in the “Shoot” state
for 5 minutes, the power is automatically turned
off. If the slide cover is closed, then reopened in
this state, the camera will be set to the “Ready-to-
Shoot” state.
✻When the power is turned off, all functions are
canceled except Red-eye reduction modes.
Fig. 7
TURNING THE POWER ON/OFF

10
With the Advanced Photo System
IX240 Cartridge film is used.
✻Do not load the cartridge before inserting the bat-
tery.
✻Confirm that the iand jsigns on the film car-
tridge are white. Cartridges in which the kand
lsigns are white cannot be used. (Optical
Double Exposure Prevention.)
(1 unexposed 2 partial 3 exposed 4 processed)
After closing the slide cover, (q)move the Film
Cartridge Compartment Cover Release Knob in the
arrow direction, open the Film Cartridge
Compartment Cover.
Fig. 8
Fig. 9
1
2
3
4
q
LOADING THE FILM CARTRIDGE

11
(w) Turn the camera over and drop in the film car-
tridge.
(e) Close the Film Cartridge Compartment Cover.
✻Do not apply unnecessary force to the Film
Cartridge Compartment Cover.
When the Film Cartridge Compartment Cover is
closed, the film is automatically advanced and “H”
is displayed on the LCD. While the film is being
advanced to the first frame, the film type and speed
are displayed.
(A: Type of Film Cartridge)
(B: Film speed)
Type of Film Cartridge
Fig. 10
Fig. 11
e
AB
w
Color Negative Positive Black and White Other
No display mno

12
With the Advanced Photo System
The style of print required can be selected from
amongst C, H and P. Use the Format Selector to
select the required print style.
✻The print format can also be changed when mak-
ing reprints, however the field of view remains the
same.
AC Print (2:3)
BH Print (9:16)
CP Print (1:3)
( ) represents the aspect ratio.
( A : Parallax correction mark)
Fig. 12
Fig. 13
A
SELECTING THE PRINT FORMAT
ABC

13
A: Viewfinder
B: Print finishing
●With taking close-up picture
When pictures are taken at distances closer than
about 1.5m, the information within the range
shown above is not printed.
✻When taking close ups, the area seen through the
viewfinder and the area actually photographed
will be different. (Because the viewfinder and the
lens are in different locations.) The parallax cor-
rection mark is the criteria for the difference
between the area seen through the viewfinder
and the area actually photographed.
( A : Parallax correction mark)
No matter what print format of the C/H/P was select-
ed, the size of the photograph on the film may be
the same(16.7 x 30.2mm). Depending on the print
format selected during printing, the image (image of
size in table) photographed within the area above
may be printed.
Fig. 14
Fig. 15
H&P
H&C P
C
A
AB
CHP
about 16 x 23 mm about 16 x 28 mm about 10 x 28 mm

14
Hold the camera firmly with both hands.
When holding vertically, keep the flash lamp upward.
✻Be careful not to block the camera lens, flash and
AE and AF Windows with your finger or strap.
The subject will not be focused correctly.
If you want to increase the size of the subject, slide
the zoom lever to the right sfor a telephoto shot. If
you want a wider field of view, slide the zoom lever
to the left tfor a wide-angle shot.
Fig. 16
Fig. 17
TAKING PICTURES

15
Aim at the subject so that it fills the whole AF frame.
( A : AF (Autofocus) frame)
When the shutter release button is pressed halfway
and the AF lamp (green) turns on, focusing is com-
plete. When the shutter trips, the flash fires and the
film advances to the next frame.
✻While the shutter release button is pressed
halfway, the film speed and type of film is indicat-
ed in the LCD.
✻When the camera is brought within about 1m of
the subject, the AF lamp will blink to warn you that
the subject is not focused. If the camera is
brought about 30cm closer to the subject, the sub-
ject cannot be focused even if the AF lamp may
light.
✻During the charging time of the flash, the shutter
cannot be released.
Fig. 18
Fig. 19
A

16
●In dark places, photos should be taken within the follow-
ing flash lamp ranges.
Effective Flash Lamp Ranges
●In the following cases, the camera may not be able to focus
on the subject. Such subjects must be shot using the “Auto-
Focus” lock or “Landscape Mode”. (refer to Fig. 20-22 and
32)
qA bright light source such as the sun is near the subject or
there is reflected light (from the windscreen of a vehicle,
waves, etc.) near the subject.
wA mirror or light-reflecting surfaces such as metals are near
the center of the picture.
eWhen shooting black light-absorbing subjects such as hair.
rThere are gaseous substances such as flame or smoke.
tTaking pictures through glass.
(Using color negative film; units; m)
Film speed
Wide angle (23mm) Telephoto (69mm)
ISO 100 1.0 - 2.5 1.0 - 1.7
ISO 200 1.0 - 3.5 1.0 - 2.5
ISO 400 1.0 - 5.0 1.0 - 3.5

17
USING THE AUTO-FOCUS LOCK
Fig. 20
Fig. 21
In the composition shown above, the AF frame is off
the subject (in this case, the people). In this state,
the Lens will not focus on the subject.
Move the camera slightly so that the subject is inside
the AF frame.

18
Press the Shutter Release Button halfway down (AF
lock) without moving the camera and confirm that
the AF lamp (Green) lights.
While holding the Shutter Release Button halfway
down to keep the Auto-Focus lock on, move the
camera back to the original position to recompose
your picture, then press the Shutter Release Button
all the way down to take picture.
✻The Auto-Focus lock operation can be repeated
any number of times before the shutter trips.
When the last frame has been exposed, and film is
rewound. The Exposure Counter shows the number
of frames remaining after subtracting the exposed
frames from the specified number of frames. When
rewinding of the film is finished, the “B” sign will
appear on the Exposure Counter.
Fig. 22
Fig. 23
UNLOADING THE FILM CARTRIDGE

19
After “B” sign appears in the Exposure Counter and
the motor stops, move the Film Cartridge
Compartment Cover Release Knob in the arrow
direction, open the Film Cartridge Compartment
Cover, and take out the cartridge.
✻Confirm the “B” sign in the Exposure Counter
before opening the Film Cartridge Compartment
Cover. Otherwise, camera trouble or accidental
exposure of the film may occur.
✻Do not apply unnecessary force to the Film
Cartridge Compartment Cover.
Fig. 24

20
Fig. 25
FILM CARTRIDGE MID-ROLL CHANGE FUNCTION
When taking out the cartridge in mid-roll, turn on the
power, by opening the Slide Cover, and then rewind
the film by pressing the MRC (Mid-Roll Change)
Button. When “B” is displayed on the Exposure
Counter and the motor stops, take out the cartridge.
Confirm that j2 sign on the cartridge is white.
✻If the MRC button is pressed when the power is
off, the film may not be rewound. Turn on the
power before rewinding the film.
2
