FujiFilm instax SQUARE SQ20 User manual

PROLINE
REFRIGERATEUR
BRF40
FUJIFILM
APP PHOTO INSTANTANE
INSTAX SQ20 NOIR
MANUEL D'UTILISATION
Besoin d'aide ?
Rendez-vous sur votre communauté https://sav.darty.com

EN
FR
HU
TW
PT
IT
DE
ES
KO
RU
NL
PL
CS
SK
BO14P102-202
User’s Guide/Trouble shooting/Safety precautions
Bedienungsanleitung/Fehlerbehebung/Sicherheitsmaßnahmen
Guide d’utilisation/Guide de dépannage/Précautions de sécurité
Manual de instrucciones/Solución de problemas/Precauciones de seguridad
使用說明書/現象、可能的原因及解決措施/安全注意事項
사용설명서/문제 해결/안전을 위한 주의사항
Manual de Utilização/Resolução de problemas/Precauções de segurança
Руководство пользователя/устранение неполадок/меры предосторожности
Guida per l’Utente/Risoluzione dei problemi/Precauzioni per la sicurezza
Gebruikershandleiding/Probleemoplossing/Veiligheidsmaatregelen
Instrukcja obsługi/Rozwiązywanie problemów/Wskazówki bezpieczeństwa
Uživatelská příručka/Řešení potíží/Bezpečnostní opatření
Používateľská príručka/Riešenie problémov/Bezpečnostné pokyny
Használati útmutató/Hibaelhárítás/Biztonsági óvintézkedések
instaxBO-1414lang.indb1instaxBO-1414lang.indb1 8/21/20184:16:12PM8/21/20184:16:12PM

© 2018 FUJIFILM Corporation. All rights reserved.
ENGLISH:
See pages 3 to 42.
DEUTSCH:
Siehe Seiten 43 bis 82.
FRANÇAIS:
Voir pages 83 à 122.
ESPAÑOL:
Consulte las páginas 123 a 162.
中國語:
請參閱第 163 到202 頁。
한국어:
203~242페이지를 참조하십시오.
PORTUGUÊS:
Veja as páginas 243 a 282.
РУССКИЙ:
См. стр. 283 – 322.
ITALIANO:
Vedere le pagine da 323 a 362.
NEDERLANDS:
Zie pagina’s 363 tot 402.
POLSKI:
Patrz strony od 403 do 442.
ČESKY:
Viz strany 443 až 482.
SLOVENČINA:
Pozrite si strany 483 až 522.
MAGYAR:
Lásd: 523–563. oldal.
instaxBO-1414lang.indb2instaxBO-1414lang.indb2 8/8/20185:51:43PM8/8/20185:51:43PM

3
EN
ENGLISH
Contents
After reading this User’s Guide, keep it in a safe, easy to
nd place where you can refer to it if needed.
Before Use.................................................. 4
Notes on Disposing of the Camera... 5
Part Names ................................................ 6
Display on the LCD Monitor................ 7
Using the selector buttons.............................. 7
Using the command dial.................................. 7
Attaching the Strap................................ 8
Attaching the Hand Strap................................ 8
Attaching the Shoulder Strap (Purchased
Separately) ............................................................ 8
Charging the Battery ............................. 9
Charging status indication.............................. 9
Turning the Camera on/o................10
Checking Remaining Battery Life................10
Performing Initial Settings.................11
Function Setting for the Shutter Button ....12
Loading/Removing the INSTAX
SQUARE Film Pack.................................13
Loading the Film Pack.....................................13
Unloading a Used Film Pack .........................13
Basic Photography and Playback....14
Taking a Picture .................................................14
Viewing Images.................................................15
Changing the Playback Display...................15
Shooting a Movie and Playback ......16
Shooting a Movie..............................................16
Playing back Movies ........................................17
Changing the number of images on the
monitor.................................................................17
Printing.....................................................18
Adjusting/Processing Images (Eect) ...20
Filter.......................................................................20
Adjusting the Brightness ...............................21
Vignette................................................................21
More on Photography.........................22
Using AF/AE Lock..............................................22
Using the Self Timer.........................................22
Using the Flash ..................................................23
Taking a Self Portrait (Sele) .........................23
Changing the Shooting Mode .........24
Selecting a Shooting Mode...........................24
Shooting Mode..................................................24
Printing from Print History (Reprint) ....27
Using a Memory Card..........................28
Inserting the Memory Card...........................28
Printing Images Taken with another Camera ....28
Copying Images to the Computer ...29
Shooting Menu......................................30
Playback Menu.......................................31
Setup Menu.............................................32
SPECIFICATIONS ....................................33
TROUBLE SHOOTING ...........................35
IMPORTANT SAFETY NOTICE ............38
instaxBO-1414lang.indb3instaxBO-1414lang.indb3 8/8/20185:51:43PM8/8/20185:51:43PM

4
EN Before Use
Before using the camera, check the following.
!
Make sure supplied accessories are
included in the package.
Read“IMPORTANT SAFETY NOTICE”
(Page 38) for safety use.
~
Ÿ
Read this User's Guide before
using the camera.
!
Supplied Accessories
• USB cable for charging (1)
• Hand strap (1)
• User's Guide (1)
instaxBO-1414lang.indb4instaxBO-1414lang.indb4 8/8/20185:51:43PM8/8/20185:51:43PM

5
EN
A built-in lithium ion battery is used for this camera.
When you dispose of the camera, follow your local regulations and dispose of it properly.
Please refer to the supplied CONTACT INFORMATION sheet for inquiry.
If your country or region is not included in the sheet, please contact your local distributor.
CAUTION
Do not remove the built-in battery by yourself; otherwise, you may be injured.
Disposal of Electric and Electronic Equipment in Private Households
Disposal of used Electrical & Electronic Equipment
(Applicable in the European Union and other European countries with separate collection systems)
For customers inTurkey:
EEE Complies with Directive.
This symbol on the product, or in the manual and in the warranty, and/or on its packaging indicates that this product shall
not be treated as household waste.
Instead it should be taken to an applicable collection point for the recycling of electrical and electronic equipment.
By ensuring this product is disposed of correctly, you will help prevent potential negative consequences to the
environment and human health, which could otherwise be caused by inappropriate waste handling of this product.
The recycling of materials will help to conserve natural resources. For more detailed information about recycling of
this product, please contact your local city office, your household waste disposal service or the shop where you have
purchased the product.
In Countries outside of EU: If you wish to discard this product, please contact your local authorities and ask for the correct
way of disposal.
Notes on Disposing of the Camera
This Symbol on the batteries or accumulators
indicates that those batteries shall not be
treated as Household waste.
instaxBO-1414lang.indb5instaxBO-1414lang.indb5 8/8/20185:51:43PM8/8/20185:51:43PM

6
EN Part Names
Front Rear
1Flash/Self timer lamp 5Lens
2Film ejection slot 6Selfie mirror
3Strap hook 7Zoom ring
4Shutter button (Right) 8Shutter button (Left)
1Film door lock 10 (Playback) button
2Strap hook 11 (Back) button
3USB port 12 (Print) button
4Reset button 13 MENU/OK button
5Micro SD card slot 14 (Brightness) button
6Card slot cover 15 Film door
7(Filter) button 16 Power switch (Still
picture/Movie)
8(Vignette) button 17 LCD Monitor
9Selector button/
Command dial
1
2
4
3
7
6
8
5
1
2
8
913
7
11
12
14
15
17
10
3
5
16
6
4
instaxBO-1414lang.indb6instaxBO-1414lang.indb6 8/8/20185:51:43PM8/8/20185:51:43PM

7
EN
Display on the LCD Monitor
Shooting Playback
1Flash mode
(Page 23) 8Movie shooting (Page 10)
2
Brightness adjustment
(Page 21) 9
Date/time print
setting
*2
(Page 32)
3Filter
(Page 20) 10 Battery level (Page 10)
4Vignette
(Page 21) 11 Number of available frames *3 (Page 14)
5
Exposure
compensation
(Page 30) 12 Current date/time
(Page 32)
6Shooting mode *1
(Page 24) 13 Auto print
*2
(Page 30)
7Still picture shooting
(Page 10) 14 Film remaining (Page 19)
1Frame number 2Shooting date/time
*1 Not displayed when STANDARD is selected.
*2 The icon is displayed in gray when the date/time print
setting is disabled.
*3 When a memory card is inserted, the icon appears
on the number.
If the number of available frames is under 10, the icon
on the number turns red.
A remaining time is displayed while shooting a movie.
Using the selector buttons
16Move cursor up
28Move cursor left
37Move cursor down
49Move cursor right
5Confirms selection
Using the command dial
Use the command dial on the following
occasions.
• Selecting a menu or item
• Changing playback display
(Page 15)
• Adjusting the value of image effect
(Pages 20 to 21)
• Selecting a frame when printing from
a movie file (Page 18)
Pressing the (Back) button displays information below. Some items are not shown depending on the file type to shoot.
0
1
2
0
5 24
7
1
3
11
6
8
9
10
12
14
13
5
1
3
24
instaxBO-1414lang.indb7instaxBO-1414lang.indb7 8/8/20185:51:44PM8/8/20185:51:44PM

8
EN Attaching the Strap
Attaching the Hand Strap
Attach the strap as illustrated below.
• When you carry or use the camera, put the strap around
your wrist so that the camera does not drop.
Caution
• Use the strap only as a shoulder strap. Do not put the
shoulder strap around your neck.
• Be careful so that the shoulder strap does not obstruct
the film ejection slot.
Attach the shoulder strap to the strap hook on each side as
in the illustrations below.
Attaching the Shoulder Strap
(Purchased Separately)
~
Ÿ
instaxBO-1414lang.indb8instaxBO-1414lang.indb8 8/8/20185:51:46PM8/8/20185:51:46PM

9
EN
Charging the Battery
Caution
• You cannot remove the battery from the camera.
• The battery is not charged fully at shipment. Be sure to
charge it before using the camera.
• Read the cautions in“The battery”. (Page 40)
Connect the camera to a smartphone power adapter using
the supplied USB cable to an indoor power outlet.
• Use a USB AC adapter to meet the rated output below:
DC 5.0 V/1000 mA
• You can take a picture or print an image while
charging is in progress.
• Charging time is approximately two to three hours.
Charging from a PC:
• Connect the camera and PC directly. Do not connect
them via a keyboard or USB hub.
• If the PC enters the sleep mode while charging is in
progress, charging will stop. If you continue charging,
resume the PC and reconnect the USB cable.
• You may not be able to charge the camera from a PC
depending on your PC specifications, settings, or status.
Charging status indication
Status While camera
is on
While camera
is o
While
charging
The ( ->
-> ) icon
appears on the lower
right of the LCD
monitor.
Self timer lamp lights
up.
Charging
finished
The ( ) icon
appears on the lower
right of the LCD
monitor. (Goes off
when disconnecting
the USB cable.)
Self timer lamp goes
off. (The USB cable is
connected.)
Charging
error
An error message
appears on the LCD
monitor.
Self timer lamp
flashes.
Be careful of the orientation.
instaxBO-1414lang.indb9instaxBO-1414lang.indb9 8/8/20185:51:46PM8/8/20185:51:46PM

10
EN Turning the Camera on/o
To turn the camera on, use the power switch on the back and select still picture or movie.
Checking Remaining Battery Life
Pressing the (Back) button on the shooting/playback
screen displays remaining battery life on the LCD monitor.
• If no operation occurs for a certain period of time, the
camera turns off automatically. You can specify the
length of time before the camera turns off. (Page 32)
• Pressing the (Playback) button displays the
playback screen and changes to the playback mode.
• Pressing the shutter button fully during the playback
mode displays the shooting screen and changes to the
shooting mode.
Indication Remaining battery life
)8// Battery is partially discharged.
0,'
Battery is more than half discharged.
Charging the battery is recommended.
(Page 9)
/2:
Battery level is low. Charge as soon as
possible. (Page 9)
R When the battery level is low, the ( ) icon appears
on the lower right of the LCD monitor.
When no battery capacity remains, the ( (03) icon
appears enlarged on the LCD monitor and the camera
turns off.
When you shoot a still picture:
When you shoot a movie:
When you turn the camera off:
Slide the power switch to“OFF”.
instaxBO-1414lang.indb10instaxBO-1414lang.indb10 8/8/20185:51:47PM8/8/20185:51:47PM

11
EN
Performing Initial Settings
The language, date, and time are not specified when the camera is turned on for the first time. Follow the procedure below
to specify them.
You can specify these settings at any time. See page 32 if you perform these settings later or
change them.
~
Ÿ
!
⁄
Turning the camera on displays the language
selection screen.
Select a language, then press the MENU/OK
button or 9.
The language is specified and the DATE/TIME
screen appears.
Specify the order, then press the MENU/OK
button or 9.
Select one of the orders below.
• year/month/day
• month/day/year
• day/month/year
The order is specified and the screen to specify the
year, month, day, hour, and minute appears.
Specify the year, month, day, hour, and minute,
then press the MENU/OK button or 9.
Use 89 to select an item (year, month, day,
hour, or minute) to specify, then use 67 to
set the value.
@Press the MENU/OK button.
instaxBO-1414lang.indb11instaxBO-1414lang.indb11 8/8/20185:51:48PM8/8/20185:51:48PM

12
EN
• When you shoot a movie, you cannot assign the shooting mode switching function to either shutter button.
• If you skip this procedure, press the (Back) button when each screen appears. The shooting screen appears.
Function Setting for the Shutter Button
Assign a function to each of the shutter buttons from the combinations on the table below.
When you shoot a still picture:
Shutter button (Right) Shutter button (Left)
Function
Shutter button Shutter button
Shutter button Shooting mode switching button
Shutter button OFF
Shooting mode switching button Shutter button
OFF Shutter button
When you shoot a movie:
Shutter button (Right) Shutter button (Left)
Function
Shutter button Shutter button
Shutter button OFF
OFF Shutter button
By default, shutter button function is assigned to both of the shutter buttons.
Use 89 to select the combination when the
SHUTTER BUTTON SETTINGS screen is displayed, then press the MENU/
OK button.
instaxBO-1414lang.indb12instaxBO-1414lang.indb12 8/8/20185:51:49PM8/8/20185:51:49PM

13
EN
Loading/Removing the INSTAX SQUARE Film Pack
~
Ÿ
⁄
!
Unloading a Used Film Pack
~
Ÿ
Loading the Film Pack
Caution
Do not open the film door until you have used up
the film; otherwise, the rest of the film is exposed
and turns white and the film can no longer be used.
• When you load the film pack, never press the two
rectangular holes on the back of the film pack.
• Never use a film pack beyond its shelf life; otherwise, it
may damage the camera.
Use FUJIFILM Instant Film“instax SQUARE” only.
The instax mini film or instax WIDE film cannot be used.
Notes on the film pack
• Each FUJIFILM Instant Film“instax SQUARE”pack contains
1 black film protective cover and 10 film sheets.
• Only remove the film pack from its inner bag just before
inserting into the camera.
• The film cover is ejected automatically when the film
door is closed. The camera works to eject a film even
though the film pack is not loaded.
For details, refer to the instructions and warnings on
FUJIFILM Instant Film“instax SQUARE”.
Hold both sides of the
film pack, align the
bottom of the film pack
on the groove of the film
chamber (1), then insert
it straight (2).
Close the film door. Make
sure the film door lock
clicks into place.
The film cover (black) is
ejected automatically when
the film door is closed.
Remove the film cover from
the film ejection slot.
When no film is left, all dots on the right of the shooting
screen are displayed in gray. (Page 19)
Unload the film pack.
Grasp the rectangular
holes on the film pack,
then pull it out straight.
1
2
1212
Press and hold the button of the film door lock (1),
then slide the lever to the right (2) until the film
door opens slightly.
Press and hold the button of the film door lock (1),
then slide the lever to the right (2) until the film
door opens slightly.
instaxBO-1414lang.indb13instaxBO-1414lang.indb13 8/8/20185:51:49PM8/8/20185:51:49PM

14
EN Basic Photography and Playback
Taking a Picture
This section describes basic operation for photography.
~Slide the power switch to (still picture).
Ÿ
⁄
!
Hold the camera.
Press the shutter button halfway to focus.
• If the camera is able to focus:
The camera beeps and the green focus frame
appears on the monitor.
• If the camera is unable to focus:
The red focus frame appears on the monitor.
Change the composition or use focus lock. (Page
22)
Lightly press the shutter button the rest of the way
down to take the picture.
The picture is taken and it is saved in the camera’s
memory.
• See page 18 for the procedure to print an
image.
• If the print mode is set to auto print mode, the
image will be printed. (Page 30)
• When you take a picture, hold the camera with both
hands and brace your elbows against your sides.
• Be careful not to touch the lens surface when you
press the shutter button.
• When you press the shutter button fully, press it
lightly.
• Be careful that your fingers or the strap do not cover
the flash, lens, or film ejection slot.
• If a subject is poorly lit, the flash may fire when the
picture is taken. You can change the flash setting to
disable flashing. (Page 23)
Select the shooting mode or perform the steps to
select your image effects. (Pages 20 to 26)
¤
Cautions on the camera’s memory
• When the memory becomes full, the shutter will not
release and you cannot take a picture. Delete the
images in the memory or use another memory card.
• Images in the memory may be damaged or lost if the
camera has any trouble. We recommend you store
important image files as backup using other media
(e.g. Hard disk, CD-R, CD-RW, or DVD-R, etc.).
• If you request a repair, we cannot guarantee the safety
of the images stored in memory.
• While the camera is being repaired, note that we may
check the contents of images in the memory.
Use the zoom ring to confirm the desired
composition of the final image.
@
instaxBO-1414lang.indb14instaxBO-1414lang.indb14 8/8/20185:51:50PM8/8/20185:51:50PM

15
EN
Basic Photography and Playback
Viewing Images
Images can be viewed on the monitor.
~
Press the (Playback) button.
!Press 8or 9to select an image to view.
Changing the Playback Display
You can zoom in on the image on the monitor or change
the number of images displayed at a time.
■Zooming in on image
You can zoom in on an image on the monitor by turning
the command dial clockwise.
• Use
6789 buttons to move the view area.
• Pressing the MENU/OK button or (Back) button
cancels zooming.
• You can print an image while it is zoomed in. (Page
18)
■Changing the number of images on the
monitor
Turning the command dial counterclockwise changes
the number of images (one, four, or nine).
• Turning the command dial clockwise changes the
number of images (four or one).
• Pressing the MENU/OK button or (Back) button
cancels the multiple image display.
• You can print an image while four or nine images are
displayed. (Page 18)
Normal Zoom
One image Four images Nine images
The most recent image will be displayed.
Pressing
8
displays a previous image.
Pressing
9
displays a next image.
• Pressing the shutter button fully returns to the
shooting screen.
Ÿ
Slide the power switch to (still picture).
instaxBO-1414lang.indb15instaxBO-1414lang.indb15 8/8/20185:51:50PM8/8/20185:51:50PM

16
EN Shooting a Movie and Playback
Shooting a Movie
This section describes basic operation for shooting a movie.
~Slide the power switch to (movie).
Ÿ
⁄
!
Hold the camera.
Press the shutter button fully.
The screen below appears and movie shooting
starts.
• You can use the zoom ring while shooting is in
progress.
• You can see the elapsed time by the bar shown
on the left.
• When you select“Retro”, “Film Frame”, or
“Sequence”, the camera applies the filter effect to
the movie file while shooting is in progress.
Press the shutter button fully again.
Movie shooting finishes.
Perform the steps to select your image effects.
(Pages 20 to 21)
@
Use the zoom ring to confirm the desired
composition of the final image.
¤
• When you shoot a movie, hold the camera with both
hands and brace your elbows against your sides.
• Be careful not to touch the lens surface when you
press the shutter button.
• Be careful that your fingers or the strap do not cover
the flash, lens, or film ejection slot.
• When you use a memory card, a movie can be shot for
up to 15 seconds.
• No sound can be recorded on the movie file.
• When you select“Retro”,“Film Frame”, or“Sequence”,
you cannot cancel the applied filter effect or apply
another filter after shooting a movie.
■Eects only for movie shooting
You can select three types of filters for movie shooting;
“Retro”,“ Film Frame”, and“Sequence”. For details see
page 20.
instaxBO-1414lang.indb16instaxBO-1414lang.indb16 8/8/20185:51:53PM8/8/20185:51:53PM

17
EN
Shooting a Movie and Playback
Playing back Movies
Movies can be played back on the monitor.
~
Press the (Playback) button.
!Press 8or 9to select a movie to play back.
Changing the number of images on
the monitor
When the movie thumbnail is displayed, turning the
command dial counterclockwise changes the number of
images (one, four, or nine).
• Turning the command dial clockwise changes the
number of images (four or one).
• Pressing the MENU/OK button or (Back) button
cancels the multiple image display.
One image Four images Nine images
The most recent movie thumbnail will be displayed.
Pressing
8
displays a previous thumbnail.
Pressing
9
displays a next thumbnail.
Ÿ
Slide the power switch to (movie).
Press 7.
The movie playback starts.
⁄
Operations during movie playback
• Press
7to pause playback. Pressing 7again
resumes playback.
• While the playback is paused, pressing 8or 9, or
turning the command dial allows you to play back
frame by frame. In addition, pressing the MENU/OK
button saves the displayed image (frame) as an image
file.
• When the playback is finished, the movie thumbnail
displayed previously appears.
instaxBO-1414lang.indb17instaxBO-1414lang.indb17 8/8/20185:51:53PM8/8/20185:51:53PM

18
EN Printing
Print an image following the steps below.
~
Ÿ
!
Pressing
8
displays a previous image.
Pressing
9
displays a next image.
Press the (Playback) button.
The most recent image will be displayed.
• When you print a still picture:
Press
8
or
9
to select an image to print.
Slide the power switch to (still picture) or
(movie).
Select an image to print.
• When you print an image captured from a
movie file:
1 Press
8
or
9
to select a movie to play back.
Pressing
8
displays a previous thumbnail.
Pressing
9
displays a next thumbnail.
2 Press
7
to play back the movie.
3 Press
7
to pause playback.
4 Press
8
or
9
, or turn the command dial to
select an image (frame) to print.
5Press the MENU/OK button.
The image is captured and saved.
• To access a saved image captured from a
movie file, slide the power switch to
(still picture) on step 1, and proceed to step
2 and 3.
instaxBO-1414lang.indb18instaxBO-1414lang.indb18 8/8/20185:51:56PM8/8/20185:51:56PM

19
EN
■Film remaining indication
Dots on the right of the monitor indicates the number
of remaining films.
One dot turns gray every time you print an image.
• When there are only two films left, the dots
will turn red.
R For still picture, you can print an image that is zoomed
in or print four or nine images on one film. Use the
command dial to change to the multiple image display
on step 2 when the image to print is displayed. (Page
15)
• For details on taking out the film, refer to the
instructions and warnings on the FUJIFILM Instant
Film“instax SQUARE”pack.
• The development time is approximately 90 seconds.
(The time varies depending on the ambient
temperature.)
Printing
⁄
#
Press the (Print) button.
The screen below appears.
@
Press the MENU/OK button.
Printing starts.
• To cancel printing press the (Back) button.
¤
Adjust the image effect as necessary.
(Pages 20 and 21)
When the film has been
ejected (the camera stops
making a sound), grab the
edges of the film, then take
it out.
instaxBO-1414lang.indb19instaxBO-1414lang.indb19 8/8/20185:51:56PM8/8/20185:51:56PM
