X-M1 Specifications
*1 Please see the Fujifilm website to check memory card compatibility.
*2 Exif 2.3 is a digital camera file format that contains a variety of shooting information for optimal printing.
*3 approximate number of frames that can be taken with a fully-charged battery
*4 OS compatibility Viewer software : Windows 8 / 7 / Vista / XP RAW File Converter : Windows 8 / 7 / Vista / XP, Mac OS X 10.6 -10.8
Wireless transmitter standard
access mode
IEEE 802.11b / g / n (standard wireless protocol)
Infrastructure
Face Detection, Auto Red-eye Removal, Setting (Color, Sharpness, D-range, Gradation), Multiple exposure, Depth of Field display,
Histogram display, Framing guideline, Frame No. memory, Monitor Sunlight mode, Focus Peak Highlight, Date stamp, Fn button setting
Model name
Number of effective pixels
Image sensor
Storage media
File format
Number of recorded pixels
Sensor Cleaning systemSensor Cleaning system
Lens mount
Sensitivity
Exposure control
Exposure mode
Exposure compensation
Image Stabilizer
Face detection
Shutter type
Continuous shooting
Auto bracketing
Focus
still image
movie
mode
type
AF frame selection
FUJIFILM X mount
TTL 256-zone metering, Multi / Spot / Average
Programmed AE / Shutter priority AE / Aperture priority AE / Manual exposure
-2.0EV -+2.0EV, 1/3EV steps
Supported with OIS type lens
Yes
Focal Plane Shutter
Manual Focus / Area AF / Multi AF / Continuous AF / Tracking AF
TTL contrast AF, AF assist illuminator available
Area AF (49 areas with 7x7), Changeable AF frame size
L : <3:2>4896×3264 <16:9>4896×2760 <1:1>3264×3264
M: <3:2>3456×2304 <16:9>3456×1944 <1:1>2304×2304
S : <3:2>2496×1664 <16:9>2496×1408 <1:1>1664×1664
White balance
Self-timer
Flash
Shutter speed
Hot shoe
LCD monitor
Movie recording
Mode dial
Film Simulation mode
Dynamic range setting
Advanced filter
Other photography functions
Wireless function
Other functions
Terminal
RAW conversion, Image rotate, Auto image rotate, Red-eye reduction, Photobook assist, Erase selected frames, Image search,
Multi-frame playback (with micro thumbnail), Slide show, Mark for upload, Protect, Crop, Resize, Favorites
Digital interface
HD output
Others
Auto / Custom / Preset (Fine / Shade / Fluorescent light (Daylight) / Fluorescent light (Warm White) / Fluorescent light (Cool White) / Incandescent light
10 sec. / 2 sec. Delay
Manual pop-up flash (Super Intelligent Flash) Guide number: approx.7 (ISO200
.
m)
Geotagging setup, Image transfer (Individual image / Selected multiple images), View & Obtain Images, PC Autosave
PictBridge, Exif Print, Language selection, Time difference, Quick start mode, Silent mode
0 - 40 C / 32 -104 F
10 - 80% (no condensation)
Yes (dedicated TTL Flash compatible)
3.0-in. aspect ratio 3:2 approx. 920K-dot Tilt-type TFT color LCD monitor (Approx.100% coverage)
Advanced SR AUTO / P / S / A / M / C / Portrait / Landscape / Sport / SP / Adv. / AUTO
PROVIA (STANDARD) / Velvia (VIVID) / ASTIA (SOFT) / MONOCHROME / SEPIA
AUTO(100-400%) / 100% / 200% / 400%
Toy camera / Miniature / Pop color / High-key / Low-key / Dynamic tone / Soft focus / Partial color (Red / Orange / Yellow / Green / Blue / Purple)
Red-eye removal OFF: Auto / Forced Flash / Suppressed Flash / Slow Synchro / Rear-curtain Synchro / Commander
Red-eye removal ON: Red-eye Reduction Auto / Red-eye Reduction & Forced Flash / Suppressed Flash /
Red-eye Reduction & Slow Synchro / Red-eye Reduction & Rear-curtain Synchro / Commander
*Red-eye removal is active when Face Detection is set to ON.
Full HD 1920 x1080 30p Continuous recording : up to approx.14 min.
HD 1280 x 720 30p Continuous recording: up to approx.27 min. * SD Card or higher
FUJIFILM X-M1
16.3 million pixels
23.6mm×15.6mm (APS-C) X-Trans CMOS with primary color filter Total number of pixels: 16.5 million pixels
Ultra Sonic Vibration
SD memory card / SDHC memory card / SDXC (UHS-I) memory card
*1
JPEG (Exif Ver 2.3*2) / RAW (RAF format) / RAW+JPEG (Design rule for Camera File system compliant, DPOF-compatible)
Movie File Format: MOV, Movie Video Compression: H.264, Audio: Linear PCM Stereo
Flash modes
Power supply
Dimensions
Weight
Operating Temperature
Operating Humidity
Battery life for still images
*3
Starting up period
Accessories included
approx. 350 frames (with XF35mmF1.4 R lens)
Approx. 0.5 sec., when QUICK START mode set to ON, Approx. 1.0 sec. when QUICK START mode set to OFF. * FUJIFILM research
Li-ion Battery NP-W126, Battery Charger BC-W126, Shoulder strap, Body cap, CD-ROM (Viewer software, RAW File Converter, etc.
*4
) , Owner's manual
NP-W126 Li-ion battery (included)
116.9 (W) mm x 66.5(H) mm x 39.0 (D) mm / 4.6 in.(W) x 2.6 in.(H) x 1.5 in.(D) (Minimum depth: 32.1mm / 1.3 in.)
Approx. 330g / 11.6 oz. (including battery and memory card) / Approx. 280 g / 9.9 oz. (excluding accessories, battery and memory card)
USB 2.0 High-Speed
HDMI mini connector (Type C)
Remote release terminal for RR-90 (sold separately)
Playback functions
AUTO / Equivalent to ISO200 -6400 (Standard Output Sensitivity)
Extended output sensitivity: equivalent to ISO100 / 12800 / 25600
(Advanced SR AUTO mode) 1/4 sec. to 1/4000 sec. (All other modes) 30 sec. to 1/4000 sec. Bulb (max. 60 min.)
Synchronized Shutter speed for flash
: 1/180 sec. or slower (At S or M mode, 1/160 sec. or slower can be set.)
approx. 5.6fps (JPEG : max. 30 frames, RAW/RAW+JPEG: max. 10 frames)
approx. 3.0fps (JPEG : max. 50 frames, RAW/RAW+JPEG: max. 10 frames) * SD Card or higher
AE Bracketing (±1/3EV / ±2/3EV / ±1EV ), Film Simulation Bracketing (3 types of film simulation selectable),
Dynamic Range Bracketing (100% .200% .400%), ISO Sensitivity Bracketing (±1/3EV / ±2/3EV / ±1EV)
For more information, please visit our website:
http://www.fujifilm.com/products/digital_cameras/x/fujifilm_x_m1/
Specifications are subject to change without notice.
Sample photos in this catalog are simulated images.
Microsoft, Windows and Windows logo are trademarks,
or registered trademarks of Microsoft Corporation in the United States and/or other countries.
Macintosh and Mac OS are trademarks of Apple Computer, Inc., registered in the U.S. and other countries.
HDMI, the HDMI Logo, and High-Definition Multimedia interface are either trademarks or registered trademarks of HDMI Licensing.
SDXC logo is a trademark. All other trademarks are the property of their respective holders.
SILKYPIX®is a registered trademark of Ichikawa Soft Laboratory Co., Ltd. in Japan.

DSLR impact in the ultimate compact.
compact
impact
<Actual Size >
More camera in a compact,
More impact in every photo.
Stylish and compact, yet possessing the power to
capture every scene with unprecedented image
quality and richness of color reproduction.
It's everything you wished for
in one camera, and more.
X-M1. A small camera with big impact.

Low noise and high sensitivity.
High image quality even shooting “quick” snaps.
Soft defocused "bokeh" effect.
ISO 1600
High image quality taken to
extremes by the large sensor.
Only this originally developed APS-C size sensor can capture your images with Fujifilm signature image quality
and color. Featuring sensor architecture that eliminates the need for an optical low-pass filter (OLPF),
the X-Trans CMOS Sensor can reproduce scenes with resolution and clarity rivaling a larger sensor. Experience
the impact of high-sensitivity/low-noise performance in low-light scenes in all your beautiful blur-free photos.
Capture vibrant detail and color with Fujifilm,s large world renowned sensor.
X-Trans CMOS &EXR PROCESSOR
1-inch
13.2 x 8.8mm
Micro Four Thirds
17x13mm
APS-C Image Sensor
23.6 x 15.6mm
*54 patterns without OIS lens attached.
Advanced SR AUTO. Trust X-M1 to take photos like a pro.
Advanced SR AUTO instantly recognizes 58* scene types and then automatically optimizes settings.
All you do is frame, press the shutter and prepare to be impressed by the impact of pro-class photos.
X-Trans CMOS Sensor
Winner of the “Innovation of the Year” Category
Amateur Photographer Awards 2013
Image Sensor Size Comparison
(actual size)

Natural colors with Auto White Balance.
Soft skin tones.Vibrant greenscapes.
Some colors can only be expressed by Fujifilm.
Color just as your eye sees them. True-to-scene color, but somehow more real,
more beautiful, and more alive. Fujifilm's 80-year pursuit of the ultimate color
reproduction as a photo film manufacturer lets you capture moments with vibrant
color fidelity.
PROVIA / Standard Velvia / Vivid ASTIA / Soft SEPIAMONOCHROME
Natural color quality
captures true-to-scene
photos.
Express the moment with
the honesty and depth of
monochrome.
Dramatic and vibrant
expression of reds, blues
and greens.
Capture both natural skin
gradations and brilliant color
tonality of backgrounds.
Define memorable
moments in the nostalgic,
warm tones of sepia.
The vivid colors of Velvia! The gentle skin tonality of ASTIA!
Just like choosing the ideal film for a creative direction, you
can select and simulate the unique look of Fujifilm’s
acclaimed films. Film Simulation also lets you replicate
MONOCHROME and SEPIA film photography.
FILM SIMULATION
Signature color expression by Fujifilm
PROVIA
PROVIA
ASTIA

Featuring a choice of 8 artistic effects, Advanced Filters make artistic photography
as easy as pressing the shutter. Before you shoot, you can preview the effect on the
LCD monitor and even fine-tune brightness.
Advanced Filters.
Transform photos into original works of art.
With Fujifilm's effortless and wireless transfer of photos to your smartphone or tablet, there is
no need to enter an ID, password or make other troublesome settings. In no time, your
high-quality photos are ready for sharing on your blog or social network. You can also use the
X-M1's built-in Wi-Fi to save your photos on your PC.
"Shoot & Share" on the spot with easy wireless image transfer
to your smartphone.
MAIL
SNS
Create a fantasy effect by
dynamically-modulated tonal
reproduction.
Enhance brightness and reduce
contrast to lighten tonal
reproduction.
Create uniformly dark tones
with emphasized highlights.
Create a look that is evenly soft
throughout the whole image.
Emphasizes contrast and color
saturation.
Create shaded borders as if you
were taking a photo on a toy camera.
Adds top and bottom blur for a diorama or
miniature effect.
Retain one selected original color and change the
rest of the photo to black and white.
( Red / Orange / Yellow /Green / Blue / Purple )
All dials and buttons are arranged on the right of the LCD for easy and direct
control at your fingertips.
Simple “One Handed” Operation
With the freedom to tilt the monitor up or down, you can hold the camera
overhead to frame and shoot over a crowd or low down to capture a different
perspective from the ground up.
Tilting Screen.
Change the LCD angle and your perspective.
Smooth operability and the freedom to express a new point of view.
High angle
Low angle
Miniature
Dynamic Tone High Key Low Key
Soft Focus Pop Color Toy Camera
Partial Color

Fujifilm's precision optical technology and relentless pursuit of the ultimate in image quality have
given birth to an impressive and growing lineup of lenses. Each is designed to be the brightest
possible, easy to carry with you everywhere and compact. Every lens opens a window into a world
of possibilities.
Clear, high fidelity descriptive performance in a
compact, lightweight form make this lens a perfect
partner for X-M1. With a focal length of 41mm*,
about the same angle of view of the human eye,
this lens is not only a superb snapshot choice, but
also performs well in a variety of scenes from
portraits and landscapes to architectural shots.
Fleeting moments can't escape its high-speed,
high-precision AF.
Zoom range from wide angle to standard/medium
telephoto in a compact size make this lens an
all-around performer. The ultra wide angle 24mm*
lens is great not only for landscapes, but also
for recording those special occasions both indoors
and out. In addition to capturing photos free
from camera-shake blur,the enhanced optical
stabilization lets you shoot stunningly clear movies
even while walking.
Interchangeable lenses.
Every lens is a window to a new world.
High-performance lens lineup
Multiply your enjoyment of
every shot with X-M1 accessories.
NEW LEATHER CASE BLC-XM1 NEW HAND GRIP HG-XM1
SHOE MOUNT FLASH EF-X20
Featuring a lightweight, compact form and analogue dial operation, the X-series shoe-mount flash is ready
when you need more flash volume. Seize even more moments with the confidence of a custom hand grip
seamlessly molded to the X-M1 body and the stylish protection of the authentic leather case.
"Perfect fit" design for X-M1 plus ease-of-use functionality.
*35mm format equivalent
Black Silver
Black Silver
XF27mmF2.8
XC16-50mmF3.5-5.6 OIS
NEW
NEW
SHOE MOUNT FLASH EF-20
SHOE MOUNT FLASH EF-X20
HAND GRIP HG-XM1
LEATHER CASE BLC-XM1
SHOE MOUNT FLASH EF-42
M MOUNT ADAPTER
REMOTE RELEASE RR-90
PROTECTOR FILTER PRF-62
PROTECTOR FILTER PRF-58
PROTECTOR FILTER PRF-52
PROTECTOR FILTER PRF-39
BATT ERY NP-W126
BATTERY CHARGER BC-W126
BODY CAP BCP-001
LENS REAR CAP RLCP-001
LENS CAP FLCP-62
LENS CAP FLCP-58
LENS CAP FLCP-52
LENS CAP FLCP-39
LENS HOOD CAP LHCP-001
LENS HOOD CAP LHCP-002
Accessories

X-M1 Specifications
*1 Please see the Fujifilm website to check memory card compatibility.
*2 Exif 2.3 is a digital camera file format that contains a variety of shooting information for optimal printing.
*3 approximate number of frames that can be taken with a fully-charged battery
*4 OS compatibility Viewer software : Windows 8 / 7 / Vista / XP RAW File Converter : Windows 8 / 7 / Vista / XP, Mac OS X 10.6 -10.8
Wireless transmitter standard
access mode
IEEE 802.11b / g / n (standard wireless protocol)
Infrastructure
Face Detection, Auto Red-eye Removal, Setting (Color, Sharpness, D-range, Gradation), Multiple exposure, Depth of Field display,
Histogram display, Framing guideline, Frame No. memory, Monitor Sunlight mode, Focus Peak Highlight, Date stamp, Fn button setting
Model name
Number of effective pixels
Image sensor
Storage media
File format
Number of recorded pixels
Sensor Cleaning systemSensor Cleaning system
Lens mount
Sensitivity
Exposure control
Exposure mode
Exposure compensation
Image Stabilizer
Face detection
Shutter type
Continuous shooting
Auto bracketing
Focus
still image
movie
mode
type
AF frame selection
FUJIFILM X mount
TTL 256-zone metering, Multi / Spot / Average
Programmed AE / Shutter priority AE / Aperture priority AE / Manual exposure
-2.0EV -+2.0EV, 1/3EV steps
Supported with OIS type lens
Yes
Focal Plane Shutter
Manual Focus / Area AF / Multi AF / Continuous AF / Tracking AF
TTL contrast AF, AF assist illuminator available
Area AF (49 areas with 7x7), Changeable AF frame size
L : <3:2>4896×3264 <16:9>4896×2760 <1:1>3264×3264
M: <3:2>3456×2304 <16:9>3456×1944 <1:1>2304×2304
S : <3:2>2496×1664 <16:9>2496×1408 <1:1>1664×1664
White balance
Self-timer
Flash
Shutter speed
Hot shoe
LCD monitor
Movie recording
Mode dial
Film Simulation mode
Dynamic range setting
Advanced filter
Other photography functions
Wireless function
Other functions
Terminal
RAW conversion, Image rotate, Auto image rotate, Red-eye reduction, Photobook assist, Erase selected frames, Image search,
Multi-frame playback (with micro thumbnail), Slide show, Mark for upload, Protect, Crop, Resize, Favorites
Digital interface
HD output
Others
Auto / Custom / Preset (Fine / Shade / Fluorescent light (Daylight) / Fluorescent light (Warm White) / Fluorescent light (Cool White) / Incandescent light
10 sec. / 2 sec. Delay
Manual pop-up flash (Super Intelligent Flash) Guide number: approx.7 (ISO200
.
m)
Geotagging setup, Image transfer (Individual image / Selected multiple images), View & Obtain Images, PC Autosave
PictBridge, Exif Print, Language selection, Time difference, Quick start mode, Silent mode
0 - 40 C / 32 -104 F
10 - 80% (no condensation)
Yes (dedicated TTL Flash compatible)
3.0-in. aspect ratio 3:2 approx. 920K-dot Tilt-type TFT color LCD monitor (Approx.100% coverage)
Advanced SR AUTO / P / S / A / M / C / Portrait / Landscape / Sport / SP / Adv. / AUTO
PROVIA (STANDARD) / Velvia (VIVID) / ASTIA (SOFT) / MONOCHROME / SEPIA
AUTO(100-400%) / 100% / 200% / 400%
Toy camera / Miniature / Pop color / High-key / Low-key / Dynamic tone / Soft focus / Partial color (Red / Orange / Yellow / Green / Blue / Purple)
Red-eye removal OFF: Auto / Forced Flash / Suppressed Flash / Slow Synchro / Rear-curtain Synchro / Commander
Red-eye removal ON: Red-eye Reduction Auto / Red-eye Reduction & Forced Flash / Suppressed Flash /
Red-eye Reduction & Slow Synchro / Red-eye Reduction & Rear-curtain Synchro / Commander
*Red-eye removal is active when Face Detection is set to ON.
Full HD 1920 x1080 30p Continuous recording : up to approx.14 min.
HD 1280 x 720 30p Continuous recording: up to approx.27 min. * SD Card or higher
FUJIFILM X-M1
16.3 million pixels
23.6mm×15.6mm (APS-C) X-Trans CMOS with primary color filter Total number of pixels: 16.5 million pixels
Ultra Sonic Vibration
SD memory card / SDHC memory card / SDXC (UHS-I) memory card
*1
JPEG (Exif Ver 2.3*2) / RAW (RAF format) / RAW+JPEG (Design rule for Camera File system compliant, DPOF-compatible)
Movie File Format: MOV, Movie Video Compression: H.264, Audio: Linear PCM Stereo
Flash modes
Power supply
Dimensions
Weight
Operating Temperature
Operating Humidity
Battery life for still images
*3
Starting up period
Accessories included
approx. 350 frames (with XF35mmF1.4 R lens)
Approx. 0.5 sec., when QUICK START mode set to ON, Approx. 1.0 sec. when QUICK START mode set to OFF. * FUJIFILM research
Li-ion Battery NP-W126, Battery Charger BC-W126, Shoulder strap, Body cap, CD-ROM (Viewer software, RAW File Converter, etc.
*4
) , Owner's manual
NP-W126 Li-ion battery (included)
116.9 (W) mm x 66.5(H) mm x 39.0 (D) mm / 4.6 in.(W) x 2.6 in.(H) x 1.5 in.(D) (Minimum depth: 32.1mm / 1.3 in.)
Approx. 330g / 11.6 oz. (including battery and memory card) / Approx. 280 g / 9.9 oz. (excluding accessories, battery and memory card)
USB 2.0 High-Speed
HDMI mini connector (Type C)
Remote release terminal for RR-90 (sold separately)
Playback functions
AUTO / Equivalent to ISO200 -6400 (Standard Output Sensitivity)
Extended output sensitivity: equivalent to ISO100 / 12800 / 25600
(Advanced SR AUTO mode) 1/4 sec. to 1/4000 sec. (All other modes) 30 sec. to 1/4000 sec. Bulb (max. 60 min.)
Synchronized Shutter speed for flash
: 1/180 sec. or slower (At S or M mode, 1/160 sec. or slower can be set.)
approx. 5.6fps (JPEG : max. 30 frames, RAW/RAW+JPEG: max. 10 frames)
approx. 3.0fps (JPEG : max. 50 frames, RAW/RAW+JPEG: max. 10 frames) * SD Card or higher
AE Bracketing (±1/3EV / ±2/3EV / ±1EV ), Film Simulation Bracketing (3 types of film simulation selectable),
Dynamic Range Bracketing (100% .200% .400%), ISO Sensitivity Bracketing (±1/3EV / ±2/3EV / ±1EV)
For more information, please visit our website:
http://www.fujifilm.com/products/digital_cameras/x/fujifilm_x_m1/
Specifications are subject to change without notice.
Sample photos in this catalog are simulated images.
Microsoft, Windows and Windows logo are trademarks,
or registered trademarks of Microsoft Corporation in the United States and/or other countries.
Macintosh and Mac OS are trademarks of Apple Computer, Inc., registered in the U.S. and other countries.
HDMI, the HDMI Logo, and High-Definition Multimedia interface are either trademarks or registered trademarks of HDMI Licensing.
SDXC logo is a trademark. All other trademarks are the property of their respective holders.
SILKYPIX®is a registered trademark of Ichikawa Soft Laboratory Co., Ltd. in Japan.
