FujiFilm X-PRO2 User manual

DIGITAL CAMERA
X-Pro2
New Features Guide
Version 5.00
Features added or changed as a result of rmware updates may no longer match the
descriptions in the documentation supplied with this product. Visit our website for
information on the updates available for dierent products:
http://www.fujifilm.com/support/digital_cameras/software/fw_table.html
EN
BL00004986-200

ENGLISH
Contents
Contents
X-Pro2 rmware version 5.00 adds or updates the features listed below. For the latest manual, visit the following
website.
http://fujifilm-dsc.com/en/manual/
No.
No.
Description
Description
X-Pro2
X-Pro2
P
P
See
See
P
P
Ver.
Ver.
1
1
To view separate RGB histograms and a display showing areas of the frame that will be overexposed
at current settings superimposed on the view through the lens, press the function button to which
HISTOGRAM is assigned.
34
34
EN-1
EN-1
4.00
4.00
2
2During movie recording, you can press the shutter button halfway to refocus using autofocus.
44
44
EN-1
EN-1
4.00
4.00
3
3The focus stick can be used to change focus areas when the display is zoomed in during checking
focus.
65
65
EN-2
EN-2
*
*
4
4A FLICKER REDUCTION option has been added to ASHOOTING SETTING in the shooting menu.
99
99
EN-3
EN-3
5.00
5.00
5
5Changes have been made to the contents of the BMOVIE SETTING> MOVIE MODE item in the
shooting menu.
104
104
EN-4
EN-4
4.00
4.00
6
6LARGE INDICATORS MODE(EVF/OVF) and LARGE INDICATORS MODE(LCD) options have been
added to DSCREEN SETTING in the setup menu.
118
118
EN-5
EN-5
EN-6
EN-6
5.00
5.00
7
7A LARGE INDICATORS DISP. SETTING option has been added to DSCREEN SETTING in the setup
menu.
118
118
EN-7
EN-7
5.00
5.00
8
8A SELECT FOLDER option has been added to DSAVE DATA SETTING in the setup menu.
123
123
EN-8
EN-8
5.00
5.00
9
9ACCESS POINT SETTINGS and IP ADDRESS options have been added to DCONNECTION
SETTING> WIRELESS SETTINGS in the setup menu.
124
124
EN-9
EN-9
4.00
4.00
10
10 A DCONNECTION SETTING> PC CONNECTION MODE item has been added to the setup menu.
124
124
EN-10
EN-10
4.00
4.00
11
11 In addition to the instax SHARE printers listed in “Accessories from FUJIFILM”, the camera now sup-
ports the SP-3.
141
141
EN-11
EN-11
4.00
4.00
12
12 Third-party studio ash commanders compatible with the FUJIFILM ash system can now be used.
143
143
EN-11
EN-11
4.00
4.00
RThe asterisks in the “Ver.” column indicate features available in earlier versions; only the descriptions in the
manual have been changed.

EN-1ENGLISH
Changes and Additions
Changes and Additions
The DISP/BACK Button
The DISP/BACK Button
X-Pro2 (Version 3.10) Owner’s Manual: P34 Ver. 4.00
Histograms
Histograms
Histograms show the distribution of tones in the image.
Brightness is shown by the horizontal axis, the number
of pixels by the vertical axis.
Shadows Highlights
No. of pixels
Pixel brightness
Optimal exposure: Pixels are distrib-
uted in an even curve throughout
the tone range.
Overexposed: Pixels are clustered
on the right side of the graph.
Underexposed: Pixels are clustered
on the left side of the graph.
To view separate RGB histograms
and a display showing areas of
the frame that will be overex-
posed at current settings super-
imposed on the view through the
lens, press the function button to
which HISTOGRAM is assigned.
AOverexposed areas blink
BRGB histograms
A
A
B
B
Recording Movies
Recording Movies
X-Pro2 (Version 3.10) Owner’s Manual: P44 Ver. 4.00
RZoom can be adjusted while recording is in progress.
RFrame size and rate can be selected using WMOVIE
SETTING> MOVIE MODE. Focus mode is selected
using the focus mode selector; for continuous focus
adjustment, select C, or choose Sand enable Intel-
ligent Face Detection. Intelligent Face Detection is
not available in focus mode M.
RDuring movie recording, you can press the shutter
button halfway to refocus using autofocus.
RDuring recording, exposure compensation can be
adjusted by up to ±2EV.
RThe indicator lamp lights while movies are being
recorded.

EN-2 ENGLISH
Changes and Additions
Focus Mode
Focus Mode
X-Pro2 (Version 3.10) Owner’s Manual: P65 *
Checking Focus
Checking Focus
To zoom in on the current focus area for precise focus, press the
center of the rear command dial. Press the center of the rear com-
mand dial again to cancel zoom. In manual focus mode, zoom can
be adjusted by rotating the rear command dial when STANDARD
or FOCUS PEAK HIGHLIGHT is selected for GAF/MF SETTING>
MF ASSIST, while if ON is selected for GAF/MF SETTING> FOCUS
CHECK, the camera will automatically zoom in on the selected focus area when the focus ring is rotated. Focus
area selection using the focus stick is available during focus zoom. Focus zoom is not available in focus mode
Cor when GAF/MF SETTING> PRE-AF is on or an option other than rSINGLE POINT is selected for AF
MODE.
M M

EN-3ENGLISH
Changes and Additions
A
A
SHOOTING SETTING
SHOOTING SETTING
X-Pro2 (Version 3.10) Owner’s Manual: P99 Ver. 5.00
FLICKER REDUCTION
FLICKER REDUCTION
Select ON to reduce icker in pictures and the display when shooting under uorescent lighting and other similar light sources.
QEnabling icker reduction disables the electronic shutter and increases the time needed to record pictures.
Options: ON/OFF

EN-4 ENGLISH
Changes and Additions
B
B
MOVIE SETTING
MOVIE SETTING
X-Pro2 (Version 3.10) Owner’s Manual: P104 Ver. 4.00
MOVIE MODE
MOVIE MODE
Select a frame size and rate for movie recording.
• U2160/29.97 P: 3840 × 2160 (29.97 fps)
• U2160/25 P: 3840 × 2160 (25 fps)
• U2160/24 P: 3840 × 2160 (24 fps)
• U2160/23.98 P: 3840 × 2160 (23.98 fps)
• i1080/59.94 P: 1920 × 1080 (59.94 fps)
• i1080/50 P: 1920 × 1080 (50 fps)
• i1080/29.97 P: 1920 × 1080 (29.97 fps)
• i1080/25 P: 1920 × 1080 (25 fps)
• i1080/23.98 P: 1920 × 1080 (23.98 fps)
• h720/59.94 P: 1280 × 720 (59.94 fps)
• h720/50 P: 1280 × 720 (50 fps)
• h720/29.97 P: 1280 × 720 (29.97 fps)
• h720/25 P: 1280 × 720 (25 fps)
• h720/23.98 P: 1280 × 720 (23.98 fps)

EN-5ENGLISH
Changes and Additions
D
D
SCREEN SETTING
SCREEN SETTING
X-Pro2 (Version 3.10) Owner’s Manual: P118 Ver. 5.00
LARGE INDICATORS MODE(EVF/OVF)
LARGE INDICATORS MODE(EVF/OVF)
Select ON to display large indicators in the electronic/optical viewnder (EVF/OVF). The indicators displayed can be selected
using DSCREEN SETTING > LARGE INDICATORS DISP. SETTING.
OFF ON
QSome icons are not displayed when ON is selected for LARGE INDICATORS MODE(EVF/OVF), including:
• Focus indicator • AF+MF indicator • Microphone/remote release
• Distance indicator • Focus mode • Others
RIf LARGE INDICATORS MODE is assigned to a function button, the button can be used to toggle LARGE INDICATORS
MODE on (ON) and o (OFF) (P51, 119).

EN-6 ENGLISH
Changes and Additions
D
D
SCREEN SETTING
SCREEN SETTING
X-Pro2 (Version 3.10) Owner’s Manual: P118 Ver. 5.00
LARGE INDICATORS MODE(LCD)
LARGE INDICATORS MODE(LCD)
Select ON to display large indicators in the LCD monitor. The indicators displayed can be selected using DSCREEN SETTING >
LARGE INDICATORS DISP. SETTING.
OFF ON
QSome icons are not displayed when ON is selected for LARGE INDICATORS MODE(LCD), including:
• Focus indicator • AF+MF indicator • Microphone/remote release
• Distance indicator • Focus mode • Others
RIf LARGE INDICATORS MODE is assigned to a function button, the button can be used to toggle LARGE INDICATORS
MODE on (ON) and o (OFF) (P51, 119).

EN-7ENGLISH
Changes and Additions
D
D
SCREEN SETTING
SCREEN SETTING
X-Pro2 (Version 3.10) Owner’s Manual: P118 Ver. 5.00
LARGE INDICATORS DISP. SETTING
LARGE INDICATORS DISP. SETTING
Choose the indicators displayed when ON is selected for D SCREEN SETTING > LARGE INDICATORS
MODE(EVF/OVF) or LARGE INDICATORS MODE(LCD).
Scale
Expo. DISP.
LARGE INDICATORS DISP. SETTING
Option
Option
Description
Description
A
A
Expo. DISP.
Expo. DISP. Choose the items listed at the bottom of the display. Selected items are indicated by check marks
(R); to deselect, highlight the check marks and press MENU/OK.
B
B
d
d
Scale
Scale Select ON to display the exposure indicator.
C
C
L1, L2, L3, L4
L1, L2, L3, L4 Choose up to four large icons for display on the left side of the screen.
D
D
R1, R2, R3, R4
R1, R2, R3, R4 Choose up to four large icons for display on the right side of the screen.

EN-8 ENGLISH
Changes and Additions
D
D
SAVE DATA SETTING
SAVE DATA SETTING
X-Pro2 (Version 3.10) Owner’s Manual: P123 Ver. 5.00
SELECT FOLDER
SELECT FOLDER
Create folders and choose the folder used to store subsequent pictures.
Option
Option
Description
Description
SELECT FOLDER
SELECT FOLDER To choose the folder in which subsequent pictures will be stored, press the selector up or down to
highlight an existing folder and press MENU/OK.
CREATE FOLDER
CREATE FOLDER Enter a ve-character folder name to create a new folder in which to store subsequent pictures.
