FujiFilm X-T2 User manual

BL00004989-200 EN
New Features Guide
Version 4.20
Features added or changed as a result of rmware updates
may no longer match the descriptions in the documentation
supplied with this product. Visit our website for information
on the updates available for dierent products:
http://www.fujifilm.com/support/digital_cameras/software/fw_table.html

Contents
X-T2 rmware version 4.20 adds or updates
the features listed below. For the latest manual,
visit the following website.
http://fujifilm-dsc.com/en/manual/
No. Description X-T2
P
See
PVer.
1
1
To view separate RGB histograms and a display
showing areas of the frame that will be overex-
posed at current settings superimposed on the
view through the lens, press the function button
to which HISTOGRAM is assigned.
22 1 3.00
2
2
The focus stick can be used to change focus areas
when the display is zoomed in during checking
focus.
83 2 *
3
3A ZFOCUS BKT item has been added to drive
modes.
95,
97 3 4.10
4
4
A ZFOCUS BKT option has been added to
ASHOOTING SETTING> DRIVE SETTING>
BKT SETTING> BKT SELECT in the shooting
menu.
150 4 4.10
5
5
A FOCUS BKT option has been added to
ASHOOTING SETTING> DRIVE SETTING>
BKT SETTING in the shooting menu.
150 5 4.10
6
6
A FLICKER REDUCTION option has been add-
ed to ASHOOTING SETTING in the shooting
menu.
155 7 4.10

No. Description X-T2
P
See
PVer.
7
7
A FULL HD HIGH SPEED REC option has been
added to BMOVIE SETTING in the shooting
menu.
167 8 4.10
8
8
A PERIPHERAL LIGHT CORRECTION (MOVIE)
option has been added to
B MOVIE SETTING in
the shooting menu.
167 9 4.10
9
9
Changes have been made to the content of the
BMOVIE SETTING> 4K MOVIE OUTPUT
option in the shooting menu.
168 10 4.10
10
10
A FULL HD MOVIE OUTPUT option has been
added to
B MOVIE SETTING in the shooting
menu.
168 11 4.10
11
11
A histogram has been added to the photo in-
formation that can be displayed by pressing the
selector up during full-frame playback.
175 12 3.00
12
12
An APERTURE UNIT FOR CINEMA LENS op-
tion has been added to DSCREEN SETTING
in the setup menu.
221 13 4.10
13
13
LARGE INDICATORS MODE(EVF) and
LARGE INDICATORS MODE(LCD) options
have been added to DSCREEN SETTING in
the setup menu.
222 14
15 4.10
14
14
A LARGE INDICATORS DISP. SETTING op-
tion has been added to D SCREEN SETTING in
the setup menu.
222 16 4.10
15
15 A SELECT FOLDER option has been added to
DSAVE DATA SETTING in the setup menu. 241 17 4.20

No. Description X-T2
P
See
PVer.
16
16
TheDCONNECTION SETTING> PC SHOOT
MODE option in the setup menu has changed to
PC CONNECTION MODE.
247 18 3.00
17
17 Third-party studio flash commanders compatible
with the FUJIFILM flash system can now be used. 265 20 3.00
18
18
In addition to the instax SHARE printers listed
in “Accessories from FUJIFILM”, the camera now
supports the SP-3.
307 21 3.00
N
The asterisks in the “Ver.” column indicate features available in
earlier versions; only the descriptions in the manual have been
changed.

1
Changes and Additions
Changes and additions are as follows.
X-T2 (Version 2.10) Owner’s Manual: P22 Ver. 3.00
Customizing the Standard Display
Histograms
Histograms show the distribution of tones in the image. Brightness is
shown by the horizontal axis, the number of pixels by the vertical axis.
Number of
pixels
Shadows Highlights
Pixel brightness
• Optimal exposure: Pixels are distributed in an
even curve throughout the tone range.
• Overexposed: Pixels are clustered on the right
side of the graph.
• Underexposed: Pixels are clustered on the left
side of the graph.
To view separate RGB histograms and a dis-
play showing areas of the frame that will be
overexposed at current settings superim-
posed on the view through the lens, press
the function button to which HISTOGRAM
is assigned.
AOverexposed areas blink
BRGB histograms
AB

2
X-T2 (Version 2.10) Owner’s Manual: P83 *
The Focus-Point Display
Checking Focus
To zoom in on the current focus area
for precise focus, press the control to
which focus zoom has been assigned
(at default settings, the center of the rear
command dial). Press the control again
to cancel zoom.
M M
Normal display Focus zoom
N
In focus mode S, zoom can be adjusted by rotating the
rear command dial when STANDARD or FOCUS PEAK
HIGHLIGHT is selected for GAF/MF SETTING> MF
ASSIST. Focus area selection using the focus stick is
available during focus zoom. Focus zoom is not avail-
able in focus mode Cor when GAF/MF SETTING>
PRE-AF is on or an option other than rSINGLE POINT
is selected for AF MODE.
Use D BUTTON/DIAL SETTING> Fn/AE-L/AF-L BUTTON
SETTING to change the function performed by the center
of the command dial or assign its default function to other
controls.

3
X-T2 (Version 2.10) Owner’s Manual: P95 Ver. 4.10
Bracketing
2 Navigate to DRIVE SETTING in the ASHOOTING
SETTING menu and select OAE BKT, WISO
BKT, XFILM SIMULATION BKT, VWHITE
BALANCE BKT, YDYNAMIC RANGE BKT, or
ZFOCUS BKT.
X-T2 (Version 2.10) Owner’s Manual: P97 Ver. 4.10
ZFOCUS BKT
Each time the shutter button is pressed, the cam-
era takes a series of photos, varying focus with each
shot. The number of shots, the amount focus chang-
es with each shot, and the interval between shots
can be selected using ASHOOTING SETTING>
DRIVE SETTING> BKT SETTING> FOCUS BKT.

4
X-T2 (Version 2.10) Owner’s Manual: P150 Ver. 4.10
BKT SETTING
Option
Option
Description
Description
BKT SELECT
Choose from OAE BKT, WISO BKT, XFILM
SIMULATION BKT, VWHITE BALANCE BKT,
YDYNAMIC RANGE BKT, and ZFOCUS BKT.

5
X-T2 (Version 2.10) Owner’s Manual: P150 Ver. 4.10
FOCUS BKT
Option
Option
Description
Description
FOCUS BKT
The following settings are available when BKT SELECT
is chosen for Z FOCUS BKT.
Option
Option
Description
Description
FRAMES Choose the number of shots.
STEP Choose the amount focus changes with
each shot.
INTERVAL Choose the interval between shots.
N
• Do not adjust zoom during shooting.
• The supplied flash does not fire.

6
Focus and FRAMES/STEP
The relation between focus and the options chosen for
FRAMES and STEP is shown in the illustration.
12345
:
Starting focus position
• Focus proceeds from the starting position toward infinity.
• Small STEP values translate to small changes in focus, larger
values to larger changes.
• Regardless of the option chosen for FRAMES, shooting ends
when focus reaches infinity.
Frames
Step

7
X-T2 (Version 2.10) Owner’s Manual: P155 Ver. 4.10
FLICKER REDUCTION
Select ON to reduce icker in pictures and the display
when shooting under uorescent lighting and other
similar light sources.
Options
Options
ON OFF
O
Enabling icker reduction disables the electronic shutter
and increases the time needed to record pictures.

8
X-T2 (Version 2.10) Owner’s Manual: P167 Ver. 4.10
FULL HD HIGH SPEED REC
Record high-frame-rate Full HD movies that play back
in slow motion, giving you time to view fast-moving
subjects or details too eeting for the naked eye: a bat-
ter’s swing, darting insects, or swiftly-owing waters.
Option
Option
Description
Description
2x a59.94P
F120P
Record Full HD footage at 2×, 4×, or 5× speed and
frame rates of 120 or 100 fps. The movies play back
at ½, ¼, or ⁄ speed. Maximum recording length is
6 minutes.
2x a50P
F100P
4x a29.97P
F120P
4x a25P
F100P
5x a24P
F120P
5x a23.98P
F120P
OFF High-speed recording off.
N
High-speed movies are recorded with no sound.

9
X-T2 (Version 2.10) Owner’s Manual: P167 Ver. 4.10
PERIPHERAL LIGHT CORRECTION (MOVIE)
Select ON to enable peripheral illumination correc-
tion during movie recording.
Options
Options
ON OFF
N
Select OFF if you notice banding in movies recorded
using this option. If ON is selected when a lens that
does not transmit data to the camera is attached using
a FUJIFILM M MOUNT ADAPTER (available separately),
peripheral illumination will be adjusted according to the
option selected for ASHOOTING SETTING> MOUNT
ADAPTER SETTING> PERIPHERAL ILLUMINATION
CORRECTION in the shooting menu (P159).

10
X-T2 (Version 2.10) Owner’s Manual: P167 Ver. 4.10
4K MOVIE OUTPUT
Choose the destination for 4K movies shot while the
camera is connected to an HDMI recorder or other
device that supports 4K.
Option
Option
Description
Description
b4K YFHD 4K movies are recorded to a camera memory card in
4K and output to the HDMI device in Full HD.
bFHD Y4K 4K movies are output to the HDMI device in 4K and
recorded to the camera memory card in Full HD.
b−Y4K
4K movies are output to the HDMI device in 4K.
The camera does not record 4K movies to a mem-
ory card.
F-Log
b4K Y− *
4K movies are recorded to a camera memory card in
4K but are not output to the HDMI device.
F-Log
bFHD Y4K*
4K movies are output to the HDMI device in 4K and
are recorded to the camera memory card in Full HD.
F-Log
b− Y4K *
4K movies are output to the HDMI device in 4K. The
camera does not record 4K movies to a memory
card.
* Movies shot with an F-Log option are recorded using a gentle gamma
curve with a wide gamut, suitable for footage intended for post-produc-
tion processing. The minimum value for sensitivity is ISO800.
N
This option is only available when U is selected for
B MOVIE SETTING> MOVIE MODE in the shooting menu.

11
X-T2 (Version 2.10) Owner’s Manual: P167 Ver. 4.10
FULL HD MOVIE OUTPUT
Choose the destination for Full HD movies shot while
the camera is connected to an HDMI device.
Option
Option
Description
Description
b
FHD Y FHD
Full HD movies are output to the HDMI device and
recorded to the camera memory card.
b−YFHD Full HD movies are not recorded to the camera
memory card but are output to the HDMI device.
F-Log
bFHD Y− *
Full HD movies are recorded to a camera memory
card in Full HD but are not output to the HDMI device.
* Movies shot with an F-Log option are recorded using a gentle gamma
curve with a wide gamut, suitable for footage intended for post-produc-
tion processing. The minimum value for sensitivity is ISO 800.
N
This option is only available when iis selected for
BMOVIE SETTING> MOVIE MODE in the shooting
menu.

12
X-T2 (Version 2.10) Owner’s Manual: P175 Ver. 3.00
The DISP/BACK Button
Viewing Photo Information
The photo information display changes
each time the selector is pressed up.
Basic data Histogram
12/31/2050 10:00 AM
BACK
1/4000
S.S
5.6
F400 +21/3 ISO
LENS 23.0 mm
F
5.6
FOCAL LENGTH 23.0 mm
COLOR SPACE sRGB
LENS MODULATION OPT. ON
NEXT
12/31/2050 10:00 AM
Info display 2 Info display 1

13
X-T2 (Version 2.10) Owner’s Manual: P221 Ver. 4.10
APERTURE UNIT FOR CINEMA LENS
Choose whether the camera displays aperture as
a T-number (used for movie camera lenses) or an
f/-number (used for still camera lenses) when an op-
tional FUJINON MKX-series lens is attached. For infor-
mation on using cinema lenses, see the documenta-
tion provided with the lens.
Option
Option
Description
Description
T NUMBER
A measure of lens aperture commonly used by cin-
ematographers. Lens transmittance is taken into ac-
count to better calculate exposure.
F NUMBER
A measure of lens aperture commonly used by
photographers. Lens transmittance is assumed to
be 100%, meaning that the same aperture may pro-
duce different exposures depending on the lens.

14
X-T2 (Version 2.10) Owner’s Manual: P222 Ver. 4.10
LARGE INDICATORS MODE(EVF)
Select ON to display large indicators in the electronic
viewnder. The indicators displayed can be selected
using DSCREEN SETTING > LARGE INDICATORS
DISP. SETTING.
OFF ON
O
Some icons are not displayed when ON is selected for
LARGE INDICATORS MODE(EVF), including:
• Focus indicator
• Focus mode
• Distance indicator
• Recording level
• IS mode
• AF+MF indicator
• Control lock
N
If LARGE INDICATORS MODE is assigned to a func-
tion button, the button can be used to toggle
LARGE INDICATORS MODE on (ON) and o (OFF)
(P226, 256).

15
X-T2 (Version 2.10) Owner’s Manual: P222 Ver. 4.10
LARGE INDICATORS MODE(LCD)
Select ON to display large indicators in the LCD mon-
itor. The indicators displayed can be selected using
DSCREEN SETTING > LARGE INDICATORS DISP.
SETTING.
OFF ON
O
Some icons are not displayed when ON is selected for
LARGE INDICATORS MODE(LCD), including:
• Focus indicator
• Focus mode
• Distance indicator
• Recording level
• IS mode
• AF+MF indicator
• Control lock
N
If LARGE INDICATORS MODE is assigned to a func-
tion button, the button can be used to toggle LARGE
INDICATORS MODE on (ON) and o (OFF) (P226,
256).

16
X-T2 (Version 2.10) Owner’s Manual: P222 Ver. 4.10
LARGE INDICATORS DISP. SETTING
Choose the indicators
displayed when ON is selected
for DSCREEN SETTING >
LARGE INDICATORS
MODE(EVF) or LARGE
INDICATORS MODE(LCD).
Scale
Expo. DISP.
LARGE INDICATORS DISP. SETTING
Option
Option
Description
Description
A
Expo. DISP.
Expo. DISP.
Choose the items listed at the bottom of the dis-
play. Selected items are indicated by check marks
(R); to deselect, highlight the check marks and
press MENU/OK.
B
d
d
Scale
Scale Select ON to display the exposure indicator.
C
L1, L2, L3, L4
L1, L2, L3, L4 Choose up to four large icons for display on the
left side of the screen.
D
R1, R2, R3, R4
R1, R2, R3, R4 Choose up to four large icons for display on the
right side of the screen.
