FujiFilm EC-3000 User manual

IMPORTANT SAFETY INSTRUCTIONS
IMPORTANT SAFETY INSTRUCTIONS ...........................................................................1
Preparation Before Use ..........................................................................................................5
Name and Functions of Components...................................................................................10
Before Starting Massage ...................................................................................................... 12
How to Adjust the Chair.......................................................................................................13
How to Use the AUTO-COURSE........................................................................................ 16
How to Use the Quick Mode................................................................................................21
Adjustment during massaging with AUTO-COURSE or in QUICK MODE ...................... 24
Registration in the Memory .................................................................................................29
Basic Movements of Massage..............................................................................................32
Using the WAIST/HIP massage functions ...........................................................................33
Using the Mecha. (knead balls) massage functions .............................................................35
Adjustment during the movement of Mecha. (knead balls) massage functions...................38
Using the Air-massage functions.......................................................................................... 41
Adjustment during the movement of LEG stretch function.................................................42
Using the Shoulders/Arms Air-massage functions...............................................................43
Adjustment during the movement ofAir-massage functions...............................................45
Combination massage of Mecha. (knead balls) and Air.......................................................47
When changing the massage on the way..............................................................................51
Other functions.....................................................................................................................55
Care and storing...................................................................................................................57
Q & A...................................................................................................................................58
When trouble is suspected....................................................................................................59
(Effect and Efficacy) Substitution of professional masseur
Recovery from fatigue
Promotion of blood circulation
Removal of muscular fatigue
Relief of muscular stiffness
Alleviation of neuralgia or muscular pain
Thank you for your purchasing of Massage Chair EC-3000.
Read this manual carefully beforehand to use the product properly.
After reading through, keep this manual at a safe place where you can consult whenever it is
necessary.
Contents

IMPORTANT SAFETY INSTRUCTIONS
1
When using an electrical appliance, basic precautions should always be followed, including the following:
Read all instructions before using this appliance.
DANGER To reduce the risk of electric shock:
1. Always unplug this appliance from electrical outlet immediately after using and before cleaning.
2. Improper connection of the equipment-grounding conductor can result in a risk of electric shock.
Check with a qualified electrician or serviceman if you are in doubt as to whether the product is properly
grounded. Do not modify the plug provided with the product - if it will not fit outlet, have a proper outlet
installed by a qualified electrician.
WARNING To reduce the risk of burns, fire, electric shock, or injury to persons:
1. An appliance should never be left unattended plugged in.
Unplug from outlet when not in use, and before off parts.
2. Do not operate under blanket or pillow.
Excessive heating can occur and cause fire, electric shock, or injury to persons.
3. Close supervision is necessary when this appliance is used by, on, or near children, invalids, or
disabled persons.
4. Use this appliance only for its intended use as described in this manual.
Do not use attachments not recommended by the manufacturer.
5 Never operate this appliance if it has a damaged cord or plug, if it is not working properly, if it has
been dropped or damaged, or dropped into water.
Return the appliance to a service center for examination and repair.
6. Do not carry this appliance by supply cord or use cord as a handle.
7. Keep the cord away from heated surfaces.
8. Never operate the appliance with the air openings blocked.
Keep the air openings free of lint, hair, and the like.
9. Never drop or insert any objects into any opening.
10. Do not use outdoors.
11. Do not operate where aerosol (spray) products are being used or where oxygen is being
administered.
12. To disconnect, turn all controls to the off position, then remove plug from outlet.

IMPORTANT SAFETY INSTRUCTIONS
2
WARNING
13. Grounding Instructions
This product must be grounded. If it should malfunction or breakdown, grounding provides a path of least
resistance for electric current to reduce the risk of electric shock. This product is equipped with a cord
having an equipment-grounding conductor and a grounding plug. The plug must be plugged into an
appropriate outlet that is properly installed and grounded in accordance with all local codes and
ordinances.
This product is for use on a nominal 120-volt circuit, and has a grounding plug that look like the plug
illustrated in sketch A. A temporary adapter that looks like the adapter illustrated B and C may be used to
connect the plug to a 2-pole receptacle as shown in sketch B if a properly grounded outlet is not available.
The temporary adapter should be used only until a properly grounded outlet (sketch A) can be installed by
a qualified electrician. The green colored rigid ear, lug, or the like extending from the adapter must be
connected to a permanent ground such as a properly grounded outlet box cover.
Whenever the adapter is used, it must be held in place by a metal screw.
14. Massager is intended for Household Use Only.
15. Be sure to check that there is not anybody (children in particular), pet or obstacle behind prior to
inclining the Back Rest.
Otherwise, it may result in a cause of injury or trouble.
16. Be sure to check that there is not anybody (children in particular), pet or obstacle behind prior to
lowering the Foot Rest.
Otherwise, it may result in a cause of injury.
17. Be careful not to operate the Back Rest with the cord wound on the main unit, or with the cord
hooked to the other obstacle.
Otherwise, the unreasonable force may be applied to the cord, probably resulting in a cause of fire or
electric shock.
18. Be careful not to put the hand into the clearance at the underside of Back Rest or to the clearance
between the Back Rest and Arm Rest.
Otherwise, it may result in a cause of injury.
- Sketch A -
GROUNDING METHODS
- Sketch B - - Sketch C -
Grounded
outlet
Grounding
pin
Grounded
outlet box
Adapter
Metal
screw
Tab for
grounding screw
Save these instructions

IMPORTANT SAFETY INSTRUCTIONS
3
WARNING
19. Do not attempt to stand on the Arm Rest, Foot Rest or Back Rest.
Otherwise, the massager may fall down, resulting in injury.
20. Do not use the massager on the head, arm, knee or abdomen. As well as, do not put your hand or
leg between knead ball.
Otherwise, the user may feel sick or an injury may occur.
21. Do not attempt to plug/unplug the power plug with wet hands.
Otherwise, it may result in injury or electric shock.
22. When the cover cloth is broken (when the built-in mechanism is exposed), do not use such
massager, but send it for repair.
Otherwise, it may result in a cause of accident, or injury.
23. Never attempt to disassemble the massager. Do not allow any personnel other than repair engineer
to disassemble or repair the massager.
Otherwise, it may result in a cause of fire, electric shock or injury.
24. The following persons are requested to consult a doctor prior to use.
Otherwise, the user may feel sick or an injury may occur.
Those who are under the medical treatment or particularly those who complain of indisposition
Those who have malign tumors
Those who suffer from heart trouble
Those who are in menstrual period or pregnant
Those who require complete rest
Those whose backbone is abnormal or bent
Those who desire to use the massager on a part of the body that is diseased or receiving medical
treatment
Those who are feverish (38C or over)
Those who have weak bones (osteoporosis etc.)
25. If sickness or pain is felt during use, stop using the massager and consult a doctor immediately.
Otherwise, it may result in injury.
26. Attempt to use the massager up to 15 minutes for each use. Limit the use of massager at one point,
up to 5 minutes.
Otherwise, the use of massager at one point for a long time continuously may result in adverse effect.
27. Check the knead ball position for the sake of safety before leaning on the massager slowly. Do not
twist the body, but lean on the massager straight, so that the backbone is located at center of
knead ball.
Otherwise, leaning on the massager abruptly may injure the backbone or result in injury.
28. Do not pull the cord, but the plug, when unplugging the massager.
Otherwise, the electric shock or short-circuit may occur, resulting in fire.
29. Do not use the massager with bare skin.
Otherwise, it may result in a cause of injury.
30. Do not move the massager with a person on it.
Otherwise, the massager may fall down.

IMPORTANT SAFETY INSTRUCTIONS
4
WARNING
31. After use, be sure to set the POWER switch to [OFF] position.
Otherwise, it may result in accident or injury due to child's mischief.
32. Do not attempt to pull the Back Pad forcibly or hang from the Back Pad.
Otherwise, the Back Pad may come off, probably resulting in injury or broken massager.
33. Do not attempt to damage, bend, pull, twist, or bundle the cord forcibly.
Otherwise, the cord may break, resulting fire or electric shock.
34. Do not use the massager on other than the designated voltage.
Otherwise, it may result in a cause of fire or electric shock.
35. Do not use the massager in the bathroom, or places where humidity is high.
Otherwise, it may result in electric shock or damage.
36. When the massager becomes inoperative, disconnect the power plug immediately for prevention of
accident, and ask the sales agent for inspection/repair information.
Otherwise, it may result in fire due to electric shock, leaking current, short circuit, etc.
37. Switch the power [OFF] instantly at the time of power failure, as well as pull the power plug out
from the socket.
Otherwise, it would become dangerous at the time of power comeback.
38. Be careful not to fall asleep during massage.
Otherwise, it may result in a cause of accident or injury.
39. Do not use the massager with other medical instruments (excluding foot type massager).
Otherwise, it may result in an accident or injury.
40. Place the massager main unit at a level floor surface.
Otherwise, if it is placed at an unstable place, it may fall down, probably resulting in a cause of injury.
41. The maximum permissible weight of the massager is 100 kilograms.
Do not use the massager with those who weigh more than 100 kilograms.
Otherwise, an accident may happen or damage to the machine may result.

Preparation Before Use
5
Take out the MAIN BODY and ACCESSORIES from the box.
[MAIN BODY] [ACCESSORIES]
Assembling and Folding the Back-Rest.
Raise the back-rest to the arrow direction,
and make sure that the stopper (encircled)
is locked, when a click sound can be heard.
Press down the stopper (encircled) to the
arrow direction, and fold the back-rest slowly
forward.
* Be careful not to turn the back-rest quickly.
* The back-rest cannot be turned when it is equipped
with the shoulder unit and the arm unit.
Becarefulnottogethandorfingers
caughtbetweenthearm-restandthe
back-rest.
Do not touch any sections other than
indicated with the circle when
operating the stopper.
Arm unit
Hexagonal wrench for
the s
houlder unit
Mounting screw (2 pcs.)
Shoulder unit
Left Right
Pillow
Front
Rear Front
Rear
Front
Rear
Back pad
Which shoulder unit
should be in right or left,
can be identified with the
air joint on the rear side.
Air joint
Shoulder cap
(2 pcs.)
Mounting screw (4 pcs.)
CAUTION
CAUTION
Stopper
Stopper
Lock
Release
Remote Controller Stand
Cap for the arm unit (open)
Cap for the arm unit (closed)
User Manual Grounding Cable
Hexagonal wrench for the
remote controller stand
Quick Operation
Guide
Do not use any accessories other than
those packaged.
Request

Preparation Before Use
6
Installation of the Shoulder Unit.
1. Install the Shoulder Unit with the
back-rest at the upright
position.
2. Insert the Shoulder Unit convex and
the air joint in the hole on the
back-rest.
3. Fix securely at two places with a pair
of mounting screws.
4. It is complete once the cap has been
installed.
Installinthesamewayalsoattheoppositeside.
Whendisassembling,proceedreferringtothe
installationmethod.
Make sure to install the Shoulder Unit securely. Otherwise,
it could cause air leakage or injury ormechanicaltrouble if
the unit has dropped off accidentally.
Installation of the Arm Unit.
1. Install the Arm Unit with the back-rest
at the upright position.
2. Insert the Arm Unit convex into the
hole of arm-rest.
3. Pressdownthe Arm
Unit a clicksound
canbe heard.
4. When removing the Arm Unit, insert the hexagonal
wrench in the hole.
Pull it upward while
pressing the button.
Installinthesamewayalsoattheoppositeside.
Whendisassembling,proceedreferringtothe
installationmethod.
Make sure to install the Arm Unit securely. Otherwise, it
could cause air leakage orinjury or mechanical trouble if
the unit has dropped off accidentally.
Shoulder Unit
Holes
Convex
Air joint
Mounting screw
Hexagonal
wrench
* In tightening the mounting screw, use fingers
first until it reaches the innermost. When you
find it difficult to tighten it, try to press the
Shoulder Unit with hand. With the screw at
the innermost, fix it with the hexagonal wrench.
CAUTION
Request
Cap
CAUTION
Request
Arm Unit
Arm
Unit
Holes
Locking mechanism
enlarged
* Arm Units are
identical at
right and left.
Convex
Hole*
Hexagonal wrench
* The hole of the Arm Unit
at the opposite side is on
the back
-
rest.
Button
Back-rest side

Preparation Before Use
7
How to install the Back Pad and the Pillow.
Install the Back Pad on the zipper of the back-rest. Install the Pillow on the Velco tape of the Back Pad.
1. Install the Back Pad. 2. Install the Pillow.
When massaging, place the pillow behind.
If you feel massaging strength strong, use the pillow.
When not massaging, use the chair as the recliner with the back pad and the pillow installed.
Before use, tuck up the back pad to make sure that there is no tear on the cover cloth of the
back-rest and on the other parts. (Should there be any tear, no matter how small it is,
discontinue using the chair immediately, disconnect the power cord plug, and ask for repair.)
Continued use with the cloth torn may cause electric shock or any hazard on the body.
Installation of the Remote Controller Stand.
* The Remote Controller Stand is designed to be installed at the left side. Should it need to be
installed at the right side, take the procedure as detailed in the next page.
1. Put the cap on the arm
unit on the right-side
arm-rest.
* The Remote Controller Stand
can be installed either at the
right side or at the left side.
 
 
2. Fix the Remote
Controller Stand on
the arm unit on the
left-side arm-rest with
the mounting screws
at 2 places.
3. Finish up the work by
installing the cap
(open).
[How to adjust the Remote
Controller Holder]
Loosen the fixing screw to a
desired position, and fix it
tightly.
[How to install or remove
the Remote Controller]
Installation:
Push it down
from upward.
Removal:
Pull it up
upward.
[View of the finished work]
Get a piece of
string through
the Remote
Controller
Stand to hang
down the
Quick
Operation
Manual.
To remove the Remote Controller
stand, reverse the order of
installation.
Make sure to install the Remote Controller Stand securely.
Otherwise, it could cause injury or mechanical trouble if
the stand has dropped off accidentally.
Back Pad Zipper
Pillow Velco tape
Cap
Right side
Left side
Left side
Mounting
screw
Cap (open)
Remote Controller
Holder
Tightening
Loosening
Fixing screw
Request CAUTION
Hexagonal
wrench
WARNING
Remote Controller Stand

Preparation Before Use
8
How to replace the Remote Controller Stand.
<In case the Remote Controller Stand, after being installed,
needs to be replaced from left to right side.>
First, take the following procedures:
Remove the pillow and the back pad (see Page 7).
Remove the Remote Controller from its stand.
Then, remove the shoulder unit and the arm unit,
and turn the back-rest forward (see Page 5, 6 and 7).
* The Remote Controller Stand does not have to be removed from the arm unit.
<In case the Remote Controller Stand is installed at the right side from the first, take
the following procedures starting 1.>
1. Remove the rubber cord grip behind the arm-rest ①.
2. Remove the Remote Controller cord from its cord grip ②.
3. Hang the Remote Controller cord on the cord grip at the opposite side ③.
4. Adjust the position of the rubber cord grip so that the cord may not loosen, and
insert the grip into the hole of the arm-rest ④.
The cord may snap if it loosens.
5. Raise the back-rest, and install the arm unit equipped with the Remote Controller
Stand at the opposite side (see Page 7).
6. Adjust an angle of the Remote
Controller holder.
7. Install the pillow and the
back pad (see Page 7).
Request
Power switch
Remove the rubber cord
together with its grip.
Caster
Cord
grip
Remote
Controller cord
Rubber cord grip
Hole
Cord grip
Rubber cord grip
Cord grip
[View of the finished work]
Rotate the stand at 180

.
Fixing screw
Tighten
Loosen

Preparation Before Use
9
Where to place the chair.
Place the chair on a level surface with enough space
around.
■Request: With the back-rest reclined backward, the foot-rest
comes up. Keep space of 70cm or more ahead and
60cm or more behind.
■Request: The chair may damage the floor. Spread a mattress
for protection.
■Request: Avoid placing the chair at the place exposed to the
direct ray of the sunshine for long hours every day
or at the place of high temperature, e.g. close to a
heater. The cover cloth may discolor or change in
quality.
How to move the chair.
Lift up the front side of the chair, and push it forward.
 Do not move the chair with a person or any object
seated on it to avoid the possible upset.
 Do not move the chair with its casters, or do not drag
it on the floor so as notto damage the floorsurface.
 Do not hold the seat, the foot-rest or the shoulder
unit to move the chair.
 Be careful when lifting up the front side of the
chair; it is very heavy.
Grounding connection.
Be sure to make grounding connection.
Without grounding connection,
leakage may cause electric shock.
For inquiry on grounding
connection, contact your dealer.
The receptacle in your place is already
equipped with the grounding terminal.
Connect the grounding cable
(packaged) with the
grounding terminal of the
receptacle of the grounding
terminal screw of the chair.
Gas pipe so as not to cause the hazard
of explosion ornot to catch fire.
Telephone cord orlightening rod not so
asto cause the hazard by thunderbolt.
Water pipe with plastics used partly,
since it does not function as
grounding connection.
* (Grounding terminals are provided on the models for
Thailand, Sweden, France and Russia.)
The receptacle in your place is not
equipped with the grounding terminal.
Contact your dealer or any electrical worker
for grounding connection.
CAUTION
Do not make grounding connection
at the following places:
60 cm or more
70cm or more
Caster
Lift up the front
side of the chair
CAUTION
Grounding cable

Name and Functions of Components
10
Back Pad
Relax and lay the bac
k on
here.
Pillow
Main Body Put it behind when massaging.
Shoulder
Air-massage on the shoulder.
Arm
Air-massage on the arm.
Arm-Rest
Seat Pad
Seat
Air
-
massage
hip
and thighs.
Foot-Rest
Air
-
massage legs and
feet.
Back-Rest
In addition to the entire back, the
air-massage is applied also to the
back and the waist.
Massaging Position
PowerSwitch
Turn
OFF
after
use.
Power Cord Plug
Power
Cord
Grounding Terminal*
Mecha. (knead balls)
massaging area
Back
Shoulder
Waist
Arm
Thigh
Calf
Caution Seal
Remote Controller Stand
Caution Tag
Quick Operation Guide
Caster
Air Bag
Ankle
Sole
*
Install the grounding cable.
(Grounding terminals are provided
on the models for Thailand,
Sweden, France and Russia.)

Name and Functions of Components
11
Remote Controller
LCD display
Various functions are
available.
“START/RESET”button
Start or stop massage, and store
the knead balls.
“AUTO-COURSE”button
11
AUTO
-
COURSE
options
are available in combination of
massaging positions and
massage types.
“AIR”button
4
air
-
massage options are
available.
“REPEAT”button
Repeatedly continue the current
option selected from the
AUTO-COURSE options.
“SKIP”button
Discontinue the current option
and change into another
AUTO-COURSE option.
“SHOULDER”button
Turn
“
ON
/
OFF
”
air
-
massage of
shoulders and changes the massaging
strength in one of the 5 steps.
“MENU”button
Adjust the current option.
“CROSS KEY”
Select any option in various
functions.
“WAIST/HIP”button
Turn
“
ON
/
OFF
”
massage of
WAIST/HIP
“ENTER”button
Determine any option.
“UP”or “DOWN”button
Adjust an angle of the “foot
-
rest.”
* “Air”does not function while the
foot-rest goes up or down.
“FOWARD”or“BACK”
button
“QUICK”button
Select any
AUTO
-
COURSE
option
preprogrammed for each of the
standard body shapes.
“STOP”button
Discontinue any in
-
progress
movement. (Press this button when
you have to discontinue massage at
once.)
“FUNCTION”button
Select any one out of 22 massaging
options.
“HEIGHTADJUSTMENT”button
Finely adjust the shoulder position while in
massage of any AUTO-COURSE option or
when fixing the shoulder position in the
process of selecting any function.
* The knead balls can be repositioned in the process of
selecting any function.
* When the knead balls are positioned around shoulders
or back in any AUTO-COURSE option, a display for
finely adjusting the “SHOULDER”position comes
out. When they are around WAIST, a display for
finely adjusting the “WAIST”position comes out.
Fine adjustment function of the “WAIST”position is
available only for “EXTREME KNEAD WAIST”and
“EXTREME TAPPING WAIST.”
“ARM”button
Select any option out of “
ARM
KNEAD
/
ARM GRASP / STOP”functions.
Or, adjust the massaging strength at one
of the 3 steps.
“LEG”stretch button
Select stretching or not.
“RESET”button
Store the back
-
rest and the foot
-
rest.
* The back-rest does not go up completely.
Adjust the
foot
-
rest
length.
* “AIR”does not function while forward
or backward the foot-rest.
STOP
START
/RESET
AUTO FUNCTION
AIR
REPEAT
SKIP
SHDR
MENU
ARM
ENTER
FOOTREST RECLINER
RESET
FORWARD BACK
HEIGHT
ADJUSTMENT
RECLINER “UP”, “DOWN”button
Adjust an angle each of the back
-
rest
and the foot-rest. The foot-rest moves
in link with the back-rest.
* While in reclining, the movements of
“AIR”, “TAPPING”and “WAVELET”do
not function.
W/H LEG

Before Starting Massage
12
Power ON.
1. Connect the power cord plug with the
receptacle.
2. Power ON.
The power switch is behind the left arm-rest.
After power ON, the LCD in the initial stage
displays the screens as shown on the right side
alternately.
Do not use the massageron other than the
designated voltage.
Do not use the chair when the power cord or its plug
isdamaged, or when the receptacle is loosened.
It could electric shock, short circuit orfire.
Check items.
1. Check around the chair.
①Check to make sure that there is nobody, no pet and nothing ahead and
behind the chair and under the foot-rest.
<Standby position>
Press the “START/RESET”button to start massage. Then, the foot-rest
automatically comes up at about 55.
* Be sure to check that there is nothing around.
2. Check the main body itself.
①Hold up the back pad, and check to make sure
that the cover cloth of the back-rest is not torn
and that there is no tear in any other parts.
* Should there by any tear, no matter how
small it is, discontinue using the chair
immediately. Disconnect the power cord
plug, and contact your dealer for repair.
②Checktomake sure that none ofthe powercord,
the Remote Controllercordorany other materials
is pinched in the mainbody.
③Check to make sure that there is no damage in
the power cord, Remote Controller cord and
the power cord plug and that nothing of dust
(e.g. pins) is attached to the plug.
④Before seated onthe chair, make sure where
there are the knead balls.
The knead balls are
usually located at
the stored position
(in the innermost at
the lower part of
the back-rest)
When the knead balls are not located at the stored
position, press the “START/RESET”button.
They move down tothe lowest position. Press it
again, and then,they go back to the storedposition.
⑤Before seated onthe chair, make sure where
there is the foot-rest.
Do not be seated forcibly with the foot-rest at
the upright position. Such attempt may result
in injury. Press the foot-rest [▼] button or the
“RESET”button to lower the foot-rest.
* Press the “RESET”button. Then, the
back-rest is also stored.
FOOTREST RECLINER
RESET
FORWARD BACK
Stored
position
WARNING
Back pad
Pillow pad
ST OR E

How to Adjust the Chair
13
How to use the RECLINER.
1. To turn down the back-rest, press the RECLINER []
button.
Continue to press the RECLINER [▼] button.
The back-rest turns down backward, and the foot-rest
comes up.
The deeper it turns down, the stronger the knead balls’
movement becomes.
2. Release your finger from the RECLINER [] button at
a desired angle.
Foot-rest angle will change depending on the reclining
angle of back-rest.
3. To raise the back-rest, press the RECLINER [] button.
Holding down the RECLINER [] button raises the
back-rest while the foot-rest is lowered.
Before reclining the back-rest, before raising or
lowering the foot-rest, or before stretching or
shortening the leg length, check to make sure that
there is nobody, no pet ornothing ahead and
behind the chair and under the foot-rest.
Negligence may result in accident, hazard on the
body or damage in furniture.
Do not allow anybody to ride on the
back-rest, the arm-rest, the foot-rest or the
shoulder unit.
The chair may overturn, and
the user may fall down and
hurt himself/herself.
■Request: When using the reclining during the massage, turn down the back-rest gradually observing
the change in the intensity of massage.
Upright position Backward position
CAUTION WARNING
STOP
START
/RESET
AUTO FUNCTION
AIR
REPEAT
SKIP
SHDR
MENU
ARM
ENTER
FOOTREST RECLINER
RESET
HEIGHT
ADJUSTMENT
FORWARD BACK
W/H LEG

How to Adjust the Chair
14
How to use the FOOT-REST.
1. To raise the FOOT-REST, press the FOOT-REST [▲]
button.
Continue to press the FOOT-REST [▲] button.
The FOOT-REST comes up.
2. Release your finger from the FOOT-REST [▲]
button at a desired angle.
3. To lowerthe foot-rest, press the FOOT-REST [▼] button.
Continue to press the FOOT-REST [▼] button.
The FOOT-REST goes down.
Before lowering the foot-rest, be careful not to have your
foot or hand pinched in it. Check to make sure that
there is nobody, no pet or nothing under the foot-rest.
Negligence may result in hazard on the body.
Downward position Upward position
WARNING
STOP
START
/RESET
AUTO FUNCTION
AIR
REPEAT
SKIP
SHDR
MENU
ARM
ENTER
HEIGHT
ADJUSTMENT
W/H LEG
FORWARD BACK
RESET
FOOTREST RECLINER

How to Adjust the Chair
15
How to FORWARD or BACK the FOOT-REST.
1. To raise the foot-rest at a desired angle, continue to
press the foot-rest button [▲]
The function of FORWARD or BACK is not available when
the foot-rest is positioned at 30or less.
In a range of 30- 55, the FORWARD length varies.
The FORWARD length becomes longest at an angle of 55or more.
2. To FORWARD the foot-rest at a desired length,
continue to press the foot-rest [] button.
Continue to press the [] button.
The foot-rest is forwarded.
3. To BACKthe foot-rest, press the foot-rest[] button.
Continue to press the [] button.
The foot-rest is backwarded.
Do not strain yourself on your feet
while FORWARD or BACKWARD
the foot-rest. Given the force, the
foot-rest may be damaged, or a
squeaking sound may be caused.
When the foot-rest is
backwarded, do not put your
hand or foot between the seat
and the foot-rest.
You may get hurt.
How to use the [RESET] button.
1. To store the back-rest and the foot-rest, press the
[RESET] button.
The back-rest is raised by about 12, and the foot-rest is
shortened and lowered down to the lowest position.
* The [RESET] function is available only when the LCD is in
an initial stage.
* The back-rest does not move up completely, stopping
halfway. To raise it up completely, press the RECLINER
[▲] button.
FOOTREST RECLINER
RESET
FORWARD BACK
Request CAUTION
STOP
START
/RESET
AUTO
FUNCTION
AIR
REPEAT
SKIP
SHDR
MENU
ARM
ENTER
HEIGHT
ADJUSTMENT
RESET
FOOTREST RECLINER
Downward position Upward position FORWARD position
W/H
LEG
FORWARD
BACK

How to Use the AUTO-COURSE
16
Introduction
After turning the power ON, the LCD in the
initial stage displays the screens as shown
on the right side alternately.
When changing from an AUTO-COURSE to
another AUTO-COURSE, or when changing
non-AUTO-COURSE massage to any
AUTO-COURSE option (see Page 51).
1. Press the [START/RESET] button.
Foot-rest goes up automatically to the standby position.
(To interrupt on the way, press the [STOP] button.)
The standby screen comes out.
Be deeply seated on the chair, and
recline yourself slowly with your
head on the back-rest.
2. Press the [AUTO] button. Or, select “AUTO”with
the button, and press the [ENTER] button.
All of the AUTO-COURSE options
are displayed.
* The [ENTER] button remains not
to be pressed. Even so, all the
options are displayed 5 seconds
later. (The same holds good of this
procedure.)
3. Select a desired course with the button or
the [AUTO] button, and press the [ENTER] button.
Select one out of the 4 courses of “WHOLE BODY”,
“SHOULDER”, “WAIST”and “7MIN”.
There are 4 sub-courses in the “WHOLE BODY”course,
and 3 sub-courses in the “SHOULDER”and, “WAIST”
course each.
STOP
START
/RESET
AUTO FUNCTION
AIR
REPEAT
SKIP
SHDR
MENU
ARM
ENTER
FOOTREST RECLINER
RESET
HEIGHT
ADJUSTMENT
W/H LEG
FORWARD BACK

How to Use the AUTO-COURSE
17
4. The course name selected is displayed. When the
AUTO-COURSE starts, a process of detecting your
body shape also starts.
When the “7MIN”course is selected,
the process of detecting your body
shape is not taken.
5. In the process of detection, the detection points are
lighted up, and the detection levels each of the points
are indicated with the detection indicator.
* When nobody is seated on the chair, or when nothing can be
detected, a message “CAN NOT DETECT BODY SHAPE”
comes out on the LCD. In this case, press the [AUTO]
button again, and try to detect the body shape again.
6. With the body shape detection completed, the knead
balls move to the shoulderposition as determined.
7. Should you feel the shoulder position not in good
fitness, finely adjust its position as desired. While a
beep sound is caused, press the button for
adjustment, and press the [ENTER] button.
At this time, the knead balls can be moved to back-and-forth
with the button for adjustment.
The massage is applied at the positions adjusted during the
movements of “NECK RELAX”, “EXTREME KNEAD”
and “EXTREME TAPPING”in the AUTO COURSE. (This
is effective only with the “REJUVENATE”course for the
“WHOLE BODY”and “SHOULDER”.)
STOP
START
/RESET
AUTO
FUNCTION
AIR
REPEAT
SKIP
SHDR
MENU
ARM
ENTER
FOOTREST RECLINER
RESET
HEIGHT
ADJUSTMENT
One scale: about 12mm
One scale: about 2mm
W/H LEG
FORWARD BACK

How to Use the AUTO-COURSE
18
Shoulder position may also be adjusted finely using the
HEIGHT ADJUSTMENT [] and [] buttons.
When the body shape was detected with the
[START/RESET] button, the body shape is remembered till
the massage is completed. When changing the body shape
in memory, press the [START/RESET] button to complete
the process and then start again.
8. When the time allowed for the fine adjustment of
shoulder position is counted up, a message “POINT
NAVI FINISHED”is displayed.
9. Contour of your back line is displayed.
10. The AUTO-COURCE presently in progress of
massaging is displayed on the LCD screen.
STOP
START
/RESET
AUTO FUNCTION
AIR
REPEAT
SKIP
SHDR
MENU
ARM
ENTER
FOOTREST RECLINER
RESET
HEIGHT
ADJUSTMENT
Present massage
mode
Next massage
mode
Air
-
massage strength
of shoulders
Air
-
massage strength
of arms
Air
-
massage
options
Mecha
.
(knead balls)
massage strength
Air-massage strength
Present position of
Mecha. (knead balls)
massage
Remaining time
Name of AUTO-COURSE
Air
-
massage
position
W/H LEG
FORWARD BACK

How to Use the AUTO-COURSE
19
11.As the AUTO-COURSE is completed, the knead balls
return automatically to the stored position.
12. After using the chair, turn the power switch “OFF”.
This prevents the chair from starting when the Remote
Controller has been operated inadvertently.
Turn the power switch OFF
after using the chair.
There is risk of accident if a
child has played with the
chair out of mischief.
When stopping the massage immediately.
Press the [STOP] button.
Knead balls stop retaining the
present position.
Standby screen is displayed.
When terminating the massage on the way.
Press the [START/RESET] button.
Knead balls move to the stored position.
After the knead balls have been stored, the initial screen is
displayed.
CAUTION
STOP
START
/RESET
AUTO FUNCTION
AIR
REPEAT
SKIP
SHDR
MENU
ARM
ENTER
FOOTREST RECLINER
RESET
HEIGHT
ADJUSTMENT
FORWARD BACK
LEG W/H
