Introduction
Thank you for purchasing the WM340
Please always read this user guide before using the product.
Beforeusingtheterminal
It is not available, at the place that out of reach of radio waves such as in tunnels, underground,
building and weak point, out of service. And you may not be available even in the high floor
vantage point, such as high-rise apartment buildings.
If use overseas, please check with your customer center.
Public places, a quiet place and where there is a lot of people, please use so as not to disturb the
people around.
Damage of this document and caused by the use of products that have been described in this
document, costs of recovery is your responsibilities.
Noteaboutthesecurityatthetimeofwireless LANuse
In wireless LAN, in order to exchange information with wireless LAN apparatus between wireless
LAN access points instead of a LAN cable using an electric wave, if it is a range which an electric
wave reaches, there is an advantage that LAN access becomes possible freely. If the other hand, if it
is within radio range can reach, in order to reach all locations beyond the obstacles that have not
been security-related settings, there is a risk or is intercepted communications, resulting in the
intrusion.
This product is not setting up security in the state of the purchase. In consideration of safety,
perform security setting and recommend to using this product. Please refer to this book for the
setting method of security.
SupportedOS(PersonalComputers)
Windows XP Service Pack 3 or later(32bit version)
Service Pack 2 or later(64bit version)
Windows Vista Service Pack 2 or later(32bit ／64bit
version)
Windows 7 Service Pack 1 or later(32bit ／64bit
version)
Mac OS X 10.5 ～ 10.7.2
*Only support Intel processor. Not
supports Mac with a Power PC
processor.
Operation System
Android 2.2 or later

WM340 User
Guide
Version 0.2
Copyright 2011FUJISOFT INCORPORATED,All rightsreserved.
4
iOS 4 or later
Mozilla Firefox 2.0 or later
Internet Explorer 6.0 or later
Safari 2.0 or later
Browser
Opera 9.64 or later
Disk free space 50MB
Display Resolution 800 600 or more (1024 768 recommended).
Other than the above, it may not work. In addition, even if applicable to the above, by your
environment, you may not operate properly.

WM340 User
Guide
Version 0.2
Copyright 2011FUJISOFT INCORPORATED,All rightsreserved.
5
SafetyNotes
Before using this product, please read the "Safety Notes" and use this product in the correct manner.
The dangers or damage that can occur if the following precautions are not strictly adhered to or this
product is not used in the correct manner are described below.
Danger This sign denotes that death or serious injury may directly result from
improper use.
Warning
This sign denotes that death or serious injury may result from improper
use.
Caution This sign denotes that bodily injury or damage to property may result
from improper use.
The following pictorial displays are used to represent what you should do or should not do.
Don’t
This symbol denotes a prohibited action.
No disassembly
This symbol denotes that disassembling the phone or its components is
not allowed.
No liquids
This symbol denotes that using the device or its components in a
bathroom or highly humid area is not allowed.
No wet hands
This symbol denotes that using the device or its components with wet
hands is not allowed.
Do
This symbol denotes an obligatory action (that must be performed).

WM340 User
Guide
Version 0.2
Copyright 2011FUJISOFT INCORPORATED,All rightsreserved.
6
NotesaboutWM340
Danger
Please do not use or leave the device in a place where it will be exposed
to high temperatures, such as near a fire or heater, in strong, direct
sunlight, or inside a car on a hot day.
●This may cause the device change shape or malfunction or overheat, catch fire. It
may also cause the device to become hot, resulting in a burn injury.
Please do not used near the vicinity of high-precision electronic devices.
●If you are using electrical devices for medical care other than an implanted
pacemaker or implanted defibrillator at home or other location outside a medical
facility, please inquire with the manufacturer of each device concerning any adverse
effects of radio waves on device.
Please do not disassemble or modify the device.
●This may cause a fire, injury, electric shock or other accident, or malfunction of the
device.
●By alter device, it is a violation of the Radio Law.
Please do not use the device with wet hands.
●This may cause electric shock, or malfunction of the device.
Please do not use the device in a bathroom and not put in the water.
●This may cause overheat, a fire, electric shock or malfunction of the device.
Do not used near a risk of spilling liquid.
●Spilled liquid may cause a fire, overheat, electric shock, or malfunction of the
device.
Warning
Please do not subject the device to strong shocks or throw it.
●It may cause malfunction of device, a fire, injury of yourself or others.
Please do not put any foreign objects from the gap.
●This may cause overheats, a fire, electric shock or malfunction.
Please do not use the device at gasoline stations or other locations where
it may cause a fire or explosion.
●This may cause explosion, or catch fire.

WM340 User
Guide
Version 0.2
Copyright 2011FUJISOFT INCORPORATED,All rightsreserved.
7
Please do not put in a microwave oven or other cooking device that use
heat, or a high-pressure container.
●This may cause overheats, a fire, electric shock or malfunction.
Please use the equipment always dedicated.
●If use the equipment not dedicated, it may cause overheats, a fire, explosion or
malfunction.
Please do not use this device while driving.
●This may cause traffic accident.
Please do not use this device in aircraft, at hospitals, or other areas
where its use is prohibited.
●It may adversely affect electronic instruments or electric devices for medical care.
Please remove the device from the PC, when not used for a long time.
●This may cause electric shock, a fire or malfunction.
Abnormal condition such as the smoke, strange odor, please remove this
device from PC immediately.
●Continuing to use, it may cause overheat, a fire. When notice any abnormality,
please discontinue use immediately.
If water enters, please discontinue use immediately.
●Continuing to use, it may cause electric shock or malfunction.
When there is a possibility of lightning-fear, please turn off the product
and wireless LAN, and please unplug the power plug of the AC adaptor
and PC.
●It may cause thunderbolt, electric shock, a fire. In the case of outdoor, please move
to a safe place.
Caution
Do not place the device on sloped or unstable surface.
●The device may fall off, causing an injury, or malfunction of the device.
Do not use more excessive force than necessary.
●This may cause injury or malfunction.
Itching, rash, eczema, or other condition may occur depending on the
customer's health or physical disposition.
●If an abnormality occurs, immediately stop using, please receive medical attention.
If the impact on electronic devices of the vehicle, please do not use.
●It may cause an adverse effect on vehicle electronic products and interfere with the
safe driving

WM340 User
Guide
Version 0.2
Copyright 2011FUJISOFT INCORPORATED,All rightsreserved.
8
Keep the device out of the reach of small children.
●Small children may accidentally swallow the device, or may injure themselves.

WM340 User
Guide
Version 0.2
Copyright 2011FUJISOFT INCORPORATED,All rightsreserved.
9
Notesaboutbattery pack
Danger
Please do not use or leave the device in a place where it will be exposed to
high temperatures, such as near a fire or heater, in strong, direct
sunlight, or inside a car on a hot day.
Please do not contact metal, such as the wire to the terminals.
Please do not use any batteries other than this product. Also, please do
not use it for other apparatus.
Please do not use anything other than the appointed AC adaptor for
charge.
When equipping, the orientation of the battery pack has been determined.
Please attach after confirming direction of the battery pack. Please do not
strain, when can not equip this product well.
Do not give a strong shock such as prick with a needle, hit with a hammer,
tramples, and do not throw.
If battery pack significantly damaged or deformed, please do not use.
Do not put in fire or water and do not heat.
Please do not disassemble or modify the device.
When the liquid inside a battery pack enters into eyes, Please Washed
with clean water, and get medical attention immediately.
Warning
Please do not put in a microwave and high-pressure container.
Please fire away from stop using it immediately, When the liquid inside a
battery pack leaks or have nasty smell.
If charging is not completed beyond the predetermined charging time
when charging, Please stop charging.

WM340 User
Guide
Version 0.2
Copyright 2011FUJISOFT INCORPORATED,All rightsreserved.
10
Please do not use it in a bathroom and do not put into water.
Please do not use the device with wet hands.
Caution
When the liquid inside a battery pack adheres to the skin or clothing, Please
wash away with clean water immediately.
Keep the device out of the reach of small children.
When the battery pack attached , if it was probably rust, nasty smell,
generation of heat and other anomalies, please do not attached the battery
pack into it.

WM340 User
Guide
Version 0.2
Copyright 2011FUJISOFT INCORPORATED,All rightsreserved.
11
NoteaboutAC adaptor
Danger
Please do not use an AC adapter other than the product. Please do not use
it for other apparatus.
AC adapter is connected directly to the outlet, please.
Please do not use or leave the device in a place where it will be exposed to
high temperatures, such as near a fire or heater, in strong, direct
sunlight, or inside a car on a hot day.
Please do not put in a microwave and high-pressure container.
Please do not use the power other than the displayed power voltage.
Please do not disassemble or modify the device.
When there is a possibility of lightning-fear, to prevent electric shock or
fire caused by lightning, please power off and unplug the AC adapter from
the electrical outlet
When not being used, for safety, please remove it from the body and put
the AC adapter.
Warning
Do not give a strong shock or do not throw.
Please do not contact a conductive foreign substance for a terminal.
When the code of the AC adaptor is hurting, please do not use.
Please fire away from stop using it immediately, When the liquid inside a
battery pack leaks or have nasty smell.
If charging is not completed beyond the predetermined charging time
when charging, Please stop charging

WM340 User
Guide
Version 0.2
Copyright 2011FUJISOFT INCORPORATED,All rightsreserved.
12
Please do not cover with cloth etc.
Please do not place heavy objects on it.
Please do not put on a dusty place.
Please do not pull a code, when you extract the AC adapter.
Please do not use it in a bathroom and do not put into water.
Please do not use the device with wet hands.
Caution
Do not place the device on sloped or unstable surface.
Keep the device out of the reach of small children.

WM340 User
Guide
Version 0.2
Copyright 2011FUJISOFT INCORPORATED,All rightsreserved.
13
BeforeUsing
Partnamesandfunction
StatusArea Icon Information
1 Antenna bar Strength of radio wave
2 Internet connection
Network searching
Connected to 3G Network
3 Connected Status
Connected to 2G Network
4 Roaming Status Roaming
Battery (Small Large) 5 Battery power
Charging
No encryption
WEP64bit/WEP128bit
WPA-PSK AES
WPA2-PSK AES
6 Wireless Security
WPA/WPA2-PSK AES
7 Access point state
8 Number of users
Power Button
WPS/WiFi Button
Internet Button
LED Lamp

WM340 User
Guide
Version 0.2
Copyright 2011FUJISOFT INCORPORATED,All rightsreserved.
14
1. PowerButton
[Power OFF State]
Pressed about 3 seconds, it displayed as "WELCOME" on the LCD screen, and the power is
turned ON.
[Power ON State]
(1) Power OFF
Pressed about 3 seconds, it displayed as "BYE" on the LCD screen, and the power is turned
OFF.
(2) Connect / Disconnect (WAN)
If the power button is pressed for less than 2 seconds, be operated connect / disconnect by
the WAN side.
2. WPS/WiFiButton
Do the following, operate after short pressing the power / disconnected button, please.
(1) ON／OFF (Wireless LAN)
Pressed it about 1 second less than 2 seconds or more, be operated wireless LAN
ON/OFF.
(2) WPS
Pressed it about 5 seconds, WPS function starts.
ResetButton
When you open the back cover of the body, there is a reset button.
Short press the reset button, and restarted this product
Press the reset button about 5seconds, Configuration of this product is returned to the
factory default condition.
LEDlampdisplay
Reset Button

WM340 User
Guide
Version 0.2
Copyright 2011FUJISOFT INCORPORATED,All rightsreserved.
15
LED Lamp State
Red Flashes always Charging
Green Flashes always Full charge
Red Flashes Error

WM340 User
Guide
Version 0.2
Copyright 2011FUJISOFT INCORPORATED,All rightsreserved.
16
PreparingUSIMcard
Attaching
1. Please turn off the power, if the power of this product is on.
2. If this product is connected with USB cable or AC adapter, remove it.
3. Remove the cover.
4. Facing down the metal surface of the USIM card, insert the USIM card into the USIM slot in
the upper right corner cutout.
5. Check the USIM card is attached.
6. Attach the cover.
Removing
1. Please turn off the power, if the power of this product is on.
2. If this product is connected with USB cable or AC adapter, remove it.
3. Remove the cover.
4. Remove by pulling in the direction of the arrow on the USIM card.
5. Attach the cover.
Cutout

WM340 User
Guide
Version 0.2
Copyright 2011FUJISOFT INCORPORATED,All rightsreserved.
17
Setting
Setting
Set the fundamental connection item.
1. Do PC and USB cable connection or wireless LAN connection, please input the private IP
address in the address field. The private IP address at the time of purchase is set
「http://192.168.0.1」. How to connect, check「Wireless LAN Connection procedure」、「USB
Connection procedure」,please.
2. Displayed login screen. Input the password to log in. The password at the time of purchase is set
「password」. For security, recommend to change the password at the time of purchase.
3. Click Admin Setup icon.

WM340 User
Guide
Version 0.2
Copyright 2011FUJISOFT INCORPORATED,All rightsreserved.
18
4. In administrator password setting screen, login password can be changed. The password at the
time of purchase is set 「password」. Select 「Next」, after inputting administrator password.
SettingItems Description
Administrator
password
WEP key(initial value) Set the inputting password when connecting
to Wi-Fi. The WEP key (5 digit number) at
the time of purchase is set.

WM340 User
Guide
Version 0.2
Copyright 2011FUJISOFT INCORPORATED,All rightsreserved.
19
The length of the password is dependent on
the security mode.
5. In APN setting screen, using APN and default APN can be selected. Select 「Next」, after
selecting APN.
6. In ｔhe default user setting screen, profile name／user name／password／APN／Tel／
Authentication type can be set.（Only if you select a 「default APN」, APN settings of the
previous screen, the default user setting screen is displayed）
