Fujitsu Siemens Computers AMILO A1650G User manual

Issue August 2005
AMILO A1650G
Back to University Batch
With Mobile AMD Processor - Preliminary
Pages 3
The AMILO A1650G notebook offers all-round mobile computing with an excellent price/performance ratio. Strong
graphics and a Widescreen display, as well as an AMD Turion
TM
64 Mobile Technology Processor are all combined into
an amazing visual experience. The preinstalled software enables you to start working, playing, surfing the Internet or
watching a film at once. Connect all sorts of devices to the notebook using one of the 3 USB 2.0 ports, IEEE 1394
Firewire, the 3-in-1 cardreader or the S-Video out. The integrated WLAN connects you to your network from any place
as long as you are in reach of an Access point without having to deal with any cables. The fan noise can be reduce to
only 25dB using a special “Silent Mode”.
Features
AMD mobile technology with Turion
TM
64 Mobile
Technology ML30
Enjoy the viewing quality of the wide 15.4” WXGA LCD
display
Connect your notebook to external storage devices
and video equipment through the IEEE 1394 port
offering transfer rates of up to 400Mbits/sec
ATI Mobility Radeon Xpress 200 with up to 128 MB
shared memory supporting Pixel Shader V2.0
Reducing the fan noise to a minimum by using “Silent
Mode”,
Memory card slot for Multimedia Card, Secure Digital
Card and MemoryStick
512 MB DDR SDRAM in 2 SO-DIMM slots
Windows XP Home and Application Software

Data Sheet PreliminaryIssue: August 2005AMILO A1650G Page 2 / 3
All rights, including rights created by patent grant or registration of a utility model or design as well
as rights of technical modifications are reserved. Delivery subject to availability. Designations may
be trademarks, the use of which by third parties for their own purposes may violate the rights of the
trademark owners.
Copyright Fujitsu Siemens Computers,08/2005
Published by
Fujitsu Siemens Computers
http://www.fujitsu-siemens.com/
Company stamp
Operating system
Windows XP Home, Recovery CD is included
Fujitsu Siemens Computers recommends Microsoft®
Windows® XP.
Application Software
a) Works 8.0 or
b) Works 8.0 with Office Trial Student & Teacher Edition
Magix Media Suite (optional)
Sipgate (optional)
Norton Internet Security 2005 or Norman Anti-Virus
DVD Playing & Burning Software
InterVideo WinDVD
Nero burning ROM 6
Driver & Utility CD including
Drivers, Online Manual, Adobe Acrobat Reader
Quick Touch application button utility
Internet Service Providers – country specific
Manual, Safety Guide and Warranty Guide
System, processors, architecture
Chipset: Northbridge: ATI RS480
Southbridge: ATI SB400
CPU: Mobile AMD Turion™ Mobile Technology
ML30 / 35W / 64 Bit / 1.6 GHz / 1024 KB
Memory
2x 256MB DDR 333 SDRAM, (DDR 333 MHz)
2 SO-DIMM memory slots (no memory on board)
Storage devices / drives
HDD: 60 or 80 GB IDE hard disk
ODD: Multi format DVD burner with double layer support
CD 24x / CD-R 24x / CD-RW 20x / DVD 8x / DVD+R 8x
DVD-R 8x / DVD+RW 8x / DVD-RW 6x
DVD+R DL 4x/ DVD-R DL 4x
Display:
Crystal View
15.4” TFT WXGA, 1280 x 800 pixel
Compliance with standards
ISO 13406-2 class II
ACPI functions
S1 LCD off
S3 stand by
S4 hibernate
S5 soft off
Graphics:
ATI MOBILITY Radeon Xpress 200
Up to 128MB RAM shared memory
I/O Interfaces
1x IEEE1394
4x USB 2.0 ports
1x S-Video
1x CRT, 1x modem
1x LAN
3 in 1 flash card port SD/MS/MMC
1x type II PC Card slot (32 bit CardBus support)
1x line in, 1x headphone out shared with SPDIF, 1x
microphone in,
1x power supply
Communications
- Built-in 56K, V.92 international modem
- 10/100 Mbps LAN
- integrated Wireless LAN (IEEE 802.11b/g) solution:
- Industry standard wireless LAN security
support
- Speeds up to 54 Mbps
For use in BE, CH, DK, DE, EE, FI, FR, EL, IE, IS, IT, LI,
LV, LT, LU, MT, NL, NO, PL, AT, PT, SE, SK, ES, CZ, HU,
UK, CY, NL
Audio
AC97 codec, 2 built-in speakers, built-in
microphone, microphone in, headphone out shared with
S/PDIF support
1x volume regulator (per function key and per wheel)
Launch Keys
3 Launch Keys located on top of the keyboard enabling the
user to launch the following applications:
WLAN
Internet browser
Fan control/silent mode
Hot Keys
The notebook uses hotkeys or key combinations for:
Fn-F1 help hotkey
Fn-F2 puts the computer in sleep mode
Fn-F3 display toggle, switches display output between
display screen and external monitor or to dual
view
Fn-F4 screen blank, turns the display screen backlight
off to save power
Fn-F5 speaker on/off
Fn-F6 volume down
Fn-F7 volume up
Fn-F8 screen brightness down
Fn-F9 screen brightness up
Fn-F10 WLAN on/off
Fn-PgUp home
Fn-PgDn end
Pointing device & control buttons
Touchpad with a left and right mouse button
Power button / lid switch
Status indicators
The notebook has 7 status icons:
Wireless communication, Caps lock, Num Lock, standby,
Media activity (ODD/HDD), power status, charge
Security
Supervisor password
Kensington lock support

Data Sheet PreliminaryIssue: August 2005AMILO A1650G Page 3 / 3
All rights, including rights created by patent grant or registration of a utility model or design as well
as rights of technical modifications are reserved. Delivery subject to availability. Designations may
be trademarks, the use of which by third parties for their own purposes may violate the rights of the
trademark owners.
Copyright Fujitsu Siemens Computers,08/2005
Published by
Fujitsu Siemens Computers
http://www.fujitsu-siemens.com/
Company stamp
Power system
Li-Ion battery, 6 cells, 3.6V / 2200mAh
approximately 2:30 hrs battery runtime, depending on
usage
1
Dynamic charge supported, ACPI 2.0 supported
External universal AC adapter: 110 – 264 V AC, 47 – 63
Hz, output: 65 W/90W with 20 V
Dimensions and weight
359 mm (W) x 273 mm (D) x 34 (H)mm
3.20 kg
2
(with 15.4” WXGA, Li-Ion battery, HDD, DVD drive)
Operating conditions
Operational: 5°C to 35°C (ambient temperature)
20% to 85% relative humidity, non-condensing
AC input 110 - 264 V, 47 - 63 Hz
Warranty
Country specific terms
Options
AC adapter
USB Floppy Drive
Carrying cases
1
) Battery life may vary depending on product model, configuration, applications, power management settings and features utilized.
Recharge time varies depending on usage.
2
) Weight may vary depending on actual configuration
