Fujitsu Siemens Computers AMILO A1650G User manual

EasyGuide
AMILO A Series
English
answers2

Are there ...
... any technical problems or other questions which you would like to be clarified?
Please contact:
•your sales partner
•your sales outlet
Additional information is contained in the "Warranty" manual and the Help Desk list.
The latest information on our products, tips, updates, etc., can be found on the internet under:
http://www.fujitsu-siemens.com

Herausgegeben von/Published by
Fujitsu Siemens Computers GmbH
Bestell-Nr./Order No.: SAP:10600366086
Bestell-Nr./Order No.: 440 N30115
Printed in the Federal Republic of Germany
AG 0703 07/03

AMILO A Series
Operating manual
Introduction
Index
Important notes
Preparing the notebook
for use
Working with the
notebook
Security functions
Connecting external
devices
Settings in BIOS Setup
Troubleshooting and tips
Memory expansion
Technical data
July 2003 edition

Microsoft, MS, MS-DOS, Windows, and Windows NT are registered trademarks of Microsoft
Corporation.
VESA and DPMS are registered trademarks of Video Electronics Standards Association.
PS/2 is a registered trademark of International Business Machines, Inc.
Acrobat Reader is a trademark of Adobe Systems Incorporated.
All other trademarks referenced are trademarks or registered trademarks of their respective
owners, whose protected rights are acknowledged.
Copyright Fujitsu Siemens Computers GmbH 2003
All rights, including rights of translation, reproduction by printing, copying or similar methods,
in part or in whole, are reserved.
Offenders will be liable for damages.
All rights, including rights created by patent grant or registration of a utility model or design,
are reserved.
Delivery subject to availability. Right of technical modification reserved.
This manual was produced by
cognitas. Gesellschaft für Technik-Dokumentation mbH
www.cognitas.de

SAP:10600366086
Contents
Introduction .....................................................................................................................................1
Notational conventions ......................................................................................................................2
Important notes ...............................................................................................................................3
Safety notes ......................................................................................................................................3
Notes on installing and removing boards and modules..............................................................4
Manufacturer’s notes.........................................................................................................................5
Copyright-protected technology .................................................................................................5
Energy saving............................................................................................................................5
Disposal and recycling...............................................................................................................6
CE marking........................................................................................................................................6
Storing the battery.............................................................................................................................6
Transporting the notebook.................................................................................................................7
Before you travel .......................................................................................................................7
Transporting the notebook.........................................................................................................7
Cleaning the notebook.......................................................................................................................8
Preparing the notebook for use......................................................................................................9
Unpacking and checking the delivery.................................................................................................9
Selecting a location ...........................................................................................................................9
Connecting the power adapter.........................................................................................................10
Switching on the notebook for the first time .....................................................................................10
Switching on the notebook...............................................................................................................11
Switching the notebook off...............................................................................................................11
Working with the notebook...........................................................................................................13
Views...............................................................................................................................................13
Interior view.............................................................................................................................13
Front........................................................................................................................................14
Right side panel.......................................................................................................................14
Left side panel.........................................................................................................................14
Back panel...............................................................................................................................15
Under side...............................................................................................................................15
Status indicators..............................................................................................................................16
Keyboard.........................................................................................................................................18
Letter keys...............................................................................................................................18
Function keys ..........................................................................................................................19
Windows logo keys..................................................................................................................19
Virtual numeric keypad............................................................................................................20
Key combinations....................................................................................................................21
Easy buttons....................................................................................................................................23
Touchpad and touchpad buttons......................................................................................................23
Closed cover switch.........................................................................................................................24
LCD display panel ...........................................................................................................................25
Information on LCD monitor.....................................................................................................25
Display settings .......................................................................................................................25
Battery.............................................................................................................................................26
Charging, caring for and maintaining the battery......................................................................26
Monitoring the battery charging level .......................................................................................27
Inserting and removing the battery...........................................................................................27
Performing the battery learning cycle.......................................................................................28
Energy saving functions...........................................................................................................29
Hard disk.........................................................................................................................................29

Contents
SAP:10600366086
Optical drive.................................................................................................................................... 30
Combo drive (CD-RW/DVD)....................................................................................................30
DVD+RW drive........................................................................................................................ 31
Handling CD/DVDs.................................................................................................................. 31
Regional codes for DVD films and DVD players...................................................................... 33
Adjusting AutoPlay function of optical drive............................................................................. 33
Floppy Disk Drive............................................................................................................................ 34
Working with floppy disks........................................................................................................ 34
PC cards......................................................................................................................................... 35
Installing a PC card................................................................................................................. 35
Removing a PC card............................................................................................................... 36
Microphone and loudspeakers ........................................................................................................ 36
Adjusting the volume............................................................................................................... 36
Switching the loudspeakers on/off........................................................................................... 36
Integrated 56k modem .................................................................................................................... 37
Connecting notebook modem to telephone connection........................................................... 37
Ethernet and LAN/DSL ready.......................................................................................................... 38
Security functions......................................................................................................................... 39
Overview of all security functions.................................................................................................... 39
Kensington Lock...................................................................................................................... 39
BIOS password protection....................................................................................................... 39
Brief overview of the security functions........................................................................................... 40
Using Kensington Lock ................................................................................................................... 40
Configuring password protection in BIOS Setup.............................................................................. 41
Protecting BIOS Setup (supervisor and user password).......................................................... 41
Password protection of operating system................................................................................ 42
Password protection for hard disk........................................................................................... 43
Connecting external devices........................................................................................................ 45
Connecting an external monitor....................................................................................................... 46
Connecting an external PS/2 mouse or keyboard ........................................................................... 46
Using the parallel port ..................................................................................................................... 46
Connecting USB devices (up to 12 Mbps)....................................................................................... 47
Connecting external audio devices.................................................................................................. 47
Connecting a television set to S-Video Out..................................................................................... 48
Connecting FireWire devices .......................................................................................................... 48
Settings in BIOS Setup................................................................................................................. 49
Start BIOS Setup ............................................................................................................................ 49
Operating BIOS Setup .................................................................................................................... 50
Exiting BIOS Setup......................................................................................................................... 50

Contents
SAP:10600366086
Troubleshooting and tips..............................................................................................................51
Restoring operating system.............................................................................................................51
The notebook's date or time is incorrect ..........................................................................................51
The LCD screen of the notebook remains blank..............................................................................52
The LCD screen is difficult to read...................................................................................................52
The external monitor stays blank.....................................................................................................52
The external monitor is blank or the image is unstable (under Windows).........................................53
The notebook cannot be started......................................................................................................53
The notebook stops working............................................................................................................54
The mouse does not work ...............................................................................................................54
The floppy disk cannot be written ....................................................................................................54
The printer does not print.................................................................................................................55
The DVD film does not continue to play...........................................................................................55
Acoustic warnings............................................................................................................................55
System configuration contains invalid data......................................................................................55
Error messages on the screen.........................................................................................................56
Memory expansion........................................................................................................................59
Installing/removing memory.............................................................................................................59
Technical data................................................................................................................................61
Notebook.........................................................................................................................................61
Battery.............................................................................................................................................62
Power adapter.................................................................................................................................62
Index...............................................................................................................................................63

SAP:10600366086 1
Introduction
Innovative technology and ergonomic design make your AMILO the ideal user-friendly and reliable
notebook. Your operating system is preinstalled on the hard disk and optimally configured to
facilitate the procedure when you use your AMILO for the first time.
Depending on the initial configuration, the main memory of your notebook can be upgraded to 128 -
1024 Mbyte with a 128, 256 or 512 Mbyte memory module. Depending on the variant, your
notebook is shipped with a DVD+RW drive or a combo drive (CD-RW/DVD). As an option your
notebook can also be equipped with a 3 1/2-inch floppy disc drive. Up to two PC card slots
(CardBus or PCMIA) enable the notebook to operate a type II or type III PC card. Your notebook is
equipped with an internal modem and LAN. In addition, your notebook is equipped with a S Video
out socket to connect to a television. You can connect external devices such as digital audio/video
devices or other high-speed devices to IEEE1394 (FireWire).
For mouse control, the notebook has a touchpad.
Your notebook has connectors for external devices such as an external monitor, a printer, and a
mouse. The ECP capable parallel port is designed for fast bi-directional data transfer. You can
connect peripheral devices such as a scanner, loudspeakers, gamepads, keyboard, or mouse via
the three USB ports.
An audio controller and two internal loudspeakers provide your AMILO with an audio capability. You
can also connect an external microphone and an external loudspeaker.
The system settings of the notebook can be configured via the user-friendly BIOS Setup programme.
This operating manual tells you how to put your AMILO into operation, and how to operate it in daily
use.
Further information on this notebook is provided:
•in the "Getting Started" manual
•in the "Safety and Ergonomics" manual
•in the "Warranty" manual
•in the information files (e.g. *.TXT,*.DOC,*.WRI,*.HLP, *.PDF)
•in the documentation of the operating system

Introduction
2SAP:10600366086
Notational conventions
The following symbols are used in this manual:
!Indicates information which is important for your health or for preventing
physical damage. Failure to follow the instructions may lead to loss of data,
invalidate your warranty, destroy the notebook, or endanger your life.
i
Indicates important information which is required to use the system
properly.
ÊText which follows this symbol describes activities that must be performed
in the order shown.
This font indicates screen outputs.
This font indicates programme names, commands or menu items.
"Quotation marks" indicate names of chapters, data carriers, and terms that are being
emphasised.

SAP:10600366086 3
Important notes
Here you will find essential safety information regarding your notebook. In addition, the
manufacturer's notes contain helpful information about your notebook.
Safety notes
!Pay attention to the information provided in the "Safety and Ergonomics" manual and in
the following safety notes.
Observe the sections in the manual marked with the symbol on the left.
•During installation and before operating the device, please observe the instructions on
environmental conditions in the "Technical data" chapter as well as the instructions in the
"Preparing the notebook for use" chapter.
•When connecting and disconnecting cables, observe the relevant notes in this operating
manual.
•When cleaning the device, please observe the relevant notes in the "Cleaning the notebook"
paragraph.
•Only use batteries designed for this notebook.
Do not store batteries for longer periods in the notebook.
Take care not to drop the batteries or otherwise damage their casing (fire risk).
If the rechargeable batteries are defective, they must not be used.
Do not touch the contacts of the batteries.
Never interconnect the positive and negative terminals of a battery.
Used batteries must be disposed of in accordance with local regulations (special waste).
•The notebook includes a lithium battery (button cell) for real-time buffering. Please note that:
The lithium battery may be replaced only by authorised personnel. Incorrect handling may lead
to a risk of explosion.
The lithium battery may be replaced only with an identical battery or with a type recommended
by the manufacturer.
The lithium battery must be disposed of in accordance with local regulations concerning special
waste.
•All batteries containing pollutants are marked with one of the two symbols below (crossed-out
garbage can).

Important notes
4SAP:10600366086
In addition, the marking is provided with the chemical symbol of the heavy metal decisive for
the classification as a pollutant.
Cd Cadmium
Hg Mercury
Pb Lead
•Your notebook is equipped with security functions that offer you a high level of security
according to a multi-level concept. Detailed information can be found in "Security functions"
chapter.
This notebook complies with the relevant safety regulations for data processing equipment. If you
have questions as to whether you can set up the notebook in the intended environment, please
contact your sales point or our hotline/help desk.
Notes on installing and removing boards and modules
!Only qualified technicians should repair the device. Unauthorised opening or incorrect
repair may greatly endanger the user (electric shock, fire risk).
Boards with electrostatic sensitive devices (ESD) are identifiable by the label shown.
When you handle boards fitted with ESDs, you must, under all circumstances, observe the following
points:
•You must statically discharge yourself before working with boards (e.g. by touching a grounded
object).
•The equipment and tools you use must be free of static charges.
•Remove the power plug from the mains supply before inserting or removing boards containing
ESDs.
•Always hold boards with ESDs by their edges.
•Never touch pins or conductors on boards fitted with ESDs.

Important notes
SAP:10600366086 5
Manufacturer’s notes
Copyright-protected technology
This product incorporates copyright protection technology that is protected by method claims of
certain U. S. patents and other intellectual property rights owned by Macrovision Corporation and
other rights owners. Use of this copyright protection technology must be authorised by Macrovision
Corporation, and is intended for home and other limited viewing uses only unless otherwise
authorised by Macrovision Corporation. Reverse engineering or disassembly is prohibited.
Energy saving
If you will not be using your notebook, switch it off.
Make use of the device's energy saving functions (see section "Working with the notebook"). The
notebook uses less power when the power management features are enabled. You will then be able
to work for longer before having to recharge the battery.
Energy saving under Windows
If a monitor with energy saving features is connected to your notebook, you can use the Screen Saver
tab to activate the energy saving features of the monitor. Select the following item in the start menu:
Settings - Control Panel - Display - Display Properties - Screen Saver - Energy saving functions for the
display. You can set additional energy saving functions in the start menu by selecting the following
item: Settings - Control Panel - Energy - Extended.
Energy Star
The notebook from Fujitsu Siemens Computers is designed to conserve
electricity by dropping to less than 8 W when it goes into standby/suspend
mode and to less than 3 W when it goes into OFF mode. With this level of
power management, the notebook qualifies for the U.S. Environmental
Protection Agency's (EPA) Energy Star Computers award.
The EPA estimates that computer equipment uses 5 percent of all business electricity and that this
is growing rapidly. If all desktop PCs and peripherals enter a low-power mode when not in use, the
overall savings in electricity could amount to $ 2 milliard annually. These savings could also prevent
the emission of 20 million tons of carbon dioxide into the atmosphere - the equivalent of 5 million
automobiles.
As an Energy Star Partner, Fujitsu Siemens Computers GmbH has determined that this product
meets the Energy Star guidelines for energy efficiency.

Important notes
6SAP:10600366086
Disposal and recycling
This device has been manufactured to the highest possible degree from materials which can be
recycled or disposed of in a manner that is not environmentally damaging. The device may be taken
back after use to be recycled, provided that it is returned in a condition that is the result of normal
use. Any components not reclaimed will be disposed of in an environmentally acceptable manner.
Do not throw batteries or accumulators into the household waste.
If you have any questions on disposal, please contact your local office, our hotline/help desk, or:
Fujitsu Siemens Computers GmbH
Recyclingcenter
D-33106 Paderborn
Tel: [phone]
Fax: [phone]
CE marking
The shipped version of this device complies with the requirements of the EEC directives
89/336/EEC "Electromagnetic compatibility" and 73/23/EEC "Low voltage directive".
Storing the battery
Store the battery in a fully charged state. Keep the battery pack between 0°C and +30°C (32 and
122 degrees Fahrenheit). The lower the temperature at which the batteries are stored, the lower is
the rate of self-discharge.
If storing for a long period of time (longer than two months) batteries should be fully charged before
storage.
To be able to make use of the optimal charging capacity of the batteries, the battery should be
completely discharged and then fully recharged.
i
If you do not use the batteries for long periods, remove them from the notebook. Never
store the batteries in the unit.

Important notes
SAP:10600366086 7
Transporting the notebook
Please observe the points listed below when transporting your notebook.
Before you travel
•Back up important data stored on your hard disk.
•If you wish to use your notebook during a flight, first check with the flight attendants if it is
permissible to do so.
•If you are travelling abroad, ensure that the power adapter can be operated with the local
mains voltage. If this is not the case, obtain the appropriate power adapter for your notebook.
Do not use any other voltage converter!
i
If you travel in another country, check whether the local power supply and the
specifications of the power cable are compatible. If this is not the case, buy a power cable
that matches the local conditions. Do not use a connection adapter for electrical devices
to connect the notebook.
If you use a modem, incompatibilities with the local telecommunications system may
result.
Transporting the notebook
•Remove all data carriers (e.g. CD) from the drives.
•Unplug the power adapter and all external devices from the mains outlet.
•Disconnect the power adapter cable and the data cables for all external devices.
•Close the LCD screen so that it locks into place.
•If the device needs to be shipped, use the original packaging or other suitable packaging to
protect it from damage caused by mishandling.
•To protect against damaging jolts and bumps, use a notebook carrying case to transport your
notebook.
Fujitsu Siemens Computers offers a number of solutions for transporting your notebook. The
current offering can be viewed on the Internet at http://www.e-shop2.de.
•Protect the notebook from severe shocks and extreme temperatures (e.g. direct sunlight in a
car).

Important notes
8SAP:10600366086
Cleaning the notebook
ÊSwitch the notebook off.
ÊPull the power plug of the network adapter out of the mains outlet.
ÊRemove the battery.
!Do not clean any interior parts yourself; leave this job to a service technician.
Do not use any cleaning agents that contain abrasives or may corrode plastic. The use of
improper cleaning agents can damage the markings on the keyboard and the notebook,
the paintwork of the device or the device itself.
Ensure that no liquid enters the notebook.
Wipe the casing with a dry cloth.
If particularly dirty, use a cloth that has been moistened in mild domestic detergent and then
carefully wrung out.
To clean the touchpad, you can use disinfectant wipes.
Wipe the LCD screen with a soft, moistened cloth.

SAP:10600366086 9
Preparing the notebook for use
!Please take note of the information in the "Important notes" chapter.
You must charge the battery and install the application programmes before you can work with the
notebook. The operating system and drivers required are preinstalled.
When not plugged into a mains outlet, the notebook runs on its built-in battery. You can increase the
battery's life by enabling the system's energy saving functions.
If you use the notebook in a normal office situation, run it from the mains using the power adapter.
Please see the "Connecting external devices" chapter for instructions on how to connect devices
such as a mouse and a printer to the notebook.
Unpacking and checking the delivery
ÊUnpack all the individual parts.
ÊCheck the delivery for damage incurred during transportation.
i
Do not discard the original packing material of the devices. Keep the original packing
material in case you need to ship the equipment again.
Selecting a location
Select a suitable location for the notebook before setting it up. Consider the following points when
looking for a location:
•Do not place it on a soft surface (e.g., a carpet or soft furnishings). The space between the
notebook's feet must be clear.
Place the notebook on a stable, flat, nonslippery surface. In view of the multitude of different
finishes used on furniture, it is possible that the rubber feet of the notebook will mark the
surface they stand on.
•Never place the notebook and the power adapter on a heat-sensitive surface.
•The notebook and the power adapter should be at least 200 mm apart.
•Keep other objects 100 mm away from the notebook and its power adapter to ensure adequate
ventilation.
•Never cover the fan intake or exhaust openings of the notebook or the power adapter.
•Do not expose the notebook to extreme environmental conditions.
Protect the notebook from dust, humidity, and heat.

Preparing the notebook for use
10 SAP:10600366086
Connecting the power adapter
!Please take note of the information in the section "Selecting a location".
The power cable supplied conforms to the requirements of the country in which you
purchased your notebook. Make sure that the power cable is approved for use in the
country in which you intend to use it.
The power adapter's AC cord should only be connected to a mains outlet if the notebook
is connected to the power adapter. (electric shock!)
Upon delivery, the battery can be found in the battery compartment.
Do not use the power adapter for other notebooks or devices.
Do not use a power adapter that is not specially intended for this notebook.
1
ÊConnect the power adapter cable to the DC
jack (DC IN) of the notebook (1).
ÊConnect the power cable into the power
adapter.
ÊPlug the power cable into the mains supply.
The battery will charge. The battery indicator
flashes green.
i
The meaning of the various displays can be found in the section "Status indicators" in the
"Working with the notebook" chapter.
Switching on the notebook for the first time
!When you switch on your notebook for the first time, the supplied software is installed and
configured. Due to the fact that this installation must not be interrupted, you should set
aside enough time for it to be fully completed and connect the notebook to the mains
outlet using the power adapter.
During installation, the notebook may only be rebooted when you are requested to do so!
ÊSwitch the notebook on.
ÊDuring installation, follow the instructions on screen.
Consult the operating system manual if there is anything unclear about the requested input data.
