Fujitsu Siemens Computers Amilo L1310G User manual

Issue
August2005
AMILO L1310G
Back ToSchool Batch:
Stylish, lightlyand innovative design on a
budget
Pages
3
TheAMILOL1310hasbeendesignedforuserswhodemand performance and visualinnovationtoaveryattractive
price.Enjoythelatestindesgin:styleandlegeritycombinedwithaninnovativeshape. Thisisagreatmultimedianote
book,whichoffersyou anextrawide15.4”CrystalViewdisplayforamazingsharpanddetailedpicturesas well asan
ATIMobilityRadeon Xprexss200graphics card. WiththeadditionalintegratedWLAN,itstrikestheperfectbalance
betweenmobileentertainmentandwireless performance.Featuring S-Videoout, and4USB2.0ports,theAMILO L1310
offersyou thepossibilitytoenjoylimitlessconnectivity. Perfectformultimediaon themove, thisAMILOhasgreat
audio, bagsofmemoryandenableseasyconnectionofdigital andvideocameras,wirelessperipherals, pocket-sized
USBstoragedevicesand muchmore!
Features
nIntel®Celeron M380processor(Dothan1.6GHz)
nEnjoytheviewingqualityof wideTFTcrystalview
displayswith15.4”WXGA
nATI Radeon Xpress 200 (sharedgraphics)upto128
MBVRAM
nConnect yournotebooktoexternalperipherals,
storagedevicesorvideoequipmentthroughthe
variousUSB 2.0ports
nBuilt-inMultiformatDVDburnerwithdoublelayer
supporttoenjoymultimediaonthemove
n512 MBDDRSDRAMintwomemorySO-DIMM slots
nWindowsXP HomeandApplicationSoftware

DataSheetIssue: August 2005AMILOL1310G Page 2/ 3
All rights,includingrightscreated bypatentgrant orregistration of autilitymodelordesign aswell
asrightsof technicalmodificationsarereserved. Deliverysubject toavailability. Designationsmay
be trademarks, theuseofwhichbythirdpartiesfortheirownpurposesmayviolatethe rightsof the
trademarkowners.
Copyright FujitsuSiemensComputers,08/2005
Published by
FujitsuSiemensComputers
http://www.fujitsu-siemens.com/
Companystamp
Operatingsystem
WindowsXP Home, RecoveryCDisincluded
FujitsuSiemensComputersrecommendsMicrosoft®
Windows®XP.
Application Software
a)Works 8.0or
b)Works 8.0withOfficeTrialStudent &TeacherEdition
MagixMediaSuite(optional)
Sipgate(optional)
NortonInternet Security2005orNorman Anti-Virus
DVDPlaying&BurningSoftware
InterVideoWinDVD
NeroburningROM6
Driver&UtilityCDincluding
Drivers,OnlineManual,AdobeAcrobat Reader
QuickTouchapplication buttonutility
InternetService Providers –countryspecific
Manual, SafetyGuideandWarrantyGuide
System,processor,architecture
Chipset:ATiRC410MB+SB400
CPU:IntelCeleron Mprocessor/400 MHzFSBCeleron
M380 (Dothan);1MB2nd levelcache
Memory
2x256 MBDDR333/400SDRAMSO-DIMM
2memoryDIMMslots200pin
Maximummemorysize: 2GB
(no memoryon board)
Storagedevices/ drives
HDD:
60,or80GBPATAIDEharddisk
ODD:
MultiformatDVDburnerwithdoublelayersupport
CD 24x/CD-R24x/CD-RW20x/DVD8x/ DVD+R8x
DVD-R8x/DVD+RW8x/ DVD-RW6x
DVD+RDL4x/DVD-RDL4x
Display:
Crystalview
Panelsize:15.4”TFTWXGA,1280x800 pixel
Compliancewithstandards
ISO13406-2ClassII
ACPIfunctions
ACPI capability:
S1LCD off
S3savetoRAM
S4savetodisk
S5softoff
Completeboot
Graphics
ATI Radeon Xpress 200
Upto128MBRAMsharedmemory
FullDirectX9.0Support: VertexShaderv2.0andPixel
Shaderv2.0tocreatemostrealistic3Deffects
DVDqualityplayback
EngineClockScaling,MemoryClockScaling, CoreVoltage
Scaleing, DynamicLaneCountSwitching
Support ATiPowerOnDemandand PowerPlayforlonger
batterylife
DualviewpossibleunderWinXP Home
Max. recommendedexternalresolution(CRTonly)
1600 x1200/16M/ 85Hz
I/O Interfaces
4xUSB (version2.0)
1xS-video(4pin)
1xCRT(VESAcompatible)
1xIEEE 1394
1xtypI/II PCcardslot(32 bit CardBussupport)
1x4in1Cardreader(SD/MS/MSPro/MMC)
1xDC-In
1xmodem(56Kbps(.V90)
1xLAN(10/100)
1xW-LAN(miniPCI, Gemtek/Ralink)
1xSPDIFsharedwithheadphoneout(stereo)
1xmicrophonein(mono)sharedwithlinein
1xRJ11,1xRJ45
Communications
§Built-in56K,.V92faxmodem(MDC (AC’97)
§10/100MpbsLAN(BroadcomBCM4401)
§Integratedwireless LAN(IEEE 802.11b/g)solution
-industrystandardwireless LANsecurity
support
-speedsup to54Mbps
ForuseinBE,CH,DK, DE, EE, FI, FR, EL,IE,IS,IT,LI,
LV, LT,LU,MT,NL, NO, PL, AT,PT,SE, SK, ES, CZ,HU,
UK, CY, NL
Audio
AC97 ALC655
2high qualitybuilt-inspeakers(1.5W)
microphonein(mono)sharedwithline-in
Headphoneout sharedwithSPDIFsupport
sound volumecontrolledbyHot Keys
LaunchKeys
3LaunchKeyslocatedontopofthekeyboardenablingthe
usertolaunchthefollowing applications:
§WLAN
§Internetbrowser
§Silent mode(reducenoiselevel/fanspeed, by
reducingtheCPU&VGAperformance)
(Officeapplications,Internet andDVDplaybackare
notaffected)
HotKeys
ThefollowingHotKeys orkeycombinationsareavailable
Fn+F3:LCD Ext.CRT/TVswitch
Fn+F6:speakeron/off
Fn+F8:increasedisplaybrightness
Fn+F9:decreasedisplaybrightness
Fn+F10:volumedown
Fn+F11:volumeup

DataSheetIssue: August 2005AMILOL1310G Page 3/ 3
All rights,includingrightscreated bypatentgrant orregistration of autilitymodelordesign aswell
asrightsof technicalmodificationsarereserved. Deliverysubject toavailability. Designationsmay
be trademarks, theuseofwhichbythirdpartiesfortheirownpurposesmayviolatethe rightsof the
trademarkowners.
Copyright FujitsuSiemensComputers,08/2005
Published by
FujitsuSiemensComputers
http://www.fujitsu-siemens.com/
Companystamp
Pointingdevices&controlbuttons
Touchpadwithaleftandright mousebutton
Powerbutton/lidswitch
Statusicons
Thenotebookhas7statusicons:
Powerstatus,batterychargestatus,capslock, numlock,
scrolllock, mediaactivity(HDD/ODD), wireless
communication
Security
Userand supervisorpassword
KensingtonLock
Powersystem
Li-lonbattery6cells,11.1V/4400mAh
Approximately2.00hrsbatteryruntime, dependingupon
usage1
Dynamicchargesupported, ACPI 2.0supported
ExternaluniversalACadapter:
Ratedvoltage:110–240VAC
Ratedfrequency: 50–60Hz
Outputvoltage: 20VAC
Outputcurrent:65 W
Dimensionsandweight
357 mm(W)x271mm(D)x24.5–39.5mm (H)
Approximately:2.8kg
Operatingconditions
operational:15°-35°C(ambienttemperature)
10%to90%relativehumidity,non-condensing
ACinput110–240V,50–60Hz
Certifications
EnergyStar(ECO)
GOSTcertification
CEMarking(EMI CISPR22)
R&TTE(WLAN)
Warranty
Countryspecificterms
Options
ACAdapter
USB Floppy
Carryingdevices
