Fujitsu Siemens Computers AMILO Li Series User manual

Notebook English, Norsk, Português,
Česky, Türkçe, Slovensko,
Slovenský
Getting Started
AMILO Li Series

Are there...
... any technical problems or other questions that you need help with?
Please contact:
• our Hotline/Help Desk(see Help Desk List) or visit "www.fujitsu-siemens.com/helpdesk"
• Your sales partner
• Your sales office
Additional information is contained in the Help Desk list and the "Warranty" manual.
The "Warranty" manual can be found on your notebook under Start - Manuals
or on the "Drivers & Utilities" CD/DVD or on our website.
For the latest information on our products, tips, updates etc., visit "www.fujitsu-siemens.com"

This manual was produced by Xerox Global Services
Published by
Fujitsu Siemens Computers GmbH
AG 01/07
Edition 1
Order No.: 10600790786
Order No.: 440 N00260

AMILO Li Series
English
Norsk
Português
Česky
Türkçe
Slovensko
Slovenský
Getting Started

Microsoft, MS, MS-DOS and Windows are registered trademarks of Microsoft Corporation.
Pentium is a registered trademark of Intel Corporation, USA.
Acrobat Reader is a trademark of Adobe Systems Incorporated.
Macrovision is a trademark of Macrovision Corporation, USA.
MultiMediaCard is a registered trademark of Infineon Technologies AG
Sony and Memory Stick are registered trademarks of Sony Electronics, Inc.
All other trademarks referenced are trademarks or registered trademarks of their
respective owners, whose protected rights are acknowledged.
Copyright © Fujitsu Siemens Computers GmbH 2007
All rights, including rights of translation, reproduction by printing, copying or similar
methods, in part or in whole, are reserved.
Offenders will be liable for damages.
All rights reserved, including rights created by patent grant or registration
of a utility model or design.
Delivery subject to availability. Right of technical modification reserved.

Contents
English
Contents
Innovativetechnology... ................................................................ 1
Areyoumissinginformation? ............................................................ 1
Notational conventions .................................................................. 1
Importantnotes ........................................................................ 2
Declarations of Conformity ............................................................... 2
Informationsources ..................................................................... 2
Safetyinformation ....................................................................... 3
Driversandutilities ...................................................................... 3
Portsandoperatingelements .......................................................... 3
Preparation for use andoperation ...................................................... 4
Unpacking and checking your notebook ................................................... 5
Selecting the location ................................................................... 5
Connecting the poweradapter ........................................................... 6
Switching the notebook on for the firsttime ................................................ 7
Switchingontheno
tebook . . . . ........................................................... 7
Switchingoffthen
otebook . . . . ........................................................... 8
Battery ................................................................................. 8
Easy Launch key . ...................................................................... 9
Touchpad and touchpadbuttons .......................................................... 9
Using the touchpadbuttons .......................................................... 10
Loudspeakers .......................................................................... 11
Switching the loudspeakeroffandon ................................................. 11
Volume: adjusting ................................................................... 11
Radio componenets(WirelessLAN) ...................................................... 12
Switching the wirelessLANmoduleonandoff ......................................... 12
BIOS Setup Utility ....................................................................... 12
Troubleshootingandtips .............................................................. 13
Restoringinstalledsoftware .............................................................. 13
Restoring the operating system, drivers, manuals and special software . . . . .............. 14
The notebook’s date or time is incorrect ................................................... 14
A beep sounds at a rate of one per second . . . ............................................ 14
The notebook’s LCD screen remains blank . . . . ............................................ 14
The LCD screen is difficulttoread ........................................................ 14
Theexternalmonitorremainsblank ...................................................... 15
Theexternalmonitorisblankortheimageisunstable ..................................... 15
The notebook cannot be started . . . ....................................................... 16
The notebook stops working . . ........................................................... 16
The printer does not print . . . . . ........................................................... 17
The radio connection to a network does not work . . ........................................ 17
10600790786, edition 1 English

Innovative technology...
Innovative technology...
and ergonomic design make your AMILO a reliable, convenient notebook. Your operating system
(e.g. Microsoft Windows) has already been preinstalled and optimally configuredsothatyou
can be up and running from the moment you switch on your AMILO for the first time.
This "Getting Started" guide tells you how to prepare your AMILO for use. If you encounter any
problems, helpful information can be found in the section "Troubleshooting and tips", Page 13.
Are you missing information?
An overview with further information about your notebook can be found
in "Information sources", Page 2.
Notational conventions
Pay particular attention to text marked with this symbol. Failure to
observe this warning may endanger your health, cause the equipment to
malfunction or lead to loss of data. The warranty does not cover defects of
the equipment caused by failure to follow these instructions.
indicates important information that is required to use the device properly.
►refers to an action which you must carry out.
indicates a result
This style flags data entered using the keyboard in a program dialog or command
line, e.g. your password (Name123) or a command to launch a program
(start.exe)
This style refers to information displayed by a program on the screen, e.g.:
Installation is completed
This style is for
• terms and texts in a software user interface, e.g.: ClickSave.
• names of programs or files, e.g. Windows or setup.exe.
"This style" is for
• cross-references to another section, e.g. "Safety information"
• Cross-references to an external source, such as a web address: For
further information visit "www.fujitsu-siemens.com"
• indicates names of CDs and DVDs as well as names and titles of other
materials, e.g.: "CD/DVD Drivers & Utilities" or "Safety" manual
Abc refers to a key on the keyboard, e.g.: F10
This style flags concepts and text that are emphasised or highlighted, e.g.: Do not
switch off device
1 - English 10600790786, edition 1

Important notes
Important notes
ImportantnotesNotes
This chapter contains references to other sources of information. It is essential that
you observe the safety information for your notebook.
Declarations of Conformity
Declarationof conformity
You will find the Declaration of Conformity for the AMILO on the Internet
at: "www.fujitsu-siemens.com".
Hereby, Fujitsu Siemens Computers, declares that the AMILO is in compliance with the
essential requirements and other relevant provisions of Directive 1999/5/EC.
Information sources
Inform ation sources
In diesem Handbuch finden Sie ausführlichere Hinweise und technische Informationen
zu Ihrem Notebook. Handbücher, die nur als PDF-Dateien vorliegen, können Sie
ausdrucken, wenn Sie einen Drucker an Ihr Notebook anschließen.
Information source Type of information Where?
Quick Start Guide (printed) Poster with information
about getting started
Accessories kit
"Safety" manual (printed
and/or PDF file)
Safety information Accessories kit and/or on your
notebook
"Recovery Process" manual
(printed and/or PDF file)
Information on restoring
the operating system,
drivers, manuals and special
software
Accessories kit, on your
notebook or on the internet at
"www.fujitsu-siemens.com/support/"
"EasyGuide" manual (PDF
file)
Detailed instructions for
startup, operation and
technical information
"Wireless LAN" manual
(PDF file)
Detailed instructions for
using wireless LAN and
technical information
"Warranty" manual (PDF
file)
General guarantee
conditions
Information files (e.g. *.TXT,
*.DOC, *.CHM, *.HLP)
Information on utilities and
programs
The manuals are located on your
notebook under Start Manuals
or, in some cases, updated versions
can be found on the Internet at:
"www.fujitsu-siemens.com/support/"
Information files (e.g. *.TXT,
*.DOC, *.CHM, *.HLP)
Information about the
operating system
In the software for these applications
10600790786, edition 1 English - 2

Ports and operating elements
Safety information
SafetyinformationNotes
Pay attention to the information provided in the "Safety" manual
and in the following safety notes.
• When cleaning the notebook, observe the relevant notes in the "EasyGuide"manual.
• Your notebook is equipped with numerous security features that offer you a high
level of security according to a multi-level concept. Details are contained in the
"Security functions" chapter in the "EasyGuide" manual.
• Pay attention to the additional safety notes for devices with radio components
provided in the "Safety" manual.
• Keep this operating manual together with the device. If you pass this device on
to others, you should also give them the operating manual.
This notebook complies with the relevant safety regulations for data processing
equipment. If you have questions about using your notebook in a particular area,
please contact your sales outlet or our Hotline/Help Desk.
Drivers and utilities
If a Windows operating system is installed on your notebook, you will find additional
information on the system and drivers, help programs and updates on your notebook
or on our website "www.fujitsu-siemens.com/support/".
If you need to reinstall your operating system, you can reload the original
software and the original drivers of your notebook onto the hard disk using the
"Drivers & Utilities" CD/DVD or the drivers from our website.
Ports and operating elements
Portsandope rating elementsModemportLCDscreenMonitorpor tBuilt-inloudspeakersLoudspeakerp ortWirelessLANKensingtonLockLANportUSBportExpressCards lotBatteryBatteryreleaseSIMcardHarddiskTouchpadbutton sTouchpadscrollbarTou ch p a dNotebookON/OFFswitchEasyLaunch keyCD/DVDdriveHeadphonepo rtMicrophoneportLineinLine outSPDIFportDC INjack
This chapter presents the individual hardware components of your notebook. It provides
an overview of the notebook’s displays and ports. Please familiarise yourself with
these components before you start to work with your notebook.
3 - English 10600790786, edition 1

720
22
10
14
12
15
9
8
13
16
17
18
19
21
1
2
54
6
3
7
11
1 = Kensington Lock
2=DCINjack
3 = Monitor port
4 = LAN port
5=USBport
6 = ExpressCard slot
7 = Built-in loudspeakers
8 = Easy Launch key
9 = ON/OFF switch for the Notebook
10 = Touchpad
11 = Touchpad scroll bar
12 = Touchpad buttons
13 = Status indicators
14 = Headphones/SPDIF port
15 = Microphone port/Line In
16 = ON/OFF switch, Wireless LAN
17 = USB ports
18 = CD/DVD drive
19 = Modem port
20 = Service compartment (hard disk, memory)
21 = Battery
22 = Battery release
Preparation for use and operation
Please observe the safety information in the section "Important notes", Page 2.
You must charge the battery and install the application programmes before you can work with
the notebook. The operating system and drivers required are preinstalled.
This chapter also describes the basics for operating your notebook.
10600790786, edition 1 English - 4
Preparation for use and operation

Preparation for use and operation
Unpacking and checking your notebook
Should you discover any damage incurred during transportation,
notify your local sales outlet immediately!
►Unpack all the individual parts.
PackagingTransport
►Check your notebook for damage incurred during transportation.
We recommend that you keep the original packaging material.
You may need the packaging in the future if you need to transport your device.
Selecting the location
Location,selec tingtheNotebookPower adapter
Select a suitable location for the notebook before setting it up. Consider
the following points when selecting a location:
• Never place the notebook on a soft surface (e.g. carpeting, upholstered furniture,
bed). This can block the air vents and cause damage due to overheating.
• Do not place the notebook directly on your legs for extended periods. The
underside of the notebook heats up during normal operation. Extended contact
with the skin can become unpleasant or even result in burns.
• Place the notebook on a stable, flat, non-slip surface. Please note that
the rubber feet may mark certain types of surfaces.
• Keep other objects 100 mm away from the notebook and its mains
adapter to ensure adequate ventilation.
• Never cover the ventilation slots on the notebook or the mains adapter.
• Do not expose the notebook to extreme environmental conditions. Protect
the notebook against dust, humidity and heat.
5 - English 10600790786, edition 1

Preparation for use and operation
Connecting the power adapter
Preparingfor operationPoweradapter
Please refer to the instructions in "Safety information", Page 3.
The power cable supplied conforms to the requirements of the country in which
you purchased your notebook. Make sure that the power cable is approved
for use in the country in which you intend to use it.
The mains adapter’s power cable must only be connected to a mains socket
if the notebook is connected to the mains adapter.
Make sure that the rated current of the mains adapter is not higher than that of the
power system to which you connect it (see technical data for the mains adapter).
1
2
3
►Connect the mains adapter cable (1) to the
DC jack (DC IN) on the notebook.
►Plug the power cable (2) into the
mains adapter.
►Plug the power cable (3) into a
mains outlet.
10600790786, edition 1 English - 6

Preparation for use and operation
Switching the notebook on for the first time
Switchingonforthefirsttime
When you switch your notebook on for the first time, the supplied software is
installed and configured. Due to the fact that this installation procedure must not
be interrupted, you should set aside enough time for it to be fully completed and
connect the notebook to the mains outlet using the mains adapter.
During installation, the notebook must only be rebooted when
you are requested to do so!
Your operating system is pre-installed on the hard disk to facilitate the procedure
when you use your notebook forthefirst time.
►Switch the notebook on (see "Switching on the notebook", Page 7).
►During installation, follow the on-screen instructions.
Consult the operating system manual if anything is unclear about the requested input data.
If a Windows operating system is installed on your notebook, you will find
additional information on the system as well as the drivers, help programs,
updates, manuals, etc. on your notebook or on the "Drivers & Utilities" CD/DVD
or on our website (see "Information sources", Page 2).
Switching on the notebook
2
1
►Slide the release button in the direction
of the arrow (1) and unfold the LCD
screen upward (2).
Notebook
1
►Press the ON/OFF switch (1) to
switch the notebook on.
The power-on indicator is lit.
7 - English 10600790786, edition 1

Preparation for use and operation
Switching off the notebook
1
►Shut down the operating system properly
(in Windows via the Start menu by clicking
Startsymbol – Shut Down – Shut Down – OK).
Notebook
►If the notebook is not switched off
automatically, press the ON/OFF switch (1)
for approx. five seconds.
1
►Close the LCD screen (1) so that
it locks into place.
Battery
The battery in the notebook is not fully charged at the time of delivery. You
must first charge the battery with the mains adapter connected to the power
socket (see "Connecting the power adapter", Page 6).
The battery supplies your notebook with the necessary power during mobile use. The
battery indicator displays the current state of the battery.
Information on how to install and remove the battery, how to maintain and service it, and how
to optimise the battery operating time can be found in the "EasyGuide" manual.
10600790786, edition 1 English - 8

Preparation for use and operation
Easy Launch key
EasyLaunch key
Your notebook is equipped with an
Easy Launch key. With the pre-installed
software you can launch the following
applications or functions by pressing a
single key.
Silent Mode
This key reduces the speed of the fan.
When the Silent Mode is switched on, the processor and graphics do not operate at
the full performance level.
Whispermode, EasyLaunchkeySilentMode,Ea syLaunchkey
Touchpad and touchpad buttons
Keep the touchpad clean. Protect it from dirt, liquids, and grease.
TouchpadTouchpad
Do not use the touchpad if your fingers are dirty.
Do not rest heavy objects (e.g. books) on the touchpad or the touchpad buttons.
1
2
31 = Touchpad
2 = Touchpad buttons
3 = Touchpad scroll bar
The touchpad enables you to move the mouse pointer on the screen.
The touchpad buttons allow you to select and execute commands. They
correspond to the buttons on a conventional mouse.
You can use the touchpad scroll bar to scroll.
9 - English 10600790786, edition 1

Preparation for use and operation
Using the touchpad buttons
Moving the pointer
►Move your finger on the touchpad.
Touchpad
The pointer will move accordingly.
Selecting an item
►Move the pointer to the item you wish to select.
Touchpad
►Tap the touchpad once or press the left button once.
The item is selected.
Executing a command
►Move the pointer to the field you wish to select.
Touchpad
►Tap the touchpad twice or press the left button twice.
The command is executed.
Dragging an object
►Select the desired object.
Touchpad
►Press and hold the left button and drag the object to the desired position
with the finger on the touchpad.
The item is moved.
Scrolling with the touchpad scroll bar
►Move your finger upwards or downwards on the scroll bar at the right edge of the touchpad.
The display area moves up or down.
10600790786, edition 1 English - 10

Preparation for use and operation
Loudspeakers
1
1
1 = Built-in loudspeakers
Loudspeakers
Two stereo loudspeakers are installed in your notebook.
The built-in loudspeakers will be disabled if headphones or external
loudspeakers are connected.
Switching the loudspeaker off and on
►Use the key combination Fn +F3 to switch the loudspeaker off and on.
Volume: adjusting
►Set the desired volume with the key combination Fn +F5 or Fn +F6 .
or
►Double-click the loudspeaker symbol in the tool bar and Mixer.
or
►Select Startsymbol – (Settings) – Control Panel – Hardware and Sound
– Sound: Adjust volume control.
►Use the slide control to change the volume.
Volume
►To turn the loudspeaker on or off, double-click the loudspeaker symbol in the tool bar.
11 - English 10600790786, edition 1

Preparation for use and operation
Radio componenets (Wireless LAN)
The installation of a wireless LAN module not approved by Fujitsu Siemens
Computers GmbH will invalidate the permits (CE!) issued for this device.
Wireless LAN
Wireless LAN is integrated in your notebook.
Switching the wireless LAN module on and off
Check whether the wireless LAN module is activated/deactivated
in the installed wireless LAN software.
Wireless LANWireless LAN
►Move the slider to the "ON" position to
activate the wireless LAN module.
The wireless LAN indicator lights up when
the wireless LAN module is switched on.
Further information on using a wireless LAN can be found in the corresponding
manual or in the help files (see "Information sources", Page 2).
BIOS Setup Utility
With the BIOS Setup Utility you can change a number of parameters and thus the configuration
of your notebook. For example, you can use the BIOS Setup Utility to set the date and
time. The BIOS Setup Utility can also be used to assign passwords. The "EasyGuide"
manual explains how to open and close the BIOS Setup Utility.
10600790786, edition 1 English - 12

Troubleshooting and tips
Troubleshooting and tips
TroubleshootingTipsFaultTroubleshooting
Refer to the safety information in the "Safety" manual when connecting
or disconnecting cables.
If a fault occurs, try to correct it as described. If you fail to correct the problem, proceed as follows:
►Make a note of the steps and the circumstances that led to the fault. Also
make a note of any error messages displayed.
►Switch the notebook off.
►Contact the Hotline/Help Desk.
You can find the telephone numbers in the help desk list. Please have
the following information ready when you call:
• The model name and serial number of the notebook. The serial number is
located on a sticker on the underside of the notebook.
• Notes of any messages that appear on the screen and
information on acoustic signals.
• Any changes you have made to the hardware or software
since receiving the notebook.
• Any changes you have made to the BIOS Setup settings since
receiving the notebook.
• Your system configuration and all peripheral devices connected to your system.
• Your sales contract.
Our notebooks have been designed primarily with mobile applications in mind.
This means that considerable effort has been made to optimise components and
equipment in terms of weight, space and energy requirements. Depending on the
particular configuration you have purchased, it is possible that functionality may be
slightly reduced compared to a desktop PC if you are running processor-intensive
gaming software, e.g. games with intensive 3D graphics. Updating your hardware
with drivers which have not been approved by Fujitsu Siemens Computers may
result in performance losses, data losses or malfunction of the equipment. A
list of approved drivers and current BIOS versions can be downloaded from:
"http://www.fujitsu-siemens.de/support/downloads.html"
Restoring installed software
Please create backup copies of your files on a regular basis. If data is lost, you can
restore your applications using the data carriers. However, if you do not have backup
copies of your own data files, it is no longer possible to restore them.
If your operating system will not start, or if there are errors on the hard disk, the
pre-installed software may have to be re-installed.
13 - English 10600790786, edition 1
