Fujitsu Siemens Computers AMILO Si 2636 Product information sheet

Notebook English
EasyGuide
AMILO Si Series

Are there ...
... any technical problems or other questions you wish to discuss?
Please contact:
• our Hotline/Help Desk (see Help Desk list or visit: "www.fujitsu-siemens.com/helpdesk")
• Your authorised distributor
• Your sales office
Additional information is contained in the Help Desk list and the "Warranty" manual.
You can find the "Warranty" manual on your notebook under Start symbol – Manual,
on the "Drivers & Utilities" CD/DVD or on our website.
Latest information on our products, tips, updates etc. can be found on our
website: "www.fujitsu-siemens.com"

This manual was produced by Xerox Global Services
Published by
Fujitsu Siemens Computers GmbH
Edition 1, October 2007
Order no.: 10600903218
Order no.: 440N00563

AMILO Si Series
Innovative technology... 1
Ports and controls 3
Important notes 5
Using your notebook for the first time 9
Working with the notebook 12
Security functions 41
Connecting external devices 44
Removing and installing components
during servicing 53
Settings in BIOS Setup Utility 59
Troubleshooting and tips 61
Technical data 66
Manufacturer’s notes 68
Index 70
EasyGuide

Microsoft, MS Windows and Windows Vista are registered trademarks of the Microsoft Corporation.
Acrobat Reader is a trademark of Adobe Systems Incorporated.
Macrovision is a trademark of Macrovision Corporation, USA.
MultiMediaCard is a registered trademark of Infineon Technologies AG
Sony and Memory Stick are registered trademarks of Sony Electronics, Inc.
All other trademarks referenced are trademarks or registered trademarks of their
respective owners, whose protected rights are acknowledged.
Copyright © Fujitsu Siemens Computers GmbH2007
All rights reserved, including rights of translation, reproduction by printing, copying
or similar methods, either in part or in whole.
Non-compliance is subject to compensation for damages.
All rights reserved, including rights created by patent grant or registration of a utility model or design.
Subject to availability and technical modifications.

Contents
Contents
Innovativetechnology... ................................................................ 1
Are you missing information? ............................................................ 1
Notational conventions .................................................................. 2
Portsandcontrols ..................................................................... 3
Importantnotes ........................................................................ 5
Safetyinformation ....................................................................... 5
Energysaving .......................................................................... 5
Energy saving under Windows ....................................................... 5
Information sources ..................................................................... 6
Travelling withyournotebook ............................................................ 7
Before youtravel ................................................................... 7
Transporting the Notebook . . . ....................................................... 7
Cleaning the Notebook .................................................................. 8
Using your notebookforthefirsttime .................................................. 9
Unpacking and checking your notebook ................................................... 9
Selecting the location ................................................................... 10
Connecting the poweradapter ........................................................... 10
Switching the notebook on for the first time ................................................ 11
Workingwiththenotebook ............................................................ 12
Switching on the Notebook . . . ........................................................... 12
Switching off the Notebook . . . ........................................................... 13
Statusindicators ........................................................................ 14
Keyboard ............................................................................... 16
Virtualnumerickeypad .............................................................. 18
Keycombinations ................................................................... 18
Country and keyboard settings ....................................................... 20
MediaPlayerButtons ................................................................... 20
Touchpadandtouchpad buttons .......................................................... 21
Usingtouchpadbuttons .............................................................. 21
LCD screen ............................................................................ 23
Information on theLCDscreen ....................................................... 23
Screensettings ..................................................................... 24
Webcam ............................................................................... 25
Battery ................................................................................. 26
Charging,caring forandmaintainingthebattery ....................................... 26
Removing andinstallingthebattery ................................................... 27
Usingthepower-managementfeatures ................................................... 28
Harddisk ............................................................................... 29
ExpressCards .......................................................................... 30
InsertingtheExpressCard ........................................................... 30
Removing theExpressCard ......................................................... 31
Memorycards .......................................................................... 32
Insertingthememory card ........................................................... 32
Removing thememorycard .......................................................... 32
CD/DVD ............................................................................... 33
CD/DVDdatastoragemedia(certain devicesonly) ..................................... 33
HandlingCD/DVDs .................................................................. 34
CD/DVD drives (device-dependent) ................................................... 35
10600903218, edition 1

Contents
Insertingorremovinga CD/DVD ...................................................... 36
Regional codes for DVD filmsand DVD players ........................................ 37
AdjustingtheAutoPlayfunctionofyourCD/DVD drive .................................. 37
Microphone and loudspeakers . . . ........................................................ 38
Volume: adjusting ................................................................... 38
EthernetandLAN ....................................................................... 39
Wireless components (wireless LAN/Bluetooth) . . . ......................................... 40
SwitchingthewirelessLAN/Bluetooth moduleon andoff ............................... 40
Securityfunctions ..................................................................... 41
Briefoverviewofsecurityfunctions ....................................................... 41
UsingKensingtonLock .................................................................. 41
ConfiguringpasswordprotectioninBIOSSetupUtility ...................................... 42
Protecting BIOS Setup Utility (supervisor and user password) . .......................... 42
Passwordprotectionofoperatingsystem .............................................. 43
Connectingexternaldevices ........................................................... 44
Ports ................................................................................... 45
Connecting an external monitor . . ........................................................ 46
Settingtherefreshrate foryourexternalmonitor ...................................... 47
Connecting USB devices (USB ports with charging function) . . .............................. 48
eSATA/USB combinationport ............................................................ 49
Connecting FireWire devices . ............................................................ 50
Connecting external audio devices . . . . . . ................................................. 50
HDMI port .......................................................................... 50
Microphone port / Line In ............................................................ 51
Headphones/SPDIF port (loudspeaker port / line out) . .................................. 51
Removing and installing components during servicing . . . .............................. 53
Notes on installing and removing boards and components .................................. 53
Removing and installingthebattery ....................................................... 53
Removing and installingthehard disk .................................................... 54
Removing the harddisk .............................................................. 54
Installing the harddisk ............................................................... 55
Memory:expansion ..................................................................... 56
Installing and removing the memory expansion . . . . . . .................................. 56
Settings in BIOS Setup Utility . . ........................................................ 59
StartingtheBIOSSetupUtility ........................................................... 59
OperatingBIOSSetupUtility ............................................................. 59
ExitingBIOSSetup Utility ................................................................ 60
Save Changes and Exit – Save the settings and exit the BIOS Setup Utility . . . ........... 60
Discard Changes & Exit– Discard changes and exit the BIOS Setup Utility ............... 60
Get Default Values–Transferring standardentries ..................................... 60
Load Previous Values – Discard Changes without exiting the BIOS Setup Utility . . . . . . .... 60
Save Changes – Saving the settings . ................................................. 60
Troubleshootingandtips .............................................................. 61
Restoringinstalled software .............................................................. 61
Restoring the operating system, drivers, manuals and special software . . . ............... 62
The notebook’sdateortimeis incorrect ................................................... 62
The notebook’sLCD screen remainsblank ................................................ 62
The LCD screen is difficulttoread ........................................................ 62
The externalmonitor remains blank ...................................................... 63
10600903218, edition 1

Contents
The externalmonitor isblank ortheimage is unstable ..................................... 63
The notebook cannot be started . . . ....................................................... 64
The notebook stops working . . ........................................................... 64
The printer does not print . . . . . ........................................................... 65
The radio connection to a network does not work . . ........................................ 65
Technicaldata ......................................................................... 66
Notebook . . ............................................................................. 67
Battery ................................................................................. 67
Mains adapter .......................................................................... 67
Manufacturer’snotes .................................................................. 68
Disposal andrecycling .................................................................. 68
Declarationsof Conformity ............................................................... 68
Copyright-protectedtechnology .......................................................... 68
CEmarking ............................................................................ 69
Index .................................................................................. 70
10600903218, edition 1

Contents
10600903218, edition 1

Innovative technology...
Innovative technology...
and ergonomic design make your AMILO a reliable, convenient notebook.
Your notebook is available in several different versions. Most of the sections in this manual apply to
all models – any differences are indicated separately. Some of the illustrations and features in this
manual may differ from your model and are for guidance only. The "optional" components described
in this manual are only available for certain models and must be selected at the time of purchase. At
the time this manual is printed it is not possible to say whether the "model-specific" components
and functions described in this manual will be available for your own particular model.
If you have purchased a notebook with a Microsoft Windows operating system, this will be pre-installed
and optimally configured for you. The notebook is ready to use when you switch it on for the first time.
Your notebook features the very latest technology so that you get the best performance from
your computing experience. Depending on which model you own, you have access to:
• up to 2 or 4 GB of main memory (RAM). Please contact our Technical Support
for information on released memory modules.
• a digital HDMI output connection in order to connect an external digital monitor
• a CD/DVD burner for watching DVD movies or recording your own CDs and DVDs
• several USB ports for easy expansion with webcams, game pads, printers and more.
All USB ports are connections with a charging function, i.e. they can be used to charge
a connected USB device even when the notebook is switched off.
• an eSATA/USB combination connection in order to connect an external SATA hard
disk or another USB device (USB with charging function).
• an integral webcam to take photos or to video chat
• internal LAN or wireless LAN for Internet access
• an ExpressCard slot for operating an ExpressCard (type 34/54)
• a memory card slot for transferring digital photos, music and videos quickly onto your notebook
• two onboard microphones for voice recording or Voice over Internet Protocol (VoIP)
• an integrated audio controller and two stereo loudspeakers for your audio enjoyment
With the user-friendly "BIOS Setup Utility" you can control your notebook’s hardware and protect
your system better against unauthorised access by using the powerful password properties.
This operating manual tells you how to put your AMILO into operation, and
how to operate it in daily use.
Are you missing information?
An overview with further information about your notebook can be found in
"Information sources", Page 6.
10600903218, edition 1 1

Innovative technology...
Notational conventions
Pay particular attention to text marked with this symbol. Failure to observe
this warning will endanger your life, will damage the device or lead to loss
of data. The warranty will be invalidated if you cause defects in the device
through failure to take notice of this warning
indicates important information that is required to use the device properly.
►indicates an activity that must be performed in the order shown
indicates a result
This style flags data entered using the keyboard in a program dialog or command
line, e.g. your password (Name123) or a command to launch a program
(start.exe)
This style refers to information displayed by a program on the screen, e.g.:
Installation is completed
This style is for
• terms and texts in a software user interface, e.g.: Click Save.
• names of programs or files, e.g. Windows or setup.exe.
"This style" is for
• cross-references to another section, e.g. "Safety information"
• cross-references to an external source, e.g. a web address: For more
information, go to "www.fujitsu-siemens.com"
• indicates names of CDs and DVDs as well as names and titles of other
materials, e.g.: "CD/DVD Drivers & Utilities" or "Safety" manual
Abc refers to a key on the keyboard, e.g.: F10
This style flags concepts and text that are emphasised or highlighted, e.g.: Do not
switch off device
210600903218, edition 1

Ports and controls
Ports and controls
MemorycardslotUSBportKensingtonLo ckDigitalHDMIportDCINjackLANportMicrophoneWebcamNotebookON/OFFswitchTou c hp a dTouchpadbuttonsStatusindicatorsON/OFFswitch,wirelessLANCD/DVDdriveExpressCard slotHeadp hones portMicrop hone portLoudspeakerHarddiskservicecompartmentBatteryrelea selatchBatteryMemoryservicecompartmenteSATA/USBcombinationport
This chapter presents the individual hardware components of your notebook. It gives an
overview of the displays and connections on the notebook. Please familiarise yourself with
these components before you start to work with your notebook.
2
11
45
6
7
8
9
10
11
12
13
14
15
16
17
18 19 202122 23
24
25
26
27
28
3
1 = Internal microphones
2 = Webcam
3 = WebCam ON/OFF switch
4 = Touchpad
5 = Touchpad buttons
6 = Media Player Buttons
7 = Memory card slot
8 = FireWire port
9 = Headphones/SPDIF port
10 = Microphone port/Line In
11 = Status indicators
12 = ExpressCard slot
13 = USB ports with charging function
14 = LAN port
15 = Kensington Lock
16 = Notebook ON/OFF switch
17 = Status indicators
18 = CD/DVD drive eject button
19 = CD/DVD drive
20 = Radio components ON/OFF switch
21 = eSATA/USB combination port (USB
with charging function
10600903218, edition 1 3

Ports and controls
22 = Digital HDMI port
23=DCINjack
24 = Memory service compartment
25 = Battery release latch
26 = Battery
27 = Battery release button
28 = Hard disk service compartment
410600903218, edition 1

Important notes
Important notes
ImportantnotesNotes
Here you will find essential safety information regarding your notebook. The other
notes provide helpful information on your notebook.
Safety information
SafetyinformationNotes
Please note the safety information provided in the "Safety" manual
and in the safety notes below.
Observe the sections in the manual marked with the symbol on the left.
When connecting and disconnecting cables, observe the relevant
notes in this operating manual.
Read the information on the ambient conditions in "Technical data", Page 66 and
the chapter "Using your notebook for the first time", Page 9 before preparing
your notebook for use and switching it on for the first time.
When cleaning the device, please observe the relevant notes in
"Cleaning the Notebook", Page 8.
If you have a notebook with a wireless component, you must also observe the additional
safety precautions for devices with wireless components in the "Safety" manual.
Please refer to the notes in the chapter "Removing and installing
components during servicing", Page 53.
This notebook complies with the relevant safety regulations for data processing
equipment. If you have questions about using your notebook in a particular area,
please contact your sales outlet or our Hotline/Help Desk.
Energy saving
NotesEnergyEnergysaving
Switch the notebook off when it is not in use. Switch off external, connected devices if you
are not using them. If you use the energy saving functions, the notebook uses less energy.
You will then be able to work for longer before having to recharge the battery.
Energy efficiency is increased and the environmental impact is reduced.
You save money while protecting the environment.
Energy saving under Windows
►Make use of the power management features (see ""Using the power-management features",
Page 28").
10600903218, edition 1 5

Important notes
Information sources
Infor matio nso urces
This manual contains more detailed instructions and technical information for your notebook.
Manuals available only as PDF files can be printed out if you connect a printer to your notebook.
Information source Type of information Where?
Quick Start Guide (printed) Poster with information about
getting started
Accessories kit
"Safety" manual (printed
and/or PDF file)
Safety information Accessories kit and/or on your
notebook
"Recovery Process" manual
(printed and/or PDF file)
Information on restoring
the operating system,
drivers, manuals and special
software
Accessories kit, on your
notebook or on our website at
"www.fujitsu-siemens.com/support/"
"EasyGuide" manual (PDF
file)
Detailed instructions for
startup, operation and
technical information
"Warranty" manual (PDF
file)
General guarantee
conditions
Information files (e.g. *.TXT,
*.DOC, *.CHM, *.HLP)
Information on utilities and
programs
The manuals are located on your
notebook under Startsymbol – Manual
or in some cases, updated versions
can be found on our website at:
"www.fujitsu-siemens.com/support/".
information files (e.g. *.TXT,
*.DOC, *.CHM, *.HLP)
Information about the
operating system, the
WebCam and Bluetooth
In the software for these applications
Information files (e.g. *.TXT,
*.DOC, *.CHM, *.HLP)or
Windows Vista Help [F1].
Information on Wireless LAN In the Wireless LAN router software /
application from your Internet provider
or Windows Vista Help [F1].
610600903218, edition 1

Important notes
Travelling with your notebook
Mobileope rationNotesTransp ortati onNotebook
Please observe the points listed below when travelling with your notebook.
Before you travel
►Back up important data stored on your hard disk.
NotebookTrav el,notebook
►Switch off the radio component for data security reasons. With data traffic via a wireless
connection, it is also possible for unauthorised third parties to receive data.
Information on activating data encryption is provided in the documentation
for your radio component.
►If you wish to use your notebook during a flight, first check with the flight
attendants if it is OK to do so.
When travelling in other countries
►If you are travelling abroad, check that the mains adapter can be operated with the
local mains voltage. If this is not the case, obtain the appropriate mains adapter for
your notebook. Do not use any other voltage converter!
►Check whether the local power supply and the specifications of the power cable are
compatible. If this is not the case, buy a power cable that matches the local conditions. Do
not use a connection adapter for electrical devices to connect the notebook.
►Enquire with the corresponding government office of the country you will be
travelling in as to whether you may operate the radio component integrated in
your notebook there (see also "CE marking", Page 69).
►If you are planning to use a modem, please be aware that it may not necessarily be compatible
with the local telephone system. This may result in poor performance, or the modem may not work
at all. You may require a country-specific telephone adapter (available as an optional accessory).
Transporting the Notebook
A placeholder must occupy the ExpressCard slot. This will prevent any
foreign bodies from entering the notebook via the slot.
Protect the notebook from severe shocks and extreme temperatures
(e.g. direct sunlight in a car).
►Remove all disks (e.g. CD, DVD) from the drives.
Transportation Notebook
►Switch the notebook off.
►Unplug the mains adapter and all external devices from the power socket.
►Disconnect the mains adapter cable and the data cables for all external devices.
►Close the LCD screen so that it locks into place.
►To protect against damaging jolts and bumps, use a notebook carrying
case to transport your notebook.
10600903218, edition 1 7

Important notes
Cleaning the Notebook
Do not clean any interior parts yourself; leave this job to a service technician.
Only use cleaning products designed for computers. Normal household
cleaners and polishes can damage the markings on the keyboard and the
device, the paintwork or the notebook itself.
Ensure that no liquid enters the notebook.
The Crystal View display is very sensitive to scratching! Only clean the
display surface with a very soft, slightly damp cloth.
►Switch the notebook off.
CleaningNotesNotebookKeyboardTouchpadLCD screenC rystalVie wdisplay
►Unplug the mains plug of the mains adapter from the mains socket.
►Remove the battery (see "Removing the battery", Page 27).
Wipe the casing with a dry cloth. If particularly dirty, use a cloth which has been
moistened in mild domestic detergent and then carefully wrung out.
To clean the keyboard and the touchpad, you can use disinfectant wipes.
810600903218, edition 1

Using your notebook for the first time
Using your notebook for the firsttime
Please read the chapter entitled "Important notes", Page 5.
GettingstartedNotebookGettingstartedNo tebook
Before you can use your notebook for the first time you need to charge the battery and install the
supplied software. The Windows operating system and drivers required are already pre-installed.
Upon delivery, the battery can be found in the battery compartment or in the accessories kit. The
battery must be charged if you want to operate your notebook with the battery.
When not plugged into a mains outlet, the notebook runs on its built-in battery. You can
increase the battery’s life by enabling the system’s energy saving functions.
When you use your notebook in your home or office, we recommend you use
the mains adapter instead of the battery.
Please read the chapter entitled "Connecting external devices", Page 44 for instructions on
how to connect devices such as a mouse and a printer to the notebook.
Unpacking and checking your notebook
Should you discover any damage incurred during transportation, notify
your local sales outlet immediately!
►Unpack all the individual parts.
PackagingTransport
►Check your notebook for damage incurred during transportation.
We recommend that you keep the original packaging material.
You may need the packaging in the future if you need to transport your device.
10600903218, edition 1 9

Using your notebook for the first time
Selecting the location
Location,sel ectingtheNotebookPoweradapt er
Select a suitable location for the notebook before setting it up. Consider
the following points when selecting a location:
• Never place the notebook on a soft surface (e.g. carpeting, upholstered furniture,
bed). This can block the air vents and cause damage due to overheating.
• Do not place the notebook directly on your legs for extended periods. The
underside of the notebook heats up during normal operation. Extended contact
with the skin can become unpleasant or even result in burns.
• Place the notebook on a stable, flat, non-slip surface. Please note that
the rubber feet may mark certain types of surfaces.
• Keep other objects 100 mm away from the notebook and its mains
adapter to ensure adequate ventilation.
• Never cover the ventilation slots on the notebook or the mains adapter.
• Do not expose the notebook to extreme environmental conditions. Protect
the notebook against dust, humidity and heat.
Connecting the power adapter
Preparingf oroperationPoweradapt er
Please refer to the instructions in "Safety information", Page 5.
The power cable supplied conforms to the requirements of the country in which
you purchased your notebook. Makesurethatthepowercableisapproved
for use in the country in which you intend to use it.
The mains adapter’s power cable must only be connected to a mains socket
if the notebook is connected to the mains adapter.
Make sure that the rated current of the mains adapter is not higher than
that of the power system to which you connect the mains adapter (see
section "Technical data", "Mains adapter", Page 67).
1
2
3
►Connect the mains adapter cable (1) to the
DC jack (DC IN) on the notebook.
►Plug the power cable (2) into the
mains adapter.
►Plug the power cable (3) into a mains outlet.
10 10600903218, edition 1
