Fujitsu Siemens Computers AMILO Pi 3525 User manual

Issue January 2009
Version 3
AMILO Notebook Pi 3525
The perfect all-round
notebook Pages 6
The AMILO Notebook P Series combines versatile performance, great technology and a fascinating design.
Processor technology
Latest Intel® Centrino® 2 processor technology1(optional) for high-definition digital
entertainment experience, blistering performance, longer-lasting battery life and the
new wireless standard for connectivity
Operating System
Windows Vista® Home Premium
Mobility
Standard 15.4-inch form-factor that fits in almost every bag
Optional with integrated draft-n Intel® WiFi Link 5100 AGN to go online when and
wherever you want
Entertainment and Multimedia
The integrated AMILOcam with low-light technology for great video-quality even in
low-light conditions and the built-in array microphone are perfect for Internet telephony
(VoIP) and video chats
LCD WXGA display with BrilliantView technology for vivid colors, amazing sharpness
and impressive contrast
Enjoy your favorite Hollywood blockbuster on an external display via DVI-I (with
HDCP support)
More convenience thanks to
The spill-proof keyboard2that protects your notebook against accidentially spilt liquids
The silent mode function that causes a noticeable reduction in fan noise
The built-in DVD drive to store and secure data comfortably on the move
Model: Reveal white
Model: Eclipse black

Data Sheet ⏐Issue: January 2009⏐AMILO Notebook Pi 3525 Page 2 / 6
Fujitsu Siemens Computers recommends Windows Vista® Home Premium
Operating systemand Recovery
Operating system Genuine Windows Vista® Home Premium (32-bit version)
Fujitsu Siemens Computers Recovery Program Backup and restore the original status of the hard disk and create system
restore disks
or individual recovery media on CD or DVD are included
Product design
Color Reveal white or eclipse black
Architecture
System architecture Intel® Centrino® 2 processor technology (optional)1
Chipset Intel® GM45 + ICH9M
Processors3
Intel® Core™2 Duo processors P7350 (2.0 GHz, 1066MHz FSB, 3MB L2 cache)
P7450 (2.13 GHz, 1066 MHz FSB, 3 MB L2 cache)
P8400 (2.26 GHz, 1066MHz FSB, 3MB L2 cache)
P8600 (2.4 GHz, 1066MHz FSB, 3MB L2 cache)
T5800 (2.0 GHz, 800 MHz FSB, 2 MB L2 cache)
T5900 (2.2 GHz, 800 MHz FSB, 2 MB L2 cache)
T6400 (2.0 GHz, 800 MHz FSB, 2 MB L2 cache)
T6600 (2.2 GHz, 800 MHz FSB, 2 MB L2 cache)
Intel® Pentium® processor T3200 (2.0 GHz, 677 MHz FSB, 1MB L2 cache, dual-core)
T3400 (2.16 GHz, 667 MHz FSB, 1 MB L2 cache, dual-core)
Memory 2 SO-DIMM memory slots (no memory on board)
Memory speed 800 MHz
Memory type DDR 2 RAM
Memory modules 1024 or 2048 MB
Max. memory size3,4 4096 MB
Drives
Hard disk drive
HDD type SATA
HDD size 2.5-inch
HDD speed 5400 rpm
HDD cache 8 MB
HDD capacity3160, 250, 320 or 500 GB
Optical disc drive(built-in)
ODD type SATA
ODD technology SuperMulti-format DVD burner with double layer (DL) support
ODD read speed CD-ROM 24x, DVD-ROM 8x
ODD write speed CD-R 24x, CD-RW 16x, DVD+R 8x, DVD-R 8x, DVD+RW 8x,
DVD-RW 6x, DVD+R DL (8.5 GB) 4x, DVD-R DL (8.5 GB) 4x,
DVD-RAM 5x
Display
Display type BrilliantView LCD
Display size 15.4-inch
Display resolution (intern) 1280 x 800 pixels
Display resolution (extern) 1920 x 1200 pixels
Resolution type WXGA
Reaction time 16 ms
Brightness (typ.) 200 NIT
Contrast (typ.) 400 : 1
Compliance with standards ISO 13406-2 class II

Data Sheet ⏐Issue: January 2009⏐AMILO Notebook Pi 3525 Page 3 / 6
Fujitsu Siemens Computers recommends Windows Vista® Home Premium
Graphics
Dedicated graphics (full name) -
Dedicated video memory -
Onboard graphics chip Mobile Intel® Graphics Media Accelerator 4500MHD
Shared video memory5Up to 1292 MB shared memory
3D Benchmark 2006 Up to 840 points6(depending on configuration)
Graphic features DirectX® 10 support
Supporting full HD video experience
Interfaces
Video 1x DVI-I (incl. HDCP support)
Audio 1x line in, 1x microphone in, 1x line out / headphone out combined with
S/PDIF out
Network 1x LAN (RJ-45)
Data 1x eSATA combined with USB, 2x USB 2.0
1x ExpressCard slot (54 / 34 mm)
1x 15-in-1 card reader7
SD, miniSD, MicroSD, SDHC
MS, MS-Duo
MMC, RS-MMC, MMC-Micro
MSPRO, MS-PRO Duo, MS-Pro HG, MS-Pro HG Duo, M2
xD picture card
Power supply 1x DC-in
Communication
Integrated Bluetooth® -
LAN (Local Area Network) 10 / 100 Mbps
Built-in WLAN (Wireless Local Area Network) Yes
WLAN brand name Intel® WiFi Link 5100 AGN
WLAN type3draft-n 802.11a/g/n
WLAN max. date rate Up to 300 Mbps
WLAN encryption WEP, WPA and WPA2
For use in BE, CH, DK, DE, EE, FI, FR, EL, IE, IS, IT, LI, LV, LT, LU, MT, NL, NO,
PL, AT, PT, SE, SK, ES, CZ, HU, UK, CY
Option3
WLAN type 802.11b/g
WLAN max. date rate Up to 54 Mbps
WLAN encryption WEP, WPA and WPA2
For use in BE, CH, DK, DE, EE, FI, FR, EL, IE, IS, IT, LI, LV, LT, LU, MT, NL, NO,
PL, AT, PT, SE, SK, ES, CZ, HU, UK, CY
Multimedia
Audio Support of high-definition audio for S/PDIF output with up to 7.1 channels
Audio chip Realtek ALC662
Speakers 2x built-in speakers (1.5 W each)
Microphone Built-in array microphone
Subwoofer -
Input device Volume control via function key combination
AMILOcam
Image sensor VGA webcam
Frames per second 308
Features Auto focus
Automatic brightness adjustment with status LED (blue: on, red:
streaming / application on)
Low-light technology for great video-quality even in dark
surrounding

Data Sheet ⏐Issue: January 2009⏐AMILO Notebook Pi 3525 Page 4 / 6
Fujitsu Siemens Computers recommends Windows Vista® Home Premium
Input devices / Control buttons
Power button Located left of the keyboard, black-lighted
Keyboard Spill-proof keyboard2with 85 keys
Touchpad Hidden touchpad, with left and right mouse button,
touchpad disable function via function key combination (Fn+F6)
Multimedia keys Located on top of the keyboard to launch the following applications:
Silent mode (reduce noise level / fan speed, by reducing the CPU
performance, office applications, Internet and DVD playback are not
affected)
DVD playback
Internet browser
Hot keys The following hot keys or key combinations are available
Fn+F1 WLAN on / off
Fn+F3 Mute on / off
Fn+F4 Volume down
Fn+F5 Volume up
Fn+F6 Touchpad on / off
Fn+F7 AMILOcam on / off
Fn+F8 Brightness down
Fn+F9 Brightness up
Fn+F10 Display switch
Fn+F11 Silent mode
Fn+F12 Suspend
Status indicators The notebook has 3 status icons:
Power status (& suspend)
Blue (always on): on; Blue blinking: stand by; None: off
WLAN
Blue: on; None: off
Battery charge
Blue (always on): full; Blue blinking: charging;
Red blinking: < 10 % capacity
Security
Supervisor and user password Yes
Kensington lock Yes
Lid switch (hidden) Yes
ACPI functions ACPI 3.0 compliant for Vista requirement
Power on stand by (S1 LCD off)
Stand by / energy saving mode (S3 save to RAM)
Hibernate mode (S4 save to disk)
Off mode (S5 soft off)
Power System
Battery9
Battery type Lithium-Ion battery
6 cells, 10.8 V / 2200 mAh (cell) / 4400 mAh (pack) or
6 cells, 11.1 V / 2400 mAh (cell) / 4800 mAh (pack)
Battery life (idle mode)10 Up to 3:45 hours
Battery life (DVD Playback)11 Up to 1:45 hours
Battery charging time (idle mode)12 Up to 1:40 hours (charging 90%)
Battery charging time (DVD playback)13 Up to 2:20 hours (charging 90%)
Battery charging time (off mode) Up to 2:00 hours (charging 90%)
AC Adapter Dynamic charge supported, ACPI 3.0 supported
Wide Range AC adapter 110 - 240 V AC, 50 - 60 Hz
Output 65 W with 20 V DC, 3.25 A

Data Sheet ⏐Issue: January 2009⏐AMILO Notebook Pi 3525 Page 5 / 6
Fujitsu Siemens Computers recommends Windows Vista® Home Premium
Energy consumption
S0 (idle mode) 19 W
S0 (max. active mode)14 48.6 W
S3 (stand by / energy saving mode) 2.3 W
S4 (hibernate) 0.8 W
S5 (off mode) 0.7 W
Noise emission
Idle mode15 19 dB(A) (silent mode off)
Maximum active mode16 28 dB(A) (silent mode off)
Operating conditions
Operational 5 °C to 35 °C (ambient temperature)
10 % to 90 % relative humidity, non-condensing
Dimensions and weight
W x D x H 358 x 256 x 37.0 (front) / 41.0 (back) mm
Weight 2.9 kg17
Certifications GOST (WLAN)
CE Marking
R&TTE (WLAN)
Warranty Country specific terms
Application Software
Home office Microsoft® Works
Microsoft® Office Home and Student Trial
Adobe Reader
Windows Mail (within Vista operating system)
Windows Calendar (within Vista operating system)
Multimedia Nero Essentials S (CD / DVD write software)
Vista DVD Playback Pack (DVD playback software)
Windows Media Player (within Vista operating system)
Windows Media Center (within Windows Vista® Home Premium
operating system)
Internet Microsoft® Internet Explorer
Country specific Internet provider
Security Norman security software solution

Data Sheet ⏐Issue: January 2009⏐AMILO Notebook Pi 3525 Page 6 / 6
Fujitsu Siemens Computers recommends Windows Vista® Home Premium
All rights reserved, including intellectual property rights. Technical data subject to modifications and
delivery subject to availability. Any liability that the data and illustrations are complete, actual or
correct is excluded.
Designations may be trademarks and/or copyrights of the respective manufacturer, the use of which
by third parties for their own purposes may infringe the rights of such owner.
For further information see http://www.fujitsu-siemens.com/terms_of_use.html
Copyright © Fujitsu Siemens Computers 01/2009
Published by
FSC IP CLI PMKT
Christiane Geis
Fujitsu Siemens Computers
http://www.fujitsu-siemens.com/
Company stamp
Accessories
Included AC adapter 65 W
First Battery (6 cells battery)
Optional Find out more: www.fujitsu-siemens.com/accessories
Manuals Manual (on hard disk), quick start guide, safety guide, warranty guide,
recovery guide
Drivers Updates downloadable at http://www.fujitsu-siemens.com
Awards
Notebookjournal.de
Germany – 09/2008
“Good”
Connect
Germany – 11/2008
“Good”
Computer Bild
Germany – 12/2008
Test winner
1The processor technology depends on the actually installed processor.
2DISCLAIMER: The keyboard is spill-proof up to 50ml. This is enough to protect your notebook from an accidental spill. However, we recommend a backup as well
as a system shut-down should liquids come into contact with the keyboard. The spill-proof protection does not prevent data loss caused by water damage. If this
should happen, please contact your local customer service desk.
3Depending on exact configuration. Please check at your local retailer
4DISCLAIMER: Up to 1 GB may not be available with 32-bit operating systems due to system resource requirements if system is preinstalled with 4096 MB RAM
5Shared video memory size may vary depending on configuration. Used video memory size depends on Microsoft® Windows Vista® memory management
- 1024 MB system memory enables up to 268 MB static and shared memory
- 2048 MB system memory enables up to 779 MB static and shared memory
- 3072 MB system memory enables up to 1292 MB static and shared memory
- 4096 MB system memory enables up to 1292 MB static and shared memory
6Configuration for measurement: Intel® Core™2 Duo T9400 processor, 4 GB RAM, 250 GB HDD; display resolution: 1280 x 1024
7An adapter is needed for the following card formats: RS-MMC, MMC-Micro, miniSD, MicroSD, SDHC, MS-Duo, MS-PRO Duo, MS-Pro HG, MS-Pro HG Duo, M2
8AMILOcam frame rate can vary significantly depending on the used software application.
9DISCLAIMER: Battery life may vary depending on product model, configuration, applications, power management settings and features utilized. Recharge time
varies depending on usage. The recharge capacity may decrease after some months so that the battery lifetime as well as operating time can not be assured for the
whole lifetime of the notebook
10 Tested with Battery Mark 4.0.1 (“power saver mode”)
11 DVD playback tested with Vista DVD playback
12 Tested with BatteryMon, V2.0 Build:1007
13 DVD playback tested with Vista DVD playback
14 Tested with 3DMark06
15 Tested with idle mode (according to ISO 7779:2001 Nr. C.15.3.1) noise emission values according to ISO 9296 at operator position
16 Tested with HDD stress test and CPU stress text at approx. 90 % CPU load, no ODD load, noise emission values according to ISO 9296 at operator position
17 Weight may vary depending on actual configuration
The configuration described in this document is generic only and non-binding. For the exact
configuration of your AMILO, please contact your licensed dealer.
