Fujitsu Siemens Computers LOOX T Series User manual

Handheld English
Getting Started
LOOX T Series

Are there...
any technical problems or other questions that you need help with?
Please contact:
• our Hotline/Help Desk (see the enclosed Help Desk List or the Internet:
"www.fujitsu-siemens.com/helpdesk"
• Your sales partner
• Your sales office
Additional information is contained in the Help Desk list and the "Warranty" manual.
The latest information on our products, tips, updates, etc., can be found on the Internet at:
"www.fujitsu-siemens.com"

This manual was produced by Xerox Global Services
Published by Fujitsu Siemens Computer GmbH
Edition 2
October 2006
Order no.: A26391-K182-Z100-1-7619
*A26391-K182-Z100-1-7619*

LOOX T Series
Getting Started
Notational conventions
Equipment overview
Pocket PC operating
Making telephone calls with
the Pocket PC
Security functions
Resetting the Pocket-PC
Wireless connection via
Wireless LAN

Adobe and Acrobat are trademarks of Adobe systems Incorporated and may
be protected in certain countries.
DPMS and VESA are registered trademarks of Video Electronics Standards Association.
The Bluetooth trademarks are the property of Bluetooth SIG, Inc., U.S.A. licensed
for Fujitsu Siemens Computers GmbH.
Intel is a registered trademark, Pentium and Celeron are trademarks of Intel Corporation, USA.
Kensington and MicroSaver are registered trademarks of ACCO World Corporation.
Macrovision is a trademark of Macrovision Corporation, USA.
Microsoft, MS, MS-DOS, Windows, and Windows NT are registered trade-
marks of Microsoft Corporation.
PS/2 is a registered trademark of International Business Machines, Inc.
All other trademarks referenced are trademarks or registered trademarks of their respective
owners, whose protected rights are acknowledged.
Copyright © Fujitsu Siemens Computers GmbH 2006
All rights, including rights of translation, reproduction by printing, copying or similar
methods, in part or in whole, are reserved.
Offenders will be liable for damages.
All rights, including rights created by patent grant or registration of a utility
model or design, are reserved.
Delivery subject to availability. Subject to technical alterations.

Contents
Contents
Notationalconventions ................................................................ 1
Equipmentoverview ................................................................... 3
Indicators(LEDs)andstatusindicatorsinthedisplay ....................................... 4
Indicators(LEDs) .................................................................... 4
Statusindicatorsonthedisplay ....................................................... 5
Pocket PC operating . . . . . .............................................................. 7
Using the profilesofyourPocketPC ...................................................... 7
Switching the Pocket PC off and on during normal use (Standby mode) . . . . . ................. 8
Switching the Pocket PC to Standby mode . ........................................... 8
SwitchingonwiththeEndbutton ..................................................... 8
EnteringPIN ............................................................................ 8
Usingthekeyboard ..................................................................... 8
Descriptionofbuttons ................................................................ 9
Making telephone calls with the Pocket PC . . ........................................... 11
Enter a phone number . . . . . .............................................................. 11
Select a phone number from your contacts . ............................................... 11
Select a phone number from your list of calls . . . ........................................... 11
Speed dial function . ..................................................................... 12
Programming the speed dial function . . . ............................................... 12
Makingacallviathespeeddialnumber ............................................... 12
Makingavideotelephonecall(optional) ................................................... 13
Makingemergencycalls ................................................................. 13
Answering an incoming call/video telephone call ........................................... 13
Conversationending .................................................................... 14
Creating and sending e-mail/SMS/MMS messages . . ....................................... 14
E-mail .................................................................................. 14
Downloading e-mails from a server (e-mail pull) . ........................................... 15
Securityfunctions ..................................................................... 17
Resetting the Pocket-PC . .............................................................. 19
Softreset(warmstart) ................................................................... 19
Coldstartingandresettingfactorydefaultsettings .......................................... 20
WirelessconnectionviaWirelessLAN .................................................. 21
Using Wireless Manager . . . .............................................................. 21
Using Wireless Manager . . . .......................................................... 21
A26391-K182-Z100-1-7619, edition 2 English

Contents
English A26391-K182-Z100-1-7619, edition 2

Notational conventions
Notational conventions
Pay particular attention to text marked with this symbol. Failure to
observe this warning endangers your life, destroys the device, or
may lead to loss of data. Your warranty will become invalid if you
cause any defects to the device by failing to follow the instructions.
indicates important information that is required to use the device
properly.
►describes a step which must be performed.
indicates a result
This style is used for inputs entered via the keyboard in a dialogue box or in a
command line, e.g. your password (Name123) or a command used
to launch a program (start netscape.exe).
This style is used for information, which is output by a program onto the
screen, e.g.: Installation is complete.
This style identifies
• Terms and text in a software interface, e.g.: Click on Save.
• Names of programs or files, e.g. Windows XP or netscape.exe.
"This style" identifies
• Cross-references to a different section, e.g. "Safety information".
• cross-references to an external source, e.g. a web address: For
more information, go to" www.fujitsu-siemens.com"
• Names of hard disks, CDs and DVDs as well as names and titles
of other materials, e.g.: "CD Drivers & Utilities" or Safety manual
Abc indicates a key on the keyboard, e.g.: F10
This style indicates terms and text that are emphasized or highlighted, e.g.:
Do not switch off device
A26391-K182-Z100-1-7619, edition 2 1

Notational conventions
2 A26391-K182-Z100-1-7619, edition 2

Equipment overview
Equipment overview
Mini USB portMicrophoneEnd buttonAnswer buttonOverviewHardware, overviewControlsPortsStatus indicatorsGSM portPower indicatorNavigation keyApplication buttonApplication buttonApplication button3-wayscroll buttonApplication buttonDisplayVoice notesVGA cameraSD slot2 megap ixel autofocus cameraRadio indicator
3
4
567
9
23
10
11
12
13
14
15
16
1
220
22
1
17
18
19
21
8
1 = Antenna indicator
2=VGAcamera
3 = Battery/events indicator
4=Display
5 = Navigation key
6 = Softkey button 2
7 = End button
8 = Application button 2: Inbox
9 = Keyboard with integrated number block
10 = GPS antenna port
11 = Mini USB port
12 = Application button 1: Calendar
13 = Answer button
14 = Softkey button 1
15 = Application button 5: SpeedMenu
and camera
16 = 3-way scroll button
17 = Pen slot
18 = Socket for headphones or headset
19 = GSM port
20 = 2 megapixel autofocus camera
21 = Battery compartment
22 = Slot for SD/MMC expansion card
23 = Application button 6: Voice notes
A26391-K182-Z100-1-7619, edition 2 3

Equipment overview
Indicators (LEDs) and status indicators in the display
Your Pocket-PC has two flashing indicators (LEDs) on the casing which light up in different
colours, as well as various status indicators in the title bar of the display which will provide
you with information about the current status of your device.
1 2
1 = Antenna indicator 2 = Battery/events indicator
Indicators (LEDs)
Power indicator Colour Indicator state Meaning
Green Is blinking GPS has been activated.Antenna (1)
Blue Is blinking Bluetooth is active.
On Battery is fully charged.Orange
Slow flashing Battery being charged
Red Quick flashing Battery is overheated.
Blue Slow flashing New message received,
missed call or
appointment reminder is active
Battery/events (2)
Green Slow flashing New e-mail waiting
If more than one event occurs at the same time then the LEDs will
flash in the relevant colours in turn.
For example, if a new e-mail is received while the battery is being charged,
the indicator will flash orange and green in turn.
4 A26391-K182-Z100-1-7619, edition 2

Equipment overview
Status indicators on the display
The most important status indicators are shown below:
Onscreen
display
Meaning Onscreen
display
Meaning
New e-mail, SMS or MMS GPRS available
Incoming telephone call Connection setup
Active telephone call UMTS available
Active data connection Roaming
Missed call(s) Telephone: off
Battery low All system tones switched off
Battery being charged WLAN active
Signal strength WLAN access point available
Caps Lock activated Special characters and numbers
activated
A26391-K182-Z100-1-7619, edition 2 5

Equipment overview
6 A26391-K182-Z100-1-7619, edition 2

Pocket PC operating
Pocket PC operating
This chapter contains descriptions of the operating elements of your Pocket PC
as well as information about how to use it.
Please take note of the information in the "Important notes" chapter of the easy guide.
Using the profiles of your Pocket PC
►Press and hold the End key to call up the profiles.
Default profiles provide convenient access to frequently used system settings, tailored to
the particular way in which you are using the device. With the aid of these profiles you
can control power consumption or the radio modules of your device. You can also use
profiles to control data behaviour and the acoustic/visual behaviour.
The default profiles can be modified by clicking on Menu - Edit.
Profile Description
Standby The Pocket PC is switched to Standby mode.
Complete Off The Pocket PC is completely switched off. (even
alarm calls will not work!)
Flight mode All radio modules (telephone, WLAN, Bluetooth)
are deactivated. The Pocket-PC is operated as
a handheld only.
Direct push Deactivates or activates the e-mail push function.
Outdoor Mode for loud environments. The volume of
acoustic signals is increased.
Meeting mode Acoustic signals are switched off. Vibration
function is active.
Normal mode The volume of the acoustic signals corresponds
to the standard volume of the device.
Max Performance,Max Battery, Automatic Mode. Depending on the profile selected, the CPU
speed, display brightness, keyboard lighting and
LED display can be adjusted accordingly.
BT carkit Switches the Pocket PC to Bluetooth handsfree
(optional).
If you would like to switch off the vibration function as well as the system tones,
you can activate silent mode by pressing and holding the star key.
A26391-K182-Z100-1-7619, edition 2 7

Pocket PC operating
Switching the Pocket PC off and on during
normal use (Standby mode)
Switching the Pocket PC to Standby mode
►From the Today screen, briefly press the End button.
The Pocket PC is switched to Standby mode.
If you have specified a switch-off time in the system settings, your Pocket PC will
automatically switch to Standby mode after this specified time.
SwitchingonwiththeEndbutton
►BrieflypresstheEndkey.
►If the device lock is activated, press and hold the Enter button afterwards.
The Pocket PC is switched on.
Entering PIN
If you are using a SIM card you will be asked to enter your PIN once the calibration process is finished.
Whenever you are asked to enter your SIM card PIN code, you can enter it using the
number block on the keyboard or via the touch-sensitive display on your Pocket PC.
►Enter the SIM card PIN code.
►Press Enter.
Using the keyboard
The keyboard is designed to offer all of the functions of a keyboard with an integrated number block.
Some enhanced keyboard functions are accessed via key combinations (short cuts).
Lower case letters are output by default.
To obtain a higher case letter, press and hold the corresponding letter button.
8 A26391-K182-Z100-1-7619, edition 2

Pocket PC operating
Description of buttons
The key buttons on your keyboard are described below together with their functions.
Key Function
Enter key
(return)
ENTER
Brief press of the button
The Enter key terminates a command line. The command you have entered
is executed when you press this key.
Long press of the button
The device lock (key lock and display lock) is set or cancelled, see also the
easy guide.
Shift key
Lock
SHIFT
The Shift key causes uppercase characters to appear. In the case of overlay
keys, the character printed on the upper left of the key appears when that key is
pressed.
Double-clicking the button
Set permanent use of higher case.
FN key Brief press of the button
The FN key activates the special characters or numbers on overlay keys.
Long press of the button
Pressing the FN key for longer switches the keyboard illumination on or off.
Double-clicking the button
Engage the FN key to activate or deactivate FN mode.
OK key Closes the active window.
Symbol key
áü
#
Brief press of the button
Replaces the current character with a related character with an accent, e.g. the
letter “a” is changed to “á”. Up to 5 different related characters are available.
Pressing the button again switches to the next available related character.
Long press of the button
A window containing all of the available characters is opened or closed (if open).
Asterisk key Long press of the button
The Pocket PC is set to Silent Mode, or Silent Mode is deactivated. All tones
and the vibration alarm are activated or deactivated.
The current status is displayed via icons.
Application
button Mail
Received
Brief press of the button
Scroll through mailbox.
Long press of the button
The menu for SMS, MMS and e-mail messaging is called up
3-way scroll
button –
scrolling during
acall
Switch off ringtone
A26391-K182-Z100-1-7619, edition 2 9

Pocket PC operating
Key Function
Scrolling during
acallusingthe
3-way scroll
button
Increase or decrease volume
Long press
of camera
application
Call up SpeedMenu
Use FSC SpeedMenu and accelerate daily processes on your Pocket LOOX!
- Create and organise your own list of frequently used documents, programs
and folders.
- Open them quickly directly from the menu.
- One-handed or stylus operation as desired.
Long press of
End button
Call up profiles
10 A26391-K182-Z100-1-7619, edition 2

Making telephone calls with the Pocket PC
Making telephone calls with the Pocket PC
Enter a phone number
You are in the Today screen.
►Enter the required telephone number via the keyboard.
►Press the Answer button.
The connection is established.
Select a phone number from your contacts
►Click on Start – Contacts.
Your saved contacts are displayed.
►Touch the required contact.
The details for the selected contact are then shown.
►Touch the corresponding telephone number.
►Press the Answer button.
The connection is established.
Select a phone number from your list of calls
►Press the Answer button.
The online keyboard for telephony is displayed.
►To u c h Call History.
The list of recent calls is displayed.
►Touch the corresponding telephone number.
►Press the Answer button.
The connection is established.
A26391-K182-Z100-1-7619, edition 2 11

Making telephone calls with the Pocket PC
Speed dial function
You can assign speed dial numbers to up to 99 contacts. These speed dial numbers
allow you to dial required telephone numbers more quickly.
Programming the speed dial function
►Click on Start – Contacts.
Your saved contacts are displayed.
►Touch the required contact.
The details for the selected contact are then shown.
►Choose an available speed dial number, e.g. "29".
►Confirm with OK.
The speed dial number for your contact has now been saved.
Making a call via the speed dial number
From the Today screen or in the telephone application:
►Press and hold the number to which you assigned the speed dial number you are calling.
The connection is established.
12 A26391-K182-Z100-1-7619, edition 2
