Fujitsu Siemens Computers Professional Notebook User manual

Professional Mobile English
Operating Manual
Professional Notebook

Are there ...
... any technical questions or problems?
Please contact:
• our Hotline/Help Desk (refer to the enclosed Help Desk List or go to:
"http://www.fujitsu-siemens.com/support")
• your sales partner
• your sales office
Additional information is contained in the Help Desk list and the "Warranty" manual. The
"Warranty" manual can be found on the "Drivers & Utilities" CD/DVD.
Latest information about our products, useful tips, updates etc. are available
from our website: "www.fujitsu-siemens.com"

This manual was produced by Xerox Global Services
Published by
Fujitsu Siemens Computers GmbH
AG 07/07
Edition 3
Order no.: A26391-K200-Z126-1-7619

Professional Notebook
Innovative technology... 1
Important notes 3
Preparing the notebook for use 6
Using your notebook 9
Security functions 30
Connecting external devices 38
Energy saving functions 42
Settings in BIOS Setup 45
Troubleshooting and tips 47
Manufacturer’s notes 59
Index 66
Operating Manual

Adobe and Acrobat are trademarks of Adobe Systems Incorporated and may
be protected in certain countries.
VESA and DPMS are trademarks of Video Electronics Standards Association.
The Bluetooth trademarks are the property of Bluetooth SIG, Inc., U.S.A. and
licensed to Fujitsu Siemens Computers GmbH.
Intel is a registered trademark, Pentium and Celeron are trademarks of Intel Corporation, USA.
Kensington and MicroSaver are registered trademarks of ACCO World Corporation.
Macrovision is a trademark of Macrovision Corporation, USA.
Microsoft, MS, MS-DOS, Windows, and Windows NT are registered trademarks of Microsoft
Corporation.
PS/2 is a registered trademark of International Business Machines, Inc.
Alle weiteren genannten Warenzeichen sind Warenzeichen oder eingetragene Warenzeichen
der jeweiligen Inhaber und werden als geschützt anerkannt.
Copyright © Fujitsu Siemens Computers GmbH 2007
All rights reserved, including rights of translation, reproduction by printing, copying
or similar methods, in part or in whole.
Offenders will be liable for damages.
All rights reserved, including rights created by patent grant or registration of a utility model or design.
Subject to availability and technical modifications.

Contents
Contents
Innovativetechnology... ................................................................ 1
Notational conventions .................................................................. 2
Importantnotes ........................................................................ 3
safetyinformation ....................................................................... 3
Additional safety notes for devices with radio components . . . . . ............................. 3
Travelling with your notebook ............................................................ 4
Before youtravel .................................................................... 4
Transporting your notebook . . . ....................................................... 4
Cleaning the notebook .................................................................. 5
Preparingthenotebookforuse ........................................................ 6
Unpacking and checking the delivery . . ................................................... 6
Selectingthelocation ................................................................... 6
Mains adapter connecting . . . . ........................................................... 7
Switching the notebook on for the first time ................................................ 8
Using your notebook .................................................................. 9
Keyboard ............................................................................... 9
Virtual numeric keypad .................................................................. 11
TouchStick, Touchpad, TouchStick and Touchpad buttons (optional) ......................... 12
Using Touchpad buttons ............................................................. 13
LCD screen ............................................................................ 14
Information on LCD screen ........................................................... 14
Screen settings ......................................................................... 15
Adjusting the resolution (under Windows XP) . . ........................................ 15
Adjusting the resolution (under Windows Vista) ........................................ 15
Selecting the font size (under Windows XP) . . . ........................................ 15
Selecting the font size (under Windows Vista) . ........................................ 15
Adjusting thebrightnessofthe display ................................................ 15
SynchronisingthedisplayontheLCD screen and anexternalmonitor .................. 15
Adjusting the speed of the mouse pointer (under Windows XP) . ......................... 16
Battery ................................................................................. 16
Charging,caringforand maintainingthebattery ....................................... 16
Module ................................................................................. 17
Removing a module . . . . . . ........................................................... 18
Installing module . . .................................................................. 19
Optical drive ............................................................................ 20
HandlingCD/DVDs .................................................................. 20
CD/DVD indicator ................................................................... 20
Insertingorremoving aCD/DVD ...................................................... 21
Manualremoval(emergencyremoval) ................................................ 21
Memorycards .......................................................................... 22
Memorycard inserting ............................................................... 22
Removingamemory Card ........................................................... 22
PC cardsandExpressCards ............................................................. 23
Insertingacard ..................................................................... 24
Removingthecard .................................................................. 26
Integrated 56k modem .................................................................. 28
Connecting notebook modem to telephone wall socket . . . . ............................. 28
Connecting the notebook to a LAN . ................................................... 29
A26391-K200-Z126-1-7619, edition 3

Contents
Securityfunctions ..................................................................... 30
Briefoverviewofsecurity functions ....................................................... 30
UsingKensingtonLock .................................................................. 31
Configuring the fingerprint sensor (optional) . . ............................................. 31
ConfiguringpasswordprotectioninBIOSSetup ........................................... 32
Password protection for BIOS Setup (supervisor and user password) . ................... 32
Passwordprotectionforstartingtheoperatingsystem .................................. 33
Passwordprotectionforthe hard disk ................................................. 34
SmartCard reader (optional) . ............................................................ 35
Trusted Platform Module (optional) . . . . . . ................................................. 37
Connectingexternaldevices ........................................................... 38
Connecting devices to the notebook . . .................................................... 38
Disconnecting devices from the notebook ................................................. 38
Connecting an external monitor . . ........................................................ 39
Connecting an external monitor to the notebook . . . . . .................................. 39
Settingtherefreshrateforyourexternalmonitor ....................................... 39
Connecting USB devices (printer, mouse, keyboard, etc.) . .................................. 40
Devicedrivers ...................................................................... 40
Connecting external audio devices . . . . . . ................................................. 40
High Definition Audio ................................................................ 40
Microphone port . . . . . ................................................................ 40
Audiooutput(Lineout)/SPDIF(optional) .............................................. 40
Connecting an external device to S-Video Out ............................................. 41
ActivatingtheexternalTV /projector .................................................. 41
Connecting FireWire devices . ............................................................ 41
Energysavingfunctions ............................................................... 42
EButton ............................................................................... 43
Standbymode .......................................................................... 44
SettingsinBIOSSetup ................................................................. 45
BIOS Setupstarting ..................................................................... 45
UsingtheBIOS Setup ................................................................... 45
Exitingthe BIOS Setup .................................................................. 46
Exit Saving Changes ................................................................ 46
Exit Discarding Changes . ............................................................ 46
LoadSetupDefault .................................................................. 46
Discard Changes . . . . ................................................................ 46
Save Changes . . . . . . ................................................................ 46
Troubleshootingandtips .............................................................. 47
Troubleshooting . . ....................................................................... 47
The notebook’s date or time is incorrect . . ............................................. 47
No display appears on the screen, the power-on indicator flashes ....................... 48
The notebook’s LCD screen remains blank . . . ......................................... 48
The LCD screen is difficultto read .................................................... 49
The externalmonitorremainsblank ................................................... 49
The externalmonitorisblankortheimage isunstable .................................. 50
Battery indicator no longer appears in status indicator panel . . .......................... 51
The batterydischarges tooquickly .................................................... 51
The notebook cannot be started . . . . . ................................................. 52
The notebook does not react . ........................................................ 52
The notebook shuts down suddenly . . ................................................. 52
A26391-K200-Z126-1-7619, edition 3

Contents
The ON/OFF button does not respond properly ........................................ 53
The wireless connection to a network does not work . . . . . . ............................. 53
The mouse does not work ........................................................... 53
Theprinter does notprint ............................................................ 54
No sound or audio signal to the internal or external loudspeakers . . ..................... 55
TheCD/DVDdoes notwork–nosound duringCD/DVDplayback ....................... 56
User and/or supervisor password forgotten ............................................ 56
Acousticwarnings ................................................................... 56
Errormessagesonthescreen ........................................................ 57
Restoring the hard disk contents under Windows . . ........................................ 58
Manufacturer’snotes .................................................................. 59
Disposal and recycling .................................................................. 59
Copyright-protectedtechnology .......................................................... 59
CEmarking ............................................................................ 60
Regulatory notices ...................................................................... 61
Regulatory information for notebooks without radio device . ............................. 61
DOC (Industry CANADA)notices ..................................................... 62
FCC Regulatory information for notebooks with radio device . . . ......................... 64
Index .................................................................................. 66
A26391-K200-Z126-1-7619, edition 3

Contents
A26391-K200-Z126-1-7619, edition 3

Innovative technology...
Innovative technology...
... and an ergonomic design make your notebook a reliable, convenient mobile PC.
This manual contains general information and instructions for use with Professional Notebooks
from Fujitsu Siemens Computers. Among other things, this operating manual will tell you how
to get your notebook ready for use and how to use its different components.
As the manual is intended to cover a whole range of models, it is possible
that your notebook may not be equipped with all of the components
and modules which are described here.
Information which is specific to your device - such as the Device
Overview and the Technical Data - can be found the EasyGuide which
is supplied together with your notebook.
Further information about your notebook can also be found:
• in the EasyGuide for your notebook which is supplied on the enclosed "Drivers
& Utilities" CD/DVD (device-specific information)
• in the hard copy "Safety" manual
• in the documentation of the operating system
• in the information files (e.g. *.TXT,*.DOC,*.WRI,*.HLP,*.PDF)
A26391-K200-Z126-1-7619, edition 3 1

Innovative technology...
Notational conventions
Pay particular attention to text marked with this symbol. Failure to observe
this warning will endanger your life, will damage the device or lead to loss
of data. The warranty will be invalidated if you cause defects in the device
through failure to take notice of this warning
indicates important information that is required to use the device properly.
►indicates an activity that must be performed in the order shown
indicates a result
This style flags data entered using the keyboard in a program dialog or command
line, e.g. your password (Name123) or a command to launch a program
(start.exe)
This style refers to information displayed by a program on the screen, e.g.:
Installation is completed
This style is for
• terms and texts in a software user interface, e.g.: Click Save.
• names of programs or files, e.g. Windows or setup.exe.
"This style" is for
• cross-references to another section, e.g. "Safety information"
• Cross-references to an external source, e.g. a web address: For more
information, go to "www.fujitsu-siemens.com"
• indicates names of CDs and DVDs as well as names and titles of other
materials, e.g.: "CD/DVD Drivers & Utilities" or "Safety" manual
Abc refers to a key on the keyboard, e.g.: F10
This style flags concepts and text that are emphasised or highlighted, e.g.: Do not
switch off device
2 A26391-K200-Z126-1-7619, edition 3

Important notes
Important notes
ImportantnotesNotes:
This chapter contains essential safety information which must be followed when working with your
notebook. Other notes also provide useful information which will help you with your notebook.
safety information
safetyinformation
Pay attention to the information provided in the "Safety" manual
and in the following safety notes.
Observe the sections in the manual marked with the symbol on the left.
• When connecting and disconnecting cables, observe the relevant notes in this operating manual.
• When cleaning the device, please observe the relevant notes in "Cleaning the notebook", Page 5.
• If you have a device with a radio component, also observe the information in the "Safety"
manual and in section "Additional safety notes for devices with radio components", Page 3.
This notebook complies with the relevant safety regulations for data processing
equipment. If you have questions about using your notebook in a particular area,
please contact your sales outlet or our Hotline/Help Desk.
Additional safety notes for devices with
radio components
Radiocom ponent:WirelessLAN:Bluetooth,safetynotes
If a radio component (Wireless LAN, Bluetooth or UMTS) is integrated in your notebook, you
must be sure to observe the following safety notes when using your notebook:
• Switch off the radio components (theON/OFFswitchmustbeinthe"OFF"position),
when you are at an airport or drivinginacar.
• Switch off the radio components (the ON/OFF switch must be in the "OFF" position),
when you are in a hospital, an operating theatre or near electronic medical equipment.
The transmitted radio waves can impair the operation of medical devices.
• Switch off the radio components (the ON/OFF switch must be in the "OFF" position), when
you take the device close to flammable gases or into hazardous environments (e.g. petrol
station, paintshops), as the transmitted radio waves can cause an explosion or a fire.
A26391-K200-Z126-1-7619, edition 3 3

Important notes
Travelling with your notebook
Mobileope rationTran spor t
Please follow these guidelines when travelling with your notebook.
Before you travel
Travelpreparation s
• Back up important data stored on your hard disk.
• Switch off the radio component (Wireless LAN/Bluetooth/UMTS) for data security reasons. Data
traffic on a wireless connection can be intercepted by unauthorised third parties.
Information on activating data encryption is provided in the documentation
for your wireless component.
• If you wish to use your notebook during a flight, first check with the flight
attendants if it is OK to do so.
When travelling in other countries
• If you are travelling abroad, check that the mains adapter can be operated with the
local mains voltage. If this is not the case, obtain the appropriate mains adapter for
your notebook. Do not use any other voltage converter!
• Check whether the local voltage and the specifications of the power cable are compatible.
If this is not the case, buy a power cable that matches the local conditions. Do not use
a connection adapter for electrical devices to connect the notebook.
• Enquire with the corresponding government office of the country you will be
travelling in as to whether you may operate the radio component integrated in
your notebook there (also see "CE marking", Page 60).
• If you use a modem, incompatibilities with the local telecommunications system may result.
This may result in poor performance, or the modem will not work at all.
You may require a country-specific telephone adapter (available as an accessory).
Transporting your notebook
Tran spor t
• Remove all data carriers (e.g. CD) from the drives.
• Switch off the notebook with the ON/OFF button (see EasyGuide, "Switching off the notebook").
• Unplug the mains adapter and all external devices from the power socket.
• Disconnect the mains adapter cable and the data cables for all external devices.
• Close the connector covers.
• Close the LCD screen so that it locks into place.
• If the device needs to be shipped, use the original packaging or other suitable
packaging to protect it from damage caused by mishandling.
• To protect the notebook against damaging jolts and bumps, use a notebook
carrying case to transport your notebook.
Current offers can be found on the Internet under "www.fujitsu-siemens.com/accessories".
• Protect the notebook from severe shocks and extreme temperatures (e.g. direct sunlight in a car).
4 A26391-K200-Z126-1-7619, edition 3

Important notes
Cleaning the notebook
CleaningKeyboard:Tou c hp a d :LCDscreen:
►Switch the notebook off.
►Unplug the mains plug of the mains adapter from the mains socket.
Do not clean any interior parts yourself; leave this job to a service technician.
Only use cleaning products designed for computers. Normal household
cleaners and polishes can damage the markings on the keyboard and the
device, the paintwork or the notebook itself.
Ensure that no liquid enters the notebook.
►Remove the battery - refer to the section entitled "Battery" in the EasyGuide.
You can clean the casing and fingerprint sensor with a dry cloth. If particularly dirty, use a cloth
which has been moistened in mild domestic detergent and then carefully wrung out.
To clean the keyboard and the touchpad, you can use disinfectant wipes.
Wipe the LCD screen with a soft, moistened cloth.
A26391-K200-Z126-1-7619, edition 3 5

Preparing the notebook for use
Preparing the notebook for use
Gettingstarted
Please read and observe the relevant notes in "Important notes", Page 3
and in the manual for your radio components.
You must charge the battery and install the application programmes before you
can work with the notebook. The operating system and drivers required are
preinstalled (only with Windows operating systems).
When not plugged into a mains outlet, the notebook runs on its built-in battery. You can
increase the battery’s life by enabling the system’s energy saving functions.
If you use the notebook in a normal office situation, run it from the mains using the mains adapter.
Please refer to "Connecting external devices", Page 38 for instructions on how to connect
external devices such as a mouse and a printer to the notebook.
Unpacking and checking the delivery
PackagingContentsofd eliveryDamagedur ingt ransportDeliverynote
►Unpack all the individual parts.
►Check the delivery for damage incurred during transportation.
►Check whether the delivery conforms to the details in the delivery note.
Should you discover that the delivery does not correspond to the delivery
note, notify your local sales outlet immediately.
Do not discard the original packing material of the devices. You may need the
packaging in the future if you need to transport your device.
Selecting the location
Selectingthelocation Notebook:Mainsadapter:
Select a suitable location for the notebook before setting it up. Consider
the following points when selecting a location:
• Never place the notebook on a soft surface (e.g. carpeting, upholstered furniture,
bed). This can block the air vents and cause overheating and damage.
• Do not place the notebook on your legs for a long period of time. The underside
of the notebook heats up during normal operation. Prolonged contact with
the skin can become unpleasant or may even cause burns.
• Place the notebook on a stable, flat, nonslippery surface. Please note that
the rubber feet may mark certain types of surfaces.
• Never place the notebook and the mains adapter on a heat-sensitive surface.
6 A26391-K200-Z126-1-7619, edition 3

Preparing the notebook for use
Mains adapter connecting
Preparingf oroperationMainsadapt er:
Please read the information in "Selecting the location", Page 6.
The power cable supplied conforms to the requirements of the country in which
you purchased your notebook. Make sure that the power cable is approved
for use in the country in which you intend to use it.
The mains adapter’s power cable must only be connected to a mains socket
if the notebook is connected to the mains adapter.
Do not use the mains adapter for other notebooks or devices.
Do not use a mains adapter that is not specially intended for this notebook.
Make sure that the rated current of the mains adapter is not higher than that of the
mains supply to which you connect it (see "Technical Data" in the EasyGuide).
1
2
3
►Connect the mains adapter cable (1) to the
DC jack (DC IN) on the notebook.
►Connect the power cable (2) into
the mains adapter.
►Plug the power cable (3) into a mains outlet.
The battery will charge.
The meanings of the various displays can be found in the EasyGuide.
A26391-K200-Z126-1-7619, edition 3 7

Preparing the notebook for use
Switching the notebook on for the first time
Notebook:Switchingonforthefirst tim e
When you switch your notebook on for the first time, the supplied software is
installed and configured. Due to the fact that this installation procedure must not
be interrupted, you should set aside enough time for it to be fully completed and
connect the notebook to the mains outlet using the mains adapter.
During installation, the notebook must only be rebooted when you are requested to do so!
►Switch the notebook on (refer to the section entitled "Switching on the
notebook" in the EasyGuide).
The installation process will start automatically.
►During installation, follow the on-screen instructions.
Consult the operating system manual if anything is unclear about the requested input data.
You will find further information on the system, drivers, utilities, updates,
manuals, etc. on the "Drivers & Utilities" CD/DVD and on the Internet
under: "http://www.fujitsu-siemens.com/support".
8 A26391-K200-Z126-1-7619, edition 3

Using your notebook
Using your notebook
Operation, notebook
This chapter describes the basics for operating your notebook.
Please refer to "Connecting external devices", Page 38 for instructions on how to connect
external devices such as a mouse and a printer to the notebook.
Please refer to the notes in the chapter "Important notes", Page 3.
An overview of the device can be found in the EasyGuide.
Keyboard
Keyboard
The keyboard of your notebook is subject to continuous wear through normal
use. The key markings are especially prone to wear. The key markings are
liable to wear away over the life of the notebook.
The keyboard has been designed to provide all the functions of an enhanced keyboard.
Some enhanced keyboard functions are mapped with key combinations.
The following description of keys and key combinations refers to Windows.
7
/7
{
7
/7
{7
/7
{
7
/7
{
Alt Gr
Num
Rol
7
/
7{
A26391-K200-Z126-1-7619, edition 3 9

Using your notebook
Backspace key
The Backspace key deletes the character to the left of the cursor.
BackspaceBackspace
Tab key
The Tab key moves the cursor to the next tab stop.
Tab k e y
Enter key (return)
The Enter key terminates a command line. The command you have entered
is executed when you press thiskey.
EnterkeyReturn
Caps Lock key
The Caps Lock key activates uppercase mode (Caps Lock indicator lit).
The Caps Lock function causes all the characters you type to appear in
uppercase. In the case of overlay keys, the character printed on the upper
left of the key appears when that key is pressed. To cancel the Caps Lock
function, simply press the Caps Lock key again.
ShiftkeyCapsLock
Shift key
The Shift key causes uppercase characters to appear. In the case of overlay
keys, the character printed on the upper left of the key appears when that
keyispressed.
ShiftkeyShift
Alt Gr key
The Alt Gr key allows you to type the characters printed on the lower right
of the key (e.g. the "{" symbol on the 7key on a German keyboard).
AltGrkey
Fn button
The Fn key enables the special functions indicated on overlay keys (refer
to "Key combinations" in the EasyGuide).
Fnkey
Cursor keys
The cursor keys move the cursor in the direction of the arrow, i.e. up, down,
left, or right.
Cursorkeys Cursorcontrolkeys
Break
Pause Pause key
The Pause key temporarily suspends the screen output. Output resumes
when you press any other key.
Pausekey
Start button (Windows XP)
The Start key opens the Windows Start menu.
Startkey
10 A26391-K200-Z126-1-7619, edition 3
