Fujitsu Siemens Computers POCKET LOOX N100 series User manual

English US
User Manual
Pocket LOOX N100 Series

Support
in the case of technical problems or questions, please contact:
• your retailer or NAVIGON at 1-888-848-0701.
• or visit the NAVIGON website at www.NAVIGON.com/PocketLOOX.

This manual was produced by Xerox Global Services
Published by Fujitsu Siemens Computers GmbH
Issue 1
AG 01/07
Order no.: A26391-K197-Z126-1-7619

Pocket LOOX N100 Series
Your Pocket LOOX 1
Important notes 2
Using your Pocket LOOX6
Troubleshooting and tips 33
Technical data 36
Index 38
User Manual

Windows Mobile CE is a trademark of Microsoft Corporation.
The mini SD Logo is a trademark of Secure Digital.
All other trademarks referenced are trademarks or registered trademarks of their respective
owners, whose protected rights are acknowledged.
Copyright © Fujitsu Siemens Computers GmbH 2007
All rights reserved, including rights of translation, reproduction by printing, copying
or similar methods, in part or in whole.
Offenders will be liable for damages.
All rights reserved, including rights created by patent grant or registration of a utility model or
design. Delivery subject to availability. Subject to technical alterations.

Contents
Contents
Your Pocket LOOX . . . .................................................................. 1
Notational conventions .................................................................. 1
Importantnotes ........................................................................ 2
Safetyinformation ....................................................................... 2
Traveling with the PocketLOOX .......................................................... 4
Transporting your PocketLOOX ..................................................... 4
UsingthePocketLOOX ................................................................. 4
Cleaning your Pocket LOOX ............................................................. 5
Liability ................................................................................ 5
FCCmarking ........................................................................... 5
UsingyourPocketLOOX ............................................................... 6
Overviewofcontrols,portsanddisplays .................................................. 6
LEDindicators ...................................................................... 6
Gettingstarted .......................................................................... 7
Insertingthebattery ................................................................. 7
Chargingthebattery ................................................................. 8
ChargingthebatteryusingtheACadapter ............................................. 8
BatterychargingviaaUSBport ...................................................... 9
Optimizingbatterylife ................................................................ 9
Starting up your Pocket LOOX for the firsttime ............................................ 9
Start screen (device dependent) . . . ................................................... 10
SwitchingthePocketLOOXonandoff .................................................... 12
Switching the Pocket LOOX on and off during normal use (Suspend mode) . .............. 12
Switchingon ........................................................................ 12
Switchingoff ........................................................................ 12
ResettingthePocketLOOX .......................................................... 13
Rebooting the Pocket LOOX . . ....................................................... 13
Usingthestylusandscreen .............................................................. 13
Usingtheholdswitch .................................................................... 14
UsingtheNavigator/GPS ............................................................... 14
Multimedia ............................................................................. 15
Connecting headphones or external loudspeakers . . .................................... 15
Usingthemusicplayer ............................................................... 16
Managing music tracks . . . ........................................................... 17
UsingPhotoViewer(onsomemodels) ................................................ 19
Using Video Player (on some models) . . . . . ............................................ 21
Managing video tracks . . . . ........................................................... 23
Usingutilities(worldclock,calculator,games) ............................................. 23
Settingdateandtime .................................................................... 25
DatatransferusingUSB ................................................................. 26
Pocket LOOX connecting with computer . . . ............................................ 26
Devicesettings ......................................................................... 27
Callingupdevicesettings ............................................................ 27
Adjustingthevolume ................................................................ 27
Adjustingscreen .................................................................... 28
Energymanagement ................................................................ 29
Displayingsysteminformation ........................................................ 30
InsertingandremovinganSDcard ....................................................... 30
InsertinganSDcard ................................................................. 31
A26391-K197-Z126-1-7619, edition 1

Contents
RemovinganSDcard ............................................................... 31
Changing the front cover . ................................................................ 32
Troubleshootingandtips .............................................................. 33
ThePocketLOOX’stimeordatearenotcorrect ........................................... 33
ThePocketLOOXswitchesoff ........................................................... 33
ThePocketLOOXdoesnotstartafterbeingswitchedon ................................... 34
The Pocket LOOX does not respond any more . . . ......................................... 34
Thebatterydischargestooquickly ........................................................ 34
Nosoundorminimalvolume ............................................................ 35
PoorreceptionviaGPS .................................................................. 35
CustomerService ....................................................................... 35
Technicaldata ......................................................................... 36
PocketLOOX ........................................................................... 36
Battery(Li-Ion) .......................................................................... 36
AC adapter . . ........................................................................... 37
Index .................................................................................. 38
A26391-K197-Z126-1-7619, edition 1

Your Pocket LOOX
Your Pocket LOOX
Your Pocket LOOX is equipped with the Windows CE 5.0 operating system. It combines the functions
of a high quality GPS navigation system and an MP3 player plus photo and video viewers.
Connect the Pocket LOOX to your computer using the USB cable and you’ll be able to
exchange data easily between your computer and your Pocket LOOX.
Depending on the model you have, when you are on the move you can play one of the
pre-installed games, or use the music player for MP3, WMA and AAC formats, or look at
photos/images or video sequences in ASF, (Microsoft MPEG4), AVI (limited) and MPEG1 formats.
In addition, the Pocket LOOX has an integrated calculator and a world clock.
You can use the Pocket LOOX as a navigation system using the fully-integrated GPS
module and the pre-installed navigation software.
Memory cards ensure that even large amounts of data can be carried reliably.
Notational conventions
Pay particular attention to text marked with this symbol. Failure to
observe this warning endangers your life, destroys the device, or
may lead to loss of data. Your warranty will become invalid if you
cause any defects to the device by failing to follow the instructions.
Indicates important information that is required to use the device
properly.
►Describes a step which must be performed.
Indicates a result
This style Is used for inputs entered via the keyboard in a dialogue box or in a
command line, e.g. your password (Name123) or a command used
to launch a program (start netscape.exe).
This style Is used for information, which is output by a program onto the
screen, e.g.: Installation is complete.
This style Identifies
• terms and text in a software interface, e.g.: Click on Save.
• names of programs or files, e.g. Windows XP or netscape.exe.
"This style" Identifies
• cross-references to a different section, e.g. "Safety information".
• cross-references to an external source, e.g. a web address: For
more information, go to"www.fujitsu-siemens.com"
• names of hard disks, CDs and DVDs as well as names and titles
of other materials, e.g.: "CD Drivers & Utilities" or Safety manual
Abc Indicates a key on the keyboard, e.g.: F10
This style Indicates terms and text that are emphasized or highlighted, e.g.:
Do not switch off device
A26391-K197-Z126-1-7619, edition 1 1

Important notes
Important notes
Important notes
This chapter contains safety notes and important information you must observe when using
your Pocket LOOX.
This Pocket LOOX complies with the relevant safety regulations for data processing equipment. If
you have questions as to whether you can set up and operate the Pocket LOOX in the intended
environment, please contact your sales point or our hotline/help desk. For additional safety
information please see the Safety Manual provided with your Pocket LOOX.
Safety information
Safety informationNotes
Follow the safety notes in the "Safety" manual and the safety notes below to
prevent damage to your device, data loss or injuries.
• During installation and before operating the keyboard, observe the instructions on
environmental conditions in the "Technical data" chapter.
• Connect the power adapter plug to the power adapter supplied. The power adapter plug
must never be plugged into an electrical outlet without the power adapter.
• The AC adapter supplied complies with the requirements of the country in which you purchased
the Pocket LOOX. Make sure the AC adapter is approved for the country in which it is used.
• The AC adapter may only be connected to an electrical outlet when the Pocket
LOOX or the cradle is connected to the AC adapter.
• Do not use the AC adapter for other devices.
• Do not use AC adapters which are not specially approved for this Pocket LOOX.
• You may only operate the Pocket LOOX with the AC adapter if the nominal voltage of
the AC adapter (100 V to 240 V) matches the local mains voltage.
• When transporting the device on a trip, observe the information in the section
"Traveling with the Pocket LOOX".
• Listening using a headset at very loud volume, particularly over a long period of time,
can cause damage to your hearing. Fujitsu Siemens Computers will not be liable
for any damage to health resulting from improper use
This product, its packaging, and its components contain chemicals known to the
State of California to cause cancer, birth defects, or reproductive harm. This Notice
is being provided in accordance with California’s Proposition 65.
NOTICE TO DRIVERS IN CALIFORNIA AND MINNESOTA:
State law prohibits drivers in California and Minnesota from using mounts on
their windshields while operating motor vehicles. NAVIGON does not take
any responsibility for any fines, penalties, or damages that may be incurred
as a result of disregarding this notice. (See California Vehicle Code Section
26708(a); Minnesota Statutes 2005, Section 169.71)
2 A26391-K197-Z126-1-7619, edition 1

Important notes
Do not attach the cradle for the navigation device in an area that would
obstruct your view or an air bag.
When installing the cradle, ensure that it does not represent a risk in the event
of an accident.
Accessories offered by other manufacturers have not been tested or approved for
use the Pocket LOOX and may cause damage to the Pocket LOOX.
Regardless of Pocket LOOX’s ability to function as a precision navigational device,
any navigational device becomes unsafe when misused or misinterpreted.
Proper operation is understood to be operation of the product under the
conditions described in this operating manual or other NAVIGON documentation.
Observe the safety notes in the "Safety" manual and the following safety notes
to prevent damage to your device, data loss or injuries.
A26391-K197-Z126-1-7619, edition 1 3

Important notes
Traveling with the Pocket LOOX
Please observe the following information when you travel with your Pocket LOOX.
Transporting your Pocket LOOX
Tran spor tPocket LOOX
►Switch the Pocket LOOX off
►Disconnect the cables from the Pocket LOOX
►Protect the Pocket LOOX from severe shocks and extreme temperatures
(e.g. direct sunlight in a car)
Pocket LOOXTravel, Pocket LO OX
►If you wish to use your Pocket LOOX during a flight, check first with the airline
if this is allowed and under which conditions
►If you are travelling abroad, check that the adapter can be operated with the local
mains voltage. Do not use any other voltage converter
Using the Pocket LOOX
BatteryStoring the battery
Battery
Store the Pocket LOOX in a fully charged state in a dry environment. If you store the Pocket
LOOX, the storage temperature should be between -13°F and 140°F. The lower the temperature
at which the batteries are stored, the lower the rate of self-discharge.
Avoid leaving your Pocket LOOX lying in direct sunlight in a car. The temperature
could exceed the permissible 140°F in such cases!
To protect the battery, battery charging is stopped at excessively high
temperatures (over 114° F).
Please note that batteries discharge themselves over time. Therefore, recharge the battery
of your Pocket LOOX at regular intervals during the storage period.
Protect your Pocket LOOX’s expansion card slots and USB connection from dirt.
Dirt can lead to contact problems.
4 A26391-K197-Z126-1-7619, edition 1

Important notes
Cleaning your Pocket LOOX
CleaningNotesYour Pocket LOOXScreen
►Switch the Pocket LOOX off.
►Pull the power plug out of the outlet.
or
►Disconnect the USB charging cable from the Pocket LOOX.
The device surface can be cleaned with a dry cloth. If it is very dirty, you can clean
the device and the screen with a damp cloth.
Do not use any cleaning agents that contain abrasives or may corrode plastic.
Please ensure that no liquid enters the Pocket LOOX.
Liability
Liability
Fujitsu Siemens Computers GmbH cannot be held responsible for radio or television faults
arising from unauthorized changes made to this device. Fujitsu Siemens Computers
is, furthermore, not responsible for replacing and/or exchanging connector cables and
devices which have not been specified by Fujitsu Siemens Computers GmbH. The user
is solely responsible for repairing faults arising from such unauthorized changes made to
a device and for replacing and/or exchanging devices. For more information regarding
liability please see the Warranty provided with your Pocket LOOX.
FCC marking
FCC marking for devices without radio component
The Pocket LOOX complies with Part 15 of the FCC interference limits for Class
B digital devices for home or office use.
A26391-K197-Z126-1-7619, edition 1 5

Using your Pocket LOOX
Using your Pocket LOOX
Your Pocket LOOX
In this section you will find a description of the operating controls of your Pocket
LOOX and how you operate the Pocket LOOX.
Please refer to the notes in the chapter "Important notes", Page 2.
Overview of controls, ports and displays
Headphone po rt
Battery charge status displayGPS radio indicatorInfra red int erfaceMini USB portScreenFront coverCoverSuspend/R esume buttonHold switchPortforminiSDexpansioncardGPS antennaExanpable st ylus
1
2
13
7
9
10
11
12
3
4
5
6
8
1 = Screen
2 = Replaceable front cover
3 = Mini USB port
4 = Signal Status
5 = Battery charge status
6 = Headphone port
7 = Reset button
8 = Battery compartment
9 = Slot for expandable stylus
10 = Hold switch
11 = Suspend/Resume button
12 = Hold switch
13 = Port for mini SD expansion card
LED indicators
GPSDisplayDisplayRadio ind icatorPower indicatorStatusLED indicator Color Description Indicator state
Battery charging
indicator
Red AC adapter connected,
Pocket LOOX connected to
aPCviatheUSBport.
Lights up
Battery charging
indicator
Red No AC adapter connected Off
GPS radio indicator Blue GPS activated. Flashing
6 A26391-K197-Z126-1-7619, edition 1

Using your Pocket LOOX
Getting started
Getting startedUse
It will only take a few moments to have your Pocket LOOX up and running, ready for
use. The steps you will need to work through include:
• inserting the battery
• connecting the power adapter
• starting up your Pocket LOOX for the first time
You will learn more about the individual steps in the following sections.
Inserting the battery
Preparation for useBattery
1
3
2
►Slide off the cover from the Pocket LOOX in the direction of the arrow (1).
►Insert the battery in the battery compartment (2). Check the contact connections.
►Slide the cover back on in the direction of the arrow as far as it will go (3).
The battery is not completely charged when delivered. So charge the battery before
the first mobile use (see section "Charging the battery", Page 8).
A26391-K197-Z126-1-7619, edition 1 7

Using your Pocket LOOX
Charging the battery
Preparation for use
Please observe the safety information in the "Important notes", Page 2 chapter.
Your Pocket LOOX is equipped with a powerful battery. When you’re on the road
your Pocket LOOX is powered by the built-in battery.
Battery
The battery is not charged on delivery and should be charged for
12 hours prior to the first mobile use.
The battery charging time is otherwise approx. 4 hours. When the Pocket
LOOX is operating, the charging time is extended.
If the Pocket LOOX is charged using the USB port, the charging process can
take longer than when using the AC adapter. The charging time depends
on the USB port of the connected computer.
You have two ways of re-charging the battery:
• you can connect the Pocket LOOX directly to an AC outlet with the AC adapter
or
• you can connect the Pocket LOOX to a computer’s USB port using the USB cable.
Charging the battery using the AC adapter
BatteryAC adapter
You can connect the AC adapter directly to the Pocket LOOX.
►Connect the USB cable to the Mini-USB port of the Pocket LOOX.
►Connect the USB cable to the AC adapter.
►Connect the AC adapter to an electrical outlet.
The installed battery will now be charged. The power-on indicator flashes red.
You can use the Pocket LOOX during the charging process. This extends the charging time.
8 A26391-K197-Z126-1-7619, edition 1

Using your Pocket LOOX
BatterychargingviaaUSBport
BatteryUSB
►Connect the USB cable to your Pocket LOOX.
►Connect the USB cable to the computer’s USB port.
The computer’s USB port must deliver no less than 500 mh of power.
Because of the low charging current, the charging process will take longer
than it does using the power adapter.
Optimizing battery life
Optimizing battery life
The maximum operating time depends on the different applications used as some consume more
energy than others.You can adjust system settings to help you to save energy when using your
Pocket LOOX. These settings enable you to use the battery operating time optimally.
In the default setting the Pocket LOOX goes into the Suspend mode after three
minutes when working without a power connection and no entries are made.
You can switch on the Pocket LOOX again at any time by brieflypressingthe
Suspend/Resume button and then continue working where you left off.
Starting up your Pocket LOOX for the first time
Preparations for First sta rt-upStylusPocket LOOX
2
1
►Press the Suspend/Resume button (1) to switch on the Pocket LOOX.
►Pull out the stylus (2) in the direction of the arrow.
Before using the Pocket LOOX, you must calibrate the screen (see
chapter "Calibrating the screen", Page 28).
A26391-K197-Z126-1-7619, edition 1 9

Using your Pocket LOOX
Start screen (device dependent)
Initial start-upStart screen
The default display on your Pocket LOOX is "Portrait" format. Screenshots are shown
in landscape format in the manual since they provide a better display.
Information on switching between displays can be found in chapter "Set the
display to portrait or landscape format.", Page 29.
Following the introduction the start screen appears. The start screen shows
all important current information at a glance.
From this screen you have access to all programs and to the system settings.
Depending on the device, the following start screen appears (N100):
The multimedia menu has three multimedia programs:
• Music player
• Photo viewer
• Video player
10 A26391-K197-Z126-1-7619, edition 1

Using your Pocket LOOX
A26391-K197-Z126-1-7619, edition 1 11

Using your Pocket LOOX
Switching the Pocket LOOX on and off
Pocket LOOXPocket LOOX
Switch the Pocket LOOX on or off with the Suspend/Resume button. After certain applications or
the use of certain cards, it may be necessary to restart the Pocket LOOX with the soft reset.
1
1 = Suspend/Resume button
Switching the Pocket LOOX on and off during
normal use (Suspend mode)
Switching on
Suspend/Resum e button
►Press the Suspend/Resume button once to switch on the Pocket LOOX.
Switching off
Suspend/Resum e button
►Press the Suspend/Resume button once to switch off the Pocket LOOX.
Suspend mode
The Pocket LOOX is switched to suspend mode.
Switch-off time
If you have specified a switch-off time in the system settings, your Pocket LOOX
will automatically switch into Suspend mode after this specified time.
TherearetwowaystoswitchonyourPocketLOOX:
12 A26391-K197-Z126-1-7619, edition 1
