Fujitsu D3607 User manual

User Manual
D3607 PCI Express Gigabit
Ethernet Adapter

Congratulations on buying an innovative product
from Fujitsu.
The latest information about our products, tips, updates etc. can be found on the Internet at:
"http://www.fujitsu.com/fts/"
For driver updates, go to: "http://support.ts.fujitsu.com/download"
Should you have any technical questions, please contact:
●our Hotline/Service Desk ("http://support.ts.fujitsu.com/contact/servicedesk")
●Your sales partner
●Your sales outlet
We hope you enjoy working with your new Fujitsu system!

Published by / Contact address in the EU
Fujitsu Technology Solutions GmbH
Mies-van-der-Rohe-Straße 8
80807 München, Germany
http://www.fujitsu.com/fts/
Copyright
© Fujitsu Technology Solutions GmbH 2019. All rights reserved.
Publication Date
03/2019
Order No.: A26361-D3607-Z320-1-7619, Edition 1

D3607 PCI Express Gigabit
Ethernet Adapter
User Manual
Notational conventions 1
Overview 2
Approvals and standards 3
LED display 4
Description 5
Power consumption 6
Mounting the bracket 7
Installation 8
Abbreviations 9

Remarks
Product description information corresponds to the design requirements of Fujitsu and is
provided for the purposes of comparison. The actual results may differ due to several factors.
Subject to changes to technical data without prior notification. Fujitsu accepts no
responsibility with regard to technical or editorial mistakes or omissions.
Trademarks
Fujitsu and the Fujitsu logo are registered trademarks of Fujitsu Limited in Japan and in other
countries.
Intel is a trademark of the Intel Corporation in the USA and/or other countries.
Microsoft and Windows are registered or unregistered trademarks of the Microsoft
Corporation in the USA and/or in other countries.
Other product names and company names mentioned are trademarks or registered
trademarks of the corresponding companies or trademark owners.
Copyright
No part of this publication may be copied, reproduced or translated without the prior, written
consent of Fujitsu.
No part of this publication may be saved or transmitted by any electronic means without the
written consent of Fujitsu.

Fujitsu
Content
Notational conventions...................................................................................................................... 1
Overview.............................................................................................................................................. 2
Approvals and standards................................................................................................................... 3
LED displays....................................................................................................................................... 4
Description.......................................................................................................................................... 5
Power consumption ........................................................................................................................... 6
Mounting the bracket ......................................................................................................................... 7
Installation........................................................................................................................................... 8
Installing the network adapter............................................................................................................... 8
Installing the driver software................................................................................................................. 8
Abbreviations...................................................................................................................................... 9

Content
Fujitsu

Notational conventions
Fujitsu 1
Notational conventions
The meanings of the symbols and fonts used in this manual are as follows:
!indicates information which is important for your health or for preventing physical damage.
i
indicates additional information which is required to use the system properly.
►Text which follows this symbol describes activities that must be performed in the order shown.
This symbol indicates that you must press the Enter key.
Text in this typeface indicates screen outputs.
Text in this bold typeface indicates the entries you make via the keyboard.
Text in italics indicates commands or menu items.
"Quotation marks" indicate names of chapters or terms.

Overview
2 Fujitsu
Overview
The D3607 is a complete low profile PCI Express Gigabit Ethernet Adapter (in the following text
called NIC) utilizing the BCM57762 LAN Controller.
The NIC is available with ATX I/O connector bracket and/or low profile bracket.
LAN Controller Broadcom BCM57762
LAN interface 10/100/1000 Base-T - IEEE 802.3 compliant
Host interface x1 PCIexpress 1.1 bus interface
Performance 40 Kbyte receive and 22 KByte transmit buffer
TCP, IP, and UDP checksum Offload
Microsoft® Large Send Offload
Receive Side Scaling (RSS)
Manageability ACPI
Wake on LAN by interesting packets and Magic-PacketTM
Special feature PXE support
Memory for LAN
Controller
2 MBit FLASH
Connector RJ45 connector
Driver Support Windows® 7
Windows® 8.1
Windows® 10
Linux
Form factor PCI Express low profile Card 66.0 x 62.5 mm

Approvals and standards
Fujitsu 3
Approvals and standards
CE certification According to EU Directives 2014/30/EU (EMC) and 2014/35/EU
(Product safety)
Product safety IEC 60950-1, EN 60950-1, UL 60950-1, CSA C22.2 No. 60950-1
Electromagn. compatibility EN55032/B, FCC class B, EN55024
RoHS (Restriction of hazardous substances)Environmental compatibility
WEEE (Waste electrical and electronical equipment)
i
The component has to be installed in a suitable housing to meet the requirements.

LED displays
4 Fujitsu
LED displays
ACT/LINK
10=OFF
100=GRN
1000=ORG
ACT/LINK
10=off
100=GRN
1000=ORG
ACT/LINK Link green LED
Activity green LED is flashing
LED-signaling 10 Mb link LED off
Speed 100 Mb link green LED
1000 Mb link orange LED
The Speed LED might flash during power-on-reset or software driver initialization.

Description
Fujitsu 5
Description
Main part of the D3607 NIC Card is the BCM57762 LAN Controller. The controller settings and MAC
Address required for operation are stored in the SPI Flash as well as the PXE code.
The BCM57762 uses a 25 MHz Crystal as reference for the generation of the LAN Signals, which are
transmitted through the transformer module integrated in the RJ45 Connector. For the operation of
the PCI Express Interface is a 100 MHz Clock required, which is provided over the PCI Express Slot.

Power consumption
6 Fujitsu
Power consumption
The D3607 NIC requires the following supply voltages provided over the PCI Express Slot.
Source Voltage Maximal variation Typical current Operating Condition
+ 3,3 V Main +/- 5 % 1 mA Working
+ 12 V Main +/- 5 % 0 mA Working
320 mA Working
Supply Voltage
+ 3,3V AUX +/- 5 % 100 mA Standby

Mounting the bracket
Fujitsu 7
Mounting the bracket
The network adapter is shipped with a low profile and a standard bracket. Depending on your
system, you need to mount one of the brackets to your adapter card.
►Align the tabs of the bracket with the holes on the network adapter and fasten the screws onto
the network adapter.

Installation
8 Fujitsu
Installation
Installing the network adapter
!
Before installing the network adapter, ensure the system power is OFF and unplugged
from the power outlet and that proper electrical grounding procedures have been followed.
►Refer to the manuals that were supplied with your system for details about installing the
network adapter card on your particular system.
Installing the driver software
When installing the network adapter on your computer and start the system, the system detects a
new adapter and installs the native Broadcom driver.
i
You may need to download the latest driver software from the Fujitsu Support website:
"http://support.ts.fujitsu.com/download"

Abbreviations
Fujitsu 9
Abbreviations
ACPI Advanced Configuration and Power Interface
CPU Central Processing Unit
FIFO First-In First-Out
LAN Local Area Network
NIC Networking Interface Card
PCI-Bus Peripheral Component Interconnect Bus
PXE Preboot eXecution Environment
RAM Random Access Memory
SMBus System Management Bus
SPI Serial Peripheral Interface
WOL Wake on LAN
