Fujitsu AMY13F User manual

Deutsch
Français
Español
Italiano
EλληvIkά
Português English
COOLING MODEL
AMY13F
REVERSE
CYCLE MODEL
AMY12U
OPERATING MANUAL
ROOM AIR CONDITIONER
WINDOW TYPE
OPERATING MANUAL
BEDIENUNGSANLEITUNG
MODE D’EMPLOI
MANUAL DE FUNCIONAMIENTO
MANUALE DI ISTRUZIONI
ΕΓΧΕΙΡΙ∆ΙΟ ΛΕΙΤΟΥΡΓΙΑΣ
MANUAL DE INSTRUÇÕES
KEEP THIS OPERATION MANUAL
FOR FUTURE REFERENCE
FUJITSU GENERAL LIMITED

En-2
CONTENTS
Safety Symbols
The triangular symbol indicates WARNING and CAUTION items.
This symbol indicates prohibited operations. The prohibited action is indicated both within the symbol,
and in nearby explanations.
●This symbol indicates instructions regarding operations which are to be performed by the user.
DANGER
Do not attempt to install this air conditioner by yourself.
●Consult authorized service personnel for all installations.
Consult authorized service personnel for any repairs.
●Do not attempt to remove parts, or service the unit yourself, since you may be
exposed to dangerous electrical shock. This appliance contains no user-serviceable
parts.
When moving, consult authorized service personnel for
disconnection and installation of the unit.
PRECAUTIONS ......................................................... 2
NAME AND FUNCTION OF PARTS ......................... 6
AIR CONDITIONER OPERATION ............................. 7
AIR DIRECTION ADJUSTMENT ............................ 10
CARE AND MAINTENANCE................................... 13
TROUBLESHOOTING ............................................. 14
OPERATION DETAILS ............................................. 15
PRECAUTIONS
●Before using the appliance, read these “PRECAUTIONS” thoroughly and operate in the correct way.
●The instructions in this section all relate to safety; be sure to maintain safe operating conditions.
●“CAUTION” and “WARNING” have the following meanings in these instructions:
WARNING!
CAUTION!
This mark indicates procedures which, if improperly performed, might lead to the death
or serious injury of the user.
This mark indicates procedures which, if improperly performed, might possibly result
in personal harm to the user, or damage to property.

En-3
PRECAUTIONS
DANGER
Do not stay in direct cooling airflow for long periods.
●Excessive direct exposure to chilled air could be bad for your health.
●Be especially careful when going to bed, and in rooms where infants, aged, or sick
people are staying.
Do not insert fingers or objects into the outlet port or intake grilles.
●A fan operates at high speed inside the unit, and personal injury could result.
●Be particularly careful regarding small children.
Do not start and stop air conditioner operation by disconnecting
the power cord and so on.
Take care not to damage the power cord.
●Do not stand heavy items on the power cord, or allow it to be pulled. Such treatment
could damage the insulation, resulting in fire hazard and electrical shock.
WARNING
If the power supply cord of this air conditioner is damaged, it must be replaced
by the manufacturer or its authorized service personnel only in order to avoid
a safety hazard.
In the event of a malfunction (burning smell, etc.), immediately
stop operation, disconnect the power plug, and consult
authorized service personnel.
●Continuing to operate the unit under such conditions could lead to hazard of fire
or electrical shock.
If the power supply cord of this appliance is damaged, it should
only be replaced by the authorized service personnel, since
special purpose tools and specified cord are required.

En-4
PRECAUTIONS
CAUTION
Provide occasional ventilation during use.
●Be careful to provide adequate ventilation particularly
when using the unit in combination with other heating
apparatus. (REVERSE CYCLE MODEL)
●Insufficient ventilation could lead to oxygen starvation.
Do not drink the water drained from the
air conditioner.
Do not expose the air conditioner directly
to water.
●Electrical insulation could be damaged, resulting in
electrical shock.
Do not pull power cord.
●Pulling on the cord to disconnect the plug could damage
the wires inside the cord, resulting in heat or fire.
Turn off power source when not using the
unit for extended periods.
Do not use in applications involving the
storage of foods, plants or animals,
precision equipment, or art works.
●The quality of the stored items may deteriorate.
Do not direct air flow at fireplaces or
heating apparatuses.
●Direct air blowing on fires could result in improper
combustion or fire.
Do not set flower vases or water containers
on top of air conditioners.
●Water leaking inside the unit could damage electrical
insulation, leading to danger of electrical shock.
Do not operate the air conditioner with
wet hands.
●Electrical shock could result.
Always turn off power and disconnect the
power plug whenever cleaning the air con-
ditioner or changing the air filter.
●A fan operates at high speed inside the unit, and
personal injury could result.
Check the condition of the installation for
damage.
●After lengthy use, arrange for visit by authorized
service personnel to check installation condition.
Do not place animals or plants in the direct
path of the air flow.
●Lengthy exposure to direct Heating or Cooling airflow
could have adverse influence on plants or animals.

En-5
CAUTION
Always operate with the air filter installed.
●Operating the unit without the air filter could cause
excessive dirt to collect on internal parts, leading to
malfunction.
Do not block or cover the intake grille and
outlet port.
●Obstructing the ports will reduce operating efficiency,
leading to improper operation and possible damage.
Do not use inflammable gases near the air
conditioner.
Do not touch the heat exchanger radiator
fins.
●Personal injury could result.
●Be particularly careful when cleaning.
●Bending or damage to the fins will affect the efficiency
of the unit.
When installing the air conditioner, take
precautions to prevent access by infants.
●Unexpected accidents could occur.
Avoid installing the air conditioner near a
fireplace or other heating apparatus.
●Exposure to excessive heat could result in deformation
of the outer case.

En-6
NAME AND FUNCTION OF PARTS
For details of operation, see the pages indicated by the ☞mark.
Air Conditioner Unit
1Drain Boat or Drain Tube
(At the bottom of the back side)
Moisture condensed from the air during Cooling
is drained here.
2Right-Left Airflow-direction Louvres
(☞P. 10)
Control airflow in the horizontal (right-left) direction.
This can also be swept.
3Up-Down Airflow-direction Louvres
(Behind Airflow-direction Louvres)
(☞P. 10)
Control airflow in the vertical (up-down) direction.
4Control Panel Cover
5Power Supply Plug
6Air Intake Grille
Air is taken in here.
7Air Filter (☞P. 13)
Removes all dirt and dust from the air.
Control Panel 1SELECT Lever
NEUTRAL: When changing the airflow by manual ope-
ration.
SUPER WAVE ZONE:
When SUPER WAVE is operated, adjust to
the desired air flow direction (☞P. 11).
2SUPER WAVE Switch
)(OFF): When the air conditioner is operated by one
direction airflow.
ON: When taking out the airflow in the widerange.
3EXHAUST AIR Lever
CLOSE: Ventilation circulates through indoor air,
without being carried out.
OPEN: Cigarette smoke and smell are exhausted to
outside a room.
4MASTER CONTROL Switch (☞P. 7, 8)
5THERMOSTAT Control Switch (☞P. 9 )
When opening and closing the
control panel cover, press the
position of “PUSH” by your finger.
Note:
Cooling effect will be reduced when operating EXHAUST
AIR “OPEN”.

En-7
Power Supply
Connect the Power Supply Plug to an electrical point.
●Connect securely, without looseness.
●In the case of direct line connections, turn on the breaker.
MASTER CONTROL Switch
POSITION FUNCTION
)(OFF) The air conditioner is switched off.
FAN Fan only is operating to provide filtered air without
cooling effect.
SUPER QUIET Fan speed is low and cooling efficiency is intermediate
with low noise level.
NORMAL A cooling effect is obtained by a quieter operation than
“HIGH POWER”.
HIGH POWER Fan speed is at its maximum resulting in maximum
cooling effect.
Cooling
To obtain maximum cooling effect in the hot summer select position HIGH
POWER on the master control. Maximum moisture removal, air circulation and
dust removal are effected at the same time.
Selection of SUPER QUIET reduces operating noise.
Air Circulation
To maintain a comfortable room temperature an important factor is the circulation
of air. Room air can be circulated without cooling by selecting FAN position on
the master control.
Air circulation only without cooling effect may also be achieved with the thermostat
knob turned counterclockwise to “1”position and with the master control knob
at either “cool”position.
AIR CONDITIONER OPERATION
COOLING MODEL

En-8
LOW FAN
POSITION FUNCTION
Fan (High Speed) and compressor operate - Rapid
heating effect at top capacity.
Fan (Low Speed) and compressor operate - Intermediate
heating effect and reduced operating noise.
High fan speed without heating/cooling - Room air is
circulated and cleaned.
)(OFF) The air conditioner is switched off.
Low fan speed without heating/cooling - Room air is
circulated and cleaned.
Fan (Low Speed) and compressor operate - Intermediate
cooling effect and reduced operating noise.
Fan (High Speed) and compressor operate-Rapid
cooling effect at top capacity.
HIGH POWER
(RED)
SUPER QUIET
(RED)
HIGH FAN
SUPER QUIET
(BLUE)
HIGH POWER
(BLUE)
AIR CONDITIONER OPERATION
REVERSE CYCLE MODEL
Air Circulation
To maintain a comfortable room temperature, an important
factor is the circulation of air. Room air can be circulated
without cooling/heating by selecting either HIGH FAN or
LOW FAN position on the master control.
Circulation of air without cooling/heating can be also effected
as follows:
1. When operating with the MASTER CONTROL switched
to HIGH POWER (RED) or SUPER QUIET (RED), turn the
thermostat fully clockwise.
2. When operating with the MASTER CONTROL switched
to HIGH POWER (BLUE) or SUPER QUIET (BLUE), turn
the thermostat fully counterclockwise.
Power Supply
Cooling
To obtain maximum cooling effect in the hot summer
select position HIGH POWER (BLUE) on the MASTER
CONTROL. Maximum moisture removal, air circulation
and dust removal are effected at the same time.
Selection of SUPER QUIET (BLUE) reduces operating
noise.
Heating
To obtain maximum heating effect in severe winter select
position HIGH POWER (RED) on the MASTER CONTROL.
Maximum air circulation is obtained at the same time.
Selection of SUPER QUIET (RED) reduces heating effect
and operating noise. However you may feel a higher
temperature at the air outlet compared to the HIGH
POWER (RED) position, due to the reduced fan speed.
Connect the Power Supply Plug to an electrical point.
●Connect securely, without looseness.
●In the case of direct line connections, turn on the breaker.
MASTER CONTROL Switch
NOTE: After you start driving, it will take approximately
10 minutes for the air from this unit become
warm. This delay is normal.

En-9
THERMOSTAT Control Switch
Once the THERMOSTAT is set to the desired temperature, the room temperature
will be automatically adjusted without excessive or insufficient cooling/heating
and thus a comfortable environment is always maintained.
The thermostat controls the compressor only, and accordingly the fan is constantly
circulating air even during the period when the compressor is off during cooling/
heating operation.
1. When you wish to lower the temperature, turn the THERMOSTAT Control switch
clockwise in the direction of the higher numbers of the dial.
2. When you wish to increase the temperature, turn the THERMOSTAT Control switch
counterclockwise in the direction of the lower numbers.
NOTE:
•When the THERMOSTAT Control switch is set at positions “5”, “6”or “7”
comfortable room temperatures can usually be obtained. Please note that it is
unhealthy for the room temperature to be lower than approximately 22°C.
•When the THERMOSTAT Control switch is set at positioned at “10”, the
room-side fin coil may freeze up and prevent effective cooling. If this happens,
turn the switch to “FAN”, and turn the THERMOSTAT Control switch
counterclockwise.
CAUTION!
When cooling/heating is stopped by means of either the MASTER CONTROL
or THERMOSTAT Control switch do not restart cooling/heating for at least 3
minutes.
•If cooling/heating is restarted within this time, the compressor motor will be
subjected to an over current and a compressor motor safety device will be
actuated. If this occurs, restarting cooling/heating will not be possible for
about 20 minutes.
COOLING MODEL
REVERSE CYCLE MODEL

En-10
AIR DIRECTION ADJUSTMENT
WARNING!
●Do not put fingers or other objects into the air louvres; an internal fan operates at high
speed and could result in personal injury or damage.
●Do not operate the air conditioner with the airflow louvres blocked, since malfunction
could result.
Up-Down Airflow-
direction Louvres
Right-Left Airflow-
direction Louvres
■Vertical Adjustment
The Up-Down Airflow-direction Louvres may be positioned using tabs to dis-
charge the air upward, downward or straight on.
Air Direction Adjustment by manual operation
■Horizontal Adjustment
The Right-Left Airflow-direction Louvres may be positioned using tabs to dis-
charge the air rightward, leftward or straight on.
NOTE:
The THERMOSTAT positions “8”, “9”and “10”can be used when the room
temperature does not become sufficiently low. This condition may occur
when the THERMOSTAT Control switches off automatically because cooled
air, when it passes through the Up-Down Airflow-direction Louvres positioned
downwards and the Right-Left Airflow-direction Louvres positioned to the left,
makes a short circuit and the recirculated air touches the sensor
of the THERMOSTAT.
CAUTION!
Adjust the Right-Left Airflow-direction Louvres after SELECT LEVER is set to the
“NEUTRAL”position.

En-11
Air Direction Adjustment by SUPER WAVE
1Move the SELECT LEVER fully right to “NEUTRAL”.
2Set the Right-Left Airflow-direction Louvres and
SELECT LEVER according to the airflow direction you
required as described below.
3Set the SELECT LEVER within “SUPER WAVE ZONE”
range. Set the SUPER WAVE Switch to “ON”.
NOTE:
If the MASTER CONTROL Switch is set to “)”, set it to the other position.
4The sweep angle can be adjusted within the “SUPER
WAVE ZONE”range. When the SELECT LEVER is
moved to the right or left the sweep angle decrease
or increase.
NOTE:
If the SELECT LEVER is returned to the “NEUTRAL”in error, the Right-Left
Airflow-direction Louvres do not function properly. In this event, carry out
the procedure from the beginning.
<Sweep Angle>
Increase
Decrease

En-12
Adjustment Super Wave
With this air conditioner, 3 Airflow-directions are available and for each direction, the required sweep angle can be set.
Blowing Direction
Adjusting the Right-
Left Airflow-direc-
tion Louvres
Left Side Centre Right Side
Lightly move the Right-Left
Airflow-direction Louvres to
the left until they stop.
Position the Right-Left
Airflow-direction Louvres
approx. at the centre.
Lightly move the Right-Left
Airflow-direction Louvres to
the right until they stop.
CAUTION!
Adjust the Right-Left Airflow-direction Louvres after SELECT LEVER is set to the “NEUTRAL”position.
AIR DIRECTION ADJUSTMENT
Minimum
Maximum
Minimum
Maximum
Minimum
Maximum

En-13
CARE AND MAINTENANCE
CAUTION!
Before cleaning the unit, be sure to stop the unit and disconnect the power supply.
1. Disconnect the power plug. 2. Turn off the electrical breaker.
●A fan operates at high speed inside the unit, and personal injury could result.
Cleaning the Air Filter
If dirt is allowed to collect in the air filter, the airflow will
be reduced, leading to reduced performance, and increased
operating noise. Be sure to clean the filters at the beginning
of the operating season, and about every two weeks during
periods of frequent operation.
Remove the Air Filter
Remove the Air Filter from the air intake grille assembly by
pulling rightward.
Installing the Air Filter
Hold the air filter by its handle, direct the mark “FRONT”
toward you, and insert into the air intake grille, then press
in fully to the handle.
Cleaning
Use a vacuum cleaner to remove dust and dirt from the
air filter, or wash in a synthetic detergent. After washing,
dry in a shaded place, then reinstall.
Cleaning the Indoor Unit
Clean the indoor unit by wiping with a cloth dipped in
cool or warm water, then wipe with another soft, clean,
dry cloth.
CAUTION!
Never use water that is hotter than 40°C. The body
may warp or change colour.
Do not use inflammable sprays such as lacquer or
hair spray near the air conditioner.
The unit can be damaged by gasoline, benzine, thinners,
insecticides and other chemical agents.
When Not Using the Unit for Extended
Periods (One Month or More)
Operate the unit on fan mode for about one-half day on a
day with clear weather, to assure that the internal parts
are dry.
CAUTION!
When not using the unit for extended periods, discon-
nect the power plug for safety.
●When a plug is left connected, dust may collect on
the blades, leading to smoke and fire hazard.
Check the Power Cord
Check the power cord occasionally to confirm that it is
not damaged by cuts or abrasions. If you discover damage
to the cord, consult authorized service personnel.
More than 40 °C
Inspections and Repairs
Depending on the conditions of use, the internal parts
of an air conditioner will become dirty after about two
or three seasons of use, and performance may be af-
fected. For this reason, regular professional maintenance
is recommended. Consult authorized service personnel.

En-14
TROUBLESHOOTING
In the event of a malfunction (burning smell, etc.), immediately stop operation, disconnect
the power plug, and consult authorized service personnel.
Merely turning off the unit's power switch will not completely disconnect the unit from the
power source. Always be sure to disconnect the power plug or turn off your circuit breaker
to ensure that power is completely off.
WARNING!
Before requesting service, perform the following checks:
Symptom
Noise is heard:
Smells:
Mist or steam are emitted:
Airflow is stop.
Problem
●During operation and immediately after stopping the unit, the sound
of water flowing in the air conditioner's piping may be heard. Also, noise
may be particularly noticeable for about 2 to 3 minutes after starting
operation (sound of coolant flowing).
●During operation, a slight squeaking sound may be heard. This is the
result of minute expansion and contraction of the front cover due to
temperature changes.
●During Heating mode, a sizzling sound may be heard occasional. This sound
is produced by the automatic defrosting operation. (REVERSE CYCLE
MODEL)
●Some smell may be emitted from the air conditioner. This smell is the result
of room smells (furniture, tobacco, etc.) which have been taken into the air
conditioner.
●During Cooling operation, a thin mist may be seen emitted from the indoor
unit. This results from the sudden Cooling of room air by the air emitted
from the air conditioner, resulting in condensation and misting.
●During Heating operation, the fan may stop, and steam may be seen rising
from the unit. This is due to operation of the defrosting mode. (REVERSE
CYCLE MODEL)
●During Heating mode, the unit will temporarily stop operation (between 6
and 12 minutes) as the automatic defrosting mode operates. During
defrosting operation, the OPERATION indicator lamp will flash slowly.
(REVERSE CYCLE MODEL)
NORMAL
FUNCTIONS
Symptom
Doesn't operate at all:
Poor Cooling (or Heating)
performance:
Items to Check
●Is the power plug disconnected from its outlet?
●Has there been a power failure?
●Has a fuse blown out, or a circuit breaker been tripped?
●Is the MASTER CONTROL switch set to the OFF position?
●Is the air filter dirty?
●Are the air conditioner's intake grille or outlet port blocked?
●Did you adjust the room temperature settings (thermostat) correctly?
●Is there a window or door open?
●In the case of Cooling operation, is a window allowing bright sunlight
to enter? (Close the curtains.)
●In the case of Cooling operation, are there heating apparatus or computers
inside the room, or are there too many people in the room?
CHECK ONCE
MORE
If these checks do not rectify the problem, stop operation, disconnect the power plug, and consult your authorized service
personnel.

En-15
OPERATION DETAILS
Please read and understand the following details regarding this air conditioner.
Operation and Performance
Heating Performance
●This air conditioner uses a heat pump which absorbs
heat from outside air and brings it indoors. As a result, its
heating performance is reduced as the temperature of
outside air drops. If you find that insufficient room heat
is produced, we recommend that you use the air
conditioner together with other heating appliances.
●Heat-pump type air conditioners use warm-air recircula-
tion to warm your entire room. As a result, some time
will be required after starting operation until your entire
room becomes warm.
Microcomputer-controlled Automatic
Defrosting
When outside air temperatures are low and humidity is high,
using the Heating mode may result in the creation of frost
inside the outdoor unit, lowering its heating performance.
A built-in microcomputer is used to monitor this condition
and when necessary, the defrosting mode operates, result-
ing in a temporary interruption of the Heating mode (both
indoor and outside fans will stop). About 7 to 15 minutes
will be required for normal operation to be resumed.
Temperature and Humidity Range
Permissible ranges of temperature and humidity are as
follows:
Outdoor temperature:
About 21°C to 43°C
Indoor temperature:
About 21°C to 32°C
Indoor humidity:
About 80% or less. If the unit is used for
long periods under conditions of high
humidity, water may condense on and drip
from the surface of the unit.
Outdoor temperature:
About 0°C to 21°C
Indoor temperature:
About 30°C or less
If the unit is used under higher temperature conditions
than those noted here, the automatic protection circuit may
operate, interrupting the operation. If the unit is used under
lower temperature conditions than those noted here, the heat
exchanger may freeze, causing water leakage or other
malfunction.
●Do not use the air conditioner for any purpose other
than room cooling or room heating.
Cooling
Operation
Heating
Operation
