Fujitsu ARXG30KMLA Service manual

AIR CONDITIONER
Duct type
DESIGN & TECHNICAL MANUAL
INDOOR ARXG24KMLA
ARXG30KMLA
ARXG36KMLA
ARXG45KMLA
OUTDOOR
AOYG24KBTB AOYG30KBTB
AOYG36KBTB
AOYG45KBTB
DR_AR028EF_04
2021.12.03

Notices:
• Product specifications and design are subject to change without notice for future improvement.
• For further details, please check with our authorized dealer.
Trademarks
FGLair™ is trademark of Fujitsu General Limited in the United States, other countries or both.
Google Play™ is trademark of Google Inc.
App Store® is a service mark of Apple Inc., registered in the U.S. and other countries.
Copyright © 2019 Fujitsu General Limited. All rights reserved.

CONTENTS
Part 1. INDOOR UNIT...........................................................................1
1. Specifications................................................................................................2
2. Dimensions....................................................................................................4
2-1. Models: ARXG24KMLA, ARXG30KMLA, ARXG36KMLA, and ARXG45KMLA ...............4
2-2. Installation space requirement .........................................................................................5
2-3. Maintenance space requirement......................................................................................6
3. Wiring diagrams ............................................................................................7
3-1. Model: ARXG24KMLA .....................................................................................................7
3-2. Models: ARXG30KMLA, ARXG36KMLA, and ARXG45KMLA.........................................7
4. Capacity table................................................................................................8
4-1. Cooling capacity...............................................................................................................8
4-2. Heating capacity ............................................................................................................10
5. Fan performance .........................................................................................11
5-1. Fan performance curve..................................................................................................11
5-2. Airflow ............................................................................................................................43
6. Operation noise (sound pressure).............................................................46
6-1. Noise level curve............................................................................................................46
6-2. Sound level check point .................................................................................................48
7. Safety devices .............................................................................................49
8. External input and output...........................................................................50
8-1. External input.................................................................................................................50
8-2. External output...............................................................................................................51
8-3. Combination of external input and output.......................................................................52
8-4. Details of function ..........................................................................................................53
9. Function settings .......................................................................................56
9-1. Function settings on indoor unit .....................................................................................56
9-2. Function settings by using remote controller..................................................................58
10. Accessories.................................................................................................63
10-1.Models: ARXG24KMLA, ARXG30KMLA, ARXG36KMLA, and ARXG45KMLA ............63
11. Optional parts .............................................................................................64
11-1.Controllers ....................................................................................................................64
11-2.Others ...........................................................................................................................65

Part 2. OUTDOOR UNIT.....................................................................67
1. Specifications..............................................................................................68
2. Dimensions..................................................................................................71
2-1. Model: AOYG24KBTB ...................................................................................................71
2-2. Models: AOYG30KBTB and AOYG36KBTB ..................................................................72
2-3. Model: AOYG45KBTB ...................................................................................................73
3. Installation space ........................................................................................74
3-1. Model: AOYG24KBTB ...................................................................................................74
3-2. Models: AOYG30KBTB, AOYG36KBTB, and AOYG45KBTB .......................................77
4. Refrigerant circuit .......................................................................................80
4-1. Models: AOYG24KBTB and AOYG30KBTB ..................................................................80
4-2. Models:AOYG36KBTB and AOYG45KBTB ...................................................................81
5. Wiring diagrams ..........................................................................................82
5-1. Model: AOYG24KBTB ...................................................................................................82
5-2. Model: AOYG30KBTB ...................................................................................................83
5-3. Model: AOYG36KBTB ...................................................................................................84
5-4. Model: AOYG45KBTB ...................................................................................................84
6. Capacity compensation rate for pipe length and height difference........85
6-1. Model: AOYG24KBTB ...................................................................................................85
6-2. Model: AOYG30KBTB ...................................................................................................86
6-3. Model: AOYG36KBTB ...................................................................................................87
6-4. Model: AOYG45KBTB ...................................................................................................88
7. Additional charge calculation ....................................................................89
7-1. Model: AOYG24KBTB ...................................................................................................89
7-2. Models: AOYG30KBTB and AOYG36KBTB ..................................................................89
7-3. Model: AOYG45KBTB ...................................................................................................89
8. Airflow..........................................................................................................90
8-1. Model: AOYG24KBTB ...................................................................................................90
8-2. Models: AOYG30KBTB and AOYG36KBTB ..................................................................90
8-3. Model: AOYG45KBTB ...................................................................................................90
9. Operation noise (sound pressure).............................................................91
9-1. Noise level curve............................................................................................................91
9-2. Sound level check point .................................................................................................93
10. Electrical characteristics............................................................................94
11. Safety devices .............................................................................................95
12. External input and output (30-45 models).................................................97
12-1.External input................................................................................................................97
12-2.External output..............................................................................................................99
13. Function settings (30-45 models) ............................................................101
13-1.Control PCB and switch buttons location ....................................................................101
CONTENTS (continued)

13-2.Local setting procedure...............................................................................................103
14. Accessories...............................................................................................105
14-1.Model: AOYG24KBTB ................................................................................................105
14-2.Models: AOYG30KBTB, AOYG36KBTB, and AOYG45KBTB ....................................105
15. Optional parts............................................................................................106
CONTENTS (continued)

Part 1. INDOOR UNIT
DUCT TYPE:
ARXG24KMLA
ARXG30KMLA
ARXG36KMLA
ARXG45KMLA

1. Specifications
Type Inverter heat pump
Model name ARXG24KMLA ARXG30KMLA ARXG36KMLA ARXG45KMLA
Power supply 230 V ~ 50 Hz
Power supply intake Outdoor unit
Available voltage range 198—264 V
Capacity
Cooling
Rated kW 6.8 8.5 9.5 12.1
Btu/h 23,200 29,000 32,400 41,300
Min.—Max. kW 0.9—8.0 2.8—10.0 2.8—11.2 4.0—13.0
Btu/h 3,100—27,300 9,600—34,100 9,600—38,200 13,600—44,400
Heating
Rated kW 7.5 10.0 10.8 13.5
Btu/h 25,600 34,100 36,900 46,100
Min.—Max. kW 0.9—9.1 2.7—11.2 2.7—12.7 4.2—15.2
Btu/h 3,100—31,000 9,200—38,200 9,200—43,300 14,300—51,900
Input power
Cooling Rated
kW
2.14 2.65 2.97 4.22
Max. 3.03 3.83 4.29 5.03
Heating Rated 1.97 2.63 2.88 3.84
Max. 2.65 4.37 4.66 4.79
Current Cooling Rated A 9.4 11.7 13.1 18.6
Heating 8.7 11.7 12.8 16.9
Power factor Cooling %98.8 98.1 98.3 98.8
Heating 98.8 97.7 98.2 98.9
EER Cooling kW/kW 3.18 3.21 3.20 2.87
COP Heating 3.80 3.75 3.52
Moisture removal L/h (pints/h) 2.5 (4.4) 3.0 (5.3) 4.0 (7.0)
Maximum operating current *1 Cooling A13.6 22.6 22.6 28.5
Heating 13.6 22.6 22.6 28.5
Fan
Airflow rate
Cooling
HIGH
m3/h
1,100 1,900 2,100
MED 910 1,620 1,750
LOW 750 1,270 1,350
QUIET 580 980 1,070
Heating
HIGH 1,100 2,100
MED 910 1,620 1,750
LOW 750 1,270 1,350
QUIET 580 980 1,070
Type × Q'ty Sirocco × 2
Motor output W 106 197
Static pressure range Pa 30 to 150
Sound pressure level *2
Cooling
HIGH
dB (A)
31 39 42
MED 29 35 38
LOW 27 30 32
QUIET 25 26 28
Heating
HIGH 31 42 42
MED 29 35 38
LOW 27 30 32
QUIET 25 26 28
Sound power level Cooling HIGH dB (A) 60 65 68
Heating 62 69 70 70
Heat exchanger type
Dimensions (H × W × D) mm 294 × 1,000 × 39.9 294 × 1,000 × 53.2
Fin pitch 1.40
Rows × Stages 3 × 14 4 × 14
Pipe type Copper
Fin type Aluminum
Enclosure Material Steel sheet
Color —
Dimensions
(H × W × D)
Net mm 270 × 1,135 × 700
Gross 300 × 1,320 × 790
Weight Net kg 35 38 39
Gross 43 45 47
Connection pipe Size Liquid mm (in) Ø6.35 (1/4) Ø9.52 (3/8)
Gas Ø12.70 (1/2) Ø15.88 (5/8)
Method Flare
Drain port Material Steel
Size mm Ø36 (I.D.), Ø38 (O.D.)
Operation range Cooling °C 18 to 32
%RH 80 or less
Heating °C 16 to 30
Remote control (Option) Wired remote controller, Wireless remote controller, Mobile app*3 (FGLair™)
NOTES:
• Specifications are based on the following conditions:
– Cooling: Indoor temperature of 27 °CDB/19 °CWB, and outdoor temperature of 35 °CDB/24 °CWB.
– Heating: Indoor temperature of 20 °CDB/15 °CWB, and outdoor temperature of 7 °CDB/6 °CWB.
– Standard static pressure; 24 type: 35 Pa, 30 and 36 types: 47 Pa, 45 type: 60 Pa
– Pipe length: 5 m, Height difference: 0 m. (Between outdoor unit and indoor unit.)
• Protective function might work when using it outside the operation range.
• *1: Maximum operating current is the total current of the indoor unit and the outdoor unit.
• *2: Sound pressure level:
– Measured values in manufacturer’s anechoic chamber.
– Because of the surrounding sound environment, the sound levels measured in actual installation conditions might be higher than the specified values here.
• *3: Available on Google Play™ store or on App Store®. Optional WLAN adapter is also required. For details, refer to the setting manual.
- 2 - 1. Specifications
DUCT TYPE ARXG24-45KMLA DUCT TYPE ARXG24-45KMLA

Model name ARXG24KMLA ARXG30KMLA ARXG36KMLA
Energy efficiency class Cooling A++ A++ A++
Heating (Average) A+A+A+
Pdesign Cooling kW 6.8 (35°C) 8.5 (35°C) 9.5 (35°C)
Heating (Average) 6.0 (-10°C) 8.0 (-10°C) 8.7 (-10°C)
SEER Cooling kWh/kWh 6.20 6.23 6.10
SCOP Heating (Average) 4.10 4.00 4.00
Annual energy consumption QCE kWh/a 384 477 545
QHE (Average) 2,045 2,797 3,044
- 3 - 1. Specifications
DUCT TYPE ARXG24-45KMLA DUCT TYPE ARXG24-45KMLA

2. Dimensions
2-1. Models: ARXG24KMLA, ARXG30KMLA, ARXG36KMLA, and
ARXG45KMLA
Front view
Top viewSide view (L) Side view (R)
Rear view
Gas pipe
Liquid pipe
Drain port
Drain port
Knockout
for fresh air
Unit: mm
138
138
P125 × 3 = 375
Φ3.2
8080
Φ205
75
82
8080
264
Φ3.2
264264
270
240
121
80 80
32
161
80 80
Φ200
40 700
173 477
73
107
1,135
1,015
120
1,177
Φ5 P125 × 3 = 375
Φ5
16
34
270
240
170
32
66
114
281
240
168
283
39
54
Air
- 4 -
2-1. Models: ARXG24KMLA, ARXG30KMLA, ARXG36KMLA, and ARXG45KMLA 2. Dimensions
DUCT TYPE ARXG24-45KMLA DUCT TYPE
ARXG24-45KMLA

2-2. Installation space requirement
Provide sufficient installation space for product safety.
NOTE: The detailed component shape depends on the model.
¢Models: ARXG24KMLA, ARXG30KMLA, ARXG36KMLA, and
ARXG45KMLA
Unit: mm
150 or more300 or more
Floor
2,500 or more
(When no ceiling)
- 5 -
2-2. Installation space requirement 2. Dimensions
DUCT TYPE ARXG24-45KMLA DUCT TYPE
ARXG24-45KMLA

2-3. Maintenance space requirement
For future maintenance and service access, provide sufficient maintenance space.
NOTES:
• Do not place any wiring or illumination in the maintenance space, as they will impede service.
• The detailed component shape depends on the model.
¢Models: ARXG24KMLA, ARXG30KMLA, ARXG36KMLA, and
ARXG45KMLA
Unit: mm
• Provide a service access for maintenance purposes.
Maintenance hole
Control box
300
500
500
100
• The service access necessary for fan units and filter maintenance.
Maintenance hole
Intake panel
300
1,550
500
100
Control box
• When using a square duct
P174 ×6 = 1,044 Φ3.2
46
23
18
219
109
• Bottom air intake hole
108 1,015
16 240
- 6 -
2-3. Maintenance space requirement 2. Dimensions
DUCT TYPE ARXG24-45KMLA DUCT TYPE
ARXG24-45KMLA

3. Wiring diagrams
3-1. Model: ARXG24KMLA
3-2. Models: ARXG30KMLA, ARXG36KMLA, and ARXG45KMLA
- 7 -
3-1. Model: ARXG24KMLA 3. Wiring diagrams
DUCT TYPE ARXG24-45KMLA DUCT TYPE
ARXG24-45KMLA

4. Capacity table
Capacity tables show each of following values calculated based on the outdoor temperature and the
indoor temperature, under given Airflow Rate (AFR):
For cooling capacity: Total Capacity (TC), Sensible Heat Capacity (SHC), and Input Power (IP)
For heating capacity: Total Capacity (TC) and Input Power (IP)
4-1. Cooling capacity
¢Model: ARXG24KMLA
AFR m3/h 1,100
Indoor temperature
°CDB 18 21 23 25 27 29 32
°CWB 12 15 16 18 19 21 23
Outdoor temperature
°CDB TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
kW kW kW kW kW kW kW
-15 5.66 4.36 0.68 6.30 4.39 0.70 6.52 4.77 0.70 6.95 4.79 0.71 7.16 5.17 0.71 7.59 5.15 0.72 8.02 5.48 0.72
-10 5.70 4.37 0.58 6.35 4.40 0.59 6.57 4.78 0.59 7.00 4.80 0.60 7.22 5.18 0.60 7.65 5.16 0.61 8.09 5.50 0.61
0 5.56 4.31 0.59 6.19 4.33 0.60 6.40 4.71 0.60 6.83 4.72 0.61 7.04 5.10 0.61 7.46 5.08 0.62 7.88 5.41 0.63
5 5.41 4.25 0.75 6.02 4.27 0.77 6.23 4.65 0.77 6.64 4.66 0.78 6.85 5.03 0.78 7.26 5.01 0.79 7.67 5.34 0.80
10 5.37 4.24 0.73 5.98 4.26 0.74 6.19 4.64 0.75 6.60 4.65 0.75 6.80 5.02 0.76 7.21 5.00 0.76 7.62 5.33 0.77
15 5.20 4.16 0.88 5.79 4.19 0.90 5.99 4.55 0.90 6.39 4.57 0.91 6.58 4.93 0.91 6.98 4.91 0.92 7.37 5.24 0.93
20 6.54 4.76 1.57 7.29 4.78 1.59 7.54 5.20 1.60 8.04 5.22 1.61 8.28 5.64 1.62 8.78 5.61 1.64 9.28 5.98 1.66
25 6.15 4.61 1.74 6.85 4.63 1.77 7.09 5.04 1.78 7.55 5.05 1.79 7.79 5.46 1.80 8.25 5.44 1.82 8.72 5.79 1.84
30 5.76 4.45 1.90 6.41 4.47 1.93 6.63 4.86 1.94 7.07 4.88 1.96 7.29 5.27 1.97 7.72 5.25 1.99 8.16 5.59 2.01
35 5.37 4.30 2.07 5.98 4.32 2.10 6.19 4.70 2.11 6.60 4.71 2.13 6.80 5.09 2.14 7.21 5.07 2.16 7.62 5.40 2.18
40 5.09 4.16 2.24 5.67 4.19 2.27 5.87 4.55 2.29 6.26 4.57 2.31 6.45 4.93 2.32 6.84 4.91 2.34 7.22 5.24 2.37
46 4.18 3.68 1.93 4.66 3.71 1.96 4.82 4.03 1.97 5.13 4.04 1.99 5.29 4.37 2.00 5.61 4.35 2.02 5.93 4.63 2.04
¢Model: ARXG30KMLA
AFR m3/h 1,900
Indoor temperature
°CDB 18 21 23 25 27 29 32
°CWB 12 15 16 18 19 21 23
Outdoor temperature
°CDB TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
kW kW kW kW kW kW kW
-15 6.18 5.12 1.03 6.40 5.13 1.06 6.54 5.14 1.08 6.91 5.39 1.09 7.27 5.64 1.11 7.68 5.82 1.13 8.29 6.09 1.15
-10 6.05 5.04 1.26 6.26 5.06 1.29 6.41 5.07 1.31 6.76 5.31 1.33 7.12 5.55 1.35 7.52 5.73 1.37 8.12 6.00 1.40
0 5.79 4.89 1.70 6.00 4.91 1.74 6.13 4.92 1.77 6.47 5.15 1.80 6.82 5.39 1.83 7.20 5.56 1.85 7.77 5.82 1.89
5 5.74 4.87 1.75 5.95 4.88 1.79 6.08 4.89 1.82 6.42 5.13 1.85 6.76 5.36 1.88 7.14 5.54 1.91 7.71 5.79 1.95
10 5.69 4.85 1.80 5.89 4.86 1.85 6.03 4.87 1.87 6.36 5.10 1.91 6.70 5.34 1.94 7.07 5.51 1.97 7.64 5.77 2.01
15 5.60 4.77 1.86 5.79 4.78 1.90 5.93 4.79 1.93 6.26 5.02 1.96 6.59 5.25 1.99 6.96 5.42 2.02 7.51 5.67 2.07
20 8.44 6.42 2.24 8.74 6.44 2.29 8.94 6.45 2.33 9.44 6.76 2.37 9.93 7.07 2.41 10.49 7.30 2.44 11.33 7.64 2.49
25 8.04 6.31 2.31 8.32 6.33 2.37 8.51 6.34 2.40 8.98 6.64 2.45 9.46 6.95 2.49 9.99 7.17 2.52 10.78 7.51 2.58
30 7.63 6.20 2.39 7.90 6.22 2.45 8.08 6.23 2.48 8.53 6.53 2.53 8.98 6.83 2.57 9.48 7.05 2.61 10.24 7.37 2.66
35 7.22 6.09 2.47 7.48 6.11 2.52 7.65 6.12 2.56 8.07 6.41 2.61 8.50 6.71 2.65 8.98 6.92 2.69 9.69 7.24 2.75
40 6.76 5.98 2.58 7.00 6.00 2.64 7.16 6.01 2.68 7.56 6.30 2.72 7.95 6.59 2.77 8.40 6.80 2.81 9.07 7.11 2.87
46 6.20 5.85 2.71 6.42 5.86 2.77 6.57 5.88 2.82 6.93 6.16 2.86 7.30 6.44 2.91 7.71 6.65 2.95 8.32 6.96 3.02
¢Model: ARXG36KMLA
AFR m3/h 1,900
Indoor temperature
°CDB 18 21 23 25 27 29 32
°CWB 12 15 16 18 19 21 23
Outdoor temperature
°CDB TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
kW kW kW kW kW kW kW
-15 6.91 5.51 1.03 7.15 5.53 1.06 7.31 5.55 1.08 7.72 5.81 1.09 8.13 6.08 1.11 8.58 6.27 1.13 9.27 6.56 1.15
-10 6.76 5.50 1.26 7.00 5.52 1.29 7.16 5.53 1.31 7.56 5.80 1.33 7.96 6.06 1.35 8.40 6.25 1.37 9.07 6.55 1.40
0 6.47 5.47 1.70 6.70 5.49 1.74 6.86 5.50 1.77 7.24 5.76 1.80 7.62 6.02 1.83 8.05 6.22 1.85 8.69 6.51 1.89
5 6.42 5.44 1.75 6.64 5.46 1.79 6.80 5.48 1.82 7.17 5.74 1.85 7.55 6.00 1.88 7.98 6.19 1.91 8.61 6.48 1.95
10 6.36 5.42 1.80 6.59 5.44 1.85 6.74 5.46 1.87 7.11 5.72 1.91 7.49 5.98 1.94 7.91 6.17 1.97 8.54 6.46 2.01
15 6.26 5.33 1.86 6.48 5.35 1.90 6.62 5.37 1.93 6.99 5.62 1.96 7.36 5.88 1.99 7.77 6.07 2.02 8.39 6.35 2.07
20 9.44 7.16 2.51 9.77 7.19 2.57 9.99 7.21 2.61 10.55 7.55 2.65 11.10 7.89 2.70 11.73 8.15 2.73 12.66 8.53 2.79
25 8.98 6.97 2.59 9.30 7.00 2.65 9.51 7.02 2.70 10.04 7.35 2.74 10.57 7.69 2.79 11.16 7.93 2.83 12.05 8.30 2.89
30 8.53 6.78 2.68 8.83 6.81 2.74 9.03 6.83 2.78 9.53 7.15 2.83 10.03 7.48 2.88 10.60 7.72 2.92 11.44 8.08 2.98
35 8.07 6.60 2.76 8.36 6.62 2.83 8.55 6.64 2.87 9.02 6.95 2.92 9.50 7.27 2.97 10.03 7.50 3.01 10.83 7.85 3.08
40 7.55 6.41 2.89 7.82 6.43 2.96 8.00 6.45 3.00 8.44 6.75 3.05 8.89 7.06 3.10 9.39 7.29 3.15 10.14 7.63 3.22
46 6.93 6.18 3.04 7.18 6.20 3.11 7.34 6.22 3.16 7.75 6.52 3.21 8.16 6.81 3.26 8.61 7.03 3.31 9.30 7.36 3.38
- 8 -
4-1. Cooling capacity 4. Capacity table
DUCT TYPE ARXG24-45KMLA DUCT TYPE ARXG24-45KMLA

¢Model: ARXG45KMLA
AFR m3/h 2,100
Indoor temperature
°CDB 18 21 23 25 27 29 32
°CWB 12 15 16 18 19 21 23
Outdoor temperature
°CDB TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
kW kW kW kW kW kW kW
-15 8.51 6.64 1.68 9.23 6.97 1.72 9.72 7.19 1.74 10.20 7.49 1.77 10.68 7.79 1.79 11.13 7.94 1.79 11.79 8.15 1.79
-10 8.58 6.70 1.70 9.31 7.04 1.74 9.80 7.26 1.77 10.28 7.57 1.79 10.77 7.87 1.82 11.22 8.01 1.82 11.89 8.23 1.82
0 8.73 6.83 1.75 9.47 7.17 1.79 9.96 7.40 1.82 10.46 7.71 1.84 10.95 8.02 1.87 11.41 8.17 1.87 12.09 8.39 1.87
5 8.57 6.74 1.80 9.30 7.08 1.84 9.78 7.31 1.86 10.27 7.61 1.89 10.76 7.92 1.92 11.20 8.06 1.92 11.88 8.28 1.92
10 8.42 6.65 1.84 9.13 6.99 1.88 9.61 7.21 1.91 10.08 7.51 1.94 10.56 7.81 1.96 11.00 7.96 1.96 11.66 8.17 1.96
15 8.27 6.54 1.89 8.98 6.87 1.94 9.45 7.10 1.96 9.91 7.39 1.99 10.38 7.69 2.02 10.82 7.83 2.02 11.47 8.04 2.02
20 11.05 8.40 3.59 11.99 8.82 3.67 12.61 9.10 3.72 13.24 9.48 3.78 13.86 9.86 3.83 14.44 10.04 3.83 15.31 10.31 3.83
25 10.58 8.18 3.71 11.48 8.60 3.80 12.08 8.87 3.85 12.68 9.24 3.91 13.28 9.61 3.96 13.83 9.79 3.96 14.66 10.05 3.96
30 10.11 7.97 3.83 10.97 8.38 3.92 11.54 8.64 3.98 12.12 9.00 4.03 12.69 9.36 4.09 13.22 9.54 4.09 14.01 9.79 4.09
35 9.64 7.76 3.96 10.46 8.15 4.04 11.01 8.41 4.10 11.55 8.77 4.16 12.10 9.12 4.22 12.61 9.28 4.22 13.36 9.53 4.22
40 8.22 7.10 3.56 8.92 7.46 3.64 9.38 7.70 3.70 9.85 8.02 3.75 10.32 8.34 3.80 10.75 8.50 3.80 11.39 8.72 3.80
46 6.51 6.31 3.09 7.07 6.63 3.16 7.44 6.84 3.21 7.80 7.13 3.25 8.17 7.41 3.30 8.51 7.55 3.30 9.03 7.75 3.30
- 9 -
4-1. Cooling capacity 4. Capacity table
DUCT TYPE ARXG24-45KMLA DUCT TYPE ARXG24-45KMLA

4-2. Heating capacity
NOTE: Values mentioned in the table are calculated based on the maximum capacity.
¢Model: ARXG24KMLA
AFR m3/h 1,100
Indoor temperature
°CDB 16 18 20 22 24
Outdoor temperature
°CDB °CWB TC IP TC IP TC IP TC IP TC IP
kW kW kW kW kW
-15 -16 6.37 2.22 6.21 2.26 6.06 2.31 5.91 2.36 5.76 2.40
-10 -11 6.99 2.31 6.82 2.36 6.65 2.40 6.49 2.45 6.32 2.50
-5 -7 7.62 2.39 7.44 2.44 7.26 2.49 7.08 2.54 6.89 2.59
0 -2 8.25 2.47 8.06 2.52 7.86 2.57 7.66 2.62 7.47 2.67
5 3 8.89 2.54 8.67 2.60 8.46 2.65 8.25 2.70 8.04 2.76
7 6 9.56 2.54 9.33 2.60 9.10 2.65 8.87 2.70 8.65 2.76
10 8 9.16 2.41 8.94 2.46 8.72 2.51 8.51 2.56 8.29 2.61
15 10 8.52 2.17 8.31 2.21 8.11 2.26 7.91 2.30 7.70 2.34
20 15 8.00 1.84 7.81 1.88 7.62 1.92 7.43 1.96 7.24 1.99
24 18 8.32 1.82 8.13 1.86 7.93 1.90 7.73 1.94 7.53 1.97
¢Model: ARXG30KMLA
AFR m3/h 2,100
Indoor temperature
°CDB 16 18 20 22 24
Outdoor temperature
°CDB °CWB TC IP TC IP TC IP TC IP TC IP
kW kW kW kW kW
-15 -16 7.10 2.78 7.07 2.78 7.04 2.79 6.86 2.79 6.40 2.80
-10 -11 8.12 3.01 8.09 3.01 8.05 3.01 7.84 3.02 7.33 3.03
-5 -7 9.14 3.23 9.10 3.24 9.07 3.24 8.83 3.24 8.25 3.26
0 -2 9.71 3.42 9.67 3.42 9.63 3.43 9.38 3.43 8.76 3.44
5 3 10.84 3.47 10.80 3.47 10.75 3.48 10.47 3.48 9.78 3.50
7 6 11.30 3.49 11.25 3.50 11.20 3.50 10.91 3.50 10.19 3.52
10 8 11.64 3.49 11.59 3.50 11.54 3.50 11.25 3.50 10.50 3.52
15 10 12.11 3.49 12.06 3.50 12.01 3.50 11.70 3.50 10.93 3.52
20 15 12.90 3.50 12.84 3.50 12.79 3.51 12.46 3.51 11.64 3.53
24 18 13.53 3.51 13.47 3.51 13.41 3.52 13.07 3.52 12.20 3.53
¢Model: ARXG36KMLA
AFR m3/h 2,100
Indoor temperature
°CDB 16 18 20 22 24
Outdoor temperature
°CDB °CWB TC IP TC IP TC IP TC IP TC IP
kW kW kW kW kW
-15 -16 8.05 3.18 8.01 3.18 7.98 3.19 7.77 3.19 7.26 3.20
-10 -11 9.21 3.44 9.17 3.44 9.13 3.44 8.89 3.45 8.31 3.46
-5 -7 10.37 3.69 10.32 3.70 10.28 3.70 10.02 3.71 9.35 3.72
0 -2 11.01 3.74 10.97 3.75 10.92 3.75 10.64 3.75 9.94 3.77
5 3 12.30 3.80 12.24 3.80 12.19 3.81 11.88 3.81 11.09 3.82
7 6 12.81 3.82 12.75 3.83 12.70 3.83 12.37 3.84 11.56 3.85
10 8 13.20 3.82 13.15 3.83 13.09 3.83 12.75 3.84 11.91 3.85
15 10 13.73 3.82 13.68 3.83 13.62 3.83 13.27 3.84 12.39 3.85
20 15 14.63 3.83 14.56 3.84 14.50 3.84 14.13 3.85 13.19 3.86
24 18 15.34 3.84 15.27 3.84 15.21 3.85 14.82 3.85 13.84 3.87
¢Model: ARXG45KMLA
AFR m3/h 2,100
Indoor temperature
°CDB 16 18 20 22 24
Outdoor temperature
°CDB °CWB TC IP TC IP TC IP TC IP TC IP
kW kW kW kW kW
-15 -16 10.89 4.34 10.63 4.36 10.37 4.38 10.13 4.38 9.53 4.38
-10 -11 12.10 4.52 11.81 4.54 11.52 4.57 11.25 4.57 10.58 4.57
-5 -7 13.30 4.71 12.99 4.73 12.67 4.75 12.37 4.75 11.64 4.75
0 -2 14.53 4.89 14.18 4.92 13.83 4.94 13.51 4.94 12.71 4.94
5 3 15.55 4.56 15.18 4.58 14.81 4.61 14.46 4.61 13.60 4.61
7 6 15.96 4.55 15.58 4.58 15.20 4.60 14.85 4.60 13.96 4.60
10 8 16.62 4.54 16.23 4.57 15.83 4.59 15.46 4.59 14.54 4.59
15 10 17.73 4.53 17.30 4.55 16.88 4.57 16.49 4.57 15.51 4.57
20 15 18.83 4.51 18.38 4.53 17.93 4.56 17.51 4.56 16.47 4.56
24 18 19.71 4.50 19.24 4.52 18.77 4.54 18.33 4.54 17.24 4.54
- 10 -
4-2. Heating capacity 4. Capacity table
DUCT TYPE ARXG24-45KMLA DUCT TYPE ARXG24-45KMLA

5. Fan performance
NOTE: Airflow and capacity/outlet temperature curve data are measured based on the same condi-
tions mentioned in "Specifications".
5-1. Fan performance curve
¢Model: ARXG24KMLA (Normal mode)
Static pressure (Pa)
6 11 14 21 25 30 35 40
Fan speed
HIGH
m3/h — — — — — 1,200 1,100 1,000
l/s — — — — — 333 306 278
CFM — — — — — 706 647 589
MED
m3/h — — — 980 915 830 — —
l/s — — — 272 254 231 — —
CFM — — — 577 539 489 — —
LOW
m3/h — — 825 690 — — — —
l/s — — 229 192 — — — —
CFM — — 486 406 — — — —
QUIET
m3/h 630 525 — — — — — —
l/s 175 146 — — — — — —
CFM 371 309 — — — — — —
Air ow (m3/h)
0
40
20
Static pressure (Pa)
500 600 800 900 1,000 1,100 1,300
Q-h Characteristic curve
700
50
30
10
1,200
Hi
Med
Low
Quiet
- 11 -
5-1. Fan performance curve 5. Fan performance
DUCT TYPE ARXG24-45KMLA DUCT TYPE ARXG24-45KMLA

•Cooling
98
102
94
Capacity (%)
Airflow (m3/h)
100
104
96
Capacity
500 600 800 900 1,000 1,100 1,300700 1,200
•Heating
98
102
94
Capacity (%)
Airflow (m3/h)
100
104
96
Capacity
500 600 800 900 1,000 1,100 1,300700 1,200
- 12 -
5-1. Fan performance curve 5. Fan performance
DUCT TYPE ARXG24-45KMLA DUCT TYPE ARXG24-45KMLA

¢Model: ARXG24KMLA (Static pressure mode 1)
Static pressure (Pa)
20 23 30 35 40 47 55 65
Fan speed
HIGH
m3/h — — — — — — 1,200 1,000
l/s — — — — — — 333 278
CFM — — — — — — 706 589
MED
m3/h — — — — 1,000 815 — —
l/s — — — — 278 226 — —
CFM — — — — 589 480 — —
LOW
m3/h — — 830 680 — — — —
l/s — — 231 189 — — — —
CFM — — 489 400 — — — —
QUIET
m3/h 650 540 — — — — — —
l/s 181 150 — — — — — —
CFM 383 318 — — — — — —
Airflow (m3/h)
Static pressure (Pa)
500 600 800 900 1,000 1,100 1,300
Q-h Characteristic curve
700 1,200
Hi
Med
Low
Quiet
10
50
30
60
40
30
70
- 13 -
5-1. Fan performance curve 5. Fan performance
DUCT TYPE ARXG24-45KMLA DUCT TYPE ARXG24-45KMLA

•Cooling
98
102
94
Capacity (%)
Airflow (m3/h)
100
104
96
Capacity
500 600 800 900 1,000 1,100 1,300700 1,200
•Heating
98
102
94
Capacity (%)
Airflow (m3/h)
100
104
96
Capacity
500 600 800 900 1,000 1,100 1,300700 1,200
- 14 -
5-1. Fan performance curve 5. Fan performance
DUCT TYPE ARXG24-45KMLA DUCT TYPE ARXG24-45KMLA
