4.6
Cable Installation
In this section:
4.6.1 Connect Frame Ground Cable
4.6.2 Connect eCPRI Optical Cable
4.6.3 Connect AISG Cables
4.6.4 Connect RF Cables
4.6.5 Connect DC –48 V Power Cable
e following sections describe how to connect all necessary cables to the RU.
Important: Do not use a cable that contains red phosphorus as a ame retardant. is may cause
problems, for example, heat generation and emiing smoke.
Important: Ensure the cable connector gland or clamp is the correct size for the selected cable
diameter to prevent water ingress.
4.6.1
Connect Frame Ground Cable
is procedure describes how to connect a Frame Ground (FG) cable to the RU.
Prerequisites:
■RU mounted and not powered up
■Available AWG ground cable with two hole lug (green or green with yellow stripe, 0.625 mm hole spacing)
■Weatherproong method to prevent moisture intrusion
■13 mm socket
■Philips screwdriver
Danger: Use properly insulated tools and perform all safety
precautions in accordance with local safety practices when working
on or around power terminals, power cables, and power connectors.
Contacting power terminals, uninsulated conductors, cable wiring,
or any connector that could be part of a live electrical circuit can
result in death or serious personal injury.
Danger: Utilisez des outils correctement isolés et appliquez toutes
les précautions de sécurité conformément à la sécurité locale
pratiques lorsque vous travaillez sur ou autour des bornes
d'alimentation, des câbles d'alimentation et des connecteurs
d'alimentation. Contacter bornes d'alimentation, conducteurs non
isolés, câblage de câbles ou tout connecteur pouvant faire partie
d'un un circuit électrique peut entraîner la mort ou des blessures
graves.
Installation
Cable Installation
112
Release 1.0 · Issue 1.1, May 2021 Fujitsu and Fujitsu Customer Use Only

Caution: e outdoor equipment must be properly grounded to
provide protection against lightning strikes, voltage surges and built-
up static charges. In the event of a short circuit, grounding reduces
the risk of electrical shock. For installation in the USA refer to
Articles 810-840 of the National Electrical Code, ANSI/NFPA No. 70,
for information with respect to proper grounding and applicable
lightning protection for telecom equipment and cabling. e
installer must also follow any additional local building and electrical
code regulations.
Aention: L'équipement extérieur doit être correctement mis à la
terre pour assurer une protection contre la foudre, les surtensions et
les charges statiques accumulées. En cas de court-circuit, la mise à
la terre réduit le risque de choc électrique. Pour une installation aux
États-Unis, reportez-vous aux articles 810-840 du National Electrical
Code, ANSI / NFPA No. 70, pour obtenir des informations sur la mise
à la terre appropriée et la protection contre la foudre applicable
pour les équipements de télécommunications et le câblage.
L'installateur doit également suivre toute réglementation locale
supplémentaire du code du bâtiment et de l'électricité.
Step 1
Locate the FG port on the RU.
FNC001652_Rev_01
Figure 28
Frame Ground Port
Step 2
Using a screwdriver or 13 mm socket, remove the screws at the ground point of the RU.
Step 3
Connect the RU end of the ground cable to the RU using M8 bolts.
Step 4
Connect the other end of the FG cable to a building exterior ground location.
Step 5
Apply weatherproong to the FG cable connector per local guidelines to protect from moisture intrusion.
Installation
Cable Installation
113
Release 1.0 · Issue 1.1, May 2021 Fujitsu and Fujitsu Customer Use Only

Note: Fujitsu recommends using industry standard UL approved self-fusing tape, but users may use any UL
approved weatherproong material. Refer to Weatherproong RU Connections for more information about
weatherproong methods.
✓ is task is complete.
4.6.2
Connect eCPRI Optical Cable
is procedure describes how to connect optical cable to the RU.
Prerequisites:
■RU mounted and not powered up
■Available 10G optical cable
■Weatherproong method to prevent moisture intrusion
Danger: Use properly insulated tools and perform all safety
precautions in accordance with local safety practices when working
on or around power terminals, power cables, and power connectors.
Contacting power terminals, uninsulated conductors, cable wiring,
or any connector that could be part of a live electrical circuit can
result in death or serious personal injury.
Danger: Utilisez des outils correctement isolés et appliquez toutes
les précautions de sécurité conformément à la sécurité locale
pratiques lorsque vous travaillez sur ou autour des bornes
d'alimentation, des câbles d'alimentation et des connecteurs
d'alimentation. Contacter bornes d'alimentation, conducteurs non
isolés, câblage de câbles ou tout connecteur pouvant faire partie
d'un un circuit électrique peut entraîner la mort ou des blessures
graves.
Step 1
Remove the protective cover from the eCPRI port.
Note: e optical SFP must be installed in the RU Optical port before the RU is connected to the DU.
Installation
Cable Installation
114
Release 1.0 · Issue 1.1, May 2021 Fujitsu and Fujitsu Customer Use Only

FNC001658_Rev_01
Figure 29
eCPRI Port Location
FNC001634_Rev_01
Figure 30
Remove Protective Cap
Step 2
Install the SFP into the eCPRI port.
Installation
Cable Installation
115
Release 1.0 · Issue 1.1, May 2021 Fujitsu and Fujitsu Customer Use Only

FNC001635_Rev_01
Figure 31
Insert SFP Module
Step 3
Push the SFP into the port until the lever closes fully.
FNC001636_Rev_01
Figure 32
SFP Module Inserted
Step 4
Remove the protective covers from both mating connectors.
Installation
Cable Installation
116
Release 1.0 · Issue 1.1, May 2021 Fujitsu and Fujitsu Customer Use Only

FNC001642_Rev_01
Figure 33
Remove Protective Cover
Step 5
Remove the ber caps from the optical cables.
FNC001643_Rev_01
Figure 34
Remove Cap from Optical Cable
Step 6
Pull back on the ber enclosure until the cylindrical cable container is completely visible.
Step 7
Clean the optical ber connections.
Installation
Cable Installation
117
Release 1.0 · Issue 1.1, May 2021 Fujitsu and Fujitsu Customer Use Only

Note: For more information about cleaning optical connectors, refer to LC End Surface Cleaning and End Surface
Cleaning In LC.
Step 8
Insert the optical cables into the SFP that is pre-positioned in the connector of the RU.
FNC001640_Rev_01
Figure 35
Insert Optical Fiber
Step 9
Ensure the locking latches of the LC ber connectors are snapped into position.
Step 10
Align the connector key on connector to the connector on the RU and insert the connector.
Installation
Cable Installation
118
Release 1.0 · Issue 1.1, May 2021 Fujitsu and Fujitsu Customer Use Only

FNC001645_Rev_01
Figure 36
Align Connector
Step 11
Insert the cable and turn the enclosure sub-assembly clockwise until it clicks into place.
FNC001638_Rev_01
Figure 37
Insert Connector
Installation
Cable Installation
119
Release 1.0 · Issue 1.1, May 2021 Fujitsu and Fujitsu Customer Use Only

FNC001641_Rev_01
Figure 38
Secure Enclosure
Step 12
Mate the two protective covers together to keep the covers intact and clean.
Step 13
Apply weatherproong to the SFP cable connector per local guidelines to protect from moisture intrusion.
Note: Fujitsu recommends using industry standard UL approved self-fusing tape, but users may use any UL
approved weatherproong material. Refer to Weatherproong RU Connections for more information about
weatherproong methods.
Continue with the next task.
4.6.3
Connect AISG Cables
is procedure describes how to connect AISG cables to the RU.
Prerequisites:
■RU mounted and not powered up
■Available AISG cables
■Weatherproong method to prevent moisture intrusion
Step 1
Remove the protective cover from the RET port.
Installation
Cable Installation
120
Release 1.0 · Issue 1.1, May 2021 Fujitsu and Fujitsu Customer Use Only

FNC001719_Rev_01
Figure 39
RET Port Location
Step 2
Install the AISG cable to the RET port on the boom of the RU.
Step 3
Route the cable to the respective port on the antenna.
Step 4
Connect the AISG cable to the RET port on the antenna and tighten until rm.
Step 5
Tighten the outer connector shell to secure the cable. Repeat for the antenna end of the cable.
Step 6
Apply weatherproong to the AISG cable connector per local guidelines to prevent moisture intrusion.
Note: Fujitsu recommends using industry standard UL approved self-fusing tape, but users may use any UL
approved weatherproong material. Refer to Weatherproong RU Connections for more information about
weatherproong methods.
Continue with the next task.
4.6.4
Connect RF Cables
is procedure describes how to connect RF cables to the RU.
Installation
Cable Installation
121
Release 1.0 · Issue 1.1, May 2021 Fujitsu and Fujitsu Customer Use Only

Prerequisites:
■RU mounted and not powered up
■RF Cables
■Weatherproong method to prevent moisture intrusion
Warning: Avoid excessive power input to prevent RU damage. e
maximum absolute input level of the Rx port is +3.5 dBm (5 minute
max) based on 3GPP in-band blocking specications.
Avertissement: Évitez une alimentation électrique excessive pour
éviter d'endommager RU. Le niveau d'entrée absolu maximal du
port Rx est de +3,5 dBm (5 minutes maximum) sur la base des
spécications de blocage dans la bande 3GPP.
Step 1
Remove the protective covers from the RF ports on the boom of the RU.
FNC001720_Rev_01
Figure 40
RF Port Locations
Step 2
If necessary, insert two weatherproong sleeves onto each cable.
Step 3
Connect each RF cable to its corresponding port on the RU.
Step 4
Secure the RF cables along their route.
Installation
Cable Installation
122
Release 1.0 · Issue 1.1, May 2021 Fujitsu and Fujitsu Customer Use Only

Step 5
Torque each connection to 5 N/m.
Step 6
Apply weatherproong to the RF cable connectors per local guidelines to protect from moisture intrusion.
Note: Fujitsu recommends using industry standard UL approved self-fusing tape, but users may use any UL
approved weatherproong material. Refer to Weatherproong RU Connections for more information about
weatherproong methods.
Continue with the next task.
4.6.5
Connect DC –48 V Power Cable
is procedure describes how to connect DC –48 V power cable.
Prerequisites:
■Torx driver
■RU mounted and not powered up
■Available –48V power cable
Important: If the power cable connector on the RU is connected in reverse, the RU does not start and
is not damaged because of the anti-reverse circuit.
Step 1
Remove the dust cover from the DC –48V port on the boom of the RU.
Installation
Cable Installation
123
Release 1.0 · Issue 1.1, May 2021 Fujitsu and Fujitsu Customer Use Only

FNC001655_Rev_01
Figure 41
Remove Dust Cover
Step 2
Align the key in the plug with the inner and outer connector grooves.
FNC001654_Rev_01
Figure 42
Align Key Plug with Port
Installation
Cable Installation
124
Release 1.0 · Issue 1.1, May 2021 Fujitsu and Fujitsu Customer Use Only

Step 3
Insert the connector into the port.
Note: e RU has reverse-polarity protection in case the DC power leads are connected incorrectly.
Step 4
Turn the locking ring clockwise until tightened.
FNC001656_Rev_01
Figure 43
Tighten Power Cable
✓ is task is complete.
Installation
Cable Installation
125
Release 1.0 · Issue 1.1, May 2021 Fujitsu and Fujitsu Customer Use Only

5
Power Up
In this chapter:
5.1 Check Connections and DC Power Polarity
5.2 Apply Power to RU
5.3 Check LED Status
5.4 LED Display
5.5 Verify Alarm Status
5.6 RU Conrmation
Prior to powering up the RU, the following criteria must be completed:
■Circuit breaker is o prior to connecting the RU
■All cables at RU connected and terminated
■Optical SFP installed
■Antenna connection is complete
■Weatherproong applied to all cable connectors
Warning: Avoid excessive power input to prevent RU damage. e
maximum absolute input level of the Rx port is +3.5 dBm (5 minute
max) based on 3GPP in-band blocking specications.
Avertissement: Évitez une alimentation électrique excessive pour
éviter d'endommager RU. Le niveau d'entrée absolu maximal du
port Rx est de +3,5 dBm (5 minutes maximum) sur la base des
spécications de blocage dans la bande 3GPP.
Important: e RU does not have a power switch. DC power on/o is controlled by the circuit breaker
of the DC power source. e circuit breaker must be set to o before applying power to the RU.
Note: e RU requires less than one minute to fully power up.
Powering up an RU has the following environmental requirements:
■Keep the temperature and humidity within the specied conditions.
■Do not place around objects that obstruct the ow of air.
Power Up
126
Release 1.0 · Issue 1.1, May 2021 Fujitsu and Fujitsu Customer Use Only

■Do not input optical signals higher than the maximum light level as this may damage the optical receiver.
■Do not submerge or bury in snow.
Power Up
127
Release 1.0 · Issue 1.1, May 2021 Fujitsu and Fujitsu Customer Use Only

5.1
Check Connections and DC Power Polarity
is procedure describes how to perform checks before turning on the power.
Step 1
Verify that all necessary cables are connected to the RU.
Step 2
Check the polarity of Pin A on the DC power supply, which should read –48 V.
Note: e RU does not have a power switch. DC power is controlled by a circuit breaker at the DC power source.
Do not turn on the circuit breaker until it's time to power up the RU.
Note: It takes less than one minute for the RU to fully power up.
Step 3
Verify weatherproong is applied to each cable connector according to local guidelines.
Note: Fujitsu recommends using industry standard UL approved self-fusing tape, but users may use any UL
approved weatherproong material. Refer to Weatherproong RU Connections for more information about
weatherproong methods.
Continue with the next task.
Power Up
Check Connections and DC Power Polarity
128
Release 1.0 · Issue 1.1, May 2021 Fujitsu and Fujitsu Customer Use Only

5.2
Apply Power to RU
is procedure describes how to apply power to the RU.
Step 1
Set the circuit breaker to ON at the DC power supply.
Note: Reset starts when RU detects power on.
Step 2
Wait approximately one minute for the RU to fully power up.
Continue with the next task.
Power Up
Apply Power to RU
129
Release 1.0 · Issue 1.1, May 2021 Fujitsu and Fujitsu Customer Use Only

5.3
Check LED Status
is procedure describes how to check the LED status aer powering up the RU.
Step 1
Using a Torx screw driver, remove the maintenance window cover to check the LED color, which should be
blinking green.
Note: Refer to RU LED Status table in LED Display section for LED indicator information.
Caution: If the power to the RU is turned o, a minimum 10-second
wait is required before it is turned back on to allow the RU to
initialize.
Aention: Si l'alimentation du RU est coupée, une aente minimale
de 10 secondes est nécessaire avant de la mere sous tension. de
nouveau pour permere à l'EUR de s'initialiser.
Note: If the fault LED is on, check the connections at the RU and power source and optical connection sources to
resolve the issue.
Note: If the LED is not blinking green aer reset, then RU status is not in a normal state.
Step 2
Close the maintenance window cover.
Continue with the next task.
Power Up
Check LED Status
130
Release 1.0 · Issue 1.1, May 2021 Fujitsu and Fujitsu Customer Use Only

5.4
LED Display
e status of the RU LEDs, as shown in the following gure, should be checked when the RU is powered up.
LED:
Fault LED
eCPRI Interface LED
Operational LED
FNC001607_Rev_01
Figure 44
RU LED Locations
e following table shows the status of the LEDs.
Table 37
RU LED Status
RU Status
LED
Operation Fault Fronthaul
Operational Green blinking Red o n/a
Transmit ON Green on Red o n/a
Blocking Green blinking Red blinking n/a
Major Alarm Green o Red blinking n/a
Minor Alarm Green blinking or Green on Red blinking n/a
Power Up
LED Display
131
Release 1.0 · Issue 1.1, May 2021 Fujitsu and Fujitsu Customer Use Only
