AMILO Pi 1505
Perform at your Peak
Pages 3
The AMILO Pi 1505 is a truly mobile notebook that allows you feel at home wherever you are. This independence is
guaranteed by Intel’s Centrino® Mobile Technology which is optimised for low power consumption, enabling an
extended battery life.
With its elegant and slim design, a large 15.4-inch wide CrystalView display and integrated Wireless LAN, the AMILO Pi
1505 offers the perfect balance between mobility and performance. An S-Video out port, IEEE 1394, SPDIF and USB 2.0
interfaces are built-in as standard to connect to all your digital peripherals and multimedia devices.
Features
Intel® Centrino® Technology with
Intel® Core™ Duo processor up to T2300 or
Intel® Core™ 2 Duo processor up to T7200 or
Intel® Core™ Solo processor up to T1350
Unique 15.4” TFT LCD WXGA display
- CrystalView
- High brightness
- Resolution: 1280 x 800
4-in-1 card reader supports SD/MS/MMC/MSPRO
multimedia storage cards.
Connect your notebook to external peripherals, storage
devices or video equipment through the various
USB 2.0, SPDIF, IEEE 1394 (Firewire), CRT ports and
S-video out
Included WLAN 802.11b/g
PCI graphic card
Intel® Graphic Media Accelerator 950
Built-in DVD Dual Double Layer (8.5GB)
for maximum user comfort
Up to 2GB RAM with two DDR2 SO-DIMM 1GB
modules (533/667MHz)
Silent Mode functionality
Windows Vista™
and Application Software

Data Sheet Issue: January 2007 AMILO Pi 1505 Page 2 / 3
Operating system
Windows Vista™ Home Premium
Fujitsu Siemens Computers recommends
Windows Vista™ Home Premium
Optional application Software
Microsoft®Works
Vista DVD Playback Pack
Nero 7 Essential
Adobe Reader
Norton Internet Security Suite
Country specific Internet Service Providers
Manual (on DUDVD), Safety Guide and Warranty Guide
Drivers and Utility
Drivers and Utility DVD included.
Updates downloadable at
http://www.fujitsu-siemens.com
System, processors, architecture
Chipset: Intel 945GM
CPU: Intel® Core™ Duo processor
T2050 (1,6GHz, 533 MHz, 2MB L2 cache)
T2250 (1.73GHz, 533MHz, 2MB L2 cache)
T2300E (1.66GHz, 667 MHz, 2MB L2 cache)
Intel® Core™ 2 Duo processor
T5500 (1.66GHz, 667 MHz, 2MB L2 cache)
T5600 (1.83GHz, 667 MHz, 2MB L2 cache)
T7200 (2.0GHz, 667 MHz, 4MB L2 cache)
Intel® Core™ Solo processor
T1350 (1.8GHz, 533 MHz, 2MB L2 cache)
Memory
2 SO-DIMM memory slots (no memory on board)
Up to 2048MB DDR2 RAM
256/ 512/ 1024MB memory modules 533/667MHz
Storage devices/drives
SATA HDD
80, 120, 160 or 200GB SATA hard disk
ODD:
8x Multi-format DVD Burner DL (Double Layer)
Read speed: CD-ROM 24x, DVD-ROM 8x
Write speed: CD-R 24x, CD-RW 20x, DVD+R6x,
DVD-R 6x, DVD+RW 4x, DVD-RW 4x,
DVD+R DL (Double Layer 8.5GB) 2,4x
Display
15.4” TFT WXGA, CrystalView
Brightness (typ.) 180cd/m
Contrast (typ.) 300:1
ISO 13406-2 class II
ACPI functions
S1 standby (LCD off)
S3 save to RAM
S4 save to disk
S5 complete off
Silent Mode
Graphics:
Intel® Graphic Media Accelerator 950 PCI Express graphic
with up to 128MB shared VGA memory
2
and Direct X9 support
I/O Interfaces
1x IEEE1394, 3x USB 2.0 ports,
1x S-Video, 1x CRT
1x modem, 1x LAN, 1x WLAN
1x ExpressCard slot (34/54mm)
1x line in / microphone in
1x headphone out combined with 1x SPDIF
1x power supply
4-in-1 card reader SD/MS/MMC/MSPRO
Communications
Built-in 56K, V.92 fax modem
10/100Mbps LAN
Intel® PRO/Wireless 3945ABG integrated Wireless LAN
(WLAN) solution for IEEE 802.11 a/b/g:
- speeds up to 54Mbps
- industry standard Wireless LAN security support
- wide range for in-house use
For use in AT, BE, CZ, CY, DK, EE, FI, FR, DE, EL, HU,
IE, IT, LV, LT, LU, MT, NL, PL, PT, SK, SI, ES, SE, UK, IS,
NO, CH, LI

Data Sheet Issue: January 2007 AMILO Pi 1505 Page 3 / 3
Audio
7.1 SPDIF, 2 built-in speakers, microphone in combined
with stereo line in, headphone combined with SPDIF
support
Launch Keys
2 Launch Keys located on top of the keyboard enabling the
user to launch the following applications:
- Internet browser
- Silent mode (reduce noise level / fan speed, by reducing
the CPU & VGA performance) (Office applications,
Internet and DVD playback are not affected)
Hot Keys
The following hotkeys or key combinations are available:
Fn-F1 Suspend
Fn-F3 Mute
Fn-F4 Display toggle, switches display output between
display screen and external monitor or to dual
view
Fn-F5 Volume up
Fn-F6 Volume down
Fn-F7 Increase display brightness
Fn-F8 Decrease display brightness
Pointing device & control buttons
Touchpad with a left and right mouse button
Power button / lid switch
Status indicators
The notebook has 7 status icons:
Caps lock, Num lock, Media activity (ODD/HDD), power
status, silent mode, battery status, WLAN on/off
Security
User and supervisor password
Kensington Lock support
Power system
Li-Ion battery, 4 cell, 14.4V / 2000mAh
Approximately 2:50 hrs battery runtime, depending on
usage
1
Dynamic charge supported, ACPI 2.0 supported
External universal AC adapter: 110 – 240 V AC, 50 - 60Hz,
output: 65 W with 20V DC, 6A
Dimensions and weight
358mm (W) x 255mm (D) x ~28mm (front) /~ 36mm (back)
2.8 kg
3
Operating conditions
Operational: 5°C to 35°C (ambient temperature)
10% to 90% relative humidity, non-condensing
Accessories (optional)
Car adapter (S26391-F2613-L600)
AC Adapter 65W
Warranty
Country specific terms
All rights, including rights created by patent grant or registration of a utility model or design as well
as rights of technical modifications are reserved. Delivery subject to availability. Designations may
be trademarks, the use of which by third parties for their own purposes may violate the rights of the
trademark owners.
Copyright Fujitsu Siemens Computers, 01/2007
Published by
Fujitsu Siemens Computers
http://www.fujitsu-siemens.com/
Company stamp
1) Battery life may vary depending on product model, configuration, applications, power management settings and features utilized.
Recharge time varies depending on usage.
2) The total of local and shared system memory used by the GPU.
3) Weight may vary depending on actual configuration.
