Technical Procedure
LifeBook E8310
Wireless Card Replacement
ESD Precautions are required when working on this LifeBook computer.
Make sure the LifeBook is turned off before beginning this procedure.
1. Turn the LifeBook over. Release and
remove the battery.
2. Remove 3 screws from inside the Battery
Bay. Remove one screw from the rear of
the Lower Cover.
3. Turn the LifeBook up and use a plastic pry
tool to release the Hinge Cover tabs on
both sides.
4. Open the LifeBook. Use a plastic pry tool
to remove the Hinge Cover.

5. Disconnect the Keyboard Cable from the
System Board.
6. Slide the Keyboard forward and tilt it up.
Disconnect the Touch Stick cable from the
System Board. Remove the Keyboard.
7. Remove 7 screws from the Keyboard Plate.
Disconnect the Speaker Cable from the
System Board. Remove the Keyboard
Plate.
8. Disconnect both Wireless Antenna Cables
from the Wireless Card.
9. Remove 2 screws from the Wireless Card.
Remove the Wireless Card.
10. Begin Assembly Procedure

11. Secure the Wireless Card with 2 screws. 12. Connect the Black Wireless Antenna
Cable to the Auxiliary connector on the
Wireless Card, and the Gray Wireless
Antenna Cable to the Main connector.
13. Secure the Keyboard Plate with 7 screws.
Connect the Speaker Cable to the System
Board.
14. Connect the Touch Stick cable to the
System Board.
15. Connect the Keyboard Cable to the
System Board.
16. Replace the Hinge Cover.

17. Make sure that the Hinge Cover tabs are
secure on both sides.
18. Insert 3 screws into the Battery Bay.
Insert one screw into the Lower
Cover.Insert 3 screws into the Battery Bay.
Insert one screw into the Lower Cover.
19. Replace the battery and lock it into place.
