Fujitsu Lifebook NH570 Manual

1
Fujitsu LifeBook
N Series
BIOS Guide
LifeBook N Series Models:
NH570
Document Date: 02/01/2010
Document Part Number: FPC58-2649-01
FUJITSU AMERICA, INC.

2
LifeBook N Series BIOS
N Series BIOS
BIOS SETUP UTILITY
The BIOS Setup Utility is a program that sets up the
operating environment for your notebook. Your BIOS
is set at the factory for normal operating conditions,
therefore there is no need to set or change the BIOS
environment to operate your notebook.
The BIOS Setup Utility configures:
■Device control feature parameters, such as changing
I/O addresses and boot devices.
■System Data Security parameters, such as passwords.
Entering the BIOS Setup Utility
There are three ways to enter the BIOS Setup Utility: The
SecureCore Menu, the [F2] key, or the Boot Menu.
Entering BIOS Setup using the SecureCore Menu
When the Fujitsu logo appears on the screen. press the
[Enter] key or click on the left mouse or touchpad
button; the SecureCore Menu will appear.
The SecureCore Menu provides shortcuts to the
following menus and information screens:
■BIOS Setup
■Diagnostic Screen
■Boot Menu
■Recovery and Utility
■Diagnostic program
■Patent Information
■System Information
■Continue Booting
Click on BIOS Setup to enter the utility.
Entering BIOS Setup using [F2] key
To enter the BIOS Setup Utility using the [F2] key:
1. Turn on or restart your notebook.
2. Press [F2] once the Fujitsu logo appears on the
screen. This will open the main menu of the BIOS
Setup Utility with the current settings displayed.
Entering BIOS Setup using Boot Menu
To enter the BIOS Setup Utility using the Boot Menu:
1. Turn on or restart your notebook.
2. Press [F12] once the Fujitsu logo appears on the
screen. This will open the Boot Menu.
3. Select <Enter BIOS Setup> and click [Enter].
Navigating Through The Setup Utility
The BIOS setup utility consists of six menus: Main,
Advanced, Security, Boot, Info, and Exit. This document
explains each menu in turn, including all submenus and
setup items.
The following procedures allow you to navigate the
setup utility menus:
1. To select a menu, use the cursor keys:
2. To select a field within a menu or a submenu, use the
cursor keys:
3. To select the different values for each field, press the
[Spacebar] or [+] to change to the next higher
selection and [F5] or [-] to go to the next lower
selection.
4. To activate a submenu press the [Enter] key.
5. To return to a menu from a submenu, press the
[Esc] key.
6. To go to the Exit menu from any other menu, press
the [Esc] key.
7. Pressing the [F9] key resets all items in the BIOS to
the default values.
8. Pressing the [F10] key saves the current configura-
tion and exits the BIOS Setup Utility. You will be
asked to verify this selection before it is executed.
9. Pressing the [F1] key gives you a general help screen.
■Selecting a field causes a help message
about that field to be displayed on the
right-hand side of the screen.
■Pressing the Enter key with the highlight
on a selection that is not a submenu or
auto selection will cause a list of all
options for that item to be displayed.
Pressing the Enter key again will select
the highlighted choice.
[ ], [ ].
[ ], [ ].

3
Entering the Setup Utility After a Configuration
Change or System Failure
If there has been a change in the system configuration
that does not agree with the parameter settings stored in
BIOS memory, or there is a failure in the system, the
system beeps and/or displays an error message after the
Power On Self Test (POST). If the failure is not too
severe, it will give you the opportunity to modify the
settings of the setup utility, as described in the following
steps:
1. When you turn on or restart the computer there is a
beep and/or the following message appears on the
screen:
Error message - please run SETUP
program Press <F1> key to continue,
<F2> to run SETUP
2. If an error message is displayed on the screen, and
you want to continue with the boot process and start
the operating system anyway, press the [F1] key.
3. If an error message is displayed on the screen, and
you want to enter the setup utility, press the [F2] key.
4. When the setup utility starts with a fault present, the
system displays the following message:
Warning!
Error message
[Continue]
5. Press any key to enter the setup utility. The system
will then display the Main Menu with current
parameters values.
■If your notebook emits a series of beeps
that sounds like a code and the display is
blank, refer to the Troubleshooting sec-
tion of your system Use’s Guide. The
Troubleshooting Section includes a list of
error messages and their meanings.
■If your data security settings require it,
you may be asked for a password before
the operating system will be opened.
Setup Utility

4
LifeBook N Series BIOS
INFO MENU - DISPLAYS BASIC SYSTEM INFORMATION
The Info Menu is a display-only screen that provides the
configuration information for your notebook.
The following table shows the names of the menu fields
for the Info menu and the information displayed in
those fields. These fields are for information purposes
only, and cannot be modified by the user.
Figure 1. Info Menu
The information, including CPU type,
speed, and total memory displayed on this
screen varies according to the unit you
purchased.
Table 1: Fields, Options and Defaults for the Info Menu
Menu Field Default Menu Field Default
Note that all of the fields on this screen are display only and are for reference.
Note that some the information listed will be different for your system, depending upon the system configuration.
Product Name: LifeBook NH570 Memory Slot 1: 2048 MB DDR3 SDRAM
Serial Number: Not Defined Memory Slot 2: 2048 MB DDR3 SDRAM
BIOS Version: 1.XX (XX/XX/2007) Onboard MAC Address: XX-XX-XX-XX-XX-XX
Processor Type: Intel(R) Core(TM) i5 CPU M 430 @ 2.27GHz UUID: XXXXXXXX-XXXX-XXXX-
XXXX-XXXXXXXXXXXX
Total Memory: 4096 MB
Phoenix SecureCore(tm) Setup Utility
F1 Help
ESC Exit
Select Item
Select Menu
-/Space Change Values
Enter Select Sub-Menu
F9 Setup Defaults
F10 Save and Exit
Info System Advanced Security Boot Exit
Product Name: NH570
Serial Number: XXXXXX
BIOS Version: 1.0X (XX/XX/2010)
Processor Type: Intel(R) Core(TM) i5 CPU M 430 @ 2.27GHz
Total Memory: 4096 MB
Memory Slot 1: 2048 MB DDR3 SDRAM
Memory Slot 2: 2048 MB DDR3 SDRAM
Onboard MAC Address: 00-XX-XX-XX-XX-XX
UUID: XXXXXXXX-XXXX-XXXX-XXXX-XXXXXXXXXXXX
▲

5
SYSTEM MENU – SETTING STANDARD SYSTEM PARAMETERS
The System Menu allows you to set or view the current
system parameters. (See Navigating Through The Setup
Utility on page 2 for more information.)
The following tables show the names of the menu fields
for the System menu and its submenus, all of the options
for each field, the default settings and a description of
the field’s function and any special information needed
to help understand the field’s use.
Figure 2. System Menu
System Time and System Date can also be
set from your operating system without
using the setup utility. Use the Date and
Time icon on your Windows Control panel
or type time or date from the command
prompt.
Table 2: Fields, Options and Defaults for the System Menu
Note that the parameters listed in the following table may vary depending upon your system’s configuration.
Menu Field Options Default Description
System Time: –— –— Sets and displays the current time. Time is in a 24 hour format
of hours:minutes:seconds with 2 digits for each. (HH:MM:SS).
Example: 16:45:57. You may change each segment of the time
separately. Move between the segments with the [Tab] key and/or
[Shift] + [Tab] keys.
System Date: –— –— Sets and displays the current date. Date is in a month/day/year
numeric format with 2 digits each for month and day and 4 digits for
year. (MM/DD/YYYY) for example: 03/20/2007. You may
change each segment of the date separately. Move between the
segments with the [Tab] key and/or [Shift] + [Tab] keys.
Phoenix SecureCore(tm) Setup Utility
F1 Help
ESC Exit
Select Item
Select Menu
-/Space Change Values
Enter Select Sub-Menu
F9 Setup Defaults
F10 Save and Exit
▲
Info System Advanced Security Boot Exit
Item Specific Help
Adjust calendar clock.
<Tab>, <Shift-Tab>, or
<Enter> selects field.
▲
System Time: [14:57:01]
System Date: [10/17/2008]
Drive0 [WDC WD3200BEVS-16VAT0]
Drive1 [TSSTcorp CDDVDW TS-L633B]
Drive4 [None]
Drive5 [None]
Language: [English (US)]
▲
▲▲
System Menu

6
LifeBook N Series BIOS
Drive0 Selects the Drive0
Serial ATA drive
submenu
The product
number of the hard
drive.
Display the type of device on this ATA/IDE interface. Pressing the
Enter key selects the Serial ATA Drive0 submenu allowing additional
device configuration options for this interface.
Drive1: Selects the Drive1
Serial ATA drive
submenu
The product
number of the
optical drive.
Display the type of device on this ATA/IDE interface, if there is one.
Pressing the Enter key selects the Serial ATA Drive1 submenu allow-
ing additional device configuration options for this interface.
Drive4 Selects the Drive4
e-ATA drive sub-
menu
The product
number of the e-
SATA drive.
Display the type of device on this e-SATA interface. Pressing the
Enter key selects the e-SATA Drive4 submenu allowing additional
device configuration options for this interface.
Drive5: Selects the Drive5
2nd hard disk drive
submenu
The product
number of the
2nd hard disk drive.
Display the type of device on this interface, if there is one. Pressing
the Enter key selects the Drive5 submenu allowing additional device
configuration options for this interface.
Language: ■English (US)
■Japanese (JP)
[English (US)] The default setting differs between the US and the Japanese model.
Selects the display language for the BIOS.
Table 2: Fields, Options and Defaults for the System Menu
Note that the parameters listed in the following table may vary depending upon your system’s configuration.
Menu Field Options Default Description

7
Drive0 Submenu of the System Menu
The Drive0 submenu identifies what ATA devices are installed.
Figure 3. Drive0 Master Submenu
Table 3: Fields, Options and Defaults for the Drive0 Submenu of the System Menu
Menu Field Options Default Description
Drive0: ■Disabled
■Enabled
[Enabled] Enables and disables Drive0.
Type: --- --- The type of drive represented by Drive0.
Model: --- --- The model of the Drive0 drive.
Capacity: --- --- The maximum capacity of your hard disk
F1 Help
ESC Exit
Select Item
Select Menu
-/Space
Enter
F9 Setup Defaults
F10 Save and Exit
Change Values
Select Sub-Menu
Item Specific Help
[Disabled]
The drive is disabled.
[Enabled]
The drive is enabled.
Drive0 [WDC WD3200BEVS-16VAT0]
Drive0: [Enabled]]
Type: Hard Disk
Model: WDC WD3200BEVS-16VAT0
Capacity: 320GB
(320,072,933,376 Bytes)
▲
Phoenix SecureCore(tm) Setup Utility
Info System Advanced Security Boot Exit
System Menu

8
LifeBook N Series BIOS
Drive1 Submenu of the System Menu
The Drive1 submenu allows you to configure secondary ATA devices.
Figure 4. Drive1 Submenu
Exiting from System Menu
When you have finished setting the parameters on this menu, you can either exit from the setup utility, or move to
another menu. If you wish to exit from the setup utility, press the [Esc] key or use the cursor keys to go to the Exit
menu. If you wish to move to another menu, use the cursor keys.
Table 4: Fields, Options and Defaults for the Drive1 Submenu of the System Menu
Menu Field Options Default Description
Drive1: ■Disabled
■Enabled
[Enabled] Enables and disables Drive1.
Type: --- --- The type of drive represented by Drive1.
Model: --- --- The model of the Drive1 drive.
F1 Help
ESC Exit
Select Item
Select Menu
-/Space
Enter
F9 Setup Defaults
F10 Save and Exit
Change Values
Select Sub-Menu
Item Specific Help
[Disabled]
The drive is disabled.
[Enabled]
The drive is enabled.
Drive1 [TSSTcorp CDCVDW TS-L633B]
Drive1: [Enabled]]
Type: CD/DVD
Model: TSSTcorp CDCVDW TS-L633B
▲
Phoenix SecureCore(tm) Setup Utility
Info System Advanced Security Boot Exit

9
Drive4 Submenu of the System Menu
The Drive4 submenu identifies what ATA devices are installed.
Figure 5. Drive4 Master Submenu
Table 5: Fields, Options and Defaults for the Drive4 Submenu of the System Menu
Menu Field Options Default Description
Drive4: ■Disabled
■Enabled
[Enabled] Enables and disables Drive4.
Type: --- --- The type of drive represented by Drive4.
Model: --- --- The model of the Drive4 drive. (This field is only present when the device is
present).
Capacity: --- --- The maximum capacity of your hard disk. (This field is only present when
the device is present).
Phoenix TrustedCore(tm) Setup Utility
F1 Help
ESC Exit
Select Item
Select Menu
-/Space
Enter
F9 Setup Defaults
F10 Save and Exit
Change Values
Select Sub-Menu
Item Specific Help
[Disabled]
The drive is disabled.
[Enabled]
The drive is enabled.
Drive4 [None]
Drive4: [Enabled]
Type: None
▲
Info System Advanced Security Boot Exit
System Menu

10
LifeBook N Series BIOS
Drive5 Submenu of the System Menu
The Drive5 submenu identifies what ATA devices are installed.
Figure 6. Drive5 Master Submenu
Table 6: Fields, Options and Defaults for the Drive5 Submenu of the System Menu
Menu Field Options Default Description
Drive5: ■Disabled
■Enabled
[Enabled] Enables and disables Drive5.
Type: --- --- The type of drive represented by Drive5.
Model: --- --- The model of the Drive5 drive. (This field is only present when the device is
present).
Capacity: --- --- The maximum capacity of your hard disk. (This field is only present when
the device is present).
Phoenix TrustedCore(tm) Setup Utility
F1 Help
ESC Exit
Select Item
Select Menu
-/Space
Enter
F9 Setup Defaults
F10 Save and Exit
Change Values
Select Sub-Menu
Item Specific Help
[Disabled]
The drive is disabled.
[Enabled]
The drive is enabled.
Drive5 [None]
Drive5: [Enabled]
Type: None
▲
Info System Advanced Security Boot Exit

11
ADVANCED MENU – SETTING DEVICE FEATURE CONTROLS
The Advanced Menu allows you to:
■Turn the Numlock on and off.
■Select between the display panel and an external
display.
■Enable or disable compensation for your display.
■Enable or disable the SATA, Bluetooth, LAN, and
Wireless LAN controllers.
■Configure CPU and USB features in your system.
(See Navigating Through The Setup Utility on page 2 for
more information.)
The following tables show the names of the menu fields
for the Advanced Menu and its submenus, all of the
options for each field, the default settings and a descrip-
tion of the field’s function and any special information
needed to help understand the field’s use.
Figure 7. Advanced Menu
Table 7: Fields, Options and Defaults for the Advanced Menu
Menu Field Description
Keyboard/Mouse Features When selected, opens the Keyboard/Mouse Features submenu, which allows setting external and
internal keyboard and mouse parameters.
Video Features When selected, opens the Video Features submenu, which allows setting of the display parameters,
including routing of video signals to different displays.
Internal Device Configurations When selected, opens the Internal Device Configuration submenu, which allows enabling or
disabling the ATA, IDE, Bluetooth, Modem, LAN, and WLAN Controllers.
CPU Features When selected, opens the CPU Features submenu to allow you to change the CPU speed for battery
life optimization.
F1 Help
ESC Exit
Select Item
Select Menu
-/Space
Enter
F9 Setup Defaults
F10 Save and Exit
Change Values
Select Sub-Menu
▲
Item Specific Help
▲ ▲ ▲ ▲ ▲
Keyboard/Mouse Features
Video Features
Internal Device Configurations
CPU Features
USB Features
Miscellaneous Configurations
Event Logging
Configures serial ports
and parallel ports.
▲ ▲
Info System Advanced Security Boot Exit
Phoenix SecureCore(tm) Setup Utility
Advanced Menu

12
LifeBook N Series BIOS
USB Features When selected, opens the USB Features submenu to allow you to enable or disable legacy USB
devices and SCSI SubClass support.
Miscellaneous Configurations When selected, opens the Miscellaneous Configurations submenu to allow you to enable or disable
the power button, Wake Up On LAN, and control volume settings.
Event Logging When selected, opens the event logging submenu.
Table 7: Fields, Options and Defaults for the Advanced Menu
Menu Field Description

13
Keyboard/Mouse Features Submenu of the Advanced Menu
The Keyboard/Mouse Features submenu is for setting the Numlock feature on or off.
Figure 8. Keyboard/Mouse Features Submenu
Table 8: Fields, Options and Defaults for the Keyboard/Mouse Submenu of the Advanced Menu
Menu Field Options Default Description
Numlock: ■On
■Off
[Off] Sets the NumLock function state on or off when the computer com-
pletes booting.
Windows preserves Numlock state when the user logs off.
F1 Help
ESC Exit
Select Item
Select Menu
-/Space
Enter
F9 Setup Defaults
F10 Save and Exit
Change Values
Select Sub-Menu
▲
Item Specific Help
[On] or [Off]
Numlock is On or Off.
* Windows XP or later
OS preserves Numlock
state when the user
logs off.
Keyboard/Mouse Features
Numlock: [Off]
Phoenix SecureCore(tm) Setup Utility
Info System Advanced Security Boot Exit
Advanced Menu

14
LifeBook N Series BIOS
Video Features Submenu of the Advanced Menu
The Video Features submenu is for setting the display parameters.
Figure 9. Video Features Submenu
Table 9: Fields, Options and Defaults for the Video Features Submenu of the Advanced Menu
Menu Field Options Default Description
Display: ■Internal Flat Panel
■External (Analog)
■Auto
[Auto] Selects where the video signal will be routed. Note that this setting is
overridden after Windows starts up.
F1 Help
ESC Exit
Select Item
Select Menu
-/Space
Enter
F9 Setup Defaults
F10 Save and Exit
Change Values
Select Sub-Menu
▲
Item Specific Help
Select display terminal.
* This setting is not
effective after
operating system
starts up.
Video Features
Display: [Auto]
Phoenix SecureCore(tm) Setup Utility
Info System Advanced Security Boot Exit

15
Internal Device Configurations Submenu of the Advanced Menu
The Internal Device Configuration submenu allows the user to enable or disable Serial ATA, Bluetooth, LAN, and
WLAN Controllers.
Figure 10. Internal Device Configuration Submenu
Table 10: Fields, Options and Defaults for the Internal Device Configuration Submenu of the Advanced
Menu
Menu Field Options Default Description
Serial ATA Controller: ■Disabled
■Enabled
[Enabled] Enables or disables the Serial ATA port.
AHCI Configuration: ■Disabled
■Enabled
[Enabled] Enables or disables the selected Advanced Host Controller Interface
(AHCI).
Bluetooth(R): ■Disabled
■Enabled
[Enabled] Enables or disables selected IDE devices.
LAN Controller: ■Disabled
■Enabled
[Enabled] Enables or disables the LAN controller.
Wireless LAN: ■Disabled
■Enabled
[Enabled] Enables or disables the Wireless LAN device.
F1 Help
ESC Exit
Select Item
Select Menu
-/Space
Enter
F9 Setup Defaults
F10 Save and Exit
Change Values
Select Sub-Menu
▲
Item Specific Help
[Disabled]
Serial ATA port is
disabled.
[Enabled]
Serial ATA port is
enabled.
Internal Device Configurations
Serial ATA Controller: [Enabled]
AHCI Configuration: [Enabled]
Bluetooth(R): [Enabled]
LAN Controller: [Enabled]
Wireless LAN: [Enabled]
Info System Advanced Security Boot Exit
Phoenix SecureCore(tm) Setup Utility
Advanced Menu

16
LifeBook N Series BIOS
CPU Features Submenu of the Advanced Menu
The CPU Features submenu provides options for configuring the Intel Core Multi-Processing and SpeedStep power
management features of the CPU.
Figure 11. CPU Features Submenu
Table 11: Fields, Options and Defaults for the CPU Features Submenu of the Advanced Menu
Menu Field Options Default Description
Multi-core: ■Enabled
■Disabled
[Enabled] Enables or disables the multiple core processing features.
HT Technology: ■Disabled
■Enabled
[Enabled] Enables or disables the Hyper-Threading Technolgy feature.
SpeedStep(R)
Technology:
■Disabled
■Enabled
[Enabled] Enables or disables the SpeedStep(R) Technology features. When
disabled, On Battery and On AC are disabled.
Virtualization
Technology:
■Disabled
■Enabled
[Disabled] Enables or disables Virtualization Technology, an Intel technology
which includes hardware enhancements to improve upon soft-
ware-based virtualization technologies.
F1 Help
ESC Exit
Select Item
Select Menu
-/Space
Enter
F9 Setup Defaults
F10 Save and Exit
Change Values
Select Sub-Menu
▲
Item Specific Help
Select enabling or
disabling for
multiple core in a
physical processor
package.
CPU Features
Multi-core:
HT Technology: [Enabled]
SpeedStep(R) Technology: [Enabled]
Virtualization Technology: [Disabled]
[Enabled]
Phoenix SecureCore(tm) Setup Utility
Info System Advanced Security Boot Exit

17
USB Features Submenu of the Advanced Menu
The USB Features submenu provides options for enabling or disabling the USB devices.
Figure 12. USB Features Submenu
Table 12: Fields, Options and Defaults for the USB Features Submenu of the Advanced Menu
Menu Field Options Default Description
Legacy USB Support: ■Disabled
■Enabled
[Enabled] When Enabled is selected, Legacy USB Emulation is enabled
and the USB devices are available without a USB-aware OS.
When Disabled is selected, Legacy USB support is disabled.
SCSI SubClass Support: ■Disabled
■Enabled
[Enabled] When Enabled is selected, USB devices that belong to the
SCSI subclass in the mass storage class (e.g., USB Memory
Key) are enabled. Note that enabling this feature may cause
the system to hang during POST, depending on the device
that is connected.
F1 Help
ESC Exit
Select Item
Select Menu
-/Space
Enter
F9 Setup Defaults
F10 Save and Exit
Change Values
Select Sub-Menu
▲
Item Specific Help
[Disabled]
The feature is disabled.
[Enabled]
Legacy USB Emulation
is enabled and USB
devices are available
without USB aware OS.
Legacy USB Support
SCSI SubClass Support: [Enabled]
[Enabled]
USB Features
Info System Advanced Security Boot Exit
Phoenix SecureCore(tm) Setup Utility
Advanced Menu

18
LifeBook N Series BIOS
Miscellaneous Configurations Submenu of the Advanced Menu
The Miscellaneous Configurations submenu provides options for enabling or disabling the power button, the Wake Up
On LAN feature, and setting the volume.
Figure 13. Miscellaneous Configurations Submenu
Table 13: Fields, Options and Defaults for the Miscellaneous Configurations Submenu of the Advanced
Menu
Menu Field Options Default Description
Power Button: ■Disabled
■Power Off
[Disabled] Selecting Disabled disables the power button. Selecting Power Off allows
you to turn off system power with the power button.
Wake up on LAN: ■Disabled
■Enabled
[Disabled] Selecting Enabled allows the system to wake when the internal LAN device
receives a specific signal while in power-off state. Selecting Disabled
disables this feature.
On Battery: ■Disabled
■Enabled
[Enabled] When disabled, [Wake up on LAN] is enabled only when an AC Adapter is
connected.
Force LAN Boot: ■Disabled
■Enabled
[Disabled] This feature is active only when “Wake up on LAN” is enabled. When
enabled, in the event of a system wake-up on LAN, the system will try to
first boot from the LAN before attempting to boot from any other device,
regardless of the BIOS boot priority settings or disabling of the Preboot
Execution Environment.
Resume on LAN: ■On AC mode only
■Always Enabled
[Always
Enabled]
When [On AC mode only] is selected, Wake up on LAN from Hibernation
state is enabled only when an AC Adapter is connected.
Auto Save To Disk: ■Off
■On
[On] Turns the Auto Save To Disk feature off and on. When turned on, a
suspended system will save it state to disk and then turn off when a low
battery state is reached.
F1 Help
ESC Exit
Select Item
Select Menu
-/Space
Enter
F9 Setup Defaults
F10 Save and Exit
Change Values
Select Sub-Menu
▲
Item Specific Help
Configures the power
button.
*ACPI OS ignores this
setting.
Miscellaneous Configurations
Phoenix SeeureCore(tm) Setup Utility
Info System Advanced Security Boot Exit
Power Button:
Wake up on LAN:
On Battery:
Force LAN Boot:
Resume on LAN: [Always Enabled]
Auto Save To Disk: [On]
Volume Setting: [Middle]
Hardware Power Management: [Disabled]
FAN Control: [Normal]
[Disabled]
[Disabled]
[Enbled]
[Disabled]

19
Volume Setting: ■Off
■Minimum
■Middle
■Maximum
[Middle] Selects the initial volume setting for the system.
Hardware Power
Management:
■Disabled
■Enabled
[Disabled] Enables or disables the Hardware Power Management feature.
FAN Control: ■Normal
■Silent
[Normal] Allows you to select whether you want the fan to run in normal or silent
mode.
Table 13: Fields, Options and Defaults for the Miscellaneous Configurations Submenu of the Advanced
Menu
Menu Field Options Default Description
Advanced Menu

20
LifeBook N Series BIOS
Event Logging Submenu of the Advanced Menu
The Event Logging submenu configures event logging features for DMI events.
Figure 14. Event Logging Submenu
Table 14: Fields, Options and Defaults for the Event Logging Submenu of the Advanced Menu
Menu Field Options Default Description
Event Log Capacity: Space Available Display only
Event Log Validity: Valid Display only
View Event Log: ■Enter [Enter] Allows you to view content of event log
Event Logging: ■Disabled
■Enabled
[Enabled] Turns event logging on and off for all DMI events.
System Boot Event: ■Disabled
■Enabled
[Disabled] Turns event logging on and off for DMI system boot events.
Clear All Event Logs: ■No
■Yes
[No] When set to [Yes] all event logs will be cleared at next boot.
Mark Events as Read: ■Enter [Enter] Lets you mark all events currently in the event log as having been read.
F1 Help
ESC Exit
Select Item
Select Menu
-/Space
Enter
F9 Setup Defaults
F10 Save and Exit
Change Values
Select Sub-Menu
▲
Item Specific Help
Press <Enter> key to
view the contents of
the event log.
Event Logging
Event Log Capacity: Space Available
Event Log Validity: Valid
View Event Log: [Enter]
Event Logging: [Enabled]
System Boot Event: [Disabled]
Clear All Event Logs: [No]
Mark Events as Read: [Enter]
Info System Advanced Security Boot Exit
Phoenix SecureCore(tm) Setup Utility
