Fujitsu Siemens AMILO Xa Series User manual

Notebook English, Norsk, Português,
Česky, Türkçe, Slovensko,
Slovenský
Getting Started
AMILO Xa Series

Are there...
... technical questions or problems?
Please refer to:
• our Hotline/Help Desk (see Help Desk List or on the Internet at:
"www.fujitsu-siemens.com/helpdesk")
• your sales partner
• your sales office
Additional information is contained in the Help Desk List and the "Warranty" manual.
You can find the "Warranty" manual on your notebook by clicking on Start - Manual
or on the "Drivers & Utilities" CD/DVD or on our website.
The latest information on our products, tips, updates, etc. can be found on
the Internet at: "www.fujitsu-siemens.com"

This manual was produced by Xerox Global Services
Published by
Fujitsu Siemens Computers GmbH
AG 04/07
Edition 1, April 2007
Order No.: 10600816217
Order No.: 440 N30822

AMILO Xa Series
English
Norsk
Português
Česky
Türkçe
Slovensko
Slovenský
Getting Started

Microsoft, MS, Windows and Windows Vista are registered trademarks of Microsoft Corporation.
Acrobat Reader is a trademark of Adobe Systems Incorporated.
Macrovision is a trademark of Macrovision Corporation, USA.
MultiMediaCard is a registered trademark of Infineon Technologies AG
Sony and Memory Stick are registered trademarks of Sony Electronics, Inc.
All other trademarks referenced are trademarks or registered trademarks of their
respective owners, whose protected rights are acknowledged.
Copyright © Fujitsu Siemens Computers GmbH 2007
All rights, including rights of translation, reproduction by printing, copying or similar
methods, in part or in whole, are reserved.
Offenders will be liable for damages.
All rights reserved, including rights created by patent grant or registration of a utility model or design.
Delivery subject to availability. Right of technical modification reserved.

Contents
English
Contents
Innovativetechnology... ................................................................ 1
Areyoumissinginformation? ............................................................ 1
Notational conventions .................................................................. 2
Importantnotes ........................................................................ 3
Declarations of Conformity ............................................................... 3
Informationsources ..................................................................... 4
Safetyinformation ....................................................................... 5
Driversandutilities ...................................................................... 5
Portsandoperatingelements .......................................................... 6
Preparation for use andoperation ...................................................... 7
Unpacking and checking your notebook ................................................... 7
Selecting the location ................................................................... 7
Connecting the mains adapter ........................................................... 8
Switching the notebook on for the firsttime ................................................ 8
SwitchingontheNo
tebook . . . ........................................................... 9
SwitchingofftheN
otebook . . . ........................................................... 10
Battery ................................................................................. 10
Easy Launch keys ...................................................................... 11
Touchpad and touchpadbuttons .......................................................... 11
Using touchpad buttons .............................................................. 12
Microphone and loudspeakers ........................................................... 13
Adjusting the volume ................................................................ 14
Wireless components (wireless LAN/Bluetooth) ............................................ 15
Switching the wireless LAN/ Bluetooth module on and off . . ............................. 15
BIOS Setup Utility ....................................................................... 15
Troubleshootingandtips .............................................................. 16
Restoringinstalledsoftware .............................................................. 16
Restoring the operating system, drivers, manuals and special software . . . . .............. 17
The notebook’s date or time is incorrect ................................................... 17
A beep sounds at a rate of one per second . . . ............................................ 17
The notebook’s LCD screen remains blank . . . . ............................................ 17
The LCD screen is difficulttoread ........................................................ 17
Theexternalmonitorremainsblank ...................................................... 18
Theexternalmonitorisblankortheimageisunstable ..................................... 18
The notebook cannot be started . . . ....................................................... 19
The notebook stops working . . ........................................................... 19
The printer does not print . . . . . ........................................................... 20
The radio connection to a network does not work . . ........................................ 20
10600816217, edition 1, April 2007 English

Contents
English 10600816217, edition 1, April 2007

Innovative technology...
Innovative technology...
and ergonomic design make your AMILO a reliable, convenient notebook. If you have purchased
a notebook with a Microsoft Windows operating system, this will be pre-installed and optimally
configured for you. The notebook is ready to use when you switch it on for the first time.
This "Getting Started" guide tells you how to prepare your AMILO for use. If you encounter any
problems, helpful information can be found in the section "Troubleshooting and tips", Page 16.
The "optional" components described in this manual are only available for certain models
and must be selected at the time of purchase. At the time this manual is printed it is
not possible to say whether the "model-specific" components and functions described
in this manual will be available for your own particular model.
Are you missing information?
An overview with further information about your notebook can be found in
"Information sources", Page 4.
10600816217, edition 1, April 2007 English - 1

Innovative technology...
Notational conventions
Pay particular attention to text marked with this symbol. Failure to observe
this warning endangers your life, destroys the device, or may lead to loss of
data. Failure to follow the instructions may lead to loss of data, invalidate
your warranty, destroy the device, or endanger your life
indicates important information that is required to use the device properly.
►refers to an action which you must carry out.
indicates a result
This style flags data entered using the keyboard in a program dialog or command
line, e.g. your password (Name123) or a command to launch a program
(start.exe)
This style refers to information displayed by a program on the screen, e.g.:
Installation is completed
This style is for
• terms and texts in a software user interface, e.g.: ClickSave.
• names of programs or files, e.g. Windows or setup.exe.
"This style" is for
• cross-references to another section, e.g. "Safety information"
• Querverweise auf eine externe Quelle, z. B. eine Webadresse: Lesen
Sie weiter auf "www.fujitsu-siemens.com"
• indicates names of CDs and DVDs as well as names and titles of other
materials, e.g.: "CD/DVD Drivers & Utilities" or "Safety" manual
Abc refers to a key on the keyboard, e.g.: F10
This style flags concepts and text that are emphasised or highlighted, e.g.: Do not
switch off device
2 - English 10600816217, edition 1, April 2007

Important notes
Important notes
ImportantnotesNotes
This chapter contains references to other sources of information. It is essential that
you observe the safety information for your notebook.
Declarations of Conformity
Declarationof conformity
The "Declarations of Conformity" concerning the AMILO can be found at our
Internet address: "www.fujitsu-siemens.com".
Hereby, Fujitsu Siemens Computers, declares that the AMILO is in compliance with the
essential requirements and other relevant provisions of Directive 1999/5/EC.
10600816217, edition 1, April 2007 English - 3

Important notes
Information sources
Inform ation source s
In this "Getting Started" manual you will find the information you need to prepare your
notebook for use. More detailed instructions and technical information for your notebook
are contained in the "EasyGuide" manual. Manuals available only as PDF files can
be printed out if you connect a printer to your notebook.
Information source Type of information Where?
Quick Start Guide (printed) Poster with information about
getting started
Accessories kit
"Safety" manual (printed
and/or PDF file)
Safety information Accessories kit and/or on your
notebook
"Recovery Process" manual
(printed and/or PDF file)
Information on restoring
the operating system,
drivers, manuals and special
software
Accessories kit, on your
notebook or on our website
"www.fujitsu-siemens.com/support/"
"EasyGuide" manual (PDF
file)
Detailed instructions for
commissioning, operation
and technical information
"Wireless LAN" manual
(PDF file)
Detailed instructions for
using wireless LAN and
technical information
"Warranty" manual (PDF
file)
General guarantee
conditions
information files (e.g.*.TXT,
*.DOC, *.CHM, *.HLP)
Information on utilities and
programs
The manuals are located on your
notebook under Startsymbol – Manual
or in some cases, updated versions
can be found on our websiteat:
"www.fujitsu-siemens.com/support/".
information files (e.g. *.TXT,
*.DOC, *.CHM, *.HLP)
Information on the operating
system, the webcam and
Bluetooth
In the software for these applications
4 - English 10600816217, edition 1, April 2007

Important notes
Safety information
SafetyinformationNotes
Pay attention to the information provided in the "Safety" manual
and in the following safety notes.
• When cleaning the notebook, observe the relevant notes in the "EasyGuide"manual.
• Your notebook is equipped with numerous security features that offer you a high
level of security according to a multi-level concept. Details are contained in the
"Security functions" chapter in the "EasyGuide" manual.
• Pay attention to the additional safety notes for devices with radio components
provided in the "Safety" manual.
• Keep this operating manual together with the device. If you pass this device on to
others, you should also give them the operating manual.
This notebook complies with the relevant safety regulations for data processing
equipment. If you have questions about using your notebook in a particular area,
please contact your sales outlet or our Hotline/Help Desk.
Drivers and utilities
If a Windows operating system is installed on your notebook, you will find additional
information on the system and drivers, help programs and updates on your notebook
or on our website "www.fujitsu-siemens.com/support/".
If you need to reinstall your operating system, you can reload the original software and
the original drivers of your notebook onto the hard disk using the "Drivers & Utilities"
CD/DVD or the drivers from our website.
10600816217, edition 1, April 2007 English - 5

Ports and operating elements
Ports and operating elements
PortsandoperatingelementsModemportLCDscreenMonitorportS-Videooutsoc ketBui lt- in lou dsp eak ersLoudspeaker portBluetoothportWirelessLANKensingtonLockLANpo rtMemorycardslotFireW ire por tUSBportExpressCard slotBatteryBatteryreleaseSIMcardHarddiskTouchpadbuttonsTou ch pa dNotebookON/OFFswitchEasyLaunchkeysInfraredinterfaceCD/DVDdriveHeadphon eportMicrop honeportLine inLineoutSPDIFportDCINjackWebcam
This chapter presents the individual hardware components of your notebook. It provides
an overview of the notebook’s displays and ports. Please familiarise yourself with these
components before you start to work with your notebook.
14
6
9
1
2
3
5
4
22
21
20
25 26
27
19
30
29
28
24
23
6
7
31
8
18
13
11 10
15
16
17
12
1 = USB port
2 = FireWire port
3 = LAN port
4 = USB ports
5 = ExpressCard slot
6 = Built-in loudspeakers
7 = ON/OFF switch of the notebook
8 = Easy Launch keys
9 = Status indicators
10 = Memory card slot
11 = Volume control
12 = Touchpad
13 = Headphones/SPDIF port (loudspeaker
port / line out)
14 = Microphone port
15 = Line in
16 = Remote control interface
17 = On/Off switch for wireless LAN, Bluetooth
18 = Touchpad keys
19 = Bass loudspeaker (subwoofer)
20 = CD/DVD drive
21 = Modem port
22 = Kensington Lock
23 = Service compartment (hard disk(s))
24 = Service compartment (memory)
25 = S-Video out socket
26 = DVI-I monitor port
27=DCINjack
28 = Battery release latch
29 = Battery
30 = Battery release latch
31 = Webcam
6 - English 10600816217, edition 1, April 2007

Preparation for use and operation
Preparation for use and operation
Please observe the safety information in the section "Important notes", Page 3.
You must charge the battery and install the application programmes before you can work with
the notebook. The operating system and drivers required are preinstalled.
This chapter also describes the basics for operating your notebook.
Unpacking and checking your notebook
Should you discover any damage incurred during transportation, notify
your local sales outlet immediately!
►Unpack all the individual parts.
PackagingT ransport
►Check your notebook for damage incurred during transportation.
We recommend that you keep the original packaging material.
You may need the packaging in the future if you need to transport your device.
Selecting the location
Location,selectingthe NotebookPower adapter
Select a suitable location for the notebook before setting it up. Consider
the following points when selecting a location:
• Never place the notebook on a soft surface (e.g. carpeting, upholstered furniture,
bed). This can block the air vents and cause damage due to overheating.
• Do not place the notebook directly on your legs for extended periods. The
underside of the notebook heats up during normal operation. Extended contact
with the skin can become unpleasant or even result in burns.
• Place the notebook on a stable, flat, non-slip surface. Please note that
the rubber feet may mark certain types of surfaces.
• Keep other objects 100 mm away from the notebook and its mains
adapter to ensure adequate ventilation.
• Never cover the ventilation slots on the notebook or the mains adapter.
• Do not expose the notebook to extreme environmental conditions. Protect
the notebook against dust, humidity and heat.
10600816217, edition 1, April 2007 English - 7

Preparation for use and operation
Connecting the mains adapter
Preparingforo perationMainsadapter
Please read the information in "Safety information", Page 5.
The power cable supplied conforms to the requirements of the country in which
you purchased your notebook. Make sure that the power cable is approved
for use in the country in which you intend to use it.
The mains adapter’s power cable must only be connected to a mains socket
if the notebook is connected to the mains adapter.
Make sure that the rated current of the mains adapter is not higher than that of the
power system to which you connect it (see technical data for the mains adapter).
1
2
3
►Connect the mains adapter cable(1)to
the DC jack (DC IN) of the notebook.
►Plug the power cable (2) into the
mains adapter.
►Plug the power cable (3) into a mains outlet.
Switching the notebook on for the first time
Switchingonforthefirstt ime
When you switch your notebook on for the first time, the supplied software is
installed and configured. Due to the fact that this installation procedure must not
be interrupted, you should set aside enough time for it to be fully completed and
connect the notebook to the mains outlet using the mains adapter.
During installation, the notebook must only be rebooted when you are requested to do so!
Your operating system is pre-installed on the hard disk to facilitate the procedure
when you use your notebook for the first time.
►Switch the notebook on (see "Switching on the Notebook", Page 9).
►During installation, follow the on-screen instructions.
Consult the operating system manual if anything is unclear about the requested input data.
If a Windows operating system is installed on your notebook, you will find
additional information on the system as well as the drivers, help programs,
updates, manuals, etc. on your notebook or on the "Drivers & Utilities" CD/DVD
or on our website (see "Information sources", Page 4).
8 - English 10600816217, edition 1, April 2007

Preparation for use and operation
SwitchingontheNotebook
2
1
►Slide the release button in the direction
of the arrow (1) and unfold the LCD
screen upward (2).
Notebook
1
►Press the ON/OFF switch (1) to switch
the notebook on.
The power-on indicator is lit.
10600816217, edition 1, April 2007 English - 9

Preparation for use and operation
Switching off the Notebook
1
►Shut down the operating system
properly (e.g. from the Windows Start
menu, by clicking on Start - Shut Down
- Shut down - OK ).
Notebook
►If the notebook is not switched off
automatically, press the ON/OFF switch (1)
for approx. five seconds.
1
►Close the LCD screen (1) so that
it locks into place.
Battery
The battery in the notebook is not fully charged at the time of delivery. You
must first charge the battery with the mains adapter connected to the power
socket (see "Connecting the mains adapter", Page 8).
The battery supplies your notebook with the necessary power during mobile use. The
battery indicator displays the current state of the battery.
Information on how to install and remove the battery, how to maintain and service it, and how
to optimise the battery operating time can be found in the "EasyGuide" manual.
10 - English 10600816217, edition 1, April 2007

Preparation for use and operation
Easy Launch keys
EasyLaunch keys Your notebook is equipped with Easy Launch
keys. With the pre-installed software you can
launch the following applications or functions
by pressing a single button.
Webcam
With this key you can start your system’s integral webcam.
Multimedia
This button starts multimedia applications.
Multimedia,Eas yLaunchkey
Silent Mode (whisper mode)
This key reduces the speed of the fan.
When the Silent Mode is switched on, the processor and graphics do not operate at
the full performance level.
This reduced power is adequate for most office applications however.
Whispermode,EasyLaunchkey SilentMode,EasyLaunchkey
Internet
With this button you can start the standard internet browser of your system.
Internet,EasyLaunchkey
Touchpad and touchpad buttons
Keep the touchpad clean. Protect it from dirt, liquids, and grease.
TouchpadTouchpad
Do not use the touchpad if your fingers are dirty.
Do not rest heavy objects (e.g. books) on the touchpad or the touchpad buttons.
1
2
1 = Touchpad
2 = Touchpad buttons
The touchpad enables you to move the mouse pointer on the screen.
10600816217, edition 1, April 2007 English - 11

Preparation for use and operation
The touchpad buttons allow you to select and execute commands. They correspond
to the buttons on a conventional mouse.
Using touchpad buttons
Moving the pointer
►Move your finger on the touchpad.
Touchpad
The pointer will move accordingly.
Selectinganitem
►Move the pointer to the item you wish to select.
Touchpad
►Tap the touchpad once or press the left button once.
The item is selected.
Executing a command
►Move the pointer to the field you wish to select.
Touchpad
►Tap the touchpad twice or press the left button twice.
The command will be executed.
Dragging an object
►Select the desired object.
Touchpad
►Press and hold the left button and drag the object to the desired position
with the finger on the touchpad.
The item will be moved.
Using the key combination Fn +F5 you can turn off the touchpad
to avoid moving the pointer on the screen accidentally (see also "Key
combinations" in the "EasyGuide" manual).
12 - English 10600816217, edition 1, April 2007
