Fujitsu Lifebook TH700 User manual

Page 1 of 2 http://store.shopfujitsu.com/fpc/Ecommerce/buildseriesbean.do?series=TH700
PRODUCT VERSATILITY
The LifeBook TH700 Tablet PC was designed for the
person who doesn’t sit in a chair all day. Whether
you use it as a notebook or as a tablet, whether you
input with the keyboard, a stylus, or your finger, the
LifeBook TH700 conforms to your needs, not the other
way around. By taking advantage of the industry-first
bi-directional swivel hinge, you can easily transform
this standard notebook into a tablet by rotating the
display (in either direction) and folding it flush with
the keyboard. While in tablet mode, you can use the
inking capabilities to take notes and annotate files or
photos, then convert your handwritten notes into text.
MAXIMUM PRODUCTIVITY
The stylus provides precise cursor control in any
software application, including applications
developed for special uses. You can also mark up
digital documents directly, annotate over images, or
even take handwritten notes. You can also use your
finger in place of the pen, and even use two-finger
on-screen gestures to interact with your system.
With the Intel® Core™ i3, Technology, and Genuine
Windows® 7 Home Premium, the LifeBook TH700
Tablet PC redefines the convertible computer.
EXCELLENT CONNECTIVITY
Connect to your local area network or the Internet
with the Gigabit Ethernet or the fast Atheros XSPAN®
802.11bgn wireless LAN. If you use a Bluetooth-
enabled cellular phone or PDA, your LifeBook TH700
Tablet PC can be equipped with optional integrated
Bluetooth V 2.1 wireless technology for data
synchronization and fast image swapping.
MODULAR FLEXIBILITY
The built-in modular bay allows you to install a second
battery for a full day’s activities away from your home
without adding significant weight or bulk. The bay can
also accommodate a modular optical drive to handle
all of your digital media needs, or a weight saver for
when you want to travel light. All of this functionality
comes in a Tablet PC that weighs as little as 4.2 lbs.5
yet offers an array of ports and card slots that allow
you to connect directly to a wide array of peripherals.
DUAL DIGITIZER
Dual digitizer technology makes communicating
with your computer a more intuitive experience. You
now have the option of not only using a stylus, but
the multi-touch screen supports two finger touch
gestures as well. Navigating through files, zooming
in and out, sorting images, or jumping from one
app to the next has never been faster or easier.
Capacitive touch means the screen senses your
finger tips so it responds to the lightest touch. It is
no longer necessary to press hard on your display
to perform different actions. Active digitizer
technology allows your display to respond to
your stylus as if it were a pen gliding across
smooth paper. Taking notes or annotating an
existing document combines state-of-the-art
technology with old familiar tools. Computers are
fun again.
§ DUAL FUNCTIONALITY FOR NOTEBOOK AND
TABLET USE
§ POWERED BY THE NEW 2010 INTEL
®
CORE™
PROCESSOR
§ DUAL DIGITIZER DISPLAY SUPPORTS BOTH PEN
AND MULTI-TOUCH SCREEN FOR ON-SCREEN
TOUCH GESTURE ACTIONS
§ 12.1-INCH LED DISPLAY
§ BI-DIRECTIONAL DISPLAY HINGE ALLOWS FOR
CONVENIENT INFORMATION SHARING
§ MODULAR BAY SUPPORTS OPTICAL DRIVE, BAY
BATTERY, HARD DISK DRIVE, OR WEIGHT SAVER
§ WI-FI CERTIFIED WIRELESS LAN, GIGABIT
ETHERNET, AND BLUETOOTH V2.1
§ WORLD-RENOWNED FUJITSU RELIABILITY
DATASHEET FUJITSU LIFEBOOK TH700 TABLET PC
DATASHEET
LIFEBOOK® TH700 TABLET PC
THE LATEST COMPUTING TECHNOLOGY THAT CHANGES AS YOUR NEEDS CHANGE—THE
FUJITSU LIFEBOOK TH700 TABLET PC.

TECHNICAL DETAILS
SOFTWARE
OPERATING SYSTEMS: Genuine Windows® 7 Home Premium
(64 bit) with Microsoft® Office Starter 20101. Microsoft® Office
Starter 2010, Adobe® Reader, Norton Internet Security™2
(60-day free trial), CyberLink® PowerDirector, PowerDVD,
MakeDisc, and YouCam, Roxio® Creator, OmniPass Fingerprint
application, Fujitsu Driver Update utility, Microsoft® Office
Activation Assistant, Microsoft® Touch Pack, Microsoft®
Windows® Live Mail
KEY SPECIFICATIONS
(Listed specifications are for the current model only and not for earlier models or revisions to this product.)
PROCESSOR: Intel® Core™ i3 350M Processor (2.26 GHz,
3 MB L3 cache)
CHIPSET: Mobile Intel® HM55 Express
MEMORY: 4 GB DDR3-1066 MHz SDRAM Dual Channel memory
(supports up to 8 GB of memory)
DISPLAY:
LCD 12.1" WXGA LED backlight display (200 nits)
Resolution Max. internal display res.: 1280 x 800,
16M colors
External monitor res.: 1920 x 1200, 16M colors
Simultaneous display res.: 1280 x 800,
16M colors
AMBIENT LIGHT SENSOR: Yes3
VIDEO: Intel® HD Graphics with dynamic frequency. Automatically
distributes performance to CPU and graphics by up to 20%.
DIGITIZER: Dual Digitizer (digital pen input plus capacitive
multi-touch screen supporting touch gesture)
HARD DRIVE4: OPTIONS: 320 GB (5400 rpm; protected by HDD
shock sensor technology
OPTIONAL WEBCAM: Built-in 2.0 megapixel
MODULAR BAY WITH QUICK-RELEASE LATCH: Modular Dual-Layer
Super Multi-Format DVD Writer, Weight Saver (included with
all configurations)
AUDIO: Realtek ALC269 with (HD) audio, two built-in speakers,
two digital array microphones
COMMUNICATION: Intel® 82577LC 10/100/1000 Gigabit
Ethernet LAN
WIRELESS COMMUNICATION: Atheros XSPAN® 802.11bgn,
Bluetooth V2.1
USER INTERFACE: 84-key full-size, spill-resistant keyboard;
touch pad with scroll sensor
PORTS: One 15-pin VGA connector, three USB 2.0 connectors, one
DC In connector, one IEEE 1394 (4-pin type) jack, one LAN (RJ-45)
connector, one HDMI port, one stereo headphone jack, one stereo
microphone/line-in jack
CARD SLOTS: ExpressCard® slot supporting 34/54mm
ExpressCard®, Memory Stick®/SD Card slot
SECURITY: Biometric fingerprint sensor; Security lock slot
BATTERY6: Standard Lithium ion battery, 6-cell, 10.8V, 5200 mAh.
Battery life up to 5 hrs.6
AC ADAPTER: Autosensing 100-240V AC, 80W, 19V DC,
4.22A (80W)
DIMENSIONS/WEIGHT: Dimensions: 11.69" x 9.17" x 1.51"
(1.54": with rubber boot) Weight: starting at 4.2 lbs.5
(weight will vary by configuration)
OPERATING TEMPERATURE: 41°F to 95°F (ambient temp.);
20% to 85% relative humidity, non-condensing
NON-OPERATING TEMPERATURE: 5°F to 140°F, 8% to 85%
relative humidity, non-condensing
KEY ACCESSORIES: For a full list of accessories,
visit www.shopfujitsu.com or call 1-800-FUJITSU Modular Bay
battery, Modular bay hard drive kit
COMPLIANCE AND SERVICE INFORMATION
COMPLIANCE: FCC Part 15B Class B, and FCC Part 15C, and
FCC Part 15E; IC ICES-003 Class B and RSS-210 UL-cUL Listed,
ExpressCard® EC100383, ENERGY STAR® qualified
WARRANTY7: One or three-year International Limited Warranty
on select corporate configurations; 24/7 technical support;
Fujitsu extended service plans available.
FUJITSU AMERICA, INC.
1250 East Arques Avenue
Sunnyvale, CA 94085-3470, U.S.A.
Telephone: [phone]
or 408 746 6000
Fax: [phone]
Web: solutions.us.fujitsu.com
Email: [e-mail]
1) Microsoft® Office Starter 2010 32-bit
includes reduced functionality versions
of Microsoft® Word and Excel only, with
advertising.
2) Preinstalled with a free 60-day trial version of
Symantec Norton Internet Security. The 60-day
trial version is activated upon user’s acceptance
of software license agreement. After 90 days,
the user must purchase a subscription from
Symantec to download latest virus definitions.
3) Ambient light sensor is factory disabled. It is
easily enabled through the “Location and Other
Sensors” applet in the Genuine Windows®
7 control panel. Applet is only available in
configurations with a Genuine Windows® 7
operating system.
4) One gigabyte (GB) = one billion bytes;
accessible capacity will be less and actual
capacity depends on the operating environment
and formatting.
5) Weight will vary by configuration,
manufacturing variability and vendor
component options.
6) Battery life tested using MobileMark 2007.
Battery life will vary depending on the product
configuration, product model, application
loaded on the product, power management
settings on the product, Operating System,
and the product features used by the customer.
As with all batteries, the maximum capacity of
the installed batteries will decrease with time,
usage, and how often the batteries are charged
by the user
7) Service and warranty turnaround time may
vary by country and product. The International
warranty is only valid for products purchased in
North, Central, and South America.
Fujitsu, the Fujitsu logo, and LifeBook are
registered trademarks of Fujitsu Limited.
Genuine Windows Vista, Microsoft, and
Windows are registered trademarks or
trademarks of Microsoft Corporation in the
United States and/or other countries. Centrino,
Intel, Intel Core, the Centrino logo and the Intel
logo are trademarks or registered trademarks
of Intel Corporation or its subsidiaries in the
United States and other countries. Atheros and
the Atheros logo are registered trademarks
of Atheros Communications. Memory Stick
is a registered trademark and Memory Stick
PRO is a trademark of Sony Corporation and/
or its affiliates. Adobe Reader is a registered
trademark of Adobe Systems, Inc. Wi-Fi is a
trademark of the Wireless Ethernet Compatibility
Alliance (WECA). Norton Internet Security is a
trademark of Symantec Corporation. ENERGY
STAR is a registered trademark of the U.S.
Government. All other trademarks mentioned
herein are the property of their respective
owners Product description data represents
Fujitsu design objectives and is provided for
comparative purposes; actual results may vary
based on a variety of factors. Specifications are
subject to change without notice.
©2010 Fujitsu America, Inc.
All rights reserved.
FPC58-2707-01 06/10.
