Fujitsu P1610 - LifeBook - Core Solo 1.2 GHz Reference guide

LifeBook P1610
Display Latch Replacement
ESD Precautions are required when working on this LifeBook computer.
Make sure the LifeBook is turned off before beginning this procedure.
1. Turn the LifeBook over and
remove the battery
3. Extract 8 screws from the front of
the display.
2. Remove 8 screw covers from the
front of the display.
4. Using the plastic pry tool pry
around the perimeter of the display
to release the front cover from the
rear.

5. Gently slide the pry tool between
the screen and the front cover to
release the tape.
7. Extract 2 screws from the display
latch and lift it out.
9. Press the front cover into place
and secure it with 8 screws.
11. Lift the display up and turn it
around.
6. Lift the front cover off.
8. Insert the new latch and secure it
with 2 screws.
10. Place 8 screw covers over these
screws.
12. Lay it back down and turn the
LifeBook over.

13. Replace the battery.
