Fujitsu DSL Modem User manual

The contents of this document are subject to change without notice.Neither
this document, nor any portion thereof, is to be reproduced in any form
without written permission of FNC.Information contained in this document
is FNC Propriety and Confidential and is for use by FNC authorized
recipients only.
Copyright

Fujitsu Network Communications, Inc. All Rights Reserved.
Copyright Notice
DSL Modem Installation Guide, Issue 2
September 1998
FJTU-320-600-900

Safety Information
SafetyWarnings
Potentially hazardous voltages exist within this unit.Always observe
standard safety precautions during installation, operation, and
maintenance of this product.There are no user provisionable options.
FCCWarning
This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference when the equipment is operated in a
residential environment.This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in
accordance with the instruction manual, may cause harmful
interference to radio communications. However, there is no
guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to
radio or television reception,which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment to an outlet on a circuit different from
that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for
help.
UL Installation Safety Instructions
This device is UL listed. Follow these instructions.
• Never install telephone wiring during a lightning storm.
• Never install telephone jacks in a wet location unless the jack is
specifically designed for wet locations.
• Never touch the telephone wires or terminals unless the
telephone line has been disconnected at the network interface.
• Use caution when installing or modifying telephone lines.

Page
Table of Contents
1 Introduction
1.1 ADSL Technology . . . . . . . . . . . . . . . . . . . . . . 1
1.2 Unpacking Instructions . . . . . . . . . . . . . . . . . 2
1.3 DSL Modem Package Contents . . . . . . . . . . . 3
2 Installing the DSL Modem
2.1 Mounting the DSL Modem . . . . . . . . . . . . . . . 4
2.2 DSL Modem Front Panel Description . . . . . . 5
2.3 DSL Modem Rear Panel Description . . . . . . . 6
3 Connecting the DSL Modem to the Splitter
3.1 Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
3.2 Inside Wiring Procedures . . . . . . . . . . . . . . . . 8
3.3 Multiple PCs Wiring Procedure . . . . . . . . . . 13
4 Turn Up and Operation
4.1 Connecting the Power Supply Convertor. . . 14
4.2 Starting the Modem . . . . . . . . . . . . . . . . . . . 14

1
1 Introduction
Congratulations on your purchase of a Digital Subscriber Line (DSL)
modem.The DSL Modem is part of a system that provides an
integrated end-to-end solution for data connectivity, multimedia
services, and high-speed Internet access services using an
asymmetrical digital subscriber line (ADSL) transmission over your
current telephone wiring.With ADSL technology, information can be
processed at speeds up to 250 times faster than today’s analog
modems.
1.1 ADSLTechnology
As the interest in telecommuting and the Internet grows, the search
for methods of delivering larger amounts of data over the existing
copper telephone wire increases.ADSL technology is one method of
delivery.
ADSL technology uses advanced digital modulation to transmit data
at high speeds over standard telephone wiring.This technology can
download data at 8 Mbps and upload data at up to 768 kb/s.
The DSL Modem is part of a system that enables Internet service
providers and local telephone companies to offer high-speed Internet
access, virtual private networks (VPNs), telecommuting, video on
demand, and other broadband services.
m0490.3
PC with
Ethernet
NIC
Phone
Splitter
DSL Modem
POWER MODEM DATA
Local Telephone
Company

2
To benefit from the high-speed transmission rate of ADSL over your
existing telephone wire, your phone line and your computer must be
separated. Each DSL line must be wired through a special filter
called a splitter.While both the DSL Modem and the telephone share
a telephone line to the customer premises, the signals are separated
at the splitter, providing an isolated path to the individual wiring,
jacks, and other telecommunications hardware.This splitter is
installed by the telephone service provider.
With the use of a DSL Modem, splitter, and your existing telephone
line, you can use the telephone and download data onto your
computer at the same time.The DSL Modem splitter is completely
passive, providing “lifeline” or continuous, telephone service even if
the power fails.The DSL Modem encodes the data sent from your PC
to a corresponding DSL Modem, located at your local telephone
company.
1.2 Unpacking Instructions
Before unpacking, make a preliminary inspection of the shipping
box.Any evidence of damage should be noted and reported
immediately to the customer support center.
Note: The customer support information can be found in the product
information packet provided by your phone company.
It is recommended that you unpack the equipment on a clean, flat
surface.
1. Place the shipping box upright. Cut the sealing tape and then
open the flaps.
2. Take out the items in the box. Search the box for any additional
small items that may be present.
3. Inspect the product for damage and verify that all parts are
included.
4. Report any damage or missing parts to the customer support
center. Keep the shipping boxes and packing materials for
reuse.

3
1.3 DSL Modem Package Contents
The DSL Modem package contains:
• DSL Modem
• Ethernet (or null) crossover cable
• ASDL cable (straight)
• Power supply convertor
m0437.2
Part # FC9660RA12
POWER MODEM DATA
DSL Modem Ethernet Crossover Cable
m0487.2
Part # FC9660CB23
ADSL Cable (Straight)
m0488.2
Part # FC9660CB22
m0494.3
Part # FC9660PS11
Power Supply Convertor

4
2 Installing the DSL Modem
2.1 Mounting the DSL Modem
The DSL Modem can be installed on desktops,shelves or mounted on
walls.The wall mounting requires two wall anchors (not included).
The feet located on the bottom of the modem are used to hang the
unit on the wall anchors.
Figure 2-1 shows a diagram of how to mount the DSL Modem.
Figure 2-1: DSL Modem Mounting Holes
m0435
Feet for
wall mounting

5
2.2 DSL Modem Front Panel Description
Figure 2-2 depicts the DSL Modem.
The following table describes the lights on the front panel of the DSL
Modem.
Figure 2-2: DSL Modem
Modem Lights Description
POWER Indicates if power is applied to the modem.
MODEM Indicates a valid link with the phone company’s equipment.
DATA Indicates if the ADSL rate is operating at efficient capacity.
m0491
POWER MODEM DATA

6
2.3 DSL Modem Rear Panel Description
Figure 2-3 depicts the rear panel of the DSL Modem.
The following table describes the functions of the items located on
the rear panel.
Figure 2-3: DSL Modem Rear Panel
Connector Description
Power Multi-pin outlet for connection of the power supply wall
transformer.This cable is supplied in the DSL Modem package.
DATA RJ-45 connector for the Ethernet crossover cable.This cable is
supplied in the DSL Modem package.
LINE RJ-11 and RJ-45 connector for a connection to the RJ-45 wall
plate using the ADSL cable (straight). This cable is supplied in
the DSL Modem package.
m0436.2
LINE
LINE
DATA
DATA

7
3 Connecting the DSL Modem to the Splitter
3.1 Overview
Note: The procedures in Section 3 only apply to those customers who
choose to wire their own splitter-to-modem connection.If a certified
technican is performing the wiring, then proceed to Section 4 Turn-Up
and Operation.
The network interface device (NID) is typically located on the outside
of the customer premises. Certain installations, such as those at an
apartment complex, require the splitter to be installed closer to the
DSL Modem.The telephone or ADSL service provider also installs
this type of splitter.
Note: The telephone service provider will install a splitter in the
network interface device (NID) to separate the voice and data interior
wire paths.
Before connecting the wires from the NID to the DSL Modem, verify
that the inside wire pair serving the DSL Modem has an isolated
path from the NID to the modem. Do not connect a telephone to the
same wire pair. In some instances,it may be necessary to reroute the
inside wire away from noise sources such as appliances, fluorescent
lighting, televisions, light dimmers, and other electrical noise
sources. It is recommended that the modem has dedicated inside
wiring.
For the DSL Modem, you will only need to connect the wires
associated with data output on the NID.The telephone company
technician has already connected the voice (or telephone) wiring.The
data module provides a connection point for the inside wire pair
serving the DSL Modem.
Note: Category 3 (CAT 3) or Category 5 (CAT 5) twisted-pair wire is
recommended.
For inside wiring procedures see Section 3.2 before you start.

8
3.2 InsideWiring Procedures
WARNING:
Interior home wire is the homeowner responsibility.The following wiring
diagrams represent a standard wiring scheme.Not all homes will follow
this convention.Standard telephone company inside wire coverage
options will not cover the cost to repair voice path problems that may
arise as a result of homeowner wiring attempts.These repairs may be
billed to homeowner as regular time and materials repair charges.It is
recommended that all ADSL inside wiring be performed by a certified
technician.
If you are using original inside wire, then see the section Spare
Inside Wire. If you are using new inside wire cable (CAT 3 or CAT 5)
for the data, then see the section New Inside Wire.
See Figure 3-1 for a diagram of the NID data and voice outputs.
Note: From the NID, open the latch door to the data module.You will
see four colored screws.Note the coloring of the wire that is connected
to the green and red screws.For this installation, you will only need to
connect the wires associated with the data output.The telephone
company technician has already connected the voice wiring.
Figure 3-1: Network Interface Device (NID) Splitter
m0372.2
Red Screw
Red Screw
Green Screw
Green Screw
DATA
VOICE
To Inside
Wall Plate
To Inside
Telephone
Wiring
Network Interface Device (NID) Splitter

9
Spare InsideWire
Note: The following wiring procedure and diagram represents a
standard wiring scheme. Not all homes will follow this convention.It is
recommended that ADSL inside wiring be performed by a certified
technician.
1. If you are using the original inside wire cable pair for the
telephone (voice), replace the existing RJ-11 wall plate with an
RJ-11/RJ-45 wall plate.
Note: ISDN Users–If you previously had ISDN, you can use the
existing ISDN wired RJ-45 jack.
2. If you are using spare inside wire pair for the DSL Modem
(data), install a new RJ-11/RJ-45 wall plate.
3. Connect the wires attached to the green and red screws on the
NID to the green and red pins on the wall jack. For example,if a
black wire is connected to the green screw in the data latch,
connect the same black wire to the green pin of the new wall
jack. Repeat this step for the voice wire.
4. Connect the RJ-45 end of theADSL cable (straight) to the RJ-45
jack on the wall plate.Connect the RJ-11 end of the ADSL cable
(straight) to the LINE connector on the modem.The LINE
connection is located on the back panel of the DSL Modem.The
ADSL cable (straight) is included in the DSL Modem package.
5. Connect your telephone set to the RJ-11 jack on the wall plate.
6. Connect one end of the Ethernet crossover cable to the DATA
connector on the modem. Connect the other end of the Ethernet
crossover cable to the network interface card in the computer.
The DATA connection is located on the back panel of the DSL
Modem.The Ethernet crossover cable is included in the DSL
Modem package.
Note: The Ethernet cable provided is a crossed cable and must be
used when connecting the DSL Modem directly to the network
interface card in the computer.

10
Figure 3-2 is a diagram for using spare inside wire.The numbers
circled in the diagram correlate to the steps in the Spare Inside Wire
procedure.
Figure 3-2: Spare Inside Wire Interconnection
LINE
LINE
DATA
DATA
m0492.3
Network Interface
Device (NID)
DSL Splitter Inside Data Wire
Ethernet Crossover Cable*
To
Telephone
Company
Voice
Wire
*Asterisk denotes item included in the DSL modem package.
Inside Wire
(CAT 3)
GR
GR
RJ-11 Cable
ADSL Cable
(Straight)*
DSL Modem*
New Wall Plate
with RJ-11 and
RJ-45 Jacks
6
4
3
5
2
1
Spare Inside Wire Connections
RJ-45
Connector
RJ-11
Connector

11
New InsideWire
Note: The following wiring procedure and diagram represents a
standard wiring scheme. Not all homes will follow this convention.It is
recommended that ADSL inside wiring be performed by a certified
technician.
1. If you are using original inside wire cable pair for the telephone
(voice), then you can replace the existing RJ-11 wall plate with
an RJ-11/RJ-45 wall plate or install a new separate RJ-45 wall
plate. Run the original wire only if you are able to run new
inside wire to this location.
Note: ISDN Users–If you previously had ISDN, you can use the
existing ISDN wired RJ-45 jack.
2. Run new inside wire cable for ADSL (data) if no existing inside
wire pairs are available.Wire the new inside wire pairs to the
new RJ-11/RJ-45 wall plate (if installed). Otherwise, install a
new RJ-45 wall plate near your PC.
3. Connect the wires attached to the data/voice green and red
screws on the NID to the green and red pins on the wall jack.
For example, if a black wire is connected to the green screw on
the data, connect the same black wire to the green pin on the
new RJ-45 wall jack.
4. Repeat Step 3 for the voice wiring.
5. Connect the RJ-45 end of theADSL cable (straight) to the RJ-45
jack on the wall plate.Connect the RJ-11 end of the ADSL cable
(straight) to the LINE connector on the modem.The LINE
connection is located on the back panel of the DSL Modem.The
ADSL cable (straight) is included in the DSL Modem package.
6. Connect your telephone set to the RJ-11 jack on the wall plate.
7. Connect one end of the Ethernet crossover cable to the DATA
connector on the modem. Connect the other end of the Ethernet
crossover cable to the network interface card in the computer.
The DATA connection is located on the back panel of the DSL
Modem.The Ethernet crossover cable is included in the DSL
Modem package.

12
Note: The ethernet cable provided is a crossed cable and must be
used when connecting the DSL Modem directly to the network
interface card in the computer.
A diagram for using new wire is shown in Figure 3-3.The numbers
circled in the diagram correlate to the steps in the procedure.
Figure 3-3: New Inside Wire Connections
LINE
LINE
DATA
DATA
m0489.3
Network Interface
Device (NID)
DSL Splitter Inside
Ethernet Crossover Cable*
To
Telephone
Company
Voice
Wire
*Asterisk denotes item included in the DSL modem package.
New Inside Wire (CAT 3 or CAT 5)
for Data (ADSL)
GR
RJ-11 Cable
ADSL Cable
(Straight)*
DSL Modem*
Existing Inside
Wire (CAT3)
Existing Wall
Plate with
RJ-11 Jack
New Wall
Plate with
RJ-45 Jack
GR
6
4
5
2
1
New Inside Wire Connections
7
3
RJ-11
Connector
RJ-45
Connector
