P23T-6 IPS
Operating Manual
Your LCD screen... 5
Important notes 7
Getting started 10
Operation 18
Notes on ergonomic colour adjustment 28
Troubleshooting 29
Explanatory information about
standard ISO 9241-307 31
Technical specification 32
Downloaded from ManualMonitor.com Manuals

Windows 7, Windows Vista and Windows XP are registered trademarks of Microsoft Corporation.
VESA, DDC and DPMS are registered trademarks of Video Electronics Standards Association.
All other trademarks used in this document are trademarks or registered trademarks of
their respective owners and are recognised as being protected.
Copyright © Fujitsu Technology Solutions GmbH 2011
All rights reserved, including rights of translation, reproduction by printing, copying
or similar methods, either in part or in whole.
Offenders will be liable to prosecution and payment of damages.
All rights reserved, including rights created by patent grant or registration of a utility model or design.
Delivery subject to availability. Subject to technical alterations.
Downloaded from ManualMonitor.com Manuals

Contents
Contents
YourLCDscreen... ..................................................................... 5
Targetgroup ............................................................................ 5
Furtherinformation ...................................................................... 6
Notational conventions .................................................................. 6
Important notes ........................................................................ 7
Safetyinstructions ...................................................................... 7
Powercable ............................................................................ 8
Transporting the device .................................................................. 8
Cleaning the device ..................................................................... 8
CEmarking ............................................................................ 9
Power management . . . .................................................................. 9
Disposal and recycling .................................................................. 9
Gettingstarted ......................................................................... 10
Unpacking and checking the delivery . . ................................................... 10
Settingupthedevice .................................................................... 11
Setting up an ergonomic video workstation ............................................ 11
Mounting the monitor base . . . ....................................................... 13
Adjustingheight ..................................................................... 14
Adjustingtheinclination .............................................................. 14
Removingmonitorbase .............................................................. 15
Connecting the device . .............................................................. 16
Connecting cables to the computer ................................................... 17
Operation .............................................................................. 18
Switching thedeviceonandoff .......................................................... 18
Notes on power management ............................................................ 19
Changing the monitorsettings ............................................................ 20
Changing the monitor settings with the buttons of the control panel . ..................... 20
Changing themonitorsettingsusingtheOSD menu .................................... 23
Noteson ergonomiccolouradjustment ................................................ 28
Troubleshooting ....................................................................... 29
Explanatory information about standard ISO 9241-307 . . . . . ............................. 31
Technical specification ................................................................. 32
VESA-DDC-compatibleVGAinterface .................................................... 33
Preset operating modes . . . . . . ........................................................... 33
Most frequent operating modes ....................................................... 33
SUB D port ............................................................................. 34
DVI-D port .............................................................................. 35
DisplayPortsocket ...................................................................... 36
Fujitsu Technology Solutions 3
Downloaded from ManualMonitor.com Manuals

Contents
4 Fujitsu Technology Solutions
Downloaded from ManualMonitor.com Manuals

Your LCD screen...
Your LCD screen...
has a whole range of useful features and functions, e.g.:
• TFT display (Thin Film Transistor; active matrix)
• minimal space requirements thanks to slim casing
• optimum ergonomic characteristics (totally distortion-free, excellent picture
definition and colour purity right into the corners)
• high degree of brightness and good contrast
• high resolution (1920 x 1080)
• presentation of up to 16.7 million colours (in conjunction with an appropriate display adapter)
• automatic scanning of horizontal frequencies from 30 to 82 kHz and refresh rates
(vertical frequencies) from 49 to 76 Hz (absolutely flicker-free)
• digital screen controller with microprocessor for storing 40 different display modes
• freely adjustable colour alignment for matching the screen colours to the
colours of various input and output devices
• convenient operation via integrated OSD (On-Screen-display) menu
• VESA-DDC compatibility
• VESA-FPMPMI compatibility (Flat Panel Monitor Physical Mounting Interface) –
Mounting device for swivel arm and wall bracket
• Plug&Play capability
• Digital video inputs (DVI and display port DP) with HDCP
• power management for reducing power consumption when the computer is not in use
• Compliance with the recommendations according to TCO 5.0
• the monitor fulfills all GS ("Geprüfte Sicherheit", Certified Security) requirements.
This operating manual contains important information you require to start up and run your LCD monitor.
A graphics card (display adapter) with VGA interface or a digital display adapter with DVI interface
or video signal source with DP interface is required to control the LCD monitor. The monitor
processes the data supplied to it by the display adapter. The display adapter or the associated
driver software is responsible for setting the modes (resolution and refresh rate).
When putting the monitor into operation for the first time, the screen display should be
optimally adapted to the display adapter used and adjusted in accordance with your
needs (see chapter "Changing the monitor settings", Page 20.
Target group
You don’t need to be an "expert" to perform the operations described here.
Nonetheless, it is important to always observe the safety notes given in the operating
instructions for the computer and in this manual.
In the event of any problems, please contact your sales office or our Service Desk.
Fujitsu Technology Solutions 5
Downloaded from ManualMonitor.com Manuals

Your LCD screen...
Further information
Details of how you set the resolution and refresh rate are provided in the documentation
for your display adapter and the associated driver software.
For ergonomic reasons, we recommend a screen resolution of 1920 x 1080 pixels.
Because of the technology used (active matrix) an LCD monitor provides a totally
flicker-free picture even with a refresh rate of 60 Hz.
Notational conventions
Pay particular attention to text marked with this symbol. Failure to observe
these warnings could pose a risk to health, damage the device or lead
to loss of data. The warranty will be invalidated if the device becomes
defective through failure to observe these warnings.
Indicates important information for the proper use of the device.
►Indicates an activity that must be performed
Indicates a result
This font indicates data entered using the keyboard in a program dialogue or at
the command line, e.g. your password (Name123) or a command used to
start a program (start.exe)
This font indicates information that is displayed on the screen by a program, e.g.:
Installation is complete.
This font indicates
• terms and texts used in a software interface, e.g.: Click on Save
• names of programs or files, e.g. Windows or setup.exe.
"This font" indicates
• cross-references to another section, e.g. "Safety information"
• cross-references to an external source, e.g. a web address: For more
information, go to "http://ts.fujitsu.com"
• Names of CDs, DVDs and titles or designations of other materials, e.g.:
"CD/DVD Drivers & Utilities" or "Safety" Manual
Key indicates a button on the monitor, e.g: MENU
This font indicates terms and texts that are emphasised or highlighted, e.g.: Do
not switch off the device
6 Fujitsu Technology Solutions
