Fujitsu A17-5 ECO User manual

A17-5 ECO / A19-5 ECO
Operating Manual Display
Downloaded from ManualMonitor.com Manuals

Do you have ...
... any technical questions or problems?
Please contact:
•ourServiceDesk
• your sales partner
• your sales office
The latest information about our products, useful tips, updates etc. is available
on our website: "http://ts.fujitsu.com/support/"
Further information can be found in the Service Desk list:
"http://ts.fujitsu.com/support/servicedesk.html"
Downloaded from ManualMonitor.com Manuals

Downloaded from ManualMonitor.com Manuals

Copyright
© Fujitsu Technology Solutions 2009
2009/09
Published by
Fujitsu Technology Solutions GmbH
Mies-van-der-Rohe-Straße 8
80807 München, Germany
Contact
http://ts.fujitsu.com/support
All rights reserved, including intellectual property rights. Technical data subject to modi cations and delivery subject to availability. Any
liability that the data and illustrations are complete, actual or correct is excluded. Designations may be trademarks and/or copyrights of
the respective manufacturer, the use of which by third parties for their own purposes may infringe the rights of such owner. For further
information see http://ts.fujitsu.com/terms_of_use.html
Order-No. Fujitsu Technology Solutions: A26361-K1338-Z220-1-7619, Edition 1
Downloaded from ManualMonitor.com Manuals

FUJITSU A17-5 ECO/A19-5 ECO
Your LCD screen... 1
Important notes 3
Getting started 7
Operation 13
Notes on ergonomic colour adjustment 21
Troubleshooting 22
Explanatory information about
standard ISO 9241-3 24
Technical data 25
Operating Manual
Downloaded from ManualMonitor.com Manuals

Windows 7, Windows Vista and Windows XP are registered trademarks of Microsoft Corporation.
VESA, DDC and DPMS are registered trademarks of Video Electronics Standards Association.
All other trademarks referred to in this publication are trademarks of the respective
owners, whose legal protection is hereby recognised.
Copyright © Fujitsu Technology Solutions GmbH 2009
All rights, including rights of translation, reproduction by printing, copying or similar
methods, of the whole document or parts thereof, are reserved.
Offenders will be liable for damages.
All rights reserved, including rights created by patent grant or registration of a utility model or design.
Subject to availability and technical modifications.
No liability for content or printing errors.
Downloaded from ManualMonitor.com Manuals

Contents
Contents
YourLCDscreen... ..................................................................... 1
Targetgroup ............................................................................ 1
Furtherinformation ...................................................................... 2
Notational conventions .................................................................. 2
Importantnotes ........................................................................ 3
Safetyinstructions ...................................................................... 3
Powercable ............................................................................ 4
Transporting the device .................................................................. 4
Cleaningthedevice ..................................................................... 4
CEmarking ............................................................................ 5
EnergyStar ............................................................................ 5
Disposal and recycling .................................................................. 6
Getting started ......................................................................... 7
Unpacking and checking the delivery . . ................................................... 7
Settingupthedevice .................................................................... 7
Setting up an ergonomic video workstation ............................................ 8
Adjustingtheinclination .............................................................. 9
Removingmonitorbase .............................................................. 10
Connecting the device . .................................................................. 11
Connecting cables to the monitor . . ................................................... 11
Connecting cables to the computer ................................................... 12
Operation .............................................................................. 13
Switching the deviceonandoff .......................................................... 13
Notes on powermanagement ............................................................ 14
Changing the monitorsettings ............................................................ 15
Changing the monitor settings with the buttons of the control panel . ..................... 15
Changing themonitorsettingsusingtheOSD menu .................................... 16
Noteson ergonomic colouradjustment ................................................ 21
Troubleshooting ....................................................................... 22
Explanatory information about standard ISO 9241-3 .................................... 24
Technicaldata ......................................................................... 25
VESA-DDC-compatibleVGAinterface .................................................... 26
Preset operating modes . . . . . . ........................................................... 26
Most frequent operating modes ....................................................... 26
SUB D port ............................................................................. 27
A26361-K1338-Z220-1-7619, edition 1
Downloaded from ManualMonitor.com Manuals

Contents
A26361-K1338-Z220-1-7619, edition 1
Downloaded from ManualMonitor.com Manuals

Your LCD screen...
Your LCD screen...
has a whole range of useful features and functions, e.g.:
• TFT display (Thin Film Transistor; active matrix)
• minimal space requirements thanks to slim casing
• optimum ergonomic characteristics (totally distortion-free, excellent picture
definition and colour purity right into the corners)
• high degree of brightness and good contrast
• high resolution (1280 x 1024)
• presentation of up to 16.7 million colours (in conjunction with an appropriate display adapter)
• automatic scanning of horizontal frequencies from 31 to 82 kHz and refresh rates
(vertical frequencies) from 56 to 76 Hz (absolutely flicker-free)
• digital screen controller with microprocessor for storing 26 different monitor modes
• freely adjustable colour alignment for matching the screen colours to the
colours of various input and output devices
• convenient operation via integrated OSD (On-Screen-display) menu
• VESA-DDC compatibility
• VESA-FPMPMI compatibility (Flat Panel Monitor Physical Mounting Interface) –
Mounting device for swivel arm and wall bracket
• Plug&Play capability
• power management for reducing power consumption when the computer is not in use
• Compliance with the recommendations according to TCO ’03
• the monitor fulfills all GS ("Geprüfte Sicherheit", Certified Security) requirements.
This operating manual contains important information you require to start up and run your LCD monitor.
A graphics card (display adapter) with VGA interface or a digital display adapter with
DVI interface is required to control the LCD monitor. The monitor processes the data
supplied to it by the display adapter. The display adapter or the associated driver software
is responsible for setting the modes (resolution and refresh rate).
When putting the monitor into operation for the first time, the screen display should be
optimally adapted to the display adapter used and adjusted in accordance with your
needs (see chapter "Changing the monitor settings", Page 15).
Target group
You don’t need to be an "expert" to perform the operations described here.
Nonetheless, it is important to always observe the safety notes given in the operating
instructions for the computer and in this manual.
In the event of any problems, please contact your sales office or our Service Desk.
A26361-K1338-Z220-1-7619, edition 1 1
Downloaded from ManualMonitor.com Manuals

Your LCD screen...
Further information
Details of how you set the resolution and refresh rate are provided in the documentation
for your display adapter and the associated driver software.
For ergonomic reasons, a screen resolution of 1280 x 1024 pixels is recommended.
Because of the technology used (active matrix) an LCD monitor provides a totally
flicker-free picture even with a refresh rate of 60 Hz.
Notational conventions
Pay particular attention to text marked with this symbol. Failure to observe
these warnings could pose a risk to health, damage the device or lead
to loss of data. The warranty will be invalidated if the device becomes
defective through failure to observe these warnings.
Indicates important information for the proper use of the device.
►Indicates an activity that must be performed
Indicates a result
This font indicates data entered using the keyboard in a program dialogue or at
the command line, e.g. your password (Name123) or a command used to
start a program (start.exe)
This font indicates information that is displayed on the screen by a program, e.g.:
Installation is complete.
This font indicates
• terms and texts used in a software interface, e.g.: Click on Save
• names of programs or files, e.g. Windows or setup.exe.
"This font" indicates
• cross-references to another section, e.g. "Safety information"
• cross-references to an external source, e.g. a web address: For more
information, go to "http://ts.fujitsu.com"
• Names of CDs, DVDs and titles or designations of other materials, e.g.:
"CD/DVD Drivers & Utilities" or "Safety" Manual
Key indicates a key on the keyboard, e.g: F10
This font indicates terms and texts that are emphasised or highlighted, e.g.: Do
not switch off the device
