USER'S MANUAL
GA-8SGXL
P4 Titan DDR Motherboard
Pentium®4 Processor Motherboard
Rev. 1001
12ME-8SGXL-1001

- 2 -GA-8SGXL Motherboard
English
Table of Content
WARNING! ............................................................................................... 4
Chapter 1 Introduction ............................................................................ 5
Features Summary ...................................................................................... 5
GA-8SGXL Motherboard Layout ................................................................. 7
Chapter 2 Hardware Installation Process ............................................... 8
Step 1: Install the Central Processing Unit (CPU)....................................... 9
Step1-1 : CPU Installation ................................................................................................ 9
Step1-2 : CPU Heat Sink Installation ............................................................................ 10
Step 2: Install memory modules ................................................................ 11
Step 3: Install expansion cards ................................................................. 12
Step 4: Connect ribbon cables, cabinet wires, and power supply ........... 13
Step 4-1 : I/O Back Panel Introduction ......................................................................... 13
Step 4-2 : Connectors Introduction ................................................................................ 15

Table of Content
English
- 3 -
Chapter 3 BIOS Setup ......................................................................... 21
The Main Menu (For example: BIOS Ver. : F1c) ...................................... 22
Standard CMOS Features......................................................................... 24
Advanced BIOS Features .......................................................................... 27
Integrated Peripherals .............................................................................. 29
Power Management Setup ....................................................................... 32
PnP/PCI Configurations ............................................................................. 34
PC Health Status........................................................................................ 35
Load Fail-Safe Defaults ............................................................................. 36
Load Optimized Defaults ........................................................................... 37
Set Supervisor/User Password .................................................................. 38
Save & Exit Setup ....................................................................................... 39
Exit Without Saving ................................................................................... 40

- 4 -GA-8SGXL Motherboard
English
Computer motherboards and expansion cards contain very delicate Integrated Circuit (IC) chips. To
protect them against damage from static electricity, you should follow some precautions whenever you
work on your computer.
1. Unplug your computer when working on the inside.
2. Use a grounded wrist strap before handling computer components. If you do not have
one, touch both of your hands to a safely grounded object or to a metal object, such as
the power supply case.
3. Hold components by the edges and try not touch the IC chips, leads or connectors, or
other components.
4. Place components on a grounded antistatic pad or on the bag that came with the
components whenever the components are separated from the system.
5. Ensure that the ATX power supply is switched off before you plug in or remove theATX
power connector on the motherboard.
If the motherboard has mounting holes, but they don't line up with the holes on the base and there are
no slots to attach the spacers, do not become alarmed you can still attach the spacers to the mounting
holes. Just cut the bottom portion of the spacers (the spacer may be a little hard to cut off, so be careful
of your hands). In this way you can still attach the motherboard to the base without worrying about short
circuits. Sometimes you may need to use the plastic springs to isolate the screw from the motherboard
PCB surface, because the circuit wire may be near by the hole. Be careful, don't let the screw contact
any printed circuit write or parts on the PCB that are near the fixing hole, otherwise it may damage the
board or cause board malfunctioning.
Installing the motherboard to the chassis...
WARNING!

Introduction
English
- 5 -
Chapter 1 Introduction
Features Summary
Form Factor y30.4cm x 24.3cm ATX size form factor, 4 layers PCB
CPU ySocket 478 for Intel®Micro FC-PGA2 Pentium®4 processor
ySupport Intel®Pentium®4 (Northwood, 0.13 m) processor
ySupport Intel®Pentium®4 Processor with HTTechnology (optional)
yIntel®Pentium®4 400/533MHz FSB
y2nd cache depends on CPU
Chipset ySiS 648 Host/Memory controller
ySiS 963 MuTIOL Media I/O
Memory y3 184-pin DDR DIMM sockets
ySupports DDR333/DDR266/DDR200 DIMM
ySupports Up to 2 un-buffer Double-sided DIMM DDR333 or up to
3 un-buffer Double-sided DIMM DDR266/200
ySupports up to 3GB DRAM (Max)
ySupports only 2.5V DDR DIMM
I/O Control yIT8705F
Slots y1 AGP slot 4X/8X (1.5V) device support
y5 PCI slot supports 33MHz & PCI 2.2 compliant
y1 CNR (Communication and Networking Riser) slot
On-Board IDE y2 IDE bus master (UDMA33/ATA66/ATA100/ATA133) IDE ports
for up to 4 ATAPI devices
ySupports PIO mode3,4 (UDMA 33/ATA66/ATA100/ATA133) IDE
& ATAPICD-ROM
On-Board Peripherals y1 Floppy port supports 2 FDD with 360K, 720K, 1.2M, 1.44M
and 2.88M bytes
y1 Parallel port supports Normal/EPP/ECP mode
y2 Serial ports (COMA & COMB)
y6 USB 2.0/1.1 ports (2 x Rear, 4 xFront by cable)
y1 FrontAudio Connector
Hardware Monitor yCPU/System Fan Revolution detect
to be continued ...

- 6 -GA-8SGXL Motherboard
English
On-Board Sound yAC97 CODEC
yLine In/ Line Out/ Mic In/ SPDIF/ CD In
On-Board LAN yBuilt in RTL8100BL Chipset
y1 RJ45 port
PS/2 Connector yPS/2 Keyboard interface and PS/2 Mouse interface
BIOS yLicensed AWARD BIOS, 2M bit Flash ROM
ySupports Q-Flash
Additional Features yPS/2 Keyboard power on
yPS/2 Mouse power on
ySTR(Suspend-To-RAM)
yAC Recovery
Please set the CPU host frequency in accordance with your processor's specifications.
We don't recommend you to set the system bus frequency over the CPU's specification
because these specific bus frequencies are not the standard specifications for CPU, chipset
and most of the peripherals. Whether your system can run under these specific bus
frequencies properly will depend on your hardware configurations, including CPU, Chipsets,
SDRAM, Cards...tc.

Introduction
English
- 7 -
GA-8SGXL Motherboard Layout
P4 Titan 533
KB_MS
COMA
LPT
USB LAN
COMB
CD_IN
ATX_12V
ATX
RTL
8100BL
F_AUDIO_I
AC97
SPDIF SYS_FAN
PWR_FAN
SiS 648
AGP
CNR F_USB2
F_USB1 PWR_LED
IT8705F
BIOS
F_PANEL
SiS 963
BUZZER
BATTERY
IDE2
GA-8SGXL
IDE1
FDD
RAM_LED
CLR_CMOS
CPU_FAN
DIMM_LED
DDR1 DDR2 DDR3
PC1
PC2
PC3
PC4
PC5
SOCKET 478
MIC_IN
LINE_OUT LINE_IN

- 8 -GA-8SGXL Motherboard
English
To set up your computer, you must complete the following steps:
Step 1- Install the Central Processing Unit (CPU)
Step 2- Install memory modules
Step 3- Install expansion cards
Step 4- Connect ribbon cables, cabinet wires, and power supply
Step 5- Setup BIOS software
Step 6- Install supporting software tools
Chapter 2 Hardware Installation Process
Step 4
Step 4
Step 3
Step 4
Step 2
Step 1

- 9 - Hardware Installation Process
English
Step 1: Install the Central Processing Unit (CPU)
Step1-1 : CPU Installation
00
00
0Please make sure the CPU type is supported by the motherboard.
00
00
0If you do not match the CPU socket Pin 1 and CPU cut edge well, it will cause
improper installation. Please change the insert orientation.
Pin1 indicator
3. CPU Top View
2. Pull the rod to the 90-degree directly.
1. Angling the rod to 65-degree maybe feel
a kind of tight, and then continue pull the
rod to 90-degree when a noise "cough"
made.
4. Locate Pin 1 in the socket and look
for a (golden) cut edge on the CPU
upper corner. Then insert the CPU
into the socket.
Angling the
rod to 650
Socket
Actuation
Lever
Pin1 indicator

- 10 -GA-8SGXL Motherboard
English
Step1-2 : CPU Heat Sink Installation
1. Hook one end of the cooler bracket
to the CPU socket first.
2. Hook the other end of the cooler
bracket to the CPU socket.
00
00
0Please use Intel approved cooling fan.
00
00
0We recommend you to apply the thermal tape to provide better heat
conduction between your CPU and heatsink.
(The CPU cooling fan might stick to the CPU due to the hardening of the
thermal paste. During this condition if you try to remove the cooling fan, you
might pull the processor out of the CPU socket alone with the cooling fan, and
might damage the processor. To avoid this from happening, we suggest you to
either use thermal tape instead of thermal paste, or remove the cooling fan with
extreme caution.)
00
00
0Make sure the CPU fan power cable is plugged in to the CPU fan connector, this
completes the installation.
00
00
0Please refer to CPU heat sink user's manual for more detail installation
procedure.
