How To Assembly advice for D2907 PCI Express Gigabit Ethernet Adapter
Page 1 of 15
ts.fujitsu.com/mainboards
How To
Assembly advice for
Fujitsu Industrial Mainboard D3003-S
& DASH-Manageability LAN Card 2907-Adapter
Contents
Assembly 2
Contact 15

How To Assembly advice for D2907 PCI Express Gigabit Ethernet Adapter
Page 2 of 15
ts.fujitsu.com/mainboards
Assembly
To assemble the LAN Card D2907-Adapter into the Fujitsu Industrial Mainboard D3003-S
please perform the following steps:
1
IPC Chassis closed
2
Open chassis with kit accessories
3
HDD bracket
If you would like to configure the
system with a HDD you have to use
the HDD bracket.
Therefore unscrew the HDD bracket
and remove it.

How To Assembly advice for D2907 PCI Express Gigabit Ethernet Adapter
Page 3 of 15
ts.fujitsu.com/mainboards
4
D3003-S Mainboard with cooling
unit
5
Please mount the cooling unit with
four screws as shown on the picture
6
D3003-S in IPC Chassis
Insert the mainboard into the
chassis

How To Assembly advice for D2907 PCI Express Gigabit Ethernet Adapter
Page 4 of 15
ts.fujitsu.com/mainboards
7
Be aware of the exact fitting of the
board within the I/O-shield
8
Mount the Mainboard into the
chassis with four screws

How To Assembly advice for D2907 PCI Express Gigabit Ethernet Adapter
Page 5 of 15
ts.fujitsu.com/mainboards
9
Main memory –optional
Insert the main memory from an
oblique angle into the slot
10
Main memory –optional
Push the memory carefully from top
onto the mainboard until the clamp
click into it form the side
11
mSATA –optional
Insert the mSATA card from an
oblique angle into the slot

How To Assembly advice for D2907 PCI Express Gigabit Ethernet Adapter
Page 6 of 15
ts.fujitsu.com/mainboards
12
mSATA –optional
Push the memory carefully from top
onto the mainboard until the clamp
click into it.
Take special care for the plasic tips!
13
WLAN module –optional
If you want to use the WLAN
module,
please break out carefully the metal
part
14
WLAN module –optional
Remove the screw for the WLAN
module

How To Assembly advice for D2907 PCI Express Gigabit Ethernet Adapter
Page 7 of 15
ts.fujitsu.com/mainboards
15
WLAN module –optional
Insert the WLAN module
Pay attention that the metal nose
clicks into the module
16
WLAN module –optional
Connect the WLAN module with the
USB cable
17
WLAN module –optional
Connect the WLAN USB cable with
the mainboard

How To Assembly advice for D2907 PCI Express Gigabit Ethernet Adapter
Page 8 of 15
ts.fujitsu.com/mainboards
18
WLAN module –optional
Cover the WLAN module with the
plastic over
19
WLAN module –optional
Fix the plastic cover with two screws
20
HDD –optional
HDD bracket
If you would like to configure the
system with a HDD you have to use
the HDD bracket.

How To Assembly advice for D2907 PCI Express Gigabit Ethernet Adapter
Page 9 of 15
ts.fujitsu.com/mainboards
21
HDD –optional
The HDD can be fixed with four
screws at the bottom site of the
bracket.
22
HDD –optional
Slide the HDD bracket into the
mounting form
23
HDD –optional
Fix the HDD bracket to the
mounting form with a screw

How To Assembly advice for D2907 PCI Express Gigabit Ethernet Adapter
Page 10 of 15
ts.fujitsu.com/mainboards
24
HDD –optional
Connect the HDD with the
mainboard
25
HDD –optional
Connect the HDD with the
mainboard

How To Assembly advice for D2907 PCI Express Gigabit Ethernet Adapter
Page 11 of 15
ts.fujitsu.com/mainboards
26
Riser Card –optional extension card
Use the PCI slot to install the riser
card.
Pay attention to the right fitting
and be aware of the cable routing
of th HDD and WLAN module
27
D2907 LAN Card –optional
Fix the bracket to the LAN card with
two screws
28
D2907 LAN Card –optional
Connect the USB cable to the LAN
card

How To Assembly advice for D2907 PCI Express Gigabit Ethernet Adapter
Page 12 of 15
ts.fujitsu.com/mainboards
29
D2907 LAN Card –optional
Use the USB cable to connect the
LAN module with the mainboard.
30
D2907 LAN Card –optional
Slide the LAN Card from the side
into the riser card and fix it with a
screw.
31
To fix the riser card in this position,
add the crossing strut.
Use one screw to mount the strut
from the rear side.

How To Assembly advice for D2907 PCI Express Gigabit Ethernet Adapter
Page 13 of 15
ts.fujitsu.com/mainboards
32
Pay attention to the right fitting.
33
Close the IPC Chassis
34
AC-plug fixture
At the rear side of the chassis it is
possible to fix the AC-plug with a
fortification if necessary.

How To Assembly advice for D2907 PCI Express Gigabit Ethernet Adapter
Page 14 of 15
ts.fujitsu.com/mainboards
35
Chassis mounting / foot assembly
36
Mount the Chassis with three screws
37
Connect with the LAN cable

How To Assembly advice for D2907 PCI Express Gigabit Ethernet Adapter
Page 15 of 15
ts.fujitsu.com/mainboards
If you have any further questions please contact the
OEM Team.
Contact:
Fujitsu Technolgy Solutions GmbH:
OEM Mainboard Sales
Phone: +49 (0) 821 - 8043822
Fax: [phone]
