Fujitsu MOTORKIT-91F267-MC User manual

Fujitsu Microelectronics Europe
User Guide
FMEMCU-UG-910052-13
FRLITE FAMILY
EVALUATION BOARD
MOTORKIT-91F267-MC
USER GUIDE

MotorKit-91F267-MC User Guide
- 2 - © Fujitsu Microelectronics Europe GmbH
Revision History
Date Issue
2006/09/20 V0.9, CHa, first draft
2007/01/12 V1.0 First release
2007/01/19 V1.1 Recycling notice added
2007/01/26 V1.2 Recycling notice changed, typo corrected
2007/09/10 V1.3 general revision
This document contains 33 pages.

MotorKit-91F267-MC User Guide
© Fujitsu Microelectronics Europe GmbH - 3 -
Warranty and Disclaimer
To the maximum extent permitted by applicable law, Fujitsu Microelectronics Europe GmbH restricts
its warranties and its liability for the MotorKit-91F267-MC Board and all its deliverables (eg.
software include or header files, application examples, target boards, evaluation boards, engineering
samples of IC’s etc.), its performance and any consequential damages, on the use of the Product in
accordance with (i) the terms of the License Agreement and the Sale and Purchase Agreement under
which agreements the Product has been delivered, (ii) the technical descriptions and (iii) all
accompanying written materials. In addition, to the maximum extent permitted by applicable law,
Fujitsu Microelectronics Europe GmbH disclaims all warranties and liabilities for the performance of
the Product and any consequential damages in cases of unauthorised decompiling and/or reverse
engineering and/or disassembling. Note, the MotorKit-91F267-MC Board and all its deliverables
are intended and must only be used in an evaluation laboratory environment.
1. Fujitsu Microelectronics Europe GmbH warrants that the Product will perform substantially in
accordance with the accompanying written materials for a period of 90 days form the date of
receipt by the customer. Concerning the hardware components of the Product, Fujitsu
Microelectronics Europe GmbH warrants that the Product will be free from defects in material
and workmanship under use and service as specified in the accompanying written materials
for a duration of 1 year from the date of receipt by the customer.
2. Should a Product turn out to be defect, Fujitsu Microelectronics Europe GmbH´s entire liability
and the customer’s exclusive remedy shall be, at Fujitsu Microelectronics Europe GmbH´s
sole discretion, either return of the purchase price and the license fee, or replacement of the
Product or parts thereof, if the Product is returned to Fujitsu Microelectronics Europe GmbH in
original packing and without further defects resulting from the customer’s use or the transport.
However, this warranty is excluded if the defect has resulted from an accident not attributable
to Fujitsu Microelectronics Europe GmbH, or abuse or misapplication attributable to the
customer or any other third party not relating to Fujitsu Microelectronics Europe GmbH.
3. To the maximum extent permitted by applicable law Fujitsu Microelectronics Europe GmbH
disclaims all other warranties, whether expressed or implied, in particular, but not limited to,
warranties of merchantability and fitness for a particular purpose for which the Product is not
designated.
4. To the maximum extent permitted by applicable law, Fujitsu Microelectronics Europe GmbH´s
and its supplier’s liability are restricted to intention and gross negligence.
NO LIABILITY FOR CONSEQUENTIAL DAMAGES
To the maximum extent permitted by applicable law, in no event shall Fujitsu
Microelectronics Europe GmbH and its suppliers be liable for any damages whatsoever
(including but without limitation, consequential and/or indirect damages for personal
injury, assets of substantial value, loss of profits, interruption of business operation,
loss of information, or any other monetary or pecuniary loss) arising from the use of
the Product.
Should one of the above stipulations be or become invalid and/or unenforceable, the remaining
stipulations shall stay in full effect

MotorKit-91F267-MC User Guide
- 4 - © Fujitsu Microelectronics Europe GmbH
0 Contents
REVISION HISTORY.............................................................................................................. 2
WARRANTY AND DISCLAIMER........................................................................................... 3
0CONTENTS........................................................................................................................4
1OVERVIEW........................................................................................................................6
1.1 Abstract..................................................................................................................... 6
1.2 Features.................................................................................................................... 6
1.3 General Description .................................................................................................. 7
2INSTALLATION................................................................................................................. 8
2.1 Jumper settings for MB91F267................................................................................. 9
3JUMPERS AND SWITCHES ........................................................................................... 12
3.1 Operating Mode ...................................................................................................... 12
3.2 Power Supply (JP: 13, 14, 28, 29, 31, 32, 63) ........................................................ 12
3.3 Analog Power Supply Voltage (JP: 15, 16, 21, 22)................................................. 14
3.4 UART0 (JP: 3, 5, 12)............................................................................................... 15
3.5 UART1 (JP: 25, 26, 27)........................................................................................... 15
3.6 CAN0 (JP: 30, 33, 34, 35)....................................................................................... 16
3.7 Reset generation (JP: 17, 19, 20, 23, 24)............................................................... 17
3.8 Buttons SW1, SW2, SW3, SW4, SW5, SW6, SW7 (JP: 2, 6, 7, 8, 10, 11)............. 18
3.9 Internal gate drivers (JP: 38, 39, 44, 45, 49, 50)..................................................... 19
3.10 Current measurement (JP: 43, 46, 48, 51, 59, 41, 47, 52, 53)................................ 20
3.11 Voltage measurement (JP: 43, 46, 48, 51, 59) ....................................................... 21
3.12 User potentiometers (JP: 1, 4, 9)............................................................................ 21
3.13 Hall sensor and encoder interface (JP: 54, 56, 57, 60, 61, 62)............................... 22
3.14 Over-current / Over-voltage DTTI (JP: 55, 58)........................................................ 22
4PROGRAMMING THE INTERNAL FLASH..................................................................... 23
5CONNECTORS................................................................................................................ 24
5.1 Power connector (X6) ............................................................................................. 24
5.2 DC bus power connector (J5) ................................................................................. 24
5.3 Pin headers (J1-J4)................................................................................................. 24
5.4 UART0, UART1 connectors (X1, X2)...................................................................... 25
5.5 CAN connector (X3)................................................................................................ 25
5.6 User LEDs & LC-Display (optional)......................................................................... 25
5.7 PWM LEDs.............................................................................................................. 25
5.8 Hall sensor connector (J12).................................................................................... 26

MotorKit-91F267-MC User Guide
© Fujitsu Microelectronics Europe GmbH - 5 -
5.9 Encoder connector (J13)......................................................................................... 26
5.10 Connector for external inverter board (J6, J7) ........................................................ 27
5.11 Voltage, current and over-voltage / over-current control points (J8, J10, J11) ....... 28
6SILK PLOT OF THE BOARD .......................................................................................... 29
7PCB HISTORY................................................................................................................. 30
8RELATED PRODUCTS ................................................................................................... 31
9INFORMATION IN THE WWW........................................................................................ 32

MotorKit-91F267-MC User Guide
- 6 - © Fujitsu Microelectronics Europe GmbH
1 Overview
1.1 Abstract
The MotorKit-91F267-MC is a multifunctional evaluation board for the Fujitsu 32-Bit FRlite
Flash microcontroller MB91F267N.
The board allows the designer immediately to start with the software development and
evaluation of low voltage three-phase motor control applications before his own final target
system is available.
1.2 Features
●Supports the MB91F267(N) MCU in FPT-64P-M23 package
●Flexible power supply voltage system:
cDC bus input 10-24V 15A max. for motor current supply
■Default configuration max. 6A (limited by shunt resistor power dissipation)
cLogic supply from DC Bus or separate input 8-15V
●10-20V gate driver supply (with optional 15V regulator) and 5V internal logic supply,
Power-LED
●In-Circuit serial Flash programming
●All resources available for evaluation
●All MCU pins routed to edge connectors
●4 MHz main crystal
●Two UART interfaces (isolated)
●One CAN interface (isolated)
●8 User LEDs, optional: alphanumeric standard LC-Display connectable
●Reset-Button, Reset-LED
●NMI button, DTTI button and 4 general-purpose user buttons
●Integrated low-voltage power stage with gate drivers for three-phase motors
●Integrated current measurement for two phases and bus current
●Integrated voltage measurement for all three phase voltages and DC bus voltage
●Hardware over-current and over-voltage detection interfaced to DTTI input
●Connector for external inverter board
●Interface for Hall sensors and incremental encoder
●Three user potentiometers connected to AN8-AN10
The target board is delivered with an MB91F267N microcontroller.
This microcontroller contains a 'burn-in'-boot loader for Flash programming.

MotorKit-91F267-MC User Guide
© Fujitsu Microelectronics Europe GmbH - 7 -
This board must only be used for test applications
in an evaluation laboratory environment.
1.3 General Description
The MotorKit-91F267-MC supports the 32bit MB91F267(N) Flash microcontroller.
The board is supplied with a socketed 4MHz crystal as the main oscillation clock. Using the
internal PLL of the µC, internal clock rates up to 32MHz can be achieved.
Two separate RS232 transceivers are available to connect two on-chip UARTs to 9-pin D-
Sub connectors (X1, X2). The transceivers generate the adequate RS232 levels for the
receive (RXD) and transmit (TXD) lines. The DTR line can be selected with jumpers (JP17,
JP19) to generate a system reset. The RTS signal can be shortcut to CTS using the jumpers
JP5 and JP26. The signals to and from the UART interfaces can be galvanically isolated by
optocouplers and a separate supply by a DC-DC converter to avoid interference with a host
PC.
In-circuit-programming (asynchronous) can be done via UART0 (X1) using the burn-in
bootloader of the microcontroller.
One CAN transceiver is available to integrate the board in a Controller Area Network. The
CAN interface can be opto-isolated or connected to the MCU directly independently of the
UART interfaces.
All pins of the microcontroller (except oscillator pins X1 and X0) are connected to the pin
headers J1-J4 and are directly available to the user. Furthermore, the most important signals
like voltage and current measurements are available on separate pin headers.
The on-board voltage regulators allow the user to configure the board to fit a variety of
situations. The board includes a 15V-regulator for the gate drivers, as well as a 5V-regulator
for the MCU and logic supply. The 15V regulator can be bypassed (JP20) if the source input
voltage is in the range of 10-20V. The 5V regulator can use a separate 8-15V input or use
the gate drive supply as regulator input. Also, solder jumpers (JP29 and JP63) can be set to
supply the DC bus from the logic power supply input (X6), e.g. when using a small motor
(<3A).
There are seven push button switches on the board, which can be connected to input pins of
the microcontroller. SW1 (NMI) can be connected to the NMI pin. SW2-SW5 can be
connected to various I/O pins of the MCU. Additionally, by setting JP7, all buttons can trigger
the external interrupt 7, which is normally connected only to SW2 ('wired-OR'). This allows
reading all buttons in a single ISR and saves external interrupt pins. SW6 is the system reset
button, and SW7 triggers the fault input pin (DTTI) of the MCU, which can shut down the
PWM output in case of over-current or over-voltage.
Eight user-LEDs are connected via a 1K pull-up resistor network to Port P00-P07. If these
LEDs are not required, the resistor network can be removed to disconnect the LEDs and free
the port.
The operating mode of the microcontroller (Program / Run) is selected by JP18.
The board provides current and voltage measurement circuits for the motor phases and the
DC bus which are connected to the ADC of the microcontroller. The signal conditioning
circuit fits a variety of applications. Some applications might require a faster or slower
filtering e.g. of the voltage measurement; this can be done by changing R/C values or
adding capacitors in the current measurement circuit (e.g. C70, C72, C75, C77).

MotorKit-91F267-MC User Guide
- 8 - © Fujitsu Microelectronics Europe GmbH
2 Installation
Carefully remove the board from the shipping carton.
Check if there are any damages before power is applied to the evaluation board.
For the logic power supply a DC input voltage of 9V – 15V is recommended. The
positive voltage (+) must be connected to the shield, and ground (GND) must be
connected to the center of the connector X6!
By default, the DC bus is supplied through the screw terminal J5. Connect to an
adequate power supply for the motor in use (24V max.). Be aware that this input is not
protected against false polarity. Always connect ‘+’ to the terminal close to the upper
board edge, and GND to the one close to X6.
Further, it is strongly recommended to use a laboratory DC power supply with
adjustable current limitation with this board. Otherwise, in case of software or
hardware malfunctions or false configurations, high currents can flow and damage
the power supply and/or the board and lead to overheating by excessive power
dissipation.
After power-on, the green power-on LEDs (LD2 and LD3) should be on, depending on the
configuration of the corresponding jumpers. If the LEDs do not light, switch off the power
supply and check the jumper settings according to the desired configuration.
By default, the evaluation board is equipped with an MB91F267N Microcontroller.
The in-circuit programming allows the user to program an own application into the Flash
memory. Programming of the Flash memory is described in chapter 4.
Depending on the power supply used for the DC bus input, it might be necessary to protect
the power supply against reverse current. This can occur when shutting down the power
supply with the board attached, or when an attached motor is externally accelerated or
quickly decelerated and thereby works as a generator. This protection can be done by a
diode of sufficient current capability. Since many power supplies are vulnerable to this issue,
inserting a shottky diode is recommended.
Depending on the application, the use of an external brake chopper circuit might be
necessary. Typical applications are high-speed or varying load applications, such as
centrifuges or elevators, in which the motor can be also moved by the load. Especially if the
motor can be externally accelerated beyond the nominal speed, high voltages can occur
which may damage the hardware.
The board is shipped with power transistors in a D2PAK package. For additional flexibility,
there are also soldering options for power MOSFETS in TO-220 packages, which can be
mounted on external heat sinks. In this case, probably also the current measurement shunts
should be replaced with a smaller value or bypassed to reduce heat.

MotorKit-91F267-MC User Guide
© Fujitsu Microelectronics Europe GmbH - 9 -
2.1 Jumper settings for MB91F267N
Jumper Description / Function Type Default Coordinates
JP1 P1 - AN8 Jumper 2 pin Closed B22
JP2 NMI Jumper 2 pin Closed D12
JP3 OC1 bypass Solder JP 2 pin Open C8
JP4 P2 - AN9 Jumper 2 pin Closed B23
JP5 UART0 RTS-CTS Jumper 2 pin Closed B4
JP6 SW2 Jumper 2 pin Closed D12
JP7 Common INT7 for SW2-SW5 Jumper 2 pin Closed E9
JP8 SW3 Jumper 2 pin Closed D12
JP9 P3 – AN10 Jumper 2 pin Closed B25
JP10 SW4 Jumper 2 pin Closed C12
JP11 SW5 Jumper 2 pin Closed C12
JP12 OC2 bypass Solder JP 2 pin Open C7
JP13 Vcc = Vcc_com Solder JP 2 pin Open G7
JP14 GND = GND_com Solder JP 2 pin Open H7
JP15 AVcc Jumper 2 pin Closed B19
JP16 AVRH2 Jumper 2 pin Closed B19
JP17 Reset A/B Jumper 3 pin Open D6
JP18 Mode (RUN/PGM) Jumper 3 pin 1-2 D15
JP19 DTR Jumper 2 pin Open B9
JP20 OC3 bypass Solder JP 2 pin Open D7
JP21 AVRH1 Jumper 2 pin Closed B19
JP22 AVss Jumper 2 pin Closed B21
JP23 External Reset Jumper 2 pin Closed B12
JP24 Watchdog Jumper 2 pin Open B14
JP25 OC4 bypass Solder JP 2 pin Open F8
JP26 UART1 RTS-CTS Jumper 2 pin Closed E4
JP27 OC5 bypass Solder JP 2 pin Open F7
JP28 VCC15 Direct / Reg Jumper 3 pin 1-2 M9
JP29 Power connect Solder JP 2 pin Closed M4
JP30 OC6 bypass Solder JP 2 pin Open J8
JP31 Power Jumper 2 pin Closed L4
JP32 VCC5V Source 15V / Vbus Jumper 3 pin 2-3 L6
JP33 CAN GND Select Solder JP 3 pin 1-2 G5
JP34 CAN Vcc Select Solder JP 3 pin 1-2 H5
JP35 OC7 bypass Solder JP 2 pin Open J7
JP36 Phase A voltage sense int/ext Jumper 3 pin 1-2 J23
JP37 Phase B voltage sense int/ext Jumper 3 pin 1-2 J23
JP38 RTO0 PWM Solder JP 2 pin Closed J18
JP39 RTO1 PWM Solder JP 2 pin Closed J18
JP40 Phase C voltage sense int/ext Jumper 3 pin 1-2 J23
JP41 Phase A shunt bypass Solder JP 2 pin Closed M19
JP42 Bus voltage sense int/ext Jumper 3 pin 1-2 H23
JP43 Phase A current sense int/ext Jumper 3 pin 1-2 H18
JP44 RTO2 PWM Solder JP 2 pin Closed J15

MotorKit-91F267-MC User Guide
- 10 - © Fujitsu Microelectronics Europe GmbH
Jumper Description / Function Type Default Coordinates
JP45 RTO3 PWM Solder JP 2 pin Closed J15
JP46 Phase B current sense int/ext Jumper 3 pin 1-2 G18
JP47 Phase B shunt bypass Solder JP 2 pin Closed M15
JP48 Phase C current sense ext Jumper 2 pin Open H23
JP49 RTO4 PWM Solder JP 2 pin Closed J18
JP50 RTO5 PWM Solder JP 2 pin Closed J18
JP51 DC Bus current sense int/ext Jumper 3 pin 1-2 G15
JP52 Phase C shunt bypass Solder JP 2 pin Closed M12
JP53 DC Bus shunt bypass Solder JP 2 pin Open M20
JP54 Hall A IC0 / INT0 Jumper 3 pin 1-2 M22
JP55 Over-current DTTI Jumper 2 pin Open H12
JP56 Hall B IC1 / INT1 Jumper 3 pin 1-2 M22
JP57 Hall C IC2 / INT2 Jumper 3 pin 1-2 M21
JP58 Over-voltage DTTI Jumper 2 pin Open G12
JP59 Phase current offset Solder JP 3 pin 2-3 G18
JP60 Encoder A - IC0 Jumper 2 pin Open M24
JP61 Encoder B - IC1 Jumper 2 pin Open M24
JP62 Encoder Z – INT3 Jumper 2 pin Open M23
JP63 Bus power connect Solder JP 2 pin Open M4

MotorKit-91F267-MC User Guide
© Fujitsu Microelectronics Europe GmbH - 11 -
A B C D E F G H J K L M N
1 1
2 2
3 3
4 4
5 5
6 6
7 7
8 8
9 9
10 10
11 11
12 12
13 13
14 14
15 15
16 16
17 17
18 18
19 19
20 20
21 21
22 22
23 23
24 24
25 25
A B C D E F G H J K L M N

MotorKit-91F267-MC User Guide
- 12 - © Fujitsu Microelectronics Europe GmbH
3 Jumpers and Switches
This chapter describes the jumpers and potentiometers to configure the various features of
the evaluation board. The default settings are shaded in the following tables.
3.1 Operating Mode
JP18 is used to select between serial Flash programming (UART0) and normal run mode.
Jumper Setting Function
1-2 Run
JP18 2-3 Program
3.2 Power Supply (JP: 13, 14, 28, 29, 31, 32, 63)
The evaluation board supports a variety of different input voltages. The regulator input for
MCU and logic supply can be provided either by a separate power input (X6), by the gate
driver supply voltage or it can be connected directly to the DC bus. The supply voltage for
the gate drive circuits must be in the range of 10-20V and can be derived either from the DC
bus or X6. A 15V voltage regulator can be inserted in case the used input voltage is higher
than 20V.
The UART and CAN interfaces can be optically isolated. Therefore, a DC-DC converter and
optocouplers are supplied on the board. They are placed in sockets, and can be bypassed
when not present.
JP13 Vcc_COM = VCC5
This jumper connects the transceiver supplies with the MCU supply when no DC-DC
converter is used (no galvanic decoupling)
JP14 GND_COM = GND
This jumper connects the transceiver ground with the MCU ground when no DC-DC
converter is used (no galvanic decoupling)
JP28 VCC15V Source
This jumper selects whether the gate driver supply voltage is fed from the 15V
voltage regulator or directly from the DC bus voltage
JP29 P_connect
This jumper can be used to connect the DC bus and gate driver supply to the supply
input X6. This can be useful when a small motor is used and the entire system is
powered by X6, or when JP63 is open, it is also possible to supply the gate driver
from X6 and only the DC bus by J5 (default).
JP31 Power
This jumper can be used to switch the logic supply on and off.

MotorKit-91F267-MC User Guide
© Fujitsu Microelectronics Europe GmbH - 13 -
JP32 VCC5V source
This jumper selects the source for the 5V voltage regulator input. This can either be
the gate driver voltage, or X6/JP29.
JP63 Bus power connect
This jumper connects the DC bus voltage input J5 with the logic and gate driver
supply. To vary the DC bus voltage from 0-30V independently of the other supply
voltages, open JP63 and supply 10-15V at X6. JP28 and JP32 should then be in 1-2
position.
Jumper Setting Description
Open DC-DC converter ‘+’ used for transceiver supply
JP13 Closed Same supply as MCU used for transceivers (Vcc5)
Open DC-DC converter ‘-’ used for transceiver supply
JP14 Closed Same GND as MCU used for transceivers (GND)
1 - 2 Bypass 15V regulator (Source voltage 10-20V)
JP28 2 - 3 Insert 15V regulator (Source voltage >18V)
Closed common inputs for 15V and 5V regulator
JP29 Open separate inputs for 15V and 5V regulator
Closed Logic supply input enabled
JP31 Open Logic supply input disabled
1-2 5V regulator input connected to VCC15
JP32 2-3 5V reg. input connected to X6 and/or 15V reg. input
Closed connect DC bus voltage to logic and gate driver
supply
JP63 Open J5 supplies only the DC bus
By default, the board is configured for DC bus voltage 0-24V and separate logic supply input
(X6) 10-20V (12V recomm.)
WARNING: There is no protection diode between the DC bus input (J5) and the
DC bus. Applying a voltage with reverse polarity can cause damage to the
power stage.
Always connect ‘+’ to the terminal close to the upper board edge, and GND to
the one close to X6.
Always use a laboratory DC power supply with adjustable current limitation
with this board. Otherwise, in case of software or hardware malfunctions or
false configurations, high currents can flow and damage the power supply
and/or the board and lead to overheating by excessive power dissipation.

MotorKit-91F267-MC User Guide
- 14 - © Fujitsu Microelectronics Europe GmbH
3.3 Analog Power Supply Voltage (JP: 15, 16, 21, 22)
The power supply as well as the positive reference voltages for the A/D-converter can be
provided internally or externally.
JP15, JP22 connect power supply voltages (AVcc and AVss)
JP16, JP21 connect reference voltages (AVRH1, AVRH2 to AVcc)
Jumper Setting Description
Closed AVcc is connected to Vcc
JP15 (AVcc) Open AVcc is disconnected from Vcc
Closed AVRH2 is connected to AVcc
JP16 (AVRH2) Open AVRH defined by resistor network*1
Closed AVRH1 is connected to AVcc
JP21 (AVRH1) Open AVRH defined by resistor network*1
Closed AVss is connected to GND
JP22 (AVss) Open AVss is disconnected from GND
*1By default the resistor networks are not mounted on the board
By default, the A/D-converter supply and reference voltages are the same as the
microcontroller supply voltage.
Note:
If JP15, JP16 and J11 are open, the user has to supply an adequate analogue voltage
supply (AVcc and AVss) to the A/D-converter.
If JP16 is open, the resistors R22 and R27 define AVRH2.
If JP21 is open, the resistors R21 and R26 define AVRH1.
By default the resistor networks are not mounted on the board.

MotorKit-91F267-MC User Guide
© Fujitsu Microelectronics Europe GmbH - 15 -
3.4 UART0 (JP: 3, 5, 12)
One RS232-transceiver (U2, X1) can be connected to the microcontrollers UART interface 0.
JP3, JP12 (Solder JP) bypass OC1, OC2 or disconnect UART interface when OC1,2 not
installed
JP5 Some Flash-programming-Tools need a connection between CTS and RTS
Jumper Setting Description
Closed UART 0 RX is directly connected to the MCU
JP3 (UART0 RxD) Open UART 0 RX is connected to the MCU via OC1
Closed UART 0 TX is directly connected to the MCU
JP12 (UART0 TxD) Open UART 0 TX is connected to the MCU via OC2
Closed RTS and CTS of X1 are connected
JP31 (RTS-CTS) Open RTS and CTS of X1 are not connected
3.5 UART1 (JP: 25, 26, 27)
One RS232-transceiver (U4, X2) can be connected to the microcontrollers UART interface 1.
JP25, JP27 (Solder JP) bypass OC4, OC5 or disconnect UART interface when OC4,5 not
installed
JP26 Some Flash-programming-Tools need a connection between CTS and RTS
Jumper Setting Description
Closed UART 1 RX is directly connected to the MCU
JP25 (UART1 RxD) Open UART 1 RX is connected to the MCU via OC4
Closed UART 1 TX is directly connected to the MCU
JP27 (UART1 TxD) Open UART 1 TX is connected to the MCU via OC5
Closed RTS and CTS of X2 are connected
JP26 (RTS-CTS) Open RTS and CTS of X2 are not connected

MotorKit-91F267-MC User Guide
- 16 - © Fujitsu Microelectronics Europe GmbH
3.6 CAN0 (JP: 30, 33, 34, 35)
One CAN-transceiver (U5, X3) can be connected to the microcontrollers CAN interface.
JP30, JP35 (Solder JP) bypass OC6, OC7 or disconnect CAN interface when OC6,7 not
installed
JP33 Select CAN ground (MCU or COM)
JP34 Select CAN VCC (MCU or COM)
Jumper Setting Description
Closed CAN0 RX is directly connected to the MCU
JP30 Open CAN0 RX is connected to the MCU via OC6
Closed CAN0 TX is directly connected to the MCU
JP35 Open CAN0 TX is connected to the MCU via OC7
1-2 CAN ground = GND_COM
JP33 2-3 CAN ground = GND
1-2 CAN VCC = VCC_COM
JP34 2-3 CAN VCC = VCC5

MotorKit-91F267-MC User Guide
© Fujitsu Microelectronics Europe GmbH - 17 -
3.7 Reset generation (JP: 17, 19, 20, 23, 24)
Additionally to the internal Power-On reset, the microcontroller can be reset by an external
reset circuit (Voltage monitor) and by the UARTs DTR lines.
JP17 Selects whether UART0 or UART1 are used for reset generation
JP19 This jumper enables the reset generation by the UARTs.
JP20 This jumper can be used to bypass OC3.
JP23 This jumper connects the reset circuit to the MCU.
JP24 This jumper enables the watchdog function of the reset circuit. When it is set, the
user program has to re-trigger it periodically by toggling a port pin (P37), or else
the system is reset.
Jumper Setting Description
1-2 DTR of UART1 is selected
JP17 (Reset A/B) 2-3 DTR of UART0 is selected
Open UART reset generation is disabled
JP19 (DTR) Closed UART reset generation is enabled
Open The DTR signal is connected to the reset circuit via
OC3
JP20 (OC3 bypass) Closed The DTR signal is connected directly to the reset
circuit.
Closed External Reset generation is active
JP23 (Ext. Reset) Open No external Reset generation
Closed The watchdog function of U3 is enabled
JP24 (Watchdog) Open The watchdog function of U3 is disabled
Note:
While a reset signal is asserted the red Reset LED (LD1) is lit.
During normal operation, this LED should be off.
If the reset LED stays on, check the power supply input voltage, and the above jumper
settings.

MotorKit-91F267-MC User Guide
- 18 - © Fujitsu Microelectronics Europe GmbH
3.8 Buttons SW1, SW2, SW3, SW4, SW5, SW6, SW7 (JP: 2, 6, 7, 8, 10, 11)
JP2 JP2 connects SW1 to the NMI (Non-Maskable Interrupt) of the MCU.
JP6, JP8, JP10, JP11
Four user push buttons (SW2-SW5) can be connected to the microcontroller.
JP7 By setting JP7, all user buttons (SW2-SW5) can also trigger external interrupt 7
(wired-OR).
Jumper Setting Description
Closed SW1 is connected to the NMI input (Pin 14) of the MCU
JP2 (SW1) Open No connection of SW1 to the microcontroller
Closed SW2 is connected to INT7 (Pin50) of the MCU.
JP6 (SW2) Open No connection of SW2 to the microcontroller
Closed SW3 is connected to P27 (Pin41) of the MCU
JP8 (SW3) Open No connection of SW3 to the microcontroller
Closed SW4 is connected to P24/CKI (Pin38) of the MCU
JP10 (SW4) Open No connection of SW4 to the microcontroller
Closed SW5 is connected to P22/PWI0 (Pin36) of the MCU
JP11 (SW5) Open No connection of SW5 to the microcontroller
Closed All buttons also trigger external interrupt 7
JP7 (Common
INT)) Open Independent operation of SW2-SW5
SW6 serves as manual reset button. It is directly connected to the MCUs reset input pin
(INITX, Pin51).
SW7 is connected to the DTTI input of the MCU. When this function is activated in software,
the DTTI input can shut down the PWM output of the MCU (e.g. fault or over-current
protection). Refer to the MB91F265 Series hardware manual for details of the DTTI function

MotorKit-91F267-MC User Guide
© Fujitsu Microelectronics Europe GmbH - 19 -
3.9 Internal gate drivers (JP: 38, 39, 44, 45, 49, 50)
JP38, JP39, JP44, JP45, JP49, JP50
These solder jumpers connect the MCUs PWM outputs to the on-board gate
driver ICs (IC2, IC3, IC4).
Jumper Setting Description
Closed RTO0 is connected to the PWM1H gate driver input.
JP38 Open RTO0 is not connected to the on-board gate drivers.
Closed RTO1 is connected to the PWM1L gate driver input.
JP39 Open RTO1 is not connected to the on-board gate drivers.
Closed RTO2 is connected to the PWM2H gate driver input.
JP44 Open RTO2 is not connected to the on-board gate drivers.
Closed RTO3 is connected to the PWM2L gate driver input.
JP45 Open RTO3 is not connected to the on-board gate drivers.
Closed RTO4 is connected to the PWM3H gate driver input.
JP49 Open RTO4 is not connected to the on-board gate drivers.
Closed RTO5 is connected to the PWM3L gate driver input.
JP50 Open RTO5 is not connected to the on-board gate drivers.

MotorKit-91F267-MC User Guide
- 20 - © Fujitsu Microelectronics Europe GmbH
3.10 Current measurement (JP: 43, 46, 48, 51, 59, 41, 47, 52, 53)
JP43, JP48, JP48, JP51
These jumpers select if the internal or external current signals are connected to
the MCU analog inputs AN0-AN3.
JP59 This solder jumper selects an offset defined by R99 and R102 which is added
to the internal phase current values (2.5V by default, R99 = R102 = 10k)
JP41, JP47, JP52, JP53
These solder jumpers can be used to bypass the measurement shunts, when
they are not mounted or to reduce the power dissipation when not used by the
application.
Jumper Setting Description
Open Shunt for phase A current measurement used
JP41 Closed Shunt for phase A current measurement bypassed
Open Shunt for phase B current measurement used
JP47 Closed Shunt for phase B current measurement bypassed
Open Shunt for phase C current measurement used
JP52 Closed Shunt for phase C current measurement bypassed
Open Shunt for DC bus current measurement used
JP53 Closed Shunt for DC bus current measurement bypassed
1-2 The current of the internal power stage phase A is
measured
JP43 2-3 The phase A current sense signal of an external power
stage is passed to the MCU
1-2 The current of the internal power stage phase B is
measured
JP46 2-3 The phase B current sense signal of an external power
stage is passed to the MCU
Closed The phase C current sense signal of an external power
stage is passed to the MCU
JP48 Open No connection to AN2
1-2 The current of the internal power stage DC bus is
measured
JP51 2-3 The DC bus current sense signal of an external power
stage is passed to the MCU
1-2 No offset on phase current values
JP59 2-3 offset defined by R99 / R102 is added to internal phase
current values
In case an external power stage is used, the external power stage has to supply adequate
voltage levels of the measured values as well as conditioned signals.
