– 4 –
SPECIFICATIONS
Power source 100-240V, 50/60Hz
Power consumption 390 W
Display panel UE-41 type
Screen size 92.0 (W) x 51.8 (H) [cm]
36.2 (W) x 20.4 (H) [inch]
Aspect ratio 16 : 9
Number of pixels 852 (H) x 480 (V) pixels
Pixel pitch 1.08mm x 1.08mm
Contrast ratio 580 : 1 (typ.)
Brightness 400 cd/m2(typ.)
Viewing angle Max. 160 degrees
Input terminals
Video input BNC connector
1.0VP-P /75
S video input S terminal
Y signal : 1.0VP-P /75
C signal : 0.3VP-P /75
Component Three BNC terminals
Video input Y : 1VP-P /75
Pb/B-Y: 0.7VP-P /75
Pr/R-Y: 0.7VP-P /75
Analog RGB 1 mD-sub:15pin (3 row type)
input Video 0.7VP-P /75
SYNC signal : TTL level
or 0.3VP-P /75
Analog RGB 2 BNC terminal x 5
input R : 0.7VP-P/75
G: 0.7VP-P/75
B : 0.7VP-P/75
H : TTL level or 0.3VP-P /75
V : TTL level or 0.3VP-P /75
Display frequency Horizontal:15.62 to 80.0kHz
Vertical : 50.0 to 120Hz
Dot clock : 50MHz Max
:XGA 68MHz Max
RS-232C D-sub 9-pin terminal
Color system
NTSC/PAL/SECAM/N-PAL/M-PAL
/4.43NTSC
Display colors 16.7 million (256 each for R.G.B.)
Audio input 2 pin terminals (one system)
500mVrms/22k
Speaker output
2 built-in speakers 1W+1W (R/L)
Lever terminal 7W+7W (R/L) 8
Language English/German/French/Italy/
Spanish/Portugese
(E type :Russian)
Dimensions Width : 103.5cm (46.7inch)
Height : 64.0cm (25.2inch)
Depth : 8.5 cm (5.9inch)
Net weight 31.5kg
Environment (Operating)
Temperature 0° to 40°C
Relative humidity 20 to 90%
Pressure 800 to 1,114 hPa
Accessories User’s manual
Remote controller and strap
Dry batteries (Type AA 2pcs.)
Power cables
Cable clamper (2 types)
Bracket (2 types)
Screw (2 types)
Connector cover
Ferrite core (4pcs.)
Options
Stand P-42TT11
Wall mounting unit P-42WB12 installation angle
Horizontal 0° to 15°
Vertical 0° to 5°
Ceiling mounting unit P-42CT11 installation angle
Available 0° to 15°
Regulation PDS4213W-H PDS4214W-S
PDS4213E-H PDS4214E-S
• AS
Safety : IEC950 A1/A2/A3/A4 IEC950 A1/A2/A3/
EMC : AS/NZS 3548 AS/NZS 3548
EN60950 1992
A1 1993
A2 1993
A3 1995
A4 1997
• CE
Safety : EN60950 1992
:A1 1993
:A2 1993
:A3 1995
:A4 1997
• UL,CSA
Safety : UL1950 UL1950
:CSA C22.2 No.950 CSA C22.2 No.950
EMC : FCC Part15 Class A FCC Part15 Class B
:ICES-003 Class A ICES-003 Class B
EMC : EN55022 1994
Class A
EN61000-3-2, 1995
EN61000-3-3, 1995
EN55024, 1998
EN61000-4-2, 1995
EN61000-4-3, 1996
EN61000-4-4, 1995
EN61000-4-5, 1995
EN61000-4-6, 1996
EN61000-4-8, 1993
EN61000-4-11,1994

CONTENTS
IMPORTANT INFORMATION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
SPECIFICATIONS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
SETTING SIGNALS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
CONNECTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
OPERATION AND ADJUSTMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
TROUBLESHOOTING. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
VOLTAGE OF EACH CONNECTOR. . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
VS AND -VY ADJUSTMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
GENERAL CONNECTION DIAGRAM . . . . . . . . . . . . . . . . . . . . . . . . . . 21
INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
DISASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
PARTS LIST . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
TRANSPORTATION AND HANDLING RESTRICTIONS . . . . . . . . . . . . 48
– 1 –

– 2 –
IMPORTANT INFORMATION
WARNING : TO REDUCE THE RISK OF FIRE AND ELECTRIC SHOCK, DO NOT EXPOSE THIS
PRODUCT TO RAIN OR MOISTURE.
Please use a screen saver to prevent burning of an after-image on the screen.
Electrical energy can perform many useful functions. This unit has been engineered and manufactured to assure your
personal safety. But IMPROPER USE CAN RESULT IN POTENTIAL ELECTRICAL SHOCK OR FIRE HAZARD.
In order not to defeat the safeguards incorporated into this unit, observe the following basic rules governing its installation,
use and service. Please read these "Important Safeguards" carefully before use.
— Read all the safety and operating instructions before operating the unit.
— Retain the safety and operating instructions for future reference.
— Adhere to all warnings on the unit and in the operating instructions.
— Follow all operating instructions.
— Unplug the unit from the wall outlet before cleaning. Do not use liquid or aerosol cleaners. Use a damp cloth for cleaning.
— Do not use attachments not recommended by the manufacturer as they may be hazardous.
— Do not use the unit near water. Do not use the unit immediately after moving it from a low temperature to a high
temperature environment, as this causes condensation, which may result in fire, electric shock, or other hazards.
— Do not place the unit on an unstable cart, stand, or table. The unit may fall, causing serious injury to a child or adult, and
serious damage to the unit. Mount the unit according to the manufacturer's instructions, using the mount recommended by
the manufacturer.
— When the unit is used on a cart, avoid quick stops, excessive force, and uneven
surfaces which may cause the unit and cart to overturn, damaging the unit or
causing possible injury to the operator.
When transporting by car, place the unit as shown in the figure.
— Slots and openings in the cabinet are provided for ventilation. These ensure reliable operation and protect the unit from
overheating. These openings must not be blocked or covered. (The openings should never be blocked by placing the unit
on a bed, sofa, rug, or similar surface. The unit should not be placed in a built - in installation such as a bookcase or rack
unless proper ventilation is provided and the manufacturer's instructions are adhered to.) For proper ventilation, separate
the unit from other equipment, which may obstruct ventilation. Keep the unit at least 10cm from other equipment.
— Operate only with the type of power source indicated on the label. If you are not sure of the type of power supply to your
home, consult your dealer or local power company.
— This unit is equipped with a three-wire plug. This plug will fit only into a grounded power outlet. If you cannot insert the plug
into the outlet, have an electrician install the proper outlet. Do not defeat the safety purpose of the grounded plug.
— Route power cords so that they are not likely to be walked on or pinched by items placed on or against them. Pay
particular attention to cords at doors, plugs, receptacles, and where they exit from the unit.
— For added protection during a lightning storm, or when the unit is left unattended and unused for long periods of time,
unplug it from the wall outlet and disconnect the cabling. This will prevent damage to the unit by lighting and power line
surges.
— Do not overload wall outlets, extension cords, or convenience receptacles on other equipment as this can result in fire or
electric shock.
— Never push objects of any kind into this unit through openings as they may touch dangerous voltage points or short-circuit
parts that could result in a fire or electric shock. Never spill liquid of any kind onto the unit.

— Do not attempt to service this unit yourself as opening or removing covers may expose you to dangerous voltages and
other hazards. Have all service done by qualified service personnel.
— Unplug this unit from the wall outlet and have it serviced by qualified service personnel in the following cases:
a) If the power supply cord or plug is damaged.
b) If liquid has been spilled, or objects have fallen onto the unit.
c) If the unit has been exposed to rain or water.
d) If the unit does not operate normally by following the operating instructions. Adjust only those controls that are
covered by the Operation Manual, as improper adjustment of controls may result in damage and will often require
extensive work by a qualified technician to restore the unit to normal operation.
e) If the unit has been dropped or damaged in any way.
f) A distinct change in performance indicates that service is required.
— When required, be sure the service technician uses replacement parts specified by the manufacturer or parts with the
same characteristics as the original parts. Unauthorized substitutions may result in fire, electric shock, or other hazards.
— Upon completion of any service of repairs, ask the service technician to perform safety checks to determine that the
unit is in proper operating condition.
— Place the unit more than one foot away from heat sources such as radiators, heat registers, stoves, and other devices
(including amplifiers) that produce heat.
— When connecting other devices such as VCR's and personal computers, turn off the power to this unit to protect
against electric shock.
— Do not place combustibles such as cloth, paper, matches, aerosol cans or gas lighters that prevent special hazards
when overheated behind the cooling fan.
— Use only the accessory cord designed for this unit to prevent shock.
The power supply voltage rating of this unit is AC100-240V, but the attached power cord conforms to the following
power supply voltage. Use only the Power Cord designated by our dealer to ensure Safety and EMC.
When used with other power supply voltages, the power cable must be changed.
Consult your local dealer.
Power Cord
Power supply voltage : AC 100 - 125 V AC 200 - 240 V AC-240V
(SAA TYPE)
– 3 –

SETTING SIGNALS
– 5 –
This display can store parameter settings for eight additional signals for both RGB1 and RGB2.
To do this, select the desired signal and follow “RGB MODE ADJUSTMENT” in the manual to adjust the parameters.
When you finish, the settings will be automatically stored.
This unit has been factory-set for the 18 signals shown below.
∗“ Out of range” appears if the dot clock of the input signal exceeds 54MHz (68MHz for XGA) even when the horizontal
and vertical frequencies are within their permissible ranges.
In this case, the sampling clock is fixed at 54MHz (68MHz for XGA).
Make sure that the vertical frequency of the input signal is 75Hz or less for SVGA and 60Hz for XGA.
Display (dots x lines) Horizontal frequency (kHz) Vertical frequency (Hz) Signal
852 x 480 31.72 59.97 When a dedicated
graphics card used
640 x 480 31.47 59.94 VGA
640 x 480 37.86 72.81 VGA 72Hz
640 x 480 37.50 75.00 VGA 75Hz
640 x 480 43.27 85.01 VGA 85Hz
720 x 400 31.47 70.09 VGA 400 lines
640 x 400 37.86 85.08 VGA 400 lines
800 x 600 35.16 56.25 SVGA 56Hz
640 x 400 37.88 60.32 SVGA 60Hz
800 x 600 48.08 72.19 SVGA 72Hz
800 x 600 48.88 75.00 SVGA 75Hz
1,024 x 768 48.36 60.00 XGA 60Hz
640 x 480 35.00 66.67 MAC 13RGB
848 x 480 31.02 60.00
640 x 480 15.73 59.94 60 fields
640 x 480 15.63 50.00 50 fields
640 x 400 24.82 56.42 NEC 24kHz
640 x 400 31.50 70.15 NEC 31kHz
15.63 to 80.00* 50.00 to 120.00* User setting
FACTORY SET SIGNALS (RGB1, RGB2 MODES)

AUDIO 2
INPUT
POWER INPUT VIDEO
INPUT S-VIDEO
INPUT
AUDIO 1
INPUT RGB 2 INPUT RS-232C
COMPONENT
VIDEO INPUT
(color difference input)
RGB 1
INPUT
To receptacle To sound
output
terminal
Connection to AV equipment Connection to PC
To video
output
terminal
To S-video
output
terminal
To sound
output
terminal
To display
(analog RGB)
output
terminal
To display
(analog RGB)
output
terminal
To RS-232C
output
terminal
To color
difference
output terminal
– 7 –
CONNECTION
Terminal Connector
VIDEO INPUT BNC
S-VIDEO INPUT S terminal
COMPONENT VIDEO BNC x 3
RGB 1 INPUT mD-sub 15P
RGB 2 INPUT BNC x 5
AUDIO INPUT Pin jack
RS-232C D-sub 9P

q
w
e
ON (GRN)
STD-BY (RED)
NO-SIGNAL (ORG)
POWER
Strap hole
Control Panel
POWER
r
MODE
t
WIDE
y
MENU
u
ENTER
!0
VOLUME
i o
ENTER
MENU
SHIFT
1
2
3
4
VIDEO
VOL
POWERON
RGB
POWER OFF
WIDE
u
!0
w
t
y
i
e
q
o
r
– 8 –
OPERATION AND ADJUSTMENT
Front Remote controller
The control panel opens when you press the
lower center of the display.
qPower indicator lamp
wRemote control signal receiver
eMain power SW indicator
rPower button (ON/OFF)
tInput mode selector button
yWide screen selector button
uMenu button
iVolume adjustment buttons
oAdjustment buttons
!0 Enter button
The remote controller comes with a strap.
This strap can be attached to the hole at the
bottom of the remote controller.
qPower ON button
wPower OFF button
eRGB mode selector button
rVIDEO mode selector button
tWide screen selector button
yMenu button
uVolume adjustment buttons
iAdjustment buttons
oEnter button
!0 Display selector buttons

– 11 –
TROUBLESHOOTING USING LED AND OSD
1. Display
(1) OSD
Two kinds of error messages are displayed on the screen, and the power is turned off 10 sec later.
(2) LED
LED error is displayed continuously after the power is turned off.
2. Error types and check points
On screen display Cause Check point
ERROR MESSAGE CONDITION 1 Fan protector operated • Fan
• AC/DC power unit
• DC/DC power PCB
• Main/Digital PCB
ERROR MESSAGE CONDITION 2 Temperature protector
operated • Ambient temperature of unit
• Main/Digital PCB
• Temp. sensor PCB
(1) OSD
LED lamp display status Cause Check point
Steady light (Red) Stand-by status –––––––––––
Continuous
Flashes continuously (Red)
No power
Power supply protector
operated
• AC/DC power unit
• DC/DC power PCB
• PDP panel
1 time
Flashes once in 3 sec. (Red) Fan protector operated
• Fan
• AC/DC power unit
• DC/DC power PCB
• Main/Digital PCB
2 times
Flashes twice in 3 sec. (Red) Temperature protector
operated
• Ambient temperature of unit
• Signal PCB
• Temperature sensor PCB
4 times
Flashes four times in 3 sec. (Red) Main/Digital circuit faulty • Main/Digital PCB
5 times
Flashes five times in 3 sec. (Red) Video circuit faulty • Video PCB Assy
(2) LED

– 19 –
VOLTAGE OF EACH CONNECTOR
• Voltage measurement in protect mode
Because the relay signal is “L” in the protect mode, voltages of Vcc, Vs, and Va are not output. The
protect mode is reset only when the power SW is turned off. Therefore, when measuring the voltage,
turn off the power SW, then turn on the power by remote control. Remeasure the power supply unit
protection operation.
• Relay signal
Voltages Vcc, Vs and Va are output only when the relay signal of “CN103-3” is “H”.
When the microcomputer detects an abnormal voltage, these voltages are not output.
• ACON signal
The ACON signal indicates whether or not AC is supplied. The relay signal is output when the ACON
signal is “H”.
CN103 Power supply unit Ground
No. NAME SPEC.
1 Vpr 5V (4.8 to 5.2V) w
7 Vcc 2 24V (23.7 to 24.3V) w
1. Power Supply Unit (PFW-422)
2. DC/DC Power PCB
CN49 Power supply unit Ground
No. NAME SPEC.
1 Vcc 1 5V (4.8 to 5.2V) w
3 Ve 15.52 to 16.48V w
10 Vs 165.0 to 185.0V w
CN50 Power supply unit Ground
No. NAME SPEC.
1 Vw 164.9 to 175.1V e
2 Va 64.35 to 65.65V e
CN42 Power supply unit Ground
No. NAME SPEC.
3 Vsc 116.4 to 123.6V r
4 -Vy -150 to -170V q
6 Vcc 1 5V (4.8 to 5.2V) q
P503 DC/DC Power PCB Ground
No. NAME SPEC.
2 A 5V 5V (4.75 to5.25V) q
4 14 V 13.3 to 14.7V q
5 Vpr 5V (4.8 to 5.2V) q
8 D 5V 5V (4.75 to 5.25V) q
9 D 3.3V 3.2 to 3.4V q
10 A-5V -5.25 to -4.75V q

– 20 –
VS AND -VY ADJUSTMENT
When the Power Supply and PDP units are replaced, Vs and -Vy must be adjusted.
Preparation : Heat-run for 5 minutes with a white pattern in the wide mode.
Adjustment : Adjust Vs and -Vy in the no-signal state (Black picture).
Test and
adjustment points : Refer to the drawing below.
Adjustment value : Within ±0.1V of the voltage indicated on the label on the PDP unit.
Power Supply Unit
-Vy adjustment VR
(RV210)
Vs adjustment VR
(RV203)
Vs test point
-Vy test point
(CN42, pin 1)
(PFW-422)
C331
Vs Vs
RV210
CN41
RV203
T 6

– 21 –
GENERAL CONNECTION DIAGRAM
SIROCCO FAN
EMI CORE
INLET
AC/DC POWER SUPPLY
PFW-422
PLASMA DISPLAY PANEL UNIT
FPF42C10660UE-41
OPTICAL FILTER PDS4213 : Glass 2.6 ΩT2.5 985 x 585 PDS4214 : Mesh T2.5 985 x 585
POWER
SW
FAN
DC/DC POWER SUPPLY
M00BEA
EXT-SP
68PIN
FAN
SIROCCO FAN
AUDIO
VIDEO
SPEAKER
MAIN / DIGITAL
LED / PHOTO AMP
THERMO SCOPE
KEY SWITCH
1 VCC2 DCF2C DCF2P GND 4
1 R-OUT NC R-GND 3 1 L-OUT L-GND 2
(RCA)
J3906
CN4500
[FX28-68P]
(BNC)
J3900 (S-terminal)
J3902 (BNC)
J3904 (RCA)
J1102 SW2001 CN1100 (BNC)
J1101 (BNC)
J1100 SW2000 P6500
POWER MODE MENU WIDE
SET
– VOLUME +
<ADJUST>
1
PRI
GND
RELAY
ACON
GND GND
VCC2 VCC2
8
1
R (8)
G (8)
B (8) GND
H
V
GND
68
1
P5V
SDA 2
SCL 2
GND
4 1
GND
REMOCON
LEDG
LEDR
P5V
5 1
GND
KEY IN0 KEY IN1 KEY IN2 KEY IN3
KEYSCAN1 KEYSCAN2 KEYSCAN3
8
1 24V ACF2C ACF2P GND 24V ACF1C ACF1P GND 24V DCF1C DCF1P GND 12
S. GND VYK S.GND VWK S.GND VSK S.GND VAK S.GND VEK S.GND NC S.GND VIAA S.GND VISS S.GND VW/VY-GO S.GND VE-GO
20
1
P502P504
CN2
CN6 CN5
TER1
L R
CN1 CN4 P6000 CN1101
CN1200
CN4500
P6600
P6300 P6001
P1001
P6400 CN1000
P503
CN50 CN8 CN42 CN10 CN41 CN49
CN38
CN4
CN103
P501
M4
P507 P505
1
GND
14V
2
1
ACON
RELAY
GND
ACF1P
ACF1C
ACF2P
ACF2C
DCF1P
DCF1C
DCF2P
DCF2C
GND
12
4
GND (VW)
GND (VA)
VA
VW
1
4
VCC1
GND (VCC1)
VA
GND (VA)
1
5
VCC1
GND (VCC1)
-VY
VSC
GND (-VY)
GND (-VY)
1
12
VCC1
GND (VCC1)
VE
GND (VE)
VA
GND (VA)
VCC1
GND (VCC1)
VE
GND (VE)
VA
GND (VA)
1
10
VS
VS
NC
GND (VS)
GND (VS)
GND (VS)
GND (VE)
VE
GND (VCC 1)
VCC 1
1
10
VS
VS
NC
GND (VS)
GND (VS)
GND (VS)
GND (VE)
VE
GND (VCC 1)
VCC 1
1
1
VCC1
GND (VCC1)
2
1
VW
VA
GND (VA)
GND (VW)
4
1
VCC1
GND (VCC1)
VA
GND (VA)
4
1
-VY
VSC
GND (VSC)
GND (-VA)
4
1
VCC1
GND (VCC1)
VE
GND (VE)
VA
GND (VA)
6
1
VCC1
GND (VCC1)
VE
GND (VE)
VA
GND (VA)
6
1
VCC1
GND (VCC1)
VE
GND (VS)
GND (VS)
GND (VS)
GND (VS)
NC
VS
VS
10
1
VCC1
GND (VCC1)
VE
GND (VS)
GND (VS)
GND (VS)
GND (VS)
NC
VS
VS
10
1
R (8)
G (8)
B (8)
GND
H
V
GND
68
1
RESET
CE
CLK
DATA
GND
5
1
L
L-GND
R-GND
R
L-1-2-GND
L-2
L-1
R-1-2-GND
R-2
R-1
10
1
GND
A5V
GND
14V
PRI
GND
D5V
D3 3V
-5V
10
1
GND
14V
2
1
RESET
CE
CLK
DATA
GND
5
1
L
L-GND
R-GND
R
L-1-2-GND
L-2
L-1
R-1-2-GND
R-2
R-1
10
1
GND
DCF2C
DCF2P
DCF1C
DCF1P
ACF2C
ACF2P
ACF1C
ACF1P
GND
RELAY
ACON
12
1
-5v
D3 3V
D5V
DGND
DGND
P5Y
A14Y
AGND
A5V
AGND
10
M00BDA
M00BDB
M00BDD
M00BDC
M00BEB
68PIN
AUDIO 2 INPUT S-VIDEO INPUT AUDIO 1 INPUT RGB1 RGB 2 RS232C
75 OHM SW 75 OHM SW
VIDEO INPUT COMPONENT VIDEO INPUT
M8KR
@@@@@@@@e? @@@@@@@@e? @@h? @@h? @@h? @@h? @@h? @@h?
@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e? @@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?
@@@@@@@@ @@@@@@@@
@@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@
?@@ ?@@ ?@@ ?@@ ?@@ ?@@
?@@@@@@@@ ?@@@@@@@@
?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@
?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@
@@g @@g @@g @@g @@g @@g @@@@@@@@ @@@@@@@@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@ @@
01:8-7 13:B-1 25:NC 37: R-6 49:R-0 61:G-2 02:S. GND 14:S. GND 26:S. GND 38:S. GND 50:S. GND 62:S. GND 03:B-6 15:B-0 27:DISPEN 39:R-5 51:G-7 63:G-1 04:S. GND 16:S. GND 28:S. GND 40:S. GND 52:S. GND 64:S. GND 05:B-5 17:VSYNC 29:NC 41:R-4 53:G-6 65:G-0 06:S. GND 18:S. GND 30:B-CNTO 42:S. GND 54:S. GND 66:S. GND 07:B-4 19:HSYNC 31:B-CNT1 43:R-3 55:G-5 67:NC 08:S. GND 20:S. GND 32:B-CNT2 44:S. GND 56:S. GND 68:S. NC 09:B-3 21:BLANK 33.HQEN 45:R-2 57:G-4 10:S. GND 22:S. GND 34:NC 46: S. GND 58: S. GND 11:B-2 23:DCLOCK 35:R-7 47:R-1 59:G-3 12: S. GND 24: S. GND 36: S. GND 48: S. GND 60: S. GND

– 22 –
INSTALLATION
INSTALLATION PRECAUTIONS
1. Installation Environment
1) Do not expose the display directly to vapor or heat. Protect the unit from rain or water.
2) The display uses glass material, and cracks easily. So, do not subject it to vibration
and shock. When carrying the display, always use two peoples so that vibration and
shock is not applied to the display.
3) Do not disturb the radiation of heat from the rear, sides and top of the unit. Install the
unit in a well ventilated place. Use the unit within an ambient temperature range of 0°C
~ 40°C.
4) Displaying a static picture for a long time may burn an after-image on the screen, the
same as a CRT. To prolong the life of the unit, turn off the display when it is not in use,
scroll the picture, and use a screen saver. Periodically display a uniformly bright
picture over the entire screen, add complimentary colors, and insert moving pictures.
Use half tones and intermediate colors, if possible, because the higher the brightness,
the easier burning occurs. The problem does not occur with moving pictures.
5) Do not expose the optical filter directly to the sun for a long time. The characteristics of
the optical filter will change and discoloration may occur.
6) Do not wipe the optical filter with a solvent such as benzene or paint thinner. The
optical filter may peel off. Wipe the surface of the optical filter with a soft, lint-free cloth
such as cotton. The surface of the optical filter scratches easily so do not rub or hit it
with a hard object.
7) The brightness and contrast of the PDP are still inferior to those of a CRT. Also note
that the ambient light may cause the screen become white and difficult to read.
Therefore, it is recommended that the ambient light be reduced.
8) Note that light from the back may adversely affect the screen. Avoid backlighting as
much as possible.
9) The display may cause radio frequency interference sensors which detect low level
and low frequency radiowaves. If an improperly shielded VCR or signal cable is
brought close to this unit, noise may appear on the screen. To avoid this, move the
unit to a new location.
10) Near infrared rays are radiated from the front of the display panel. These rays may
interfere with the infrared ray remote control unit of other equipment and with infrared
communication systems. In this case, change the direction of the equipment relative to
the screen or move the unit away from the other equipment so that the rays radiated
directly from the screen (or reflected rays, depending on the situation) have no affect
on other equipment.
11) When the display is installed in a quiet room, it is recommended that a thick curtain is
hung on the wall behind the display to reduce the noise.
12) Dark gray scenes may appear purplish or greenish. To avoid this, increase the
brightness.

Fixing bracket.
Fix a handle on the PDP Unit. Take out the PDP Unit.
Frame Panel-Bottom
PDP panel unit
X-SUS Shield Y-SUS Heat-SinkFrame Panel-TopHolder Fan-L Holder Fan-R
Audio PCBTemp. Sensor PCB
Power Cover
Power Supply Unit
DC/DC Power PCBNoise Filter
Sirocco Fan-RSirocco Fan-L
Fan motor-RFan motor-L
Frame Panel MID (Upper)
Main/Digital PCB
Frame Panel MID (Lower) Frame Panel MID
(Upper)
Temp. Sensor PCB
Power Cover
Duct Fans
Rear Case (Lower)
Power Supply Unit
Frame Panel MID (Lower)
Rear Case (Upper)Front Case
Rear Case (Lower) Optical Filter
Key-Switch Assy
Video PCB
PDS4213/ 4214
Video PCB Unit
1
7
3
12
48
11
10
3
6
9
13 to 14
25
10 12
11
– 29 –
DISASSEMBLY FLOWCHART

Ref.No. Description PDS4213W-H PDS4213E-H PDS4214W-S PDS4214E-S
Cabinet
Rear Case (Upper) 8110642004
Rear Case (Lower) 8110686003
Bezel Front 8110121004 8110675002
Frame Panel - Mid 8109740001
Cover Stand 8108298008 ––––– –––––
Cover Stand - L ––––– ––––– 8108360002
Cover Stand - R ––––– ––––– 8108585009
Cover Terminal 8110299000
Holder Filter (T/B) 8110614001 8109903000
Holder Filter (L/R) 8110619006 8109904007
Key Switch unit
Holder Key-switch 8107744001
Plate Key-switch 8110793003 8110794000
Cover Key-switch 8107743004
Spring Key-switch 8108316009
Holder damper 8110122001
Damper Key-switch 8109047001
Latch Key-switch 8108703007
Button Key-switch 8107745008
Key Switch PCB Assy 8110656018
– 46 –
PARTS LIST
: Same as left

– 48 –
TRANSPORTATION AND HANDLING RESTRICTIONS
Transportation
Don't load the plasmavision on a truck
as shown in the drawing.
Don't hold the
surface of the
optical filter.
Over 30 cm
Drop
Floor
Bad loading
Handling
Never drop.Never topple.

– 49 –
Don't stack the
plasmavision over
three units high.
Load the plasmavision as shown above.
Example of good transportation and handling
Good loading
3
4

MEMO

August 2000 Printed in Japan0008J1729

– 47 –
Packing
Packing Pad-Top (2 pcs.) 8110234001
Packing Pad-Bottom (2 pcs.) 8110235008
Carton Box - Top 8110634009
Label, Carton 8110820006 8110821003 8110823007 8110824004
Carton Box - Bottom 8108658000
Packing Joint - D 8108655009
Carton Box Accessory 8108657003
Ref.No. Description PDS4213W-H PDS4213E-H PDS4214W-S PDS4214E-S
Electric
Video PCB Assy 8110594020
Main/Digital PCB Assy ∗8110545022 8110545022 8110545022 8110545022
LED/Photo PCB Assy 8110754011
Power Supply Unit (PFW-422) 8108193006
DC/DC Power PCB (M8KR) 8110809018
Audio PCB Assy 8110592026
Temp. Sensor PCB 8110756015
PDP Panel 8110753007
FPF42C10660UE-41
Optical Filter 8110688002 8105046145
Fan Motor (Small) 8900243015
Sirocco Fan 8900242025
Adapter Main-SW 8110620002
Power Cord VDE 8108106006
UL/CSA 8108105009 8105865005
SAA 8108238004 8108238004
Remote Control Unit 8108442005 8110867001
Speaker 8109975014
4213E4213W 4214W 4214E
∗When ordering the Main/Digital PCB Assy, always enter the Model No. : Same as left
