Functional Devices PSC100AB10 User manual

PSB / PSC Series Installation Instructions
Application
These general-purpose power supplies can be used to
fulll all the 120 Vac and 24 Vac*(Class 2) power require-
ments needed inside a building automation (BAS) panel,
industrial enclosure, or other general purpose electrical
enclosure, in addition to on/o control, equipment over-
current protection, power indication, high/low voltage
separation, and convenience receptacles. They are also
useful for many applications outside of BAS.
Installation
When installing this product...
1. Read these instructions carefully. Failure to follow them
could damage the product or cause a hazardous condition.
2. Check the product ratings and ensure that the product is
suitable for your application.
3. Installer must be a trained, experienced service technician.
4. After installation is complete, perform a voltage check as
provided in these instructions.
CAUTION
RISK OF ELECTRICAL SHOCK  MORE THAN ONE DISCONNECT MAY BE
REQUIRED TO DEENERGIZE THE DEVICE BEFORE SERVICING.
CAUTION
REMOVAL OF COVER OR ACCESS PLATE IF PRESENT EXPOSES
HIGH VOLTAGE.
PSB / PSC Series Selection Guide
Model Number * VA Rating Panel
Mount Enclosed 120 Vac Receptacles Aux Output Main Breaker on Input Power
Secondary
Conguration
PSC100AB10 100 VA • • • 10 Amp Switch / Breaker Terminal Strip
PSB100AB10 100 VA • • • 10 Amp Switch / Breaker Terminal Strip
PSC40AB10 40 VA • • • 10 Amp Switch / Breaker Terminal Strip
PSB40AB10 40 VA • • • 10 Amp Switch / Breaker Terminal Strip
RESET
OFF
ON
OFF
Com
24 Vac
120 Vac
Neutral Ground
120 Vac Aux. Output
120 Vac Convenience Outlet*
10 Amp Main
Breaker/Switch
24 Vac ON/OFF
LED Indicator
5.620˝
2.245˝ 3.900˝
5.620˝
6.250˝
4.500˝
Removable Access Plate
4.500˝
4.610˝ To remove cover
4 Mounting Screw Holes
Hole diameter .203"
* All models may be followed by –IC.
Functional Devices, Inc. • p: 800.888.5538 • f: 765.883.7505 • www.functionaldevices.com • [email protected]
Bulletin B1450

Mounting
1. Remove the entire front cover (PSC versions) by extracting 2 screws on top front.
2. Attach uncovered power supply using 4 screw holes.
3. Make desired wire connections.
4. Reattach cover for PSC versions.
Wiring
All wiring must comply with local codes and ordinances. Disconnect power before making wiring connections to prevent
electrical shock or equipment damage.
Hot Neut Gnd AUX
120V INPUT
24 Vac LED Indicator
Class 2, 12-18 AWG, 10 lb./in max, copper 60ºC
TRANSFORMER:
24Vac, 100VA, Class 2
Note
Convenience Outlets & Aux. Load:
120Vac, Total Load not to exceed 9A
* Move internal jumper to“ALWAYS HOT”position if you wish outlets
to always be hot otherwise outlets will be switched by main breaker.
OUTPUT
See Note
COM 24 VAC
RESET
OFF
RESET
120Vac
10A Main
24Vac for Output Only
24Vac
Breaker
ON
OFF
Class 2, 12-18 AWG, 10 lb./in max, copper 60ºC
1. Bring wiring into 1 of the 2 openings on the side of the power supply while cover is removed (PSC version).
2. Make appropriate connections to the terminal strips.
Note: All eld wire leads are intended for installation inside the enclosure.
Voltage Check
After installation is complete, turn on power supply and perform a voltage check:
1. Place controlled equipment in operation and observe through one complete cycle.
2. Using a voltmeter, check for proper primary and secondary voltages.
3. If voltage readings are incorrect, be sure primary voltage connections are made correctly.
4. Measure voltage again:
a. If correct primary voltage is measured and secondary voltage is signicantly less than the voltage shown on the
regulation curves, transformer winding is damaged. Replace transformer and repeat checkout procedures.
b. If primary voltage is 0V, be sure power supply is connected correctly or repair, if necessary. Repeat checkout
procedures.
393170C 07.18.17
