FunCub 21 4243 User manual

1
F
GB
D
E
I
Baukasten / kit # 21 4243
Bauanleitung 3 ... 8
Notice de construction 9 ... 14
Building instructions 15 ... 24
Instruzioni di montaggio 25 ... 29
Instrucciones de montaje 30 ... 35
Ersatzteile
Replacement parts
Pièces de rechanges
Parti di ricambio
Repuestos
36 ... 37
© Copyright by MULTIPLEX 2010 Version 1.0

2
D
F
GB
I
E
Sicherheitshinweise
PrüfenSievorjedemStartdenfestenSitzdesMotorsundderLuftschraube-insbesonderenachdemTransport,härterenLandungen
sowieAbstürzen.PrüfenSie ebenfalls vor jedemStartden festenSitzund die richtige PositionderTragflächenaufdem Rumpf.
Akkuerstanstecken,wenn Ihr Sender eingeschaltetistundSiesichersind,dassdasBedienelement für die Motorsteuerungauf"AUS"
steht.
ImstartbereitenZustandnicht in den BereichderLuftschraubegreifen!
Vorsichtin der Luftschraubendrehebene- auch ZuschauerzurSeite bitten!
ZwischendenFlügendie Motortemperatur durch vorsichtige Fingerprobeprüfenund
vor einem Neustart den Motor ausreichend abkühlen lassen. Die Temperatur ist richtig, wenn Sie den Motor problemlos berühren
können.InsbesonderebeihohenAußentemperaturenkann dieses einige Minutendauern.
DenkenSieimmer daran: NiemalsaufPersonenundTierezufliegen.
Conseils de sécurité
Avantchaquedécollage,vérifiez la fixation dumoteuretde l'hélice, notamment après letransport,aprèsles atterrissages violents et
aprèsun“Crash”.Vérifiezégalement,avantchaquedécollagela fixation ainsi que le positionnement de l’aileparrapportaufuselage.
Nebranchez l’accu depropulsion que sivous êtes sûrque votre émetteurest allumé etque l’élément decommande moteur esten
position“ARRET”.
Nemettezpas vos doigtsdans l’hélice!Attention à la miseenmarche,demandezégalementaux spectateursdereculer.
Entre deux vols, vérifiez en posant un doigt dessus, la température du moteur, laissezle refroidir suffisamment avant le prochain
décollage.Latempératureestcorrectesivouspouvez maintenir votre doigt ou votre main surlemoteur.Letempsde refroidissement
peutvarierjusqu’à15minutess’ilfaitparticulièrementchaud.
Pensez-ytoujours: ne volez jamaisvers ou au-dessus despersonnes ou desanimaux.
Safety notes
Beforeeveryflight check that themotorandpropeller are in placeandsecure - especially aftertransportingthemodel, and after hard
landingsand crashes. Checkalso that thewing is correctlylocated and firmlysecured on thefuselage before eachflight.
Don’tplugin the batteryuntilyou have switched onthe transmitter,and you aresurethat the motor controlon the transmitter issetto
“OFF”.
When the model is switched on, ready to fly, take care not to touch the propeller. Keep well clear of the propeller disc too, and ask
spectators to stay back.
Allow the motor to cool down after each flight. You can check this by carefully touching the motor case with your finger. The
temperatureis correct whenyou can holdyour finger on the case without anyproblem. On hotdays this maytake up to15 minutes.
Pleasekeepinmindatalltimes: don’t fly towards people or animals.
Note di sicurezza
Primadiognidecollocontrollarecheilmotoreelaelichesianofissatistabilmente-specialmentedopoiltrasporto,atterraggidurieseil
modelloèprecipitato.Controllareprimadeldecolloancheil fissaggio e la posizione corretta delle alisullafusoliera.
Collegarelabatteriasoloquandola radio è inserita ed il comando delmotoreèsicuramenteinposizione”SPENTO”.
Primadeldecollo nonavvicinarsialcampodi rotazionedellaeliche.Attenzionealla elicheinmovimento-pregare cheeventualispettatori
siportinoalla dovuta distanza disicurezza!
Traunvoloel’altro controllare cautamente con leditalatemperaturadelmotoreefarliraffreddaresufficientementeprimadiogninuovo
decollo.La temperatura è giustase sipossono toccare senza problemi.Specialmentecon una temperatura esternaaltaquestopuò
durarefinoa15minuti.
Fareattenzione:Nonvolaremainella direzione di persone ed animali.
Advertencias de seguridad
Compruebeantesde cadadespeguequeelmotory lahéliceesténfuertementesujetados,sobretodo despuésdehaberlotransportado,
deaterrizajesmás fuertes así como despuésdeunacaída. Compruebe igualmente antesdecadadespegue que las alas esténbien
sujetasy bien colocadas enel fuselaje.
Conectarlabatería,cuandolaemisoraesté encendida y Usted esté seguro queelelementodemandoparael motor esté en ”OFF”.
Nometerlamano en la zonainmediataalahélicecuando el avión estéapuntodedespegar.¡Cuidadoconlazonade la hélice! ¡Pedira
losespectadoresque se aparten!
Entrelosvuelos hayquecomprobarcuidadosamentelatemperatura delmotorconeldedo ydejarqueelmotorse enfríeantesdevolver
adespegar.Latemperaturaescorrecta,sipuedetocarel motorsinproblemas.Sobretodoenel casodetemperaturasdelambientemuy
altas,estopuede tardar unos 15 minutos.
Recuerde:Novolarnuncahacíapersonasoanimales.

9
Examine your kit carefully!
MULTIPLEX model kits are subject to constant quality checks throughout the production process, and we sincerely hope that you
are completely satisfied with the contents of your kit. However, we would ask you to check all the parts before you start
construction, referring to the Parts List, as we cannot exchange components which you have already modified. If you find any
part is not acceptable for any reason, we will readily correct or exchange it once we have examined the faulty component. Just
send the offending part to our Model Department. Please be sure to include the enclosed complaint form, duly completed. We
are constantly working on improving our models, and for this reason we must reserve the right to change the kit contents in terms
of shape or dimensions of parts, technology, materials and fittings, without prior notification. Please understand that we cannot
entertain claims against us if the kit contents do not agree in every respect with the instructions and the illustrations.
# 21 4243
GB
Caution!
Radio-controlled models, and especially model aircraft, are by no means playthings in the usual sense of the term.
Building and operating them safely requires a certain level of technical competence and manual skill, together with
discipline and a responsible attitude at the flying field. Errors and carelessness in building and flying the model can
result in serious personal injury and damage to property. Since we, as manufacturers, have no control over the
construction, maintenance and operation of our products, we are obliged to take this opportunity to point out these
hazards and to emphasise your personal responsibility.
Recommended equipment:
Min. RX-7-light M-Link receiver Order No. 5 5810
or RX-9-DR M-LINK receiver Order No. 5 5812
or RX-7-Synth IPD 35 MHz A-band Order No. 5 5880
alternatively 40 / 41 MHz band Order No. 5 5882
2 Tiny-S servos (rudder, elevator) Order No. 6 5121
2 Nano-S servos (aileron) Order No. 6 5120
Optional: 2 / 3 additional Nano-S servos Order No. 6 5120
(for landing flaps and aero-tow release)
Power set:
“FunCub” power set Order No. 33 2649
including brushless motor, speed controller,
propeller, driver and accessories.
Recommended battery:
Li-BATT eco 3/1-2000 (M6) Order No. 15 7231
Adhesive:
Zacki ELAPOR® 20 g VE 20 Order No. 59 2727
Zacki ELAPOR® super liquid, 10 g VE 20 Order No. 59 2728
Tip!
“FunCub” power set, Li-BATT powered Order No. 33 3649
As above, but including Li-BATT eco 3/1-2000 (M6) flight battery
Tools:
Scissors, balsa knife, combination pliers, screwdriver.
Specification:
Wingspan 1400 mm
Overall length 980 mm
All-up weight approx. 1130 g
Wing area 38 dm²
Wing loading min. 30 g/dm²
RC functions Aileron, rudder, elevator, throttle
Optional landing flaps and aero-tow release

10
Important note
This model is not made of styrofoam™, and it is not possible to glue the material using white glue, polyurethane or
epoxy; these adhesives only produce a superficial bond which gives way when stressed. Use medium-viscosity
cyano-acrylate glue for all joints, preferably our Zacki-ELAPOR®, # 59 2727 - the cyano glue optimised specifically for
ELAPOR® particle foam.
If you use Zacki-ELAPOR® you will find that you do not need cyano ‘kicker’ or activator for most joints. However, if
you wish to use a different adhesive, and are therefore obliged to use kicker / activator spray, we recommend that
you apply the material in the open air as it can be injurious to health.
1. Before assembling the model
Please check the contents of your kit before you start working
on it. You will find Figs. 1 + 2 and the Parts List helpful here.
2. The fuselage
The first step is to glue the latch catches 22 and the motor
mounts 37 in both fuselage shells.
Fig.3
3. Installing the servos
Check that the elevator and rudder servos are a snug fit in the
fuselage shells 3 + 4 and apply a drop of glue to the mounting
lugs to secure them. Fix the servo leads in place using paper
masking tape, so that the wires and connectors cannot cause
damage, and do not get in the way when the shells are joined.
Fig.4
4. Control “snakes”
Prepare the control snakes 54 / 56 and 55 / 57: cut the outer
and inner sleeves to length, and slip the steel pushrods 52 /
53 inside them. Install the swivel pushrod connectors in the
outermost hole of the rudder and elevator horns. Note that the
pre-formed pushrod end should be connected to the second
hole from the outside of the servo output arm. Lay the fuselage
shells down flat so that they are not distorted.
Figs. 5 - 6
5. Preparing the wing spreader plates
Clip together the wing spreader plates 33 + 34, using a pair of
flat-nose pliers if necessary, and glue the joints. Glue the
prepared wing spreader plates in the right-hand fuselage
shell.
Fig.7
6. Joining the fuselage shells
Offer up the fuselage shells 3 / 4, initially without glue. When
you are confident that everything fits properly, the shells can be
glued together. Keep the fuselage perfectly straight while the
glue is curing.
Fig.7
7. Preparing the elevator pushrod connector
Fit the swivel pushrod connector 25 for the elevator 8in the
outermost hole of the elevator horn 24, and secure it with the
washer 26 and nut 27.Caution: take care to fit the connector
with the barrel on the outside (see drawing). Be careful when
fitting the retaining nut: tighten it just to the point where the
barrel rotates smoothly, but without lost motion, and then use
the point of a needle to apply a tiny drop of cyano or paint to the
nut threads to prevent it working loose. Fit the socket-head
grubscrew 28 in the swivel pushrod connector 25 using the
allen key 29. Glue the horn 24 in the recess of the elevator 8,
with the row of linkage holes facing forward.
Fig.8
8. Attaching the tailplane
Place the tailplane on the fuselage “dry” - without glue - and
check that it is possible to set it exactly horizontal; minor
trimming to the tailplane saddle might be necessary. When
you are satisfied, glue the tailplane in place, and immediately
align it accurately. Fig. 9
9. Fin and tailwheel unit
Fit the steel wire tailwheel unit 76 through the glue-fitting
tailwheel bracket 36 and the glue-fitting rudder horn 35. Bend
the straight end of the wire through 90°, as close to the horn
surface as possible, as shown in Fig. 10.
Glue the rudder horn 35 in the slot in the rudder, but only apply
cyano to the bottom surface. Allow the glue to harden, then cut
a slot about 1.5 mm wide above the horn to accept the tailwheel
wire. Wipe off any excess adhesive. Rotate the wire tailwheel
unit 76 until it is located over the rudder horn 35, and align the
parts carefully before gluing it in place with a little cyano. Install
the swivel pushrod connector, and lock the nut with a drop of
paint or glue as previously described.
Fig.11
Install the tailwheel 77 as shown: fit one wheel retainer (tubular
rivet) 78 on the wire axle, followed by the wheel, and finally the
second retainer.
Fix both wheel retainers 78 to the axle with a drop of cyano.
Fig.12
10. Gluing the fin to the fuselage
Check that the fin assembly is a snug fit in the fuselage and
tailplane, and glue it in place as shown.
Fig.13
11. Main undercarriage
The main undercarriage 70 can now be prepared for
installation:
Slip a collet 72 onto each axle (right and left), and secure them
with the socket-head grubscrews 73. Fit the wheels 71 on the
axles and secure them with two further collets 72 and
grubscrews 73. Adjust the collet spacing to ensure that the
wheels rotate freely. Fig. 15
The undercarriage bracket 74 can now be glued to the
underside of the fuselage: press it in firmly before applying the
adhesive. Fig. 14
Push the main undercarriage unit 70 into the bracket until it
engages, then fit the retaining screw 75 to secure it.
Fig.15
12. The wings
The wing panels 6 / 7 should not be glued together!
Before you install the spars in the wings, offer up the tubular
spars 50 / 51 and the spar joiners 30 / 31 “dry” to check that the
parts fit neatly.
Please note: the front spar joiner 30 is deeper than the rear
joiner 31.
When you are confident that everything fits properly, glue the

11
spars 50 / 51 and the spar joiners 30 / 31 in the right-hand
wing panel only.
Fig.16
Allow the glue to set hard, then push the second set of spars
into the end of the spar joiners (don’t glue them!). Fit the left-
hand wing panel on the projecting spars and spar joiners and
check that the parts fit together neatly. When you are satisfied,
apply adhesive to the spar recess of the left-hand wing panel,
and glue the wing panel in place; take care to position the
parts accurately.
Fig.17
13. Freeing the ailerons and landing flaps
The ailerons are an integral part of the wing panels 6and 7;
release them by cutting along the recessed lines at both ends.
Move the ailerons up and down repeatedly to “free up” the
hinge lines, but take care not to over-stretch them - don’t sepa-
rate the ailerons from the wings!
If you intend using the landing flaps, release them in the same
way by cutting at both ends, then separate them from the wing
panels. Sand the cut lines smooth and flat.
Figs. 18 / 19
Position the flaps against the wings with the top and bottom
surfaces flush, and fix them in place temporarily using paper
masking tape. Check that the flaps still follow the wing airfoil
accurately. If you do not wish to fit working landing flaps, the
projecting part can simply be cut off.
Fig.20
If you do wish to install working landing flaps, assemble the
six offset hinges from parts 41 and 42.
Spray a very thin coat of cyano activator (kicker) into the horn
recesses in the flaps, and allow it to air-dry for about sixty
seconds. The prepared hinges can now be glued in the
recesses in the landing flaps as shown.
Fig.21
Insert the pivot barrels 43 in the holes of both aileron horns.
Fit the socket-head grubscrews 28 in the pivot barrels 43 using
the allen key 29.
Glue the horns 41+44 in the appropriate recesses in the
ailerons.
Fig.22
14. Installing the aileron servos
Set the aileron servos to neutral (centre) from the transmitter,
then fit the output arms on them in such a way that the arms
project at 90° to one side of the case - 1 x left and 1 x right
(mirror-image pair).
Check that the servos are a snug sliding fit in the moulded-in
recesses in the wing panels 6and 7; Note that the output shaft
should be towards the wing leading edge.
Depending on the type of servo you are using, you may find
that minor trimming is required to the servo recesses. The
servos can be secured with a drop of hot-melt glue or cyano
applied to the slots in the wings which accommodate the servo
mounting lugs: press the servos into the recesses immediately
after applying the glue, and apply another drop of adhesive to
each mounting lug if required for security.
15. Installing the aileron pushrods
Connect the pre-formed end of the aileron pushrods 45 to the
outermost hole in the servo output arm, and slip the plain end
through the swivel pushrod connectors attached to the aileron
horns. Hold the ailerons at neutral, and tighten the grubscrews
28 to clamp the pushrods in place.
16. Installing the landing flap servos
Set the flap servos to “neutral” from the transmitter. Fit the long
output arms on the servos in such a way that the levers are
positioned at 70° at the neutral position (see template in Fig.
23). The servos should form a mirror-image pair, i.e. one left,
one right. Cut out the template if required.
Connect the pre-formed end of the landing flap pushrods 46 to
the servo output arms at a distance of about 23 mm from the
servo shaft centre, and slip the plain end through the swivel
pushrod connectors 25. With the servos at centre, set the flaps
to the neutral position and tighten the grubscrews 28 to clamp
the pushrods in place.
Fig. 24
Once everything is correctly assembled, you can separate the
wing panels again by sliding them apart in the centre.
17. Aero-tow mechanism
The aero-tow mechanism 47 can be installed at any time.
The aero-tow unit should be glued in the recess in the right-
hand wing panel. Set the servo to “neutral” and fit the output
arm on the servo, facing directly forward. Connect the tow-
release pushrod 48 to the servo output arm, then bend it to the
shapeshown and cut itto length. Secure theservo in the recess
in the underside of the wing with a little hot-melt glue or cyano.
Fig.25
18. Trial assembly
Fit the wing panels together, place the wing on the fuselage,
andfix it in placeusing the two plasticscrews32. Theprojecting
areas on the underside of the wing centre section automatically
keep the wing in the correct position.
Fig.26
19. Power set:
The model is designed for the MULTIPLEX FunCub power set,
Order No. 33 2649. The current drain with a 3S LiPo flight
battery and the standard propeller (supplied) is:
approx. 23A
The power set consists of a Himax C 3516-0840 motor,
MULTIcont BL-30 S-BEC speed controller, 13 x 4” propeller,
propeller driver and spinner.
Fig.27
20. Attaching the motor bulkhead to the motor mount
The motor sidethrust and downthrust can be adjusted in
conjunction with the motor mounts 37 and the motor bulkhead
38. The motor mounts are installed asymmetrically as
standard: when the four adjustment screws 39 are set flush,
the motor is positioned with maximum possible sidethrust
and no downthrust, which is our recommended basic setting.
These settings apply when looking at the motor bulkhead from
the tail.
Fig.28
The grubscrews should project from the rear of the motor
bulkhead by the amounts stated below:
Upper left: 3.0 mm
Upper right: 3.0 mm
Lower left: 1.5 mm
Lower right: 1.5 mm
The screws should project by the stated values.
You will need to make minor adjustments during test-flying!

12
21. Installing the motor
Fix the motor to the motor bulkhead 38 using the screws
included in the power set. Install this assembly using the
screws 40, as shown in Fig. 27.
22. Installing the canopy latch catches
Fit the canopy 5into the fuselage from the front, sliding it in
towards the wing, and only then push it down at the front. Fit
the two latch tongues 23 “dry”, and carefully position them
flush. Apply thick cyano to the serrated areas, then insert the
latch tongues into the slots in the canopy. Slide the canopy into
the fuselage, and allow the latch tongues to engage in the
latch catches 22. Immediately position the canopy accurately
on the fuselage while the glue is still wet. Wait for about one
minute before carefully opening the canopy again. Apply more
glue to the latch tongues if necessary.
Fig.29
23. Installing the flight pack and receiver
Thespacefor the flightbattery is underthe canopy, andextends
back under the wing saddle. Stick the strips of Velcro (hook-
and-loop) tape 20 / 21 in this area to secure the battery.
The speed controller fits in the side of the fuselage adjacent to
the flight pack. Install the receiver under the wing saddle, again
using the Velcro strips 20 / 21.
Fig.30
Do not connect the battery to the speed controller unless
the transmitter is already switched on, and you are sure
that the throttle control is at the “OFF” position.
Connect the servo plugs to the receiver. Switch the transmitter
on, connect the flight battery to the speed controller, and the
controller to the receiver.
Now switch the motor on briefly so that you can check the
direction of rotation of the propeller (when checking the motor
be sure to hold the model securely, and remove any loose,
lightweight objects in front of and behind the model). If the
motor spins in the wrong direction, reverse two of the wires at
the motor - do not reverse the flight battery!
Caution:keepwellclearof the propeller blades: serious injury
risk!
24. Deploying the aerial on the underside of the fuselage
The receiver aerial can be routed down and out of the
underside of the fuselage, and then deployed aft towards the
tail. You will need to pierce a hole through the fuselage floor,
working from the inside of the fuselage. Slip the aerial through
the hole from the inside, and fix it to the fuselage with a strip of
adhesive tape. If the aerial is longer (35 / 40 MHz), allow the
loose end to trail freely.
25. Setting the control surface travels
Setting the correct control surface travels is important if you
wish the model to respond to the control commands in a
balanced manner.
Up-elevator (stick back, towards you) 25 mm
Down-elevator (stick forward, away from you) 22 mm
Left rudder 25 mm
Right rudder 25 mm
Up-aileron 22 mm
Down-aileron 12 mm
The travels should always be measured at the widest part of
the control surface.
The control surface throws are not critical, and if you are unable
to set the exact stated travels using your transmitter’s
adjustment facilities, that’s no problem. If the discrepancy is
relatively great, you will need to re-connect the linkage using a
different hole at the horn or servo output arm.
If you intend to fly the model as a trainer, we recommend that
you reduce the control surface travels to about 50 - 60% of the
stated values.
26. Gilding the lily - applying the decals
The kit is supplied with a multi-colour decal sheet 2. Cut out
the individual name placards and emblems and apply them to
the model in the position shown in the kit box illustration, or in
an arrangement which you find pleasing. The decals cannot
be re-positioned once applied, so place them carefully!
27. Setting the Centre of Gravity
Like any other aircraft, the FunCub must be balanced at a
particular point in order to achieve stable flying characteristics.
Assemble your model ready to fly, and install the flight battery.
The Centre of Gravity (CG) should be at a position 80 mm aft
of the root leading edge, i.e. at the fuselage sides. Mark this
point on both sides of the fuselage.
Support the model at this position on two fingertips, and it
should balance level. If not, you can move the flight battery
forward or aft to correct the balance point. Once the correct
position is found, mark the location of the flight pack inside the
model to ensure that it is always replaced in the same position.
The CG location is not critical - 10 mm forward or aft of the
stated position presents no problems.
Fig.31
28. Preparations for the first flight
Please wait for a day with as little breeze as possible for the
model’s initial test-flight. The evening hours are often ideal for
calm conditions.
Be sure to carry out a range check before the first flight,
using the procedure described in your RC system
instructions. If you encounter a problem, please don’t risk a
flight.
Send the whole system (including battery, switch harness and
servos) to the Service Department of your RC system
manufacturer and ask them to check it.
The first flight ...
The FunCub should always be launched exactly into any wind.
Ifyou are a beginner to model flying westrongly recommend
that you ask an experienced model pilot to help you for the
first few flights.
29. Taking off from a hard strip
If you have access to a hard landing strip, a ground take-off is
always the safest option.
Once the model is test-flown you will be able to take off and
land from rough grass, i.e. without a mown strip - and precisely
that is the charm of this model.
30. Hand-launching
Please don’t try unpowered test-glides with this model - the
result is invariably a damaged airframe. The FunCub should
be hand-launched with the motor running at half-throttle, and
always pointing directly into wind.
Ask an experienced modeller to hand-launch your aircraft for
you.
The launcher should run forward for two or three paces, then

13
give the machine a powerful straight launch, with the wings
and fuselage level. Use the controls to hold the model in a
steady, gentle climb - remember to keep the rate of ascent
shallow and the airspeed high!
Allow the aeroplane to climb to a safe height, then adjust the
trims on the transmitter until it flies in a perfectly straight line
“hands off”. While the model is still at a safe altitude, throttle
back and try out the controls on the glide. Carry out a “dry run”
landing approach at a safe height so that you are prepared for
the real landing when the battery runs flat.
Don’ttry any tight turnsat first, and especially not on thelanding
approach at low altitude. It is always better to land safely at
some distance from you, than to force the model back to your
feet and risk a heavy landing.
31. Safety
Safety is the First Commandment when flying any model
aircraft.
Third party insurance should be considered a basic essential.
If you join a model club suitable cover will usually be available
through the organisation. It is your personal responsibility to
ensure that your insurance is adequate. Make it your job to
keep your models and your radio control system in perfect
order at all times. Check the correct charging procedure for the
batteries you are using. Make use of all sensible safety
systems and precautions which are advised for your system.
An excellent source of practical accessories is the MULTIPLEX
main catalogue, as our products are designed and
manufactured exclusively by practising modellers for other
practising modellers.
Always fly with a responsible attitude. You may think that flying
low over other people’s heads is proof of your piloting skill;
others know better. The real expert does not need to prove
himself in such childish ways. Let other pilots know that this is
what you think too.
Always fly in such a way that you do not endanger yourself or
others. Bear in mind that even the best RC system in the world
is subject to outside interference. No matter how many years
of accident-free flying you have under your belt, you have no
idea what will happen in the next minute.
We - the MULTIPLEX team - hope you have many hours of
pleasure building and flying your new model.
MULTIPLEX Modellsport GmbH & Co. KG
Product development and maintenance
Klaus Michler

14
Parts List - FunCub
Part No. Description Material Dimensions
No. off
1 1 Building instructions
2 1 Decal sheet 500 x 880 mm
3 1 L.H. fuselage shell Moulded Elapor foam Ready made
4 1 R.H. fuselage shell Moulded Elapor foam Ready made
5 1 Canopy Moulded Elapor foam Ready made
6 1 L.H. wing panel Moulded Elapor foam Ready made
7 1 R.H. wing panel Moulded Elapor foam Ready made
8 1 Tailplane Moulded Elapor foam Ready made
9 1 Fin Moulded Elapor foam Ready made
70 1 Main undercarriage unit Spring steel, 2.5 Ø Ready made
71 2 Lightweight wheel Plastic, EPP 120 Ø, hub bore 2.6 mm
Small parts set, motor mount
20 3 Velcro tape, hook 25 x 60 mm
21 3 Velcro tape, loop 25 x 60 mm
22 2 Latch catch Inj.-moulded plastic Ready made
23 2 Latch tongue Inj.-moulded plastic Ready made
24 1 Glue-fitting horn Inj.-moulded plastic Ready made
25 4 Swivel pushrod connector Metal Ready made, 6 mm Ø
26 4 Washer Metal M2
27 4 Nut Metal M2
28 6 Socket-head grubscrew Metal M3 x 3 mm
29 1 Allen key Metal 1.5 mm A/F
30 1 Front spar joiner, “deep” Inj.-moulded plastic Ready made
31 1 Rear spar joiner, “shallow” Inj.-moulded plastic Ready made
32 2 Screw Plastic M5 x 50 mm
33 2 Wing spreader plate A Inj.-moulded plastic Ready made, M5
34 2 Wing spreader plate B Inj.-moulded plastic Ready made, M5
35 1 Glue-fitting horn, tailskid Inj.-moulded plastic Ready made
36 1 Glue-fitting tailwheel bracket Inj.-moulded plastic Ready made
37 2 Motor mount Inj.-moulded plastic Ready made
38 1 Motor bulkhead Inj.-moulded plastic Ready made
39 4 Motor bulkhead adjustment screw Metal M3 x 10 mm
40 2 Motor bulkhead mounting screw Metal M3 x 16 mm
41 8 “Twin” control surface horn Plastic Ready made
42 6 “Twin” horn bracket Plastic Ready made
43 2 Pivot barrel Metal Ready made, 6 mm Ø
44 2 Glue-fitting horn, landing flaps Inj.-moulded plastic Ready made
45 2 Pre-formed aileron pushrod (Z-bend) Metal 1 Ø x 90 mm
46 2 Pre-formed flap pushrod (Z-bend) Metal 1 Ø x 105 mm
47 1 Aero-tow mechanism Inj.-moulded plastic Ready made
48 1 Aero-tow release pushrod (Z-bend) Metal 1 Ø x 90 mm
Wire and rod set
50 2 Front tubular spar CRP tube 8 Ø x 6 x 400 mm
51 2 Rear tubular spar CRP tube 8 Ø x 6 x 100mm
52 1 Elevator pushrod (Z-bend) Metal 0.8 Ø x 510 mm
53 1 Rudder pushrod (Z-bend) Metal 0.8 Ø x 510 mm
54 1 Elevator snake outer sleeve Plastic 3/2 Ø x 480 mm
55 1 Rudder snake outer sleeve Plastic 3/2 Ø x 480 mm
56 1 Elevator snake inner sleeve Plastic 2/1 Ø x 500 mm
57 1 Rudder snake inner sleeve Plastic 2/1 Ø x 500 mm
Undercarriage set
72 4 Collet Metal 2.7 Ø / 8 x 5 mm
73 4 Socket-head grubscrew Metal M3 x 3 mm
74 1 Undercarriage bracket Plastic Ready made
75 1 Screw Metal M3 x 12 mm
76 1 Tailwheel unit Metal 1.3 mm Ø
77 1 Lightweight tailwheel Plastic, EPP 53 Ø, hub bore 1.6 mm
78 2 Tailwheel retainer (tubular rivet) Metalrivet 2.0 Ø x 0.2 x 3 mm

18
6
7
8
9
5
4
3
35
51
36
29
31
30
73
23
32
71
74
38
37
45
8x41 44 52
56
54
57
53
55
48
6x 42
46
25
78
76
24
Abb. 1
Abb. 2
34
3x 20
3x 21
4x 39 2x 40
72
22
47
33
50
75
70
77
43
28 27 26
26
27
28
25

19
Abb. 3 Abb. 4
Abb. 6Abb. 5
Abb. 7
Abb. 9 Abb.10
4
22
37
4
52
56
54
54 56 52
53 57 55
43
27 26 24 25 28
8
8
3
4
35
36
76
Abb.8
43
2x 33/34

20
7
Abb. 18
Abb. 16
Abb. 14
Abb. 12
Abb. 13
Abb. 15
Abb. 17
Abb. 11
28
25
35
26
27
76 78
77
78
76
36
9
8
74
34
70
6
51
50
7
50
30
51
31
71
73
72
75

21
Abb. 19 Abb. 20
Abb. 22
Abb. 21
Abb. 25
7
7
8
48
47
Abb. 26
32
7
6
3 x 41+42
28
43
41
27, 26, 44, 25, 28
70°
Abb. 23
46
45
Abb. 24

22
Abb. 30
Abb. 31
Abb. 29
Abb. 28
23
5
Motor ESC
Akku RX
Antriebsatz / Powerset
# 33 2649
Abb. 27
38
80 mm

23

37
Ersatzteile (bitte bei Ihrem Fachhändler bestellen)
Replacement parts (please order from your model shop)
Pièces de rechanges (S.V.P. à ne commander que chez votre revendeur)
Parti di ricambio (da ordinare presso il rivenditore)
Repuestos (por favor, diríjase a su distribuidor)
# 22 4113
Tragflächen
Wing panels
Ailes
Ali
Alas
# 22 4140
Leitwerkssatz
Tail set
Kit de stabilisateurs
Piani di coda
Kit de empenajes
# 22 4137
Rumpfhälften + Bowdenzüge
Fuselage shells + snakes
Moitié de fuselage + tringlerie
Semigusci fusoliera + bowden
Fuselaje + transmisiones bowden
# 22 4138
Kabinenhaube
Canopy
Verrière
Capottina
Cabina
# 72 3130
CFK Holmrohr
CFRP Wing joiner
Tube en fibre de carbo
Tubi in carbonio
Tubo Fibra de vidrio

38
Ersatzteile (bitte bei Ihrem Fachhändler bestellen)
Replacement parts (please order from your model shop)
Pièces de rechanges (S.V.P. à ne commander que chez votre revendeur)
Parti di ricambio (da ordinare presso il rivenditore)
Repuestos (por favor, diríjase a su distribuidor)
# 72 4565
Dekorbogen
Decal sheet
Planche de décoration
Decals
Lámina decorativa
# 22 4115
Kleinteilesatz
Small items set
Petit nécessaire
Minuteria
Piezas pequeñas
# 22 4114
Hauptfahrwerk
Mainundercarriage
Train d’atterrissage principal
Carrelloprincipale
Tren principal
#70 2010
Landeklappen Scharniere 6 Satz
Landing flap hinge, set of 6
Charnières volets à fente, lot de 6
Cerniere flap 6 pz.
bisagras de flaps, set de 6
#73 3198
Räder Ø 120 mm
wheels 120 mm Ø
roues 120 mm Ø
Ruote 120 mm Ø
ruedas 120 mm Ø
#73 3189
Räder Ø 54 mm
wheels 54 mm Ø
roues 54 mm Ø
Ruote 54 mm Ø
ruedas 54 mm Ø
A
B
