Funke ATR833-II Instruction Manual

ff.u.n.k.e. f.u.n.k.e. means –fabrication · utilities · network · know-how · engineering
Operation and Installation
(Dokument-Nr. 01.1313.010.71e)
OLED/LCD P/N 600R01-(3xx)-(xxx)
ATR - Remote
Control Unit

ATR-Remote-Control / P/N 600R01-(3xx)-(xxx)
Operation and Installation
Doc.-Nr. 01.1313.010.71e / Revision 1.00 2
Change History
Revision
Date
Description of Change
1.00
15.11.2017
First release
List of the Service Bulletins (SB)
Services bulletins are to be inserted in the manual and to be put down
in this table.
SB Number
Rev.
No.
Issue Date
Entry Date
Name

ATR-Remote-Control / P/N 600R01-(3xx)-(xxx)
Operation and Installation
3 Doc.-Nr. 01.1313.010.71e / Revision 1.00
Contents
1GENERAL.........................................................................................4
1.1 Symbols..................................................................................4
1.2 Abbreviations..........................................................................4
1.3 Customer Support...................................................................5
1.4 Features..................................................................................5
2OPERATION.....................................................................................6
3INSTALLATION ................................................................................7
3.1 Advices and Tips.....................................................................7
3.2 Scope of delivery.....................................................................7
3.3 Unpacking and Inspecting the Equipment...............................7
3.4 Mounting.................................................................................8
3.5 Wiring......................................................................................8
3.5.1 Connection Using the Provided Cable Set....................8
3.5.2 Connections Using .......................................................9
3.5.3 Connector Pin Allocations.............................................9
3.5.4 Wiring Diagram...........................................................10
3.6 Post-Installation Check..........................................................10
3.7 Accessories...........................................................................10
3.8 Drawings...............................................................................11
3.8.1 Dimensions.................................................................11
3.8.2 Mounting Advices.......................................................11
4APPENDIX......................................................................................12
4.1 Frequency/Channel-Plan.......................................................12
4.2 Technical Data......................................................................13
4.3 Environmental Conditions .....................................................14

ATR-Remote-Control / P/N 600R01-(3xx)-(xxx)
Operation and Installation
Doc.-Nr. 01.1313.010.71e / Revision 1.00 4
1 GENERAL
This manual contains information about the physical, mechanical and
electrical characteristics as well as information about installation and
operation of the ATR-Remote-Control Unit for the VHF Com transceivers
ATR833-II/ATR833A-II. The ATR-Remote-Control Unit is available with
LCD or OLED display.
1.1 Symbols
Advices whose non-observance can cause radiation
damage to the human body or ignition of combustible
materials.
Advices whose non-observance can cause damage to the
device or other parts of the equipment.
Information
1.2 Abbreviations
Abb.
Name/subject
Definition
DIM
Dimming
Display Brightness
EXT
External audio input
Volume of external audio signal
INT
Intercom
Volume of board-internal intercom
MIC
Microphone
PTT
Push-To-Talk
Key to activate radio transmission
SEL
Selection
SQ
Squelch
Noise suppression radio reception
VOL
Volume
Volume of radio reception
VOX
Voice activation
Volume threshold for voice-
activated intercom

ATR-Remote-Control / P/N 600R01-(3xx)-(xxx)
Operation and Installation
5 Doc.-Nr. 01.1313.010.71e / Revision 1.00
1.3 Customer Support
In order to facilitate a rapid return of shipments, please follow the
instructions of the input guide “Reshipment RMA” provided at the
Service-Area within the f.u.n.k.e. AVIONICS GmbH web portal
www.funkeavionics.de.
Any suggestions for improvement of our manuals are
welcome. Contact: [e-mail].
Informations on software updates are available at f.u.n.k.e.
AVIONICS GmbH.
1.4 Features
Remote Control for controlling VHF COM transceivers
oATR833-II
oATR833A-II
Ideal for tandem seated aircraft:
oAutomatic deactivation of remote control on deactivation of
radio
oUse of radio still possible without activation of remote control
Fully transparent remote control –everybody sees what the other
does
Direct access to the 20frequency memories of the remote
controlled radio, including their names
Easy recall of the 10 last used frequencies
Easy installation –plugin of one connector only.
High contrast LCD / OLED display 128x64 dot matrix

ATR-Remote-Control / P/N 600R01-(3xx)-(xxx)
Operation and Installation
Doc.-Nr. 01.1313.010.71e / Revision 1.00 6
2 OPERATION
Operation of the ATR833-II or ATR833A-II radio via the ATR-Remote-
Control Unit is identical to operation on the radio itself.
The description of the controls, as well as the settings and configuration
menu can be found in the manual for the ATR833-II radio
(Doc. No. 01.143.010.71e) in Chapters 2 and 3.
Note:
The AUTO ON setting applies to the remote control, not the radio.

ATR-Remote-Control / P/N 600R01-(3xx)-(xxx)
Operation and Installation
7 Doc.-Nr. 01.1313.010.71e / Revision 1.00
3 INSTALLATION
3.1 Advices and Tips
The following suggestions should be considered before installing
The assigned installation company could perform wiring. For diagrams
refer to section 3.5 Wiring.
3.2 Scope of delivery
Part Number
Description
ATR-Remote-Control
(ATR833RT-II)
Remote Control Unit for ATR833-II and
ATR833A-II in two-knob versions
ZUB4
2x solid an 2x hollow mounting screws –for
panels up to 3mm
BSKS600R4
Cable set for remote control
01.1313.010.71e
User Manual „Operation and Installation“
EASA Form 1
3.3 Unpacking and Inspecting the Equipment
Carefully unpack the equipment. Damages due to transportation must be
reported to the shipping company immediately. Save the shipping
container and all packing materials to substantiate your claim
For storage or reshipment the original packaging should be
used.

ATR-Remote-Control / P/N 600R01-(3xx)-(xxx)
Operation and Installation
Doc.-Nr. 01.1313.010.71e / Revision 1.00 8
3.4 Mounting
In cooperation with a maintenance shop, location and kind of the
installation are specified. The maintenance shop can supply all
cables. Suitable sets of cables are available from f.u.n.k.e.
AVIONICS GmbH.
Select a position away from heat sources. Care for adequate
convection cooling.
Leave sufficient space for the installation of cables and connectors.
Avoid sharp bends and wiring close to control cables.
Leave sufficient lead length for inspection or repair of the wiring of
the connector.
Bend the harness at the rear connectors to inhibit water droplets
(formed due to condensation) from collecting in the connector.
Remove rotary knobs before mounting:
oLift-off caps of the rotary knobs with an appropriate tool
oLoosen screw and remove rotary knob
oInsert cap correctly orientated!
The equipment is fixed front-laterally with four 6-mm through-hole
screws in a 57 mm cut-out.
For mounting details/drawing refer to chapter 3.8.2 Mounting
Advices.
3.5 Wiring
3.5.1 Connection Using the Provided Cable Set
Simply connect one D-SUB connector to the ATR-Remote-Control and
the other D-SUB connector to the mating connector of the remote
controlled radio’s cable set.
The ATR-Remote-Control now gets the power from the remote controlled
device; thus it’s operation depends onto the operation of the remote
controlled device.

ATR-Remote-Control / P/N 600R01-(3xx)-(xxx)
Operation and Installation
9 Doc.-Nr. 01.1313.010.71e / Revision 1.00
3.5.2 Connections Using
Power Supply (Power, GND): AWG18 (0,96 mm²)
Signals: AWG22 (0,38 mm²)
The conductors must be approved for aircraft use.
RX and TX should be shielded individually, or at least be pair-twisted and
shielded together.
The light input should
in aircraft with lighting bus connected to this,
in the more common case of aircraft without lighting bus connected
to the power supply.
3.5.3 Connector Pin Allocations
DATA TX
DATA RX + 5V
GND
Connector side
MAIN SW
REMOTE SW
+ 5V
When powering the remote control not by the output of the
switched power output of the remote controlled device but
directly by the aircraft’s power supply, the power input line
(+UB) must be equipped with an external fuse (1 Amp. slow-
blow).
Connector side
(Devices backside)

ATR-Remote-Control / P/N 600R01-(3xx)-(xxx)
Operation and Installation
Doc.-Nr. 01.1313.010.71e / Revision 1.00 10
3.5.4 Wiring Diagram
The connection between the remote control and the 9-pin D-SUB
connector of the ATR833-II cable can be realized by a standard 9-wire
D-SUB cable.
The connection between the 9-pin D-SUB remote connector and the
radio (ATR833-II, ATR833A-II) is shown in the following figure.
3.6 Post-Installation Check
When installation is completed all steering and control functions of the
aircraft are to be examined, in order to exclude disturbances by the
wiring.
For performing an installation check of the remote control, first switch on
the remote controlled device, and subsequently the ATR600RT. After the
startup-message, which includes the device type, the display should first
show the message “SYNCHRONIZING”, followed by changing to the
normal mode display including the two frequencies, within a few
seconds. The remote control is now ready for use.
3.7 Accessories
Suitable accessories like cable sets, connectors or switches can be
purchased at our online shop on www.funkeavionics.de.
to ATR833-II
ATR833A-II
to ATR-Remote-Control
9-pol. SUB-D Female

ATR-Remote-Control / P/N 600R01-(3xx)-(xxx)
Operation and Installation
11 Doc.-Nr. 01.1313.010.71e / Revision 1.00
3.8 Drawings
3.8.1 Dimensions
3.8.2 Mounting Advices
For mounting in panels with a thickness of 3–5 mm longer screws are
available (Order No. ZUB5: includes 2x solid und 2x hollow mounting
screws):
Dimensions in
connection area
Dimensions of
panel cut-out
57,5 mm
47,0 mm
2 x 6,5 mm
2 x 4,5 mm
47,0 mm
No screws may be turned in more than max. 15mm into the
device –even if no hard limit is noticeable!
The D-SUB-Connector hast to be clamped with both spring
locks. It is recommended to additionally secure them with a
cable tie.
37mm
ATR
Remote
Control

ATR-Remote-Control / P/N 600R01-(3xx)-(xxx)
Operation and Installation
Doc.-Nr. 01.1313.010.71e / Revision 1.00 12
4 APPENDIX
4.1 Frequency/Channel-Plan
In the following table examples for operating and displayed frequencies
in the range between 118.000 ... 118.100 MHz are given. This table can
be continued to 136.975 MHz following the same scheme.
Operating
Frequency
(MHz)
Channel
Width
(kHz)
Displayed
Frequency in
8.33/25 kHz Mode
Displayed
Frequency in
25 kHz Mode
118.0000
25
118.000
118.000
118.0000
8.33
118.005
118.0083
8.33
118.010
118.0166
8.33
118.015
118.0250
25
118.025
118.025
118.0250
8.33
118.030
118.0333
8.33
118.035
118.0416
8.33
118.040
118.0500
25
118.050
118.050
118.0500
8.33
118.055
118.0583
8.33
118.060
118.0666
8.33
118.065
118.0750
25
118.075
118.075
118.0750
8.33
118.080
118.0833
8.33
118.085
118.0916
8.33
118.090
118.1000
25
118.100
118.100
118.1000
8.33
118.105
etc.
etc.
etc.
etc.

ATR-Remote-Control / P/N 600R01-(3xx)-(xxx)
Operation and Installation
13 Doc.-Nr. 01.1313.010.71e / Revision 1.00
4.2 Technical Data
GENERAL
COMPLIANCE
JTSO-2C37e,ED-23B Class 4, 6
JTSO-2C38e,ED-23B Class C, E
TSO-C37d, RTCA DO-186A Class 4, 6
TSO-C38d, RTCA DO-186A Class C, E
LBA.O.10.911/115 JTSO
DIMENSIONS
Height: 65 mm (2,56 in)
Width: 65 mm (2,56 in)
Depth: 86 mm (3,27 in) behind the panel
WEIGHT
0.43 lbs (0.20 kg)
MOUNTING
Panel Mounted
TEMPERATURE RANGES
OPERATION
STORAGE
-20 °C ... +55 °C,30 min at +70 °C
-55 °C . . +85 °C
MAX. HEIGHT
35.000ft
VIBRATION
DO-160D, Cat. S, Vibration Curve M
HUMIDITY
RTCA DO-160D, Cat. A
SHOCK
6 G operation
20 G crash safety
RTCA DO-160D ENV.CAT.
[C1Z]CAA[SM]XXXXXXZBAAA[YY]M[B3F3]XXA
POWER SUPPLY
13,8 VDC (11 VDC ... 18 VDC)
60 mA ( typ.)
CURRENT
CONSUMPTION
600 mW
COMPASS-SAFE
DISTANCE
30cm

ATR-Remote-Control / P/N 600R01-(3xx)-(xxx)
Operation and Installation
Doc.-Nr. 01.1313.010.71e / Revision 1.00 14
4.3 Environmental Conditions
Characteristic DO–160D
Section
Cat
Condition
Temperature / Altitude
4.0
C1
Low ground survival
temperature
4.5.1
–55°C
Low operating temperature
4.5.1
–20°C
High ground survival
Temperature
4.5.2
+ 85°C
High Short-time Operating
Temperature
4.5.2
+ 70°C
High Operating Temperature
4.5.3
+ 55°C
In-Flight Loss of Cooling
4.5.4
Z
No auxiliary cooling
required
Altitude
4.6.1
C1
35 000 ft
Temperature Variation
5.0
C
2°C change rate minimum
per minute
Humidity
6.0
A
Shock
7.0
A
6 G operational shocks
20 G Crash Safety
Test Type R in all 6
directions
Vibration
8.0
S
Vibration Curve M
Explosion Proofness
9.0
X
No test required
Water Proofness
10.0
X
No test required
Fluids Susceptibilities
11.0
X
No test required
Sand and Dust
12.0
X
No test required
Fungus Resistance
13.0
X
No test required
Salt Spray
14.0
X
No test required
Magnetic Effect
15.0
Z
Less than 0,3 m Compass
Safe Distance
Power Input (DC)
16.0
B
Voltage Spike Conducted
17.0
A

ATR-Remote-Control / P/N 600R01-(3xx)-(xxx)
Operation and Installation
15 Doc.-Nr. 01.1313.010.71e / Revision 1.00
Characteristic DO–160D
Section
Cat
Condition
Audio Frequency Conducted
Susceptibility
18.0
A
Induced Signal Susceptibility
19.0
A
Radio Frequency
Susceptibility
20.0
YY
Emission of RF Energy
21.0
M
Lightning Induced Transient
Susceptibility
22.0
B3
F3
Lightning Direct Effects
23.0
X
No test required
Icing
24.0
X
No test required
Electrostatic Discharge (ESD)
25.0
A

ATR-Remote-Control / P/N 600R01-(3xx)-(xxx)
Operation and Installation
Doc.-Nr. 01.1313.010.71e / Revision 1.00 16
Notes:

ATR-Remote-Control / P/N 600R01-(3xx)-(xxx)
Operation and Installation
17 Doc.-Nr. 01.1313.010.71e / Revision 1.00

ff.u.n.k.e. f.u.n.k.e. means –fabrication · utilities · network · know-how · engineering
f.u.n.k.e. AVIONICS GmbH
Heinz-Strachowitz-Str. 4
DE-86807 Buchloe
Germany
phone.: [phone]
fax.: [phone]
E-mail:
[e-mail]
www.funkeavionics.de
