Funkwerk P/N 800ATC-A-(201)-(301) Instruction Manual

TRT800
A
- OLED
Mode S Transponder
P/N 800ATC-A-(201)-(301)
Operation and Installation
(Document-No. 03.2112.010.71e)

TRT800A / P/N 800ATC-A-(201)-(301)
Operation and Installation
2 Document-No: 03.2112.010.71e / Revision: 1.02
Change History
Revision Date Description of Change
1.00 19.11.2008 First Release
1.01 24.04.2009 Added explanation of „LOCK“ indicator in 2.3
In consequence of customer feedback added
hint in section 4.2.1.
Corrections after internal review
1.02 02.07.2010 Corrections after internal review
Added information on connectors
List of Service-Bulletins (SB)
Service Bulletins have to be inserted into this manual and to be enlisted
in the following table.
SB No
Rev.
No. Issue Date
Insertion
Date Name
SB TRT800-A-H-1 1.04 17.10.2008
Survey of Variants
Part Number Description
P/N 800ATC-A-(201)–(301) Version with OLED-Display
Manual adjustment of display brightness
one VFR-Code
eight storable record sets for
AA-/AC-Code (ICAO 24bit-Address),
FID, Ground-Switch, RI-Code, GPS-
/Interface-Setting

TRT800A / P/N 800ATC-A-(201)-(301)
Operation and Installation
3Document-No: 03.2112.010.71e / Revision: 1.02
Table of Contents
1GENERAL ..........................................................................................5
1.1 Symbols ...................................................................................5
1.2 Abbreviations ...........................................................................5
1.3 Customer Support ....................................................................6
1.4 Features ...................................................................................7
2OPERATION ......................................................................................8
2.1 Controls....................................................................................8
2.2 ON/OFF..................................................................................10
2.3 Display - Brightness ...............................................................10
2.4 Display - Indications ...............................................................10
2.5 Flight-ID (FID) ........................................................................12
2.5.1 Display of Flight-ID ......................................................12
2.5.2 Configure Flight-ID ......................................................12
2.6 Transponder Mode selection..................................................13
2.7 Squawk-Setting ......................................................................13
2.8 VFR – Squawk .......................................................................14
2.9 ID – Special Position Identification (SPI): “Squawk Ident”......14
2.10 Error-Codes............................................................................14
3INSTALLATION................................................................................15
3.1 Notes......................................................................................15
3.2 Telecommunication data ........................................................15
3.3 Scope of Delivery ...................................................................15
3.4 Unpacking and Inspection of the Equipment..........................16
3.5 Mounting ................................................................................16
3.6 Equipment Connections .........................................................17
3.6.1 Electrical Connections.................................................17
3.6.2 Static Air Port ..............................................................18
3.7 Wiring .....................................................................................19
3.7.1 Conductor Cross Section.............................................19
3.7.2 TRT800EM – External Memory ...................................19
3.7.3 TRT800EMSS – External Memory (with RS232) ........20
3.8 Antenna..................................................................................21
3.8.1 Antenna Selection .......................................................21

TRT800A / P/N 800ATC-A-(201)-(301)
Operation and Installation
4 Document-No: 03.2112.010.71e / Revision: 1.02
3.8.2 Installation Recommendation ......................................21
3.8.3 Antenna Wiring............................................................21
3.9 Post-Installation Check ..........................................................22
3.10 Starting Up .............................................................................22
3.11 Accessories............................................................................23
3.12 Drawings ................................................................................24
3.12.1 Dimensions..................................................................24
3.12.2 Mounting Advices ........................................................25
4SETTINGS .......................................................................................27
4.1 Overview ................................................................................27
4.1.1 Error Logging...............................................................27
4.1.2 ICAO 24-Bit Aircraft Address (AA)...............................27
4.1.3 Aircraft Category (AC) .................................................28
4.1.4 Flight-ID (FID)..............................................................28
4.1.5 Option Ground-Switch .................................................29
4.1.6 Reply Information - Speed Category (RI) ....................29
4.1.7 Serial Interface (RS232)..............................................29
4.2 Configuration..........................................................................31
4.2.1 Setup Steps.................................................................31
4.2.2 Functions Overview.....................................................35
5APPENDIX .......................................................................................37
5.1 Technical Data .......................................................................37
5.2 Environmental Conditions ......................................................38

TRT800A / P/N 800ATC-A-(201)-(301)
Operation and Installation
5Document-No: 03.2112.010.71e / Revision: 1.02
1 GENERAL
This manual contains information about the physical, mechanical and
electrical characteristics and about installation and operation of the
Mode S Transponder TRT800A.
1.1 Symbols
Advices whose non-observance can cause radiation
damage to the human body or ignition of combustible
materials
Advices whose non-observance can cause damage to the
device or other parts of the equipment.
Supplementary information
1.2 Abbreviations
Abb. Meaning Explanation
FID Flight ID Flight plan number or if not assigned
registration number of aircraft
SPI Special Position
Identification
Activation on request by controllers
„Squawk Ident“, transmits SPI Pulse
for 18 seconds, which highlights the
respective traffic item on the
controllers radar screen
AA Aircraft Address assigned ICAO 24 bit Address
AC Aircraft Category Defines aircraft type into specific
categories
RI Reply Information Maximum airspeed

TRT800A / P/N 800ATC-A-(201)-(301)
Operation and Installation
6 Document-No: 03.2112.010.71e / Revision: 1.02
1.3 Customer Support
In order to facilitate a rapid handling of return shipments, please follow
the instructions of the input guide „Reshipment RMA“ provided at the
Service-Area within the Funkwerk Avionics web portal www.funkwerk-
avionics.com.
Any suggestions for improvement of our manuals are
welcome. Contact: [email protected].
Informations on software updates are available at Funkwerk
Avionics

TRT800A / P/N 800ATC-A-(201)-(301)
Operation and Installation
7Document-No: 03.2112.010.71e / Revision: 1.02
1.4 Features
In order to operate the Mode-S transponder it is necessary
to request an ICAO 24-Bit Aircraft Address at the
responsible national aviation authorities. The received Code
is assigned to the specific transponder/aircraft and must be
configured within the transponder. The 24bit Address is
stored in an external memory which allows the transponder
being exchanged without requiring any further configuration.
(for detailed information refer to sections 4.1.2 and 4.2.1).
•Class 1 Level 2es Non-Diversity Mode-S-Transponder for ground
based interrogations at 1030 MHz and response at 1090 MHz
•Replies to (Secondary) Radar Interrogations
oMode-A replies with a Squawk (one of 4096 possible Codes;
e.g. flight plan number, Squawk assigned by a Controller or
the VFR Squawk 7000)
oMode C replies, including encoded flight level
oMode S replies, including aircraft address and flight level
oExtended Squitter, containing additional information on
position and velocity
•IDENT capability for activating the Special Position Identification“-
Pulse (SPI) for 18 seconds, which is requested by the Controller
„Squawk Ident“
•Maximum flight level 35 000 ft; maximum airspeed 250 kt
•Display information contains Squawk code, mode of operation and
pressure altitude.
•Temperature compensated high precision piezo-resistive pressure
sensor
•RS-232 I/O data port enabling connection with certain GPS-
Receivers in order to support ADS-B Out
•8 storable entries for AA-/AC-Code, FID, Ground-Switch, RI-Code
and GPS-/Interface-setting (stored in external memory TRT800EM)

TRT800A / P/N 800ATC-A-(201)-(301)
Operation and Installation
8 Document-No: 03.2112.010.71e / Revision: 1.02
2 OPERATION
2.1 Controls
ON / OFF „Squawk Ident“
Activate/
deactivate VFR
Change
Active ÙStandby
S
q
uawk
Select Operation
Mode
Cursor
adjustment
DIM-Regulation
Rotary Knob
for adjusting values
at the cursor
position
Operation Mode
(Mode)
Standby
S
q
uawk
Active
S
q
uawk
Flight-ID
(FID)

TRT800A / P/N 800ATC-A-(201)-(301)
Operation and Installation
9Document-No: 03.2112.010.71e / Revision: 1.02
ON/OFF Switch ON press button for approx. 0,5 s
Switch OFF press button for approx. 3 s
VFR
1. activate/deactivate VFR Squawk
(press shortly)
2. store active Squawk as VFR/VFRW-Squawk
(press button 3 s) see section. 2.8
CHANGE
1. change between active and standby-Squawk
2. works as cursor back button (opposite
function of the cursor button) during entering
values and also for navigating backwards
through the configuration menu (see 4.2.1)
IDENT „Squawk Ident“, sends Ident marking (SPI) for
18 s (in normal mode) see section. 2.9
MODE Select transponder mode ACS, A-S or Standby
(see section 2.6)
CURSOR Set position of Cursor
Activation for DIM-Regulation (see section 2.3)
Flight-ID configuration of Flight-ID (FID)
(in standby mode, press button for 5 s)
Rotary
Knob
Adjust/Enter values at current cursor position,
select options; set standby Squawk see section
2.7

TRT800A / P/N 800ATC-A-(201)-(301)
Operation and Installation
10 Document-No: 03.2112.010.71e / Revision: 1.02
2.2 ON/OFF
Switch ON: press button for 0.5 s
Switch OFF: press button for 3 s
After turning-on the display appears as follows:
(Example)
Device Name
Software-Version
Firmware-Version
If more than one aircraft address/FID exists, select the correct entry with
the rotary knob and confirm with . If there is no external memory
(TRT800EM) connected or no 24bit address defined (000000) the
message “CRADLE OFF” appears and the transponder is not working as
Mode-S device but as Mode A-C transponder.
The transponder starts in standby mode (see section 2.6).
2.3 Display - Brightness
In active mode (not standby) press -button for 2 s
Adjust brightness (DIM) with rotary knob
Return to normal operation: press or wait 5 s.
2.4 Display - Indications
