FURNA E2 User manual
FURNA E2
ASSEMBLY GUIDE
MODEL FNAE2FRM18XXX
NO Name Qty NO Name Qty
1 Lifting System 1set 9 4mm Hex Spanner 1set
2 Foot Pad 4 10 5mm Hex Spanner 1
3 Foot Margin 2 11 M6x12 Screw 8
4 M8x16 Screw 8 12 Rubber Cushion 6
5 Bracket 2 13 ST3 5x19 Screw 2
6 M6x14 Screw 8 14 ST4 8x19 Screw 8
7 M6X10 Screw 8
8 Support Beam 1
PARTS & TOOLS LIST
2
1
7 8
9 10 11 12
13 14
3
4
5
6
STEP 1
STEP 2
Loosen the 4 screws using the hex
spanner, so the frame can adjust
to the desk top size as/when needed.
Attach legs to the support beams
using the parts shown
4mm Hex spanner
4mm Hex spanner
6x12 screw 4pcs
6x14 screw 8pcs
STEP 3
STEP 4
Attach the feet and then the foot
levelling pads
Switch the frame to the upright
position and attach the brackets.
4mm Hex spanner
8x16 screw 8pcs
Foot pad 4pcs
4mm Hex spanner
Rubber Cushion 6pcs
6x12 screw 4pcs
STEP 5
STEP 6
Put the frame upside down onto
the desk top in a centered position.
Adjust the frame width to suit the
desk top (we suggest around 5cm
from each side)
Screw in the frame and control box to
the under side of the desk
top as shown using Part 14 wood
screws. Position of control box is
exible based on preference
4mm Hex spanner
6x10 screw 8pcs
Once in position, tighten the
M6x10 screws to set the frame
width
Screw in the control button panel on
the front, under side of the desk top
using Part 13 wood screws
STEP 7
Make sure all screws and bolts are
tight, then plug in cables as shown
and your desk is ready to be used!
Need help?
Get in touch by emailing contact@furna.co.uk or
by using our Live Chat feature on our website!
