Fusion MS-FHM User manual

®
Handheld Microphone
VAROITUS
Näiden varoitusten ja muistutusten laiminlyönti saattaa aiheuttaa
henkilövahinkoja, veneen vioittumisen tai tuotteen
toimintavirheitä.
Lue lisätietoja varoituksista ja muista tärkeistä seikoista stereon
mukana toimitetusta Tärkeitä turvallisuus- ja tuotetietoja
‑oppaasta.
Laite on asennettava näiden ohjeiden mukaisesti.
Katkaise aluksen virransaanti ennen tuotteen asennusta.
HUOMIO
Vältä vammat pitämällä aina turvalaseja, korvasuojaimia ja
hengityssuojusta, kun poraat, sahaat tai hiot osia.
HUOMAUTUS
Kun poraat tai sahaat, tarkista aina, mitä pinnan toisella puolella
on, jottet vahingoita alusta.
Lue asennusohjeet kokonaan ennen asennusta. Jos
asennuksessa on ongelmia, ota yhteys Fusion® tuotetukeen.
Tools Needed
• Pencil
• Drill
• 16 mm (5/8 in.) drill bit
• 2.5 mm (3/32 in.) drill bit
• 16 mm (5/8 in.) socket or wrench
• Phillips screwdriver
• Marine sealant (optional)
Installing the Connector Mount
Before drilling a hole to mount the connector, you should verify
that the microphone cable is long enough to reach the back of
the stereo and the connector mounting location.
You can use the included hardware to mount the connector on
the end of the microphone cable onto the dashboard or other
mounting surface.
1Orient the mounting plate with the flat edge of the central
hole pointing to the left, and place it on the surface where
you plan to mount the connector.
If you orient the plate with the flat surface pointing to any
direction other than the left, the microphone cable will not
point downward when you connect it.
2Using the mounting plate as a template, trace the cable
hole in the center of the mounting plate, and mark the screw
locations.
3Set the mounting plate aside.
Do not drill through the mounting plate.
4Using a 16 mm (5/8 in.) drill bit, drill the center cable hole
in the mounting surface.
5Using a 2.5 mm (3/32 in.) drill bit, drill the pilot holes.
6Place the rubber gasket between the mounting plate and
the mounting surface.
7Using the included screws, attach the mounting plate and
gasket to the mounting surface.
8Route the microphone cable to the back of the stereo and to
the connector mount.
9Feed the connector through the back of the mounting
surface.
10Secure the connector and weather cap to the mounting
plate using the nut .
HUOMAUTUS
If you disconnect the microphone from the connector, you
should secure the weather cap to avoid corrosion on the
connector contacts.
Mikrofonipidikkeen kiinnittäminen
HUOMAUTUS
Jos kiinnität telinettä lasikuituun ruuveilla, reiät on suositeltavaa
senkata pintakerroksen läpi (mutta ei syvempään)
upotusporanterällä. Siten pintakerros ei halkea, kun ruuvit
kiristetään.
Voit kiinnittää mikrofonipidikkeen kätevään paikkaan radion
lähelle.
1Valitse mikrofonin kiinnityspaikka siten, että mikrofonin
kaapeli ulottuu siihen hyvin.
2Merkitse aloitusreiät mikrofonipidikkeen avulla.
3Poraa kiinnitysreiät 3 mm (1/8 tuumaa) poranterällä.
4Kiinnitä mikrofonipidike kiinnityspintaan mukana toimitetuilla
ruuveilla .
GUID-1CD23792-2CC2-4768-B1BD-D1E11B6C23D8 v1Kesäkuu 2020
Connection Diagram
Microphone
connector
You can securely mount the microphone
connector in an accessible location (Installing
the Connector Mount, sivu 1).
RCA connectors You must connect these to the AUX IN
connector on the stereo wiring harness.
If the stereo has more than one AUX IN
connector, you must connect to the AUX1
connector.
Compatible
stereo
TELEMUTE You must connect the bare wire from the
microphone cable to the TELEMUTE wire on
the stereo wiring harness if you want the
microphone to change the source when
activated(Operating the Handheld Microphone,
sivu 2).
Negative (-)
power connection
For the best results, you should connect the
negative (-) wire from the microphone to the
same negative (-) terminal as the stereo.
Positive (+)
ignition power
connection
You should connect the positive (+) wire from
the handheld microphone to the ignition wire
from the stereo to avoid draining the battery.
You must route the combined positive (+) and
ignition wires through a 3 A fuse before connec-
ting to the ignition or manual switch.
Ignition or manual
switch
The ignition or manual switch turns on the
stereo and microphone.
Stereo power
positive connec-
tion
You should not connect the positive (+) wire
from the microphone to the constant power
cable from the stereo to avoid draining the
battery.
Power source
Operating the Handheld Microphone
You must configure the stereo before you can operate the
handheld microphone (Configuring the Fusion Stereo for the
Handheld Microphone, sivu 2).
You can use the handheld microphone from any source on the
stereo. If the source is set to anything other than AUX1 when
you hold the microphone button, the source switches to AUX1
automatically, and switches back to the original source after you
release the button.
HUOMAUTUS: you should stand behind the speakers that will
be broadcasting from the microphone. If you are standing in
front of the speakers, the microphone will pick up the broadcast
and cause feedback.
1Select any source on the stereo.
HUOMAUTUS: if you set the stereo to the AUX1 source,
there is no sound until you hold the microphone button and
speak.
2Hold the button on the side of the microphone and speak into
it.
HUOMAUTUS: if the stereo is playing music from a source,
you should wait about 2 seconds before speaking to avoid
cutting off the beginning of your announcement.
3After you have finished speaking, release the button.
If the stereo was playing music from a source before you held
the button, the stereo switches back to that source
automatically.
Configuring the Fusion Stereo for the Handheld
Microphone
1On the stereo, select > Asetukset >
PUHELINMYKISTYS.
2Select AUX1 to fill the check box.
The stereo will now change to the AUX1 source when you
hold the button on the side of the handheld microphone.
3Select > Asetukset > LÄHDE > AUX1.
4Select PARTYBUS KÄYTÖSSÄ to clear the checkbox.
When you clear the checkbox, the AUX1 source is no longer
available for streaming over the Fusion PartyBus™ network. It
is recommended to disable network streaming for the
microphone source to avoid feedback caused by the slight
delay present when streaming.
Adjusting the Gain of the Handheld Microphone
If the volume of the microphone broadcast is too loud or too
quiet in relation to the other sources on the stereo, you can
adjust the gain level for the AUX1 source.
1On the stereo, change the source to AUX1.
2Adjust the gain to raise or lower the microphone volume in
1 db steps.
A positive (+) gain setting increases the microphone volume,
and a negative (-) gain setting decreases the microphone
volume.
Specifications
Microphone dimensions (H×W×D) 88 × 60 × 34 mm (31/2 × 23/8 ×
111/32 in.)
Power and audio cable length 60 cm (23 5/8 in.)
Frequency response From 100 Hz to 4 kHz
Microphone weight 250 g (8.75 oz)
Output (max.) 1 Vrms
THD+N (Vo = 1 Vrms, 1 kHz) Less than 0.1% Vrms
Gain +18 ± 0.5 dB
Load impedance (min.) 10k Ohm
Operating voltage From 10.5 to 32 Vdc
Current (at 14.4 Vdc) 0.005 A
Fuse (not included) 3 A
Water rating IEC 60529 IPX7 1
© 2020 Garmin Ltd. tai sen tytäryhtiöt
Garmin®, Garmin logo, Fusion® ja Fusion logo ovat Garmin Ltd:n tai sen tytäryhtiöiden
tavaramerkkejä, jotka on rekisteröity Yhdysvalloissa ja muissa maissa. Näitä
tavaramerkkejä ei saa käyttää ilman yhtiön Garmin nimenomaista lupaa.
M/N: A13014
1 For more information, go to garmin.com/waterrating.
© 2020 Garmin Ltd. tai sen tytäryhtiöt www.fusionentertainment.com
