Fuso eCANTER User manual

Body/equipment mounting directives
Australia
Body/equipme nt mounting
directive

1
MITSUBISHI FUSO body/equipment mounting directives for FE Issue date: 20.10. 2020
!Only print out complete sections from the current version
1Introduction
1.1 The aim of these directives 5
1.2 Symbols 7
1.3 Vehicle safety 8
1.4 Operational safety 9
1.5 Accident prevention 10
1.6 Note on copyright 11
2 General
2.1 Technical advice and
contact persons 12
2.2 Product safety 13
2.3 Ensuring traceability 15
2.4 Mitsubishi three diamonds and
Fuso emblem 16
2.5 Trademarks 17
2.6 Recycling of components 18
2.7 Quality system 19
2.8 Issue of letter of no objection 20
3 Planning of bodies
3.1 Selecting the chassis 22
3.2 Vehicle modifications 23
3.3 Dimensions, weights, overall
vehicle height 24
3.4 Vehicle type identification data 26
3.5 Tires 27
3.6 Bolted and welded connections 28
3.7 Soundproofing 30
3.8 Maintenance and repairs 31
3.9 Advanced Emergency Braking
System (AEBS) 34
3.10 Lane Departure Warning System
(LDWS) 35
3.11 Optional equipment 36
3.12 ADR/GGVS 37
4 Technical threshold values for
planning
4.1 Vehicle overhang and technical
wheelbases 38
4.2 Weight distribution, CoG height,
anti-roll bars 40
4.3 Steerability 41
4.4 Clearance for the basic vehicle and
bodies 42
4.5 Permissible load on cab roof 45
4.6 Vehicle body incline 46
4.7 Others 51
5 Damage prevention
5.1 Brake hoses/cables and lines 53
5.2 Welding work 54
5.3 Corrosion protection measures 56
5.4 Bolted connections 59
5.5 Painting work 63
5.6 Chassis springs 72
5.7 Tilting the cab 73
5.8 Towing and tow-starting 74
5.9 Risk of fire 75
5.10 Electromagnetic compatibility (EMC) 76
5.11 Storing and handing over the vehicle 77
6 Modifications to the basic vehicle
6.1 General 78
6.2 Chassis frame material 80
6.3 Drilling work on the vehicle frame 81
6.4 Welding work on the vehicle frame 83
6.5 Modifications to the wheelbase 84
6.6 Frame modifications 85
6.7 Mounting of implements and
auxiliary components 88
6.8 Cab 95
6.9 Seats and bench seat 99
6.10 Installation of propeller shafts 100
6.11 Brake systems 102
6.12 Handling of EV system 107
6.13 Others 122
Contents

2
MITSUBISHI FUSO body/equipment mounting directives for FE Issue date: 20.10. 2020
!Only print out complete sections from the current version
Contents
7 Construction of bodies
7.1 General 126
7.2 Mounting frame 129
7.3 Mounting frame attachment 138
7.4 Others 142
8 Electrics/electronics
8.1 Electrical system 143
8.2 Electric wiring 152
8.3 Handling of electric/
electronic equipment 164
8.4 Power supply 165
8.5 Electric circuit continuity check 172
8.6 Precautions for electric welding 174
8.7 Lighting 177
9Calculations
9.1 Axle load calculation 181
10 Technical data
10.1 Model line-up T1
10.2 Specifications T2
10.3 Weight distribution table T4
10.4 Chassis cab drawings T6
10.5 Frame structure T11
10.6 Spring characteristic T21
10.7 Electrical systems T26
10.8 Other equipment T27

MITSUBISHI FUSO Service
Body/equipment mounting directives
FEB
Common Section
KAWASAKI, JAPAN
EuroVI OBD + regulation complied
models

4
MITSUBISHI FUSO body/equipment mounting directives for FE Issue date: 20. 10. 2020
!Only print out complete sections from the current version
MITSUBISHI FUSO TRUCK & BUS CORPORATION, as
the manufacturer of MITSUBISHI FUSO vehicles,
publishes this body/equipment mounting directive to
provide body manufacturers with important technical
information about the basic vehicle. This information
must be observed by the body manufacturer in the
production of bodies and equipment, fittings and
modifications for MITSUBISHI FUSO vehicles.
Due to the large number of body manufacturers and
body types, MITSUBISHI FUSO TRUCK & BUS CORPO-
RATION cannot take into account all the possible
modifications to the vehicle, e.g. performance,
stability, load distribution, center of gravity and
handling characteristics, that may result from the
design of attachments, bodies, equipment or modifi-
cations. For this reason, MITSUBISHI FUSO TRUCK &
BUS CORPORATION can accept no body manufacturer
liability for accidents or injuries sustained as a result
of such modifications to the vehicles if such modifica-
tions have a negative impact on the overall vehicle.
Accordingly, MITSUBISHI FUSO TRUCK & BUS
CORPORATION will only assume liability as vehicle
manufacturer within the scope of the design, produc-
tion and instruction services which it has performed
itself.
The body manufacturer is bound to ensure that its
bodies and equipment, fittings and modifications are
themselves not defective, nor capable of causing
defects or hazards to the overall vehicle. If this obliga-
tion is violated in any way, the body manufacturer shall
assume full product liability. The body/equipment
mounting directives enable MITSUBISHI FUSO TRUCK
& BUS CORPORATION to instruct the body manufac-
turer about important aspects that must be observed
when mounting its bodies and equipment, fittings and
modifications.
These body/equipment mounting directives are
primarily intended for the professional manufacturers
of bodies, equipment, fittings and modifications for
our vehicles. As a result, these body/equipment
mounting directives assume that the body manufact-
urer has suitable background knowledge. If you intend
to mount attachments, bodies and equipment on or
carry out modifications to our vehicles, please be
aware that certain types of work (e.g. welding work on
load-bearing components) may only be carried out by
qualified personnel. This will avoid the risk of injury
while also ensuring that the degree of quality required
for the attachments, bodies, equipment and modifica-
tions is given.
1Introduction

5
MITSUBISHI FUSO body/equipment mounting directives for FE Issue date: 20. 10. 2020
!Only print out complete sections from the current version
1Introduction
1.1 The aim of these directives
1.1 The aim of these directives
These directives serve as instructions for the manu-
facture of attachments, bodies, equipment and modi-
fication to other make bodies and major assemblies.
These directives are divided into 10 interlinked chap-
ters to help you find the information you require more
quickly:
1 Introduction É1.1
2 General É2.1
3 Planning of bodies É3.1
4 Technical threshold values for planning É4.1
5 Damage prevention É5.1
6 Modifications to the basic vehicle É6.1
7 Construction of bodies É7.1
8 Electrics/electronics É8.1
9CalculationsÉ9.1
10 Technical data É10.1
Appendix
Index
iAdditional information
The index, in PDF format, is linked to help you find
the information you require quickly.
Make absolutely sure that you observe the tech-
nical threshold values selected in Section 4 as
planning must be based on these values.
Section 6 "Modifications to the basic vehicle" and
Section 7 "Construction of bodies" represent the
main source of technical information contained in
these body/equipment mounting directives.

6
MITSUBISHI FUSO body/equipment mounting directives for FE Issue date: 20. 10. 2020
!Only print out complete sections from the current version
1Introduction
1.1 The aim of these directives
The illustrations below explain the difference between
"Basic vehicle" and "Body":
Basic vehicle
Body
The instructions listed herein must be observed in full
to maintain the operational reliability and road safety
of the chassis and for observance of material defect
claims.
Illustrations and schematic drawings are examples
only and serve to explain the texts and tables.
References to regulations, standards, directives etc.
are given in keywords and serve for information only.
Additional information is available from an authorized
MITSUBISHI FUSO dealer.
Your
MITSUBISHI FUSO TRUCK & BUS CORPORATION
N00.00-3192-00
N00.00-3193-00
aRisk of accident
Before installing any attachments, special-purpose
bodies, equipment or carrying out any modifica-
tions to the basic vehicle and/or its assemblies,
you must read the relevant sections of the Owner’s
Handbook, as well as the operating and assembly
instructions issued by the manufacturer of the
accessories and items of optional equipment.
You could otherwise fail to recognize dangers,
which could result in injury to yourself or others.

7
MITSUBISHI FUSO body/equipment mounting directives for FE Issue date: 20. 10. 2020
!Only print out complete sections from the current version
1Introduction
1.2 Symbols
1.2 Symbols
The following symbols are used in these directives:
aRisk of accident
A warning draws your attention to possible risks of
accident and injury to yourself and others.
Environmental note
An environmental note gives you tips on the protec-
tion of the environment.
iAdditional information
This note points out any additional information.
É
This symbol indicates the item on which you will find
further information on the subject. These items are
cross-linked in the PDF file.
!Property damage
This note draws your attention to possible damage
to your vehicle.

8
MITSUBISHI FUSO body/equipment mounting directives for FE Issue date: 20. 10. 2020
!Only print out complete sections from the current version
1Introduction
1.3 Vehicle safety
1.3 Vehicle safety
Notes on vehicle safety
MITSUBISHI FUSO recommends
using appropriate parts only for each particular vehicle
model.
In many countries, parts that make extensive changes
to the vehicle can invalidate the general operating
permit. Specifically, this concerns parts which:
• change the vehicle type approved in the general
operating permit
• could endanger road users
• could adversely affect noise levels
aRisk of accident and injury
The use of parts, assemblies or conversion parts
and accessories which have not been approved
may jeopardize the safety of the vehicle.
Before installing any attachments, special-purpose
bodies, equipment or carrying out any modifica-
tions to the basic vehicle and/or its assemblies,
you must read the relevant sections of the Owner’s
Handbook, as well as the operating and assembly
instructions issued by the manufacturer of the
accessories and items of optional equipment.
You could otherwise fail to recognize dangers,
which could result in injury to yourself or others.
Official acceptance by public testing bodies or
official approval does not rule out safety hazards.
iAdditional information
Make absolutely sure that you comply with national
registration regulations as attachments, bodies,
equipment on or modifications to the vehicle will
change the vehicle type approved and may
invalidate the general operating permit.

9
MITSUBISHI FUSO body/equipment mounting directives for FE Issue date: 20. 10. 2020
!Only print out complete sections from the current version
1Introduction
1.4 Operational safety
1.4 Operational safety
aRisk of accident
Before installing any attachments, special-purpose
bodies, equipment or carrying out any modifica-
tions to the basic vehicle and/or its assemblies,
you must read the relevant sections of the Owner’s
Handbook, as well as the operating and assembly
instructions issued by the manufacturer of the
accessories and items of optional equipment.
You could otherwise fail to recognize dangers,
which could result in injury to yourself or others.
Work incorrectly carried out on electronic compo-
nents and their software could prevent this equip-
ment from working correctly. Since the electronic
systems are networked, this might also affect
systems that have not been modified.
Malfunctions in the electronic systems could seri-
ously jeopardize the operating safety of the vehicle.

10
MITSUBISHI FUSO body/equipment mounting directives for FE Issue date: 20. 10. 2020
!Only print out complete sections from the current version
1Introduction
1.5 Accident prevention
1.5 Accident prevention
Observe the requirements and precautions set out in
this manual when carrying out body-building work or
modification work.
The body, the attached or installed equipment and any
modifications must comply with the applicable laws
and ordinances as well as work safety or accident
prevention regulations, safety rules and accident
insurer requirements.
All technical means shall be used to avoid operating
conditions that may be unsafe or liable to cause an
accident.
All national laws, directives and registration
requirements must be complied with.
The manufacturer of the attachment, body, equip-
ment or conversion or the device manufacturer is
responsible for compliance with these laws and
regulations.

11
MITSUBISHI FUSO body/equipment mounting directives for FE Issue date: 20. 10. 2020
!Only print out complete sections from the current version
1Introduction
1.6 Note on copyright
1.6 Note on copyright
All the text, illustrations and data contained in these
body/equipment mounting directives are protected
by copyright.
If you have any questions, contact the department
responsible É2.1.

12
2.1 Technical advice and contact persons
MITSUBISHI FUSO body/equipment mounting directives for FE Issue date: 20. 10. 2020
!Only print out complete sections from the current version
2.1 Technical advice and contact persons
Please log in from the following BODYBUILDER PORTAL URL and contact us.
2General

13
2General
2.2 Product safety
MITSUBISHI FUSO body/equipment mounting directives for FE Issue date: 20. 10. 2020
!Only print out complete sections from the current version
2.2 Product safety
Both the vehicle manufacturer and the body manufac-
turer must always ensure that they introduce their
scopes into the market in a safe condition and that
third parties are not at risk of any safety hazard. If this
is not adhered to they may be subject to civil, criminal
and public law consequences. Every manufacturer is
liable for the products it manufactures.
From this, it follows that the vehicle body/conversion
manufacturer therefore also bears responsibility for
the following:
• the operating and road safety of the body
• the operating and road safety of parts and modifi-
cations
• testing and maintaining the operating and handling
safety of the vehicle after the body/equipment is
mounted (the body and/or equipment must not
have a negative effect on the driving, braking or
steering characteristics of the vehicle)
• influences of parts on or modifications to the
chassis
• consequential damage resulting from the body,
attachment, equipment or modification
• consequential damage resulting from retrofitted
electrical and electronic systems
• maintaining the operational reliability and freedom
of movement of all moving parts of the chassis
after the body/equipment is mounted (e.g. axles,
springs, propeller shafts, steering, transmission
linkage, etc.) even in the case of diagonal torsion
between the chassis and the bodies

14
2General
2.2 Product safety
MITSUBISHI FUSO body/equipment mounting directives for FE Issue date: 20. 10. 2020
!Only print out complete sections from the current version
Be careful of the following points when carrying out
body-building or modification work.
Safety design
• Securing adequate safety and reliability, and
preparing safety devices (design which is fail-safe
and takes account of misoperation and misuse,
safety evaluation)
• Storing technical material, drawings and
documents during development
Manufacturing quality
• Manufacturing according to the drawings in order
to prevent errors, missing parts and defective
assembly, and secure high manufacturing quality
• Implementing a quality confirmation inspection,
and storing the records of the inspection
Use the post-body-building/modification
inspection sheet.
Preparing an instruction manual and warning
indications
• Instruction manual
Concrete indication of the effect of incorrect
operation on the human body, the vehicle, and
other locations (elimination of indications that are
likely to cause misunderstanding, and also
ambiguous expressions)
• Warning indications
To ensure that the vehicle is used as safely as
possible, warning indications must use expressions
that are easy to understand and letters that are
large enough to read easily, include pictures, and
be applied to locations that are readily visible to the
driver.

15
2General
2.3 Ensuring traceability
MITSUBISHI FUSO body/equipment mounting directives for FE Issue date: 20. 10. 2020
!Only print out complete sections from the current version
2.3 Ensuring traceability
Hazards in your implement/body which become
known after delivery may necessitate supplementary
measures in the market (customer notification, warn-
ings, recalls). In order to make these measures as effi-
cient as possible, your product must be traceable after
delivery.
For this purpose and to enable the Federal Office for
Motor Vehicles' Central Vehicle Register (ZFZR) or
comparable registers abroad to be used for
determining which owners are affected, we advise you
to promptly file the serial number/identification
number of your equipment/add-on part linked to the
vehicle identification number for the truck in your
databases.
Similarly, it is also advisable to store the addresses of
your customers for this purpose and to grant
subsequent purchasers the opportunity to register.

16
2General
2.4 Mitsubishi three diamonds and Fuso emblem
MITSUBISHI FUSO body/equipment mounting directives for FE Issue date: 20. 10. 2020
!Only print out complete sections from the current version
2.4 Mitsubishi three diamonds and Fuso emblem
The Mitsubishi three diamonds and Fuso emblem are
owned or controlled by MITSUBISHI FUSO.
They must not be removed or affixed in another posi-
tion.
Mitsubishi three diamonds and Fuso emblems
supplied separately must be attached at the points
specified by MITSUBISHI FUSO.
Overall appearance of the overall vehicle
If the vehicle fails to comply with the appearance and
quality standards as required by MITSUBISHI FUSO
TRUCK & BUS CORPORATION, the trademarks such as
the Mitsubishi three diamonds and Fuso emblem must
be removed.
Third-party trademarks
• may not be affixed next to MITSUBISHI FUSO
trademarks
Binding ruling
The MITSUBISHI FUSO Brand Trademark Directive
governs the use of trademarks by body manufacturers
on integrated bodies mounted on chassis. MITSU-
BISHI FUSO TRUCK & BUS CORPORATION reserves
the right to prohibit the body manufacturer from using
MITSUBISHI FUSO trademarks in the event of any
violations to this body/equipment mounting directive,
including the trademark directive.
• If you have any question, contact the department
responsible É2.1.
N62.00-2041-00

17
2General
2.5 Trademarks
MITSUBISHI FUSO body/equipment mounting directives for FE Issue date: 20. 10. 2020
!Only print out complete sections from the current version
2.5 Trademarks
Labels and marks must be applied to the
predetermined positions.
For details of the location and method of applying
labels and marks, refer to "10.8 Other Equipment"
É10.8.2.

18
2General
2.6 Recycling of components
MITSUBISHI FUSO body/equipment mounting directives for FE Issue date: 20. 10. 2020
!Only print out complete sections from the current version
2.6 Recycling of components
Materials with risk potential and restriction by REACH,
such as halogen additives, heavy metals, asbestos,
CFCs and CHCs, are to be avoided.
• It is preferable to use materials which permit
recycling and closed material cycles.
• Materials and production processes are to be
selected such that only low quantities of waste are
generated during production and that this waste
can be easily recycled.
• Plastics are to be used only where they provide
advantages in terms of cost, function or weight.
• In the case of plastics, and composite materials in
particular, only compatible substances within one
material family are to be used.
• For components which are relevant to recycling,
the number of different types of plastics used must
be kept to a minimum.
• It must be assessed whether a component can be
made from recycled material or with recycled
elements.
• It must be ensured that components can be
dismantled easily for recycling, e.g. by snap
connections or predetermined breaking points.
These components should generally be easily
accessible and should permit the use of standard
tools.
• Service products must be capable of being
removed simply and in an environmentally
responsible manner by means of drain plugs, etc.
• Wherever possible, components should not be
painted or coated; colored plastic parts are to be
used instead.
• Components in areas at risk from accidents must
be designed in such a way that they are damage-
tolerant, repairable and easy to replace.
• All plastic parts are to be marked in accordance
with VDA code of practice 260, e.g. "PPGF30R".
• EU Directive 2000/53/EC must be complied with.
Environmental note
When planning attachments, bodies, equipment
and modifications, and with regard to the legal
requirements according to EU Directive 2000/53/
EC and 1907/2006/EC (REACH: Registration,
Evaluation, Authorisation (and Restriction) of
Chemicals), the following principles for
environmentally-compatible design and material
selection shall be taken into account.

19
2General
2.7 Quality system
MITSUBISHI FUSO body/equipment mounting directives for FE Issue date: 20. 10. 2020
!Only print out complete sections from the current version
2.7 Quality system
World-wide competition, increased quality standards
demanded by the customer from the product as a
whole, national and international product liability laws,
new organizational forms and rising cost pressures
make efficient quality assurance systems a necessity
in all sectors of the automotive industry.
For the reasons quoted above, MITSUBISHI FUSO
TRUCK & BUS CORPORATION urgently advises body
manufacturers to set up a quality management system
with the following minimum requirements:
• Does the quality management system clearly
define responsibility and authority?
• Is there a description of processes/workflows?
• Are the contracts checked/is the feasibility of
construction checked?
• Are product checks on the basis of specified
instructions carried out?
• What provisions are made for the handling of faulty
products?
• Are the inspection results documented and
archived?
• Do all employees concerned have currently valid
proof of the qualification required?
• Is the test equipment systematically monitored?
• Is there a system for labelling materials/parts?
• Are quality assurance measures carried out at
suppliers?
