FWE RHRB-20 User manual

OPERATING
INSTRUCTIONS
RHRB-20 RETHERM OVEN
RETHERM DOCKING SYSTEM
“RHRB SERIES”
RETHERM OVEN FOR ROLL-IN RACKS

FWE RETHERM DOCKING SYSTEM OVEN
STREAMLINE YOUR OPERATION!
CONGRATULATIONS...
...and thank you for purchasing an FWE Retherm Docking System
Oven. Your unit has been designed and manufactured under rigid
controls to assure you the most efficient service.
Please take a moment to read through this booklet of important
information pertaining to your cabinet. By following a routine of
proper use and care described on the following pages, your cabinet
will last for many years.
IMPORTANT: Your Manufacturer Registration Card must be
returned within 30 days after initial delivery to activate the warranty.
2
FWE’s RHRB-20
RETHERM OVEN
for use with with Baskets
using Transport Base,
Transfer Dolly,
or Transfer Rack
(Sold Separately)

3
FWE RHRB-20 models operate on 208/240 volt, 60 Hz, 3 ph, A.C.
(unless ordered otherwise). If you have any questions with regard
to adequate wiring or grounding in your building, a qualified
electrician should be contacted before using your cabinet.
The amperage of your cabinet is stamped on the name plate
attached to the unit.
WARNING: ONLY A QUALIFIED ELECTRICIAN SHOULD
ATTEMPT TO REPAIR OR REPLACE ELECTRICAL
COMPONENTS OR WIRING.
FWE RETHERM DOCKING SYSTEM OVEN
SERIAL AND MODEL NUMBER
INSTALLATION AND CARE
UNPACKING
ELECTRICAL REQUIREMENTS AND GROUNDING
These numbers are found on the nameplate (serial tag) affixed to
the lower back of the unit. Please record them in this booklet, in the
space provided on page 13. When ordering parts and/or service,
you will need to provide this information. The voltage and amperage
of the unit are also stamped on the serial tag.
After uncrating your cabinet, remove all tape and padding which
held all doors, shelves, racks, cord, etc., in place during shipment.

FWE RETHERM DOCKING SYSTEM OVEN
OVEN LOCATION
4
The well planned and proper placement of your oven will result in
long term operator convenience and satisfactory performance.
• Proper clearance must be kept on both the left and right of the
cabinet, allowing proper ventilation to the cooling fans. As the oven
achieves heat, latent heat will build inside the control panel area.
Cooling fans assure that these temperatures are kept to a minimal.
If proper clearance of these vents are NOT kept, heat will quickly
build up. The thermal protectors will trip, shutting the unit down.
Improper installation, or failure to keep proper clearance will void
warranty.
• Keep the oven area free and clear of all combustibles such as
paper, cardboard, and flammable liquids and solvents, as these
materials may ignite and become a fire / safety hazard.
• Agency regulations may require 6” clearance on the bottom and
sides of the unit for cleaning. Do not place the oven on a curb base
or seal to a wall. Please check with your local health code agencies
to assure proper placement of your unit, as local codes may vary.
• Before making any utility connections to this oven, check the
rating plate to be sure the oven specifications are compatible with
the electrical services supplied for the oven. Please review all
installation instructions, electrical requirements and connection to
power.
INSTALLATION
Installation must conform with all Local and National installation
standards. Local installation codes and / or requirements may vary.
If you have any questions regarding the proper installation and / or
operation of your oven, please contact your local distributor.
If you do not have a local distributor, please call your local
FWE representative, government agency, qualified electrical
contractor or Health Department to verify your local standards.

5
FWE RETHERM DOCKING SYSTEM OVEN
CARE AND OPERATION
Keep your cabinet clean by simply wiping the interior and
exterior, as needed, with a damp cloth or sponge and a mild
soapy solution.
NEVER USE ABRASIVES, ACIDS, OR
STRONG CLEANERS.
Do not flood or allow electrical parts to become wet.
The interior tray slide assemblies and humidifier pans
are removable for easy cleaning.
A stainless steel cleaner/polish is recommended for the
exterior to maintain a "like-new" appearance.
DO NOT USE WAX OR STRONG CLEANERS ON
DOOR GASKETS, VINYL , OR RUBBER.
CLEANING
CONTROLS
The control panel, recessed at the top of the unit above the
door, is equipped with an adjustable thermostat (225°F to 550°F)
for temperature selection, and a master power ON/OFF rocker-switch.
Count-down timer has a bell alert only and does not
control oven functions.

6
OVEN HAS TWO (2) ON/OFF SWITCHES:
1) Press main power ON/OFF Rocker-Switch
to “ON” position. This will power the blower fans.
2) SELECT A TEMPERATURE SETTING
recommended by MEAL CONTAINER manufacturer.
CAUTION: Food container may melt if temperature is set too high.
Temperature settings vary due to food tray material.
Temperature dial also has an “OFF” position.
3) PRE-HEAT CABINET FOR 30 MINUTES.
By pre-heating the unit 30 minutes before each use, you can be
assured of maintaining the temperature and obtaining the best
results from your cabinet.
4) DOCK THE ROLL-IN RACK. Dock the cart to the oven
using the alignment pins as a guide. Cart will latch to cabinet
automatically.
5) LOAD THE CABINET.Release Baskets by stepping down on
the Basket Rack Release (upper latch). Slide Roll-In Rack from
Transport Cart into oven. Baskets and Rack are now loaded into
the cabinet.
6) UNDOCK THE CART. Step down on Docking Latch Release
(lower latch) to remove cart.
CAUTION: PRODUCT IS HOT.
Use oven mitts and proper precautions.
GENERAL OPERATING INSTRUCTIONS
PREPARING AND LOADING THE OVEN

Retherm Product Notes:
Menu Item: Tray Type: Temperature: Time:
7
GENERAL OPERATING INSTRUCTIONS
OVEN SETTINGS
BELL TIMER
TIMER has an bell alert function only.
Does not control oven functions.
Follow food tray manufacturer
retherm guidelines for
temperature and time settings.

8
Transport Cart or
Transport Base
Docking
Latch
Release
Basket Rack
Release
GENERAL OPERATING INSTRUCTIONS
DESCRIPTION OF DOCKING / RELEASE FEATURES
Docking
Latch
Alignment
Pin 1
Alignment
Pin 2
Transfer Dolly
or Dolly Frame
FWE: RBD-BL
Blodgett: DBRI-L
Dolly Frame or
Transfer Dolly
Maximum
320 Food
Containers
Container
Size: 1.3 lb
Maximum
total food load
is 416 lbs.

9
Release Baskets
by stepping down on the
Basket Rack Release
(upper latch).
Release Cart
by stepping down on
Docking Latch Release
(lower latch).
Close the door to oven
and retherm product.
GENERAL OPERATING INSTRUCTIONS
LOADING THE OVEN

10
FWE RETHERM DOCKING SYSTEM OVEN
FOOD SAFETY GUIDELINES
FOOD SAFETY & COOKING
Most foods are at risk during preparation and service. As foods
are thawed, cooked, held, served, cooled and reheated, they may
pass several times through the temperature danger zone of
40°F to 140°F (4.4°C to 60°C). Each time food is handled, it
runs the risk of cross-contamination from other food and from
food-contact surfaces, such as: human hands, cutting boards,
and utensils. It is recommended that passing through the
40°F to 140°F (4.4°C to 60°C) zone be done as quickly and
infrequently as possible.
THE FOUR HOUR RULE
The temperature danger zone is considered 40°F to
140°F (4.4°C to 60°C) and rapid bacteria growth zone
is considered 70°F to 120°F (21°C to 49°C). Prevent
potentially hazardous foods from spending more than four
(4) hours combined total time in these zones. The exposure
time is accumulative from time of receiving products until
time it is cooked. Exposure time begins again when food is
fully cooked, held, served, cooled, and reheated.
FOOD
SHOULD NEVER BE REHEATED TWICE!
Food and public health dangers can be avoided with proper food
handling, storage, cooking (rethermalizing) and holding methods.
The key to foodborne illness prevention is constant monitoring of
food temperatures (both storage and internal).
FOOD SAFETY
HACCP is a Food Safety Program that is an effective tool for
safety and quality of food, from processing, receiving, storage,
cooking, holding and serving. By definition, HACCP is:
“
H
AZARD
A
NALYSIS
C
RITICAL
C
ONTROL
P
OINT.”
PROPER FOOD HANDLING - HACCP OVERVIEW

PROBLEM POSSIBLE CAUSE REMEDY
TEMP
TOO
HOT
TEMP
NOT
HOT
ENOUGH
NO HEAT
AT ALL
1
A] Adjustable thermostat
set too high
1B] Thermostat needs
re-calibrating**
2A] Opening door unnecessarily
2B] Thermostat set too low
2C] Cord plug pulled out from outlet
2D] Fuse blown - no power to outlet
2E] Thermostat out of calibration**
3A] Cabinet not plugged into outlet
3B] Thermostat knob at “ OFF ”
3C] Rocker switch at “ OFF ” position
3D] Fuse Blown - no power to outlet
3E] Thermostat needs replacing
3F] Heating element burned out*
1A] Set thermostat at a lower temperature
(no lower than 225°F).
1B] Loosen screw in thermostat knob and remove knob.
Adjust set screw in hollow stem with small blade
screwdriver by turning CLOCK-WISE.
1/4 turn lowers temperature approximately 10°F.
DO NOT REMOVE SET SCREW.
2A] Keep door closed and latched shut
as much as possible.
2B] Set thermostat at a higher temperature.
2C] Replug cord into proper outlet.
2D] Have a qualified electrician check power
and fuse box.
2E] Loosen set screw in thermostat knob
and remove knob. Adjust set screw in hollow stem
with small blade screwdriver by turning
COUNTER-CLOCKWISE.
1/4 turn raises temperature approximately
10°F. DO NOT REMOVE SET SCREW.
3A] Plug cabinet into properly grounded electrical outlet.
3B] Adjust thermostat knob to temperature
setting required.
3C] Turn switch to “ ON ” position.
3D] Have a qualified electrician check power
to fuse box.
3E] Unplug cabinet from electrical source.
Loosen set screw in thermostat knob and remove
knob. Remove control panel, disconnect wires from
terminals on thermostat, and remove 2 screws
holding thermostat to control panel. Replace
thermostat with new one, and re-install control
panel and thermostat knob.
3F] Unplug cart from electrical source. Remove screws
holding heating element in place. Gently pull
element away from back wall a few inches to
expose wire connections. Disconnect wires, and
replace element with new one. Reconnect wires,
secure element with screws.
* * NOTE: CALIBRATION IS EXCLUDED FROM FWE WARRANTY. Thermostats on all units are calibrated at the factory
* * prior to shipping. Due to conditions in transit, beyond our control, occasionally units will need to be re-calibrated prior
* * to use. This is a simple procedure for which instructions are given above. (1B, 2E)
* Heating element will either function or not function. Only a slight warmth indicates a problem with the thermostat,
* not the element.
TROUBLE-SHOOTING CHART
Check this list first before you call for service...
11

LEGS PART NUMBER
6'' ADJUSTABLE LEGS LEG SS6
CONTROL PANEL
TIMER 60MIN MANUAL CENTER STD MOUNT TMR-BELL-60
DIAL FOR TMR-BELL-60 TMR-BELL-DIAL
BLACK KNOB FOR TMR-BELL-60 TMR-BELL-KNB
DIAL FACE 225°F TO 550°F CNTRL-PNL 550 DIAL
KNOB WITH MARKING KNB H6
ON/OFF ROCKER SWITCH, UNLIGHTED SWH RCK E1
ELECTRICAL COMPONENTS
ELEMENT 4000W/220V SPIRAL EL-4000-220-SPIRAL
BLOWER, SPIDER 230/400V BLWR-R2D-225
CONTACTOR COIL 208-240VAC 60AMP CONACT-3POLE-75A
MINI CONTACTOR 240V IEC 6 AMP CONTACT-IEC-240
TUBE AXIAL FAN 230V FAN BLOW 230-3-125SQ
GASKET HI-TEMP TADPOLE 1/2'' GSKT-HI-TEMP
AIR PRESSURE SENSING SWITCH KIT SENSOR-AIR-PRESSURE
HARDWARE
FLANGED SLEEVE BEARING.875X750X500 BEARING-FLDG-875X750X500
THRUST BEARING 1.50X.125THKX.875 BEARING-THRUST-1500X0625
THRUST BEARING 1.50X1.0X.0625THK BEARING-THRUST-1500X875
TURN BUCKLE 1/4'' X 5-3/8 BUCKLE-T-25-5-375
SINGLE STL RLR CHAIN #35 3/8 PITCH 20FT CHAIN-STL-RLR-35X.375
CABLE CLIP 1/16'' SS CLP-CBL-0625
RUBBER HANDLE COATING, BLACK HDL-RUBBER-COATING-BLK
HANDLE GRIP, BLACK, 7.5'' L X 1'' DIA HDL-GRIP-BLK-7-5
S HOOK 1-3/4 X 3/8'' OPENING” HOOK-S-1-075
CABLE LATCH LTH-CBL
NUT 1/4-20 HEX LEFT HAND THRD SS N1-4-20HX-LFTDSS
NUT 3/8-16 HEX SS 5/8'' W X 1/4'' N3-8-16HXSS
PIN SQUARE KEY STOCK 5/16 X 5/16 SS PIN-312-SQ
RELAY OVERLOAD 0.36-0.54 AMP RLY-OVERLOAD-036-054
CAP SCREW 3/8-16X3.5'' L PARTIAL THREAD S3-8-16X3-5THDSS
BOLT 5/16-18 X1-1/2'' 18-8SS FLTHRD “B5-16-18 X 1,5 SS HX”
STEEL SHAFT COLLAR 1.5OD X 5/8W SHAFT-COLLAR
SPROCKET 3/4 BORE 3/8 PIT #35CHAIN SPROCKET-750X375X14X35
WIRE WOVEN CLOTH GASKET WIRE-CLTH-023
FWE RETHERM OVEN PARTS LIST
FWE PARTS DEPARTMENT: 815 459 7500
12

FWE RETHERM DOCKING SYSTEM OVEN
SERVICE RECORD
Model Number ______________________
Serial Number ______________________
Date of Purchase ______________________
Notes:
___________________________________________________
___________________________________________________
___________________________________________________
___________________________________________________
___________________________________________________
___________________________________________________
___________________________________________________
___________________________________________________
___________________________________________________
___________________________________________________
___________________________________________________
___________________________________________________
___________________________________________________
___________________________________________________
___________________________________________________
___________________________________________________
___________________________________________________
___________________________________________________
___________________________________________________
___________________________________________________
___________________________________________________
___________________________________________________
___________________________________________________
___________________________________________________
___________________________________________________
___________________________________________________
___________________________________________________
13

FWE RETHERM DOCKING SYSTEM OVEN
WIRING DIAGRAM
14

FWE RETHERM DOCKING SYSTEM OVEN
LIMITED TWO YEAR WARRANTY
15
FWE / Food Warming Equipment Company, Inc. (Seller) warrants to the original purchaser,
subject to the exceptions and conditions below, that FWE manufactured equipment shall be
free from defects in material or factory workmanship, under ordinary use for the purpose for
which it is designed. The effective warranty period is as follows:
PARTS: Seller will furnish without charge to the original purchaser, FOB Sellers’ factory,
replacement parts for repairs to all new standard catalog products and factory custom /
modified units, which in Seller’s sole judgement, prove defective in materials or workmanship
under normal and proper use with the reserved right to request the return of any part claimed
to be defective, prior to issuing replacement part or authorizing warranty service, for a period
of two (2) years from date of original shipment from Seller’s plant,
except for equipment used
in a Correctional Environment / Facilities, which is warranted for a period of one (1) year
from date of original shipment from Seller’s plant.
LABOR: Seller’s labor warranty shall be performed by a Seller-approved Service Agency who
must contact Seller to obtain a Warranty Service Authorization (WSA) number prior to
performing any repairs. If service is required during overtime periods, the difference between
overtime and standard labor rates shall be paid by the purchaser. Seller does not assume any
responsibility for any charges not expressly authorized, incidental to the repair or replacement
of equipment covered by this warranty, nor charges exceeding, in Sellers sole judgement,
normal and customary amounts. Only approved travel charges will be allowed. Seller’s labor
warranty shall be from the date of original shipment date from Seller’s plant for a period of one
(1) year,
except for equipment used in a Correctional Environment / Facilities which is
warranted for a period of six (6) months.
This warranty is for normal usage and does not apply to any product or parts thereof that have
been misused, altered, or where Seller’s operating instructions or specific voltage is not
observed; nor shall this warranty apply to defective products or parts resulting from accident
following date of original shipment, nor extend to or cover removal, installation, reinstallation or
calibration, or service calls or cost of repairs undertaken by a customer. This warranty is also
subject to the following:
1.] Customer returning the warranty registration card, accompanying Sellers original
shipment, to Seller within thirty (30) days of receipt;
2.] Giving immediate notice of any allegedly defective part or product to Seller; and
3.] Customer, at Sellers request, returning said defective parts or product to Seller.
This is the sole warranty applicable to the merchandise. It is expressly understood that Seller’s
liability hereunder is limited to the repair or replacement, at Seller’s option, of products or parts,
defective materials or workmanship as provided above. Seller’s judgement as to the cause and
nature of any defect will be final.Seller shall in no case be responsible for special or con-
sequential damages or any other obligation or liability with respect to products sold by Seller.
This warranty, as stated above, applies to equipment installed in the Continental United States.
FWE equipment installed outside the Continental United States shall carry parts coverage
only. All labor costs are approved on a discretionary basis, based on like repairs in the
Continental U.S. This warranty shall stand in whole or in part as allowed by law. Any exclusion
of a part of this warranty, as may be allowed by law, shall not void balance of warranty.
This is a limited warranty pursuant to the Consumer Product Warranties Act, 15 U.S. Code. section 2303.
© 2006 Food Warming Equipment Co., Inc.

WE OFFER SALES AND SERVICE WORLDWIDE
Food Warming Equipment Company, Inc.
P.O. Box 1001
Crystal Lake, IL 60039-1001
Manufacturing Facilities:
7900 S. Route 31
Crystal Lake, IL 60014
OpsManual_ RHRB-20 © 2008 Food Warming Equipment Co., Inc. Printed in USA
FWE Parts Department:
815 459 7500
FAX:
815 459 7989
The best designed . . .
The best built . . .
The best performing units on the market!
◊
◊
◊
◊
◊
◊
◊
◊
◊
Retherm Cabinets
Self-Propelled Transports
Heated Banquet Cabinets
Universal Bulk Food
Cabinets
Utility Carts
Refrigerators, Freezers and
Convertibles
Prisoner & Correctional Tray
Delivery
Hospital Tray Delivery Carts
Portable Bars and Back-ups
Errors subject to correction. All specifications
subject to change without notice.
© 08 Food Warming Equipment Company. Inc.
Table of contents
Other FWE Oven manuals
